1. BEFORE YOU BEGIN
What is Included
•1 x Mini Strobe LED
•1 x Warranty Card •1 x User Manual
Unpacking Instructions
Immediately upon receiving a fixture, carefully unpack the carton, check the contents to
ensure that all parts are present, and have been received in good condition. Notify the
shipper immediately and retain packing material for inspection if any parts appear damaged
from shipping or the carton itself shows signs of mishandling. Save the carton and all
packing materials. In the event that a fixture must be returned to the factory, it is important
that the fixture be returned in the original factory box and packing.
Safety Instructions
•Please keep this User Manual for future consultation. If you sell the unit to
another user, be sure that they also receive this instruction booklet.
•Always make sure that you are connecting to the proper voltage, and that the line
voltage you are connecting to is not higher than that stated on the decal or rear
panel of the fixture.
•The unit must be installed in a location with adequate ventilation, at least 20 in
(50 cm) from adjacent surfaces. Be sure that no ventilation slots are blocked.
•Always disconnect from power source before servicing or replacing lamp or fuse
and be sure to replace with same lamp source.
•Secure fixture to fastening device using a safety chain. Never carry the fixture
solely by its head. Use its carrying handles.
•Maximum ambient temperature (Ta) is 104° F (40° C). Do not operate fixture at
temperatures higher than this.
•In the event of a serious operating problem, stop using the unit immediately.
Never try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized
technical assistance center.
•Never connect the device to a dimmer pack.
•Make sure the power cord is never crimped or damaged.
•Never disconnect the power cord by pulling or tugging on the cord.
•Avoid direct eye exposure to the light source while it is on.
There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repairs yourself. In the unlikely event your unit may require service,
please contact CHAUVET® at: 954-577-4455.
Please read these instructions carefully, which includes important
information about the installation, usage and maintenance of this product.

Mini Strobe LED User Manual 4 Rev. 3
2.INTRODUCTION
Features
•Ready to go out of the box
•Manually adjustable strobe rate
Product Overview
Turn the strobe speed adjustment knob clockwise to increase the strobe speed.
Turning the speed adjustment fully counter-clockwise does NOT turn off the fixture. It
turns it to the lowest setting. It is NOT possible to turn the strobe OFF when plugged
into power.
Strobe Output
Hanging Bracket
Power In
Strobe Speed
Adjustment Knob

Mini Strobe LED User Manual 5 Rev. 3
3.SETUP
AC Power
To determine the power requirements for a particular fixture, see the label affixed to the
back plate of the fixture or refer to the fixture’s specifications chart. All fixtures must be
powered directly off a switched circuit and cannot be run off a rheostat (variable resistor)
or dimmer circuit, even if the rheostat or dimmer channel is used solely for a 0–100%
switch. Before applying power to a fixture, check that the source voltage matches the
fixture’s requirement.
All fixtures must be connected to circuits with a suitable Earth Ground.
Mounting
Orientation
This fixture may be mounted in any safe position.
Rigging
The fixture includes a mounting yoke to which a rigging clamp can be attached.
You must make sure the clamp is capable of supporting the weight of this fixture.
You can order “C” and “O” clamps from any CHAUVET® dealer or distributor
(CLP-02, CLP-10 recommended).
There are 2 types of mounting options for this fixture: floor stand for up
lighting, and overhead use for down lighting. You must use at least one (1)
safety cable/chain for each fixture in addition to the mounting clamp.
If hanging the fixture for overhead use, please follow the steps below.
1. Block access below the work area and use a suitable and stable platform
when installing or servicing fixture.
2. Safety cables must always be used. The safety cable must be capable of
holding 10 times the weight of the fixture.
3. Verify the structure can hold 10 times the weight of all to-be installed fixtures.
Hanging clamp sold separately.
Hanging Clamp
Sold separately

Mini Strobe LED User Manual 6 Rev. 3
4.APPENDIX
General Maintenance
To maintain optimum performance and minimize wear fixtures should be cleaned at least twice a
month frequently. Usage and environment are contributing factors in determining frequency. Dust
build-up reduces light output performance and can cause overheating, leading to reduced lamp
life and increased mechanical wear. Be sure to power off fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust
collected on external vents and internal components. Clean all glass when the fixture is cold with
a mild solution of glass cleaner or Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue.
Apply solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently
polish optical surfaces until they are free of haze and lint.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically
to optimize light output. Cleaning frequency depends on the environment in which the fixture
operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on
the unit’s optics. Clean with soft cloth using normal glass cleaning fluid. Always dry the parts
carefully. Clean the external optics at least every 20 days. Clean the internal optics at least every
30/60 days.
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be
issued. Package must be clearly labeled with a Return Merchandise Authorization Number (RMA
#). Products returned without an RMA # will be refused.
Call CHAUVET® and request an RMA # prior to shipping the fixture. Be prepared to provide the
model number, serial number and a brief description of the cause for the return. Be sure to
properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. FedEx packing or double-boxing are recommended.
CHAUVET® reserves the right to use its own discretion to repair or replace product(s).
Note: If you are given an RMA #, please include the following information on a piece of
paper inside the box:
1) Your name
2) Your address
3) Your phone number
4) RMA #
5) A brief description of the symptoms
Claims
Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and
submit claims with the shipper in the event that a fixture is damaged due to shipping. Any other
claim for items such as missing component/part, damage not related to shipping, and concealed
damage, must be made within seven (7) days of receiving merchandise.

Mini Strobe LED User Manual 7 Rev. 3
Technical Specifications
WEIGHT & DIMENSIONS
Length .............................................................................................................................5.1 in (130 mm)
Width..................................................................................................................................4 in (102 mm)
Height................................................................................................................................3.7 in (95 mm)
Weight..............................................................................................................................0.5 lbs (0.2 kg)
POWER
Non-switchable.................................................................................120 VAC, 60 Hz or 230 VAC, 50 Hz
Power consumption @ 120 V, 60 Hz..............................................................12 W (0.1 A), <0.1 A inrush
Power consumption @ 230 V, 50 Hz..............................................................12 W (0.1 A), <0.1 A inrush
LIGHT SOURCE
LED......................................................................................................................21 (white) 100,000 hrs.
THERMAL
Maximum ambient temperature..........................................................................................104° F (40° C)
ORDERING INFORMATION
Mini Strobe LED...........................................................................................................MINISTROBELED
WARRANTY INFORMATION
Warranty...............................................................................................................1-year limited warranty
Contact Us
World Wide
General Information CHAUVET®
5200 NW 108th Avenue
Sunrise, FL 33351
voice: 954.577.4455
fax: [phone]
toll free: 800.762.1084
Technical Support CHAUVET®
5200 NW 108th Avenue
Sunrise, FL 33351
voice: 954.577.4455(Press 4)
fax: [phone] (Attention: Service)
World Wide Web www.chauvetlighting.com
