Lanta Orion Link v2 User guide

Owner Handbook
Orion Link v2™
Colour Mixing LED Bar

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
For your Safety
• Follow all instructions to maintain Manufacturer Warranty and for your own safety.
• There are no user replacement parts inside the product. Do not open the product for
any reason. This will invalidate your Manufacturer Warranty and may impair the safety
features of the product.
• Do not use if the product if you suspect it has been damaged in any way, including
being dropped, is malfunctioning, or has been exposed to liquids or moisture. The unit
must be repaired by an authorised service centre only. Manufacturer Warranty is void
if unit is opened or adapted in any way. Operator safety may be compromised if this
product is not operated and maintained in accordance with the details contained in
this Owner Handbook.
• This appliance must be earthed. Do not remove the earth connection in the plug or any
other location- it is essential for user safety.
• Be aware that products are mains powered and may be capable of producing high
voltages from its outputs and has mains voltages inside the cabinet.
Product Installation, Use & Maintenance
• Keep this Owner Handbook safe for future reference.
• Clean the product with a clean and dry, non-abrasive cloth. Do not use solvents or
liquids to clean the product.
• To prevent overheating, do not obstruct any ventilation opening, fan cover or vent. Do
not install near any sources of heat such as radiators, heaters, other heat producing
items such as amplifiers, power units etc.
• Power connection to the product is via a UK 240 Volt AC three-pin mains plug. Do not
remove or adapt this plug. If necessary, only replace the plug top fuse with one of the
same type, size and value.
• The mains lead must not be crushed or damaged. If any damage occurs, disconnect
from the mains immediately. Replace the damaged cable, or if the mains lead is
captive, return the product to an authorised repair centre for cable replacement. Do
not attempt to repair the cable - it must be discarded and destroyed.
• To maintain the Manufacturer Warranty, only attach authorised accessories and external
devices. This includes cables, connectors and other electrical and/or mechanical
devices.
• Unplug the product from the mains during lightning storms or periods of mains
fluctuations. If the product is going to be unused for long periods, unplug from the
mains.
Product Quality & Compliance
Products from Lanta Lighting meet all required safety standards in force at the time of
manufacture and are fully compliant with them.

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
Unpacking & Inspection
• Inspect the packaging before opening. If the packaging appears to have sustained
significant damage, please take extra care before using the product. If you are in any
doubt, consult a suitably qualified professional.
• If you suspect the product has been damaged, do not use it. Return it to your original
supplier without delay.
• Keep all packaging in a safe place for storage or transport in future.
Manufacturer Warranty
• This Manufacturer Warranty is valid in the UK only.
• Lanta Lighting warrants that this product is free from workmanship defects and material
failure during normal use and operation for a period of 12 months from first use or from
original date of sale (whichever is the earliest) providing all of the terms indicated in the
warranty section have been fully complied with.
• Expressly excluded is our liability for any directly connected or indirectly connected item
or items or any consequential loss associated with the failure of the product howsoever
caused.
• If the product has been opened, modified, tampered with, incorrectly connected,
used inappropriately or in conflict with the instructions herein, or the product model
or serial number has been damaged, removed, tampered with, obliterated or made
partly unreadable by any person or persons, the Manufacturer Warranty is irrevocably
null and void.
• No extension, adaption, alteration or modification to the terms of this Manufacturer
Warranty will be permitted, unless expressly authorised in writing (excluding email
and fax) by a Director of Lanta Lighting. Warranty is transferrable during the Warranty
period.
For Further Information about Lanta Lighting
Our website can be found at www.lantalighting.com and is available for the benefit
of customers worldwide. Please consult for information, advice and support on this and
other high quality products from Lanta.

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
About Lanta Lighting™
Based in the UK, Lanta are committed to providing high quality products at cost-effective
prices to the professional lighting market. Since the first product was launched in 2006,
Lanta has established a reputation for reliability, common sense design and customer
support that has become the envy of others.
The Lanta Lighting range includes:-
Professional Lighting
Focussing on the use of LED technology, Lanta offer distinctive lighting effects for install
and mobile applications. From washes to floods, spots to projectors, LED technology now
outperforms traditional lights while at the same time requiring significantly lower power
and generating far less unwanted heat.
Performance Lasers
Recent advances have reduced the costs of Lasers, made them more portable and
brought improved performance and reliability. With step and animation lasers in multi
and single colour formats for mobile DJs and static installs, Lanta promise Lasers that
won’t burn a hole in your pocket.
Atmospheric Effects
When you need special atmospherics effects, Lanta have everything from bubble
machines to snow machines, hazers and foggers. There’s also a range of fluids and
consumables specially designed to get the best from the range.
Control Gear
Lightweight and portable, Lanta Control Gear is robust enough to survive life on the road
and smart enough to control DMX kit whatever the venue.
Visit us at www.lantalighting.com for more details.

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
Getting to know your Lanta Product
The Lanta Orion Link V2™ lighting fixture features 10mm LEDs for seamless colour mixing. It
has a built in colour fading, fading and pattern sequencing. A range of features can be
DMX controlled from any of the LANTA DMX controllers or equivalent products.
LEDs 320 10mm LEDS (Red - 128 Green - 96 Blue – 96)
DMX Control 2, 3, 4, 7, 14, 26 DMX Channel Modes
Control Connections 3 Pin Female XLR socket,
3 Pin Male XLR socket In / Out IEC Chassis
Control Modes Sound / Auto / Static Colour / DMX
Power Requirement 240 Volt AC 50 / 60Hz
Power Consumption 36 Watts
Dimensions W x D x H 1070 x 65 x 88 mm
Weight 2.6Kg
Rear Panel
Power Output
Power Input
Fuse
1A/250V

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
Operating Modes
Five distinct operating modes are supported by the unit. To select, use the “A” button to
enter the menu. The “B” button steps through specific settings for each operating mode.
1- In-built Program Mode
1. Press mode until it shows Pr**, you can select 22 different built-in Programs. Press
“SETUP”and “UP” “DOWN” buttons to select the programs (from Pr01 to Pr22) and
select the desired program values.
2. When it shows Pr01, press “SETUP” to choose the seven static colour.
3. When it is Pr02 to Pr22, press “SETUP” and “UP” “DOWN” buttons, you can set the
values for flash (FS00-FS99), fading time (Fd00-Fd99), running speed (SP00-SPFL).
2- Auto Run Mode
1. You can press “MODE”button to select auto run mode, it shows “AUTO”, and then it
will run the built-in programs automatically.
2. Press “SETUP”, it shows n. 001, then you can adjust the running loops number by “UP”
“DOWN”
3. When continuing to press “SETUP”, it will show SPxx, Fdxx, FSxx, then you can set the
value for speed, fading and flash by “UP” “DOWN”

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
3- Slave Mode
1. Press “MODE” button to select “SLAv” to run the slave mode.
4- Sound Active Mode
1. Press “MODE” button to select SU31 to be run, now if activated one time, it will run
one step, adjust the sensitivity by “UP” and “DOWN” buttons.
2. Sensitivity: SU01-SU31
5- Static Colour Mode
1. Press “MODE” button to select “Colr” to be run, press “SETUP”, it will show
R/G/B255, and then you can adjust the colours by “UP”and“DOWN”buttons.

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
6- DMX Mode
1. You can control the devices individually via your DMX-controller. Press the“MODE”button
until it shows “d001”, this means DMX address is 001, you can set the DMX address
by “UP”and“DOWN”buttons. If press “SETUP” button, it will show d-p1, it means the de-
vice is in which DMX mode 1. You can switch these DMX modes by “UP”and“DOWN”
buttons. There are 6 DMX modes.
LED Display shows DMX Control Mode
d.-P5 2 Channel
d.-P1 3 Channel
d.-P2 4 Channel
d.-P6 7 Channel
d.-P3 14 Channel
d.-P4 26 Channel

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
2 Channel DMX
Channel 1 Channel 2
Program Selection Speed
0-7 Off Off
8-15 Red Slowest
16-23 Yellow
24-31 Green
32-39 Cyan
40-47 Blue
48-55 Purple
56-63 White
64-71 Program 1
72-79 Program 2
80-87 Program 3
88-95 Program 4
96-103 Program 5
104-111 Program 6
112-119 Program 7
120-127 Program 8
128-135 Program 9
136-143 Program 10
144-151 Program 11
152-159 Program 12
160-167 Program 13
168-175 Program 14
176-183 Program 15
184-191 Program 16
192-199 Program 17
200-207 Program 18
208-215 Program 19
216-223 Program 20
224-231 Program 21 Fastest
232-255 Sound Mode Sensitivity 0 - 255

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
DMX Control Channel Settings
3 Channel DMX
Channel 1 Channel 2 Channel 3
Red Green Blue
0-99 Off Off Off
100-150
151-200
201-255 Full On Full On Full On
4 Channel DMX
Channel 1 Channel 2 Channel 3 Channel 4
Red Green Blue Master Dimming
0-99 Off Off Off Dimmest
100-150
151-200
201-255 Full On Full On Full On Brightest

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
DMX Control Channel Settings
7 Channel DMX
Ch1 Ch2 Ch3 Ch4 * Ch 5A * Ch 5B Ch 6 Ch7
Red Green Blue Program Speed Sensitivity Flash Dimming
0-7 Off Off Off Off Slowest Least Slowest Dimmest
8-15 Red
16-23 Yellow
24-31 Green
32-39 Cyan
40-47 Blue
48-55 Purple
56-63 White
64-71 Program 1
72-79 Program 2
80-87 Program 3
88-95 Program 4
96-103 Program 5
104-111 Program 6
112-119 Program 7
120-127 Program 8
128-135 Program 9
136-143 Program 10
144-151 Program 11
152-159 Program 12
160-167 Program 13
168-175 Program 14
176-183 Program 15
184-191 Program 16
192-199 Program 17
200-207 Program 18
208-215 Program 19
216-223 Program 20
224-231 Program 21
232-255 Full
On
Full
On
Full
On Sound Mode Fastest Most Sensitive Fastest Brightest

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
DMX Control Channel Settings
14 Channel DMX
Channel
1
Channel
2
Channel
3
Channel
4
Channel
5
Channel
6
Channel
7
Red1 Green1 Blue1 Red2 Green2 Blue2 Red3
0 Off Off Off Off Off Off Off
1-100
101-200
201-255 Full On Full On Full On Full On Full On Full On Full On
14 Channel DMX (continued)
Channel
8
Channel
9
Channel
10
Channel
11
Channel
12
Channel 13 Channel 14
Green3 Blue3 Red4 Green4 Blue4 Flash
Frequency
Master
Dimming
0 Off Off Off Off Off Static Off
1-100
101-200
201-255 Full On Full On Full On Full On Full On Fastest Most

© Lanta Lighting™ 2012. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
Revision 1
Owner Handbook Orion Link v2™
DMX Control Channel Settings
26 Channel DMX
Ch 1 Ch 2 Ch 3 Ch 4 Ch 5 Ch 6 Ch 7 Ch 8 Ch 9
Red1 Green1 Blue1 Red2 Green2 Blue2 Red3 Green3 Blue3
0 Off Off Off Off Off Off Off Off Off
1-100
101-200
201-255 Full On Full On Full On Full On Full On Full On Full On Full On Full On
26 Channel DMX (continued)
Ch 10 Ch 11 Ch 12 Ch 13 Ch 14 Ch 15 Ch 16 Ch 17 Ch 18
Red4 Green4 Blue4 Red5 Green5 Blue5 Red6 Green6 Blue6
0 Off Off Off Off Off Off Off Off Off
1-100
101-200
201-255 Full On Full On Full On Full On Full On Full On Full On Full On Full On
26 Channel DMX (continued)
Ch 19 Ch 20 Ch 21 Ch 22 Ch 23 Ch 24 Ch 25 Ch 26
Red7 Green7 Blue7 Red8 Green8 Blue8 Flash Dimming
0 Off Off Off Off Off Off Off Off
1-100
101-200
201-255 Full On Full On Full On Full On Full On Full On Most Most

www.lantalighting.com
