VDC Display Systems Marquee 8521 User manual

Display Systems
VDCDS P/N 790200201 / Revision 1.00
Rear View
100 - 240 VAC
50
-
60
H
z
GREENRED BLUE HOR/COMP VERT
SYNC
Video and Sync Signals from Source
BNC
connectors
Remote Control Layout and Controls
SOURCE
123RECALL
HELP
POWER
6
9
5
8
4
7
0MUTESTBY
PROJ UTIL PIC
GEOM
CONV
EXIT
DETAIL
VOL
TINT
BRITE
COLOR
CONT
ENTER
*
#
Picture Menu
Utilities Menu
Display Controls
Projector
S
tatus Page
Geometry Menu
Convergence Menu
Exit
Source
Recall
Help
# Test Pattern
Mute
Numeric Keys
Enter
To adjust or set:
Phase
Size
White Balance
Focus
Sync









Blanking
Clamping
Retrace
Decoder Options
To access the following utilities:
Source Setup
Channel List
Memories Display
Preferences




To adjust:



Color
Tint
Detail



Contrast
Brightness
Volume
 to command a single
projector in a multi-
projector system
 to display status
pages
To adjust:
Size
Keystone
Side Pin
Top
Bottom









Bow
C Linearity
S Linearity
Skew
 to adjust additional
geometry (Green)
 to exit from a menu or
function



for input selection
for channel up/down selection
for source message display



to select a Recall Memory
to go back one screen during
menu/help display
to view hidden slide bars
when message display is turned off


for context sensitive help
for setup guides
 to select a test pattern
for display
Power
 to turn the projector on or off
Standby
 to turn both picture and
audio on or off
 to turn audio on or off
to turn menus on or off



for menu item selection
for number entry


to select a highlighted
menu item
to select a dialog box
option
Arrow Keys



for adjustments
for menu item selection
for movement between
edit fields



Remote Options
Clock/Events
Service
Display Systems
For Technical assistance please contact VDCDS Technical Services 321.784.4427 or [e-mail]
MARQUEE8521 Quick Start Guide
This document is intended to provide a quick-start guideline on the Marquee® 8521 Green (HUD) projector. For detailed
information refer to the User’s Manual (VDCDS P/N 71180-02) on the accompanying CD.
1.1 Quick Setup
Follow these 5 steps for quick set up of the projector:
Step 1. Position the Projector
To perform a quick setup, the projector must be positioned so that the throw distance is the same as that
used during the most recent optical alignment; otherwise a detailed setup is required. The throw distance is
the distance between the center lens on the projector and the center of the projection screen.
Note: If an optical lens alignment is required, refer to Section 2.5, Optical Alignment on the accompanying
CD.
Step 2. Connect the Power Cord
Plug the AC line cord into the line input unit on the electronic chassis. Plug the three prong end of the line
cord in a grounded AC outlet.
Note: Input voltage must be between 90 VAC and 264 VAC.
Note: Ensure the line cord is the proper type for the AC receptacle.
Step 3. Connect a Source
Connect a source to the projector's built-in RGB input (slot 1). Ensure the source is on and properly
connected. Refer to Section 1.2 and Figure 1 below.
Step 4. Turn the Projector On
Hold down the [POWER]on the keypad for one second to turn the projector on.
Note: If the keypad has been configured for IR remote operation, point it towards the screen or the front of
the electronic chassis.
Step 5. Select the Input
Press [SOURCE] [0] [1] to select the source connected to the built-in RGB input.
Adjust the Display; Press [HELP] [1] to select the Guided Source Setup tutorial.
1.2 Source Connections
To apply power to the projector, plug the AC line cord into the line input socket
located at the rear panel of the electronic chassis. Plug the three prong end of
the line cord in a grounded AC outlet. Input voltage to the projector must be
between 90 and 264 VAC, 50 or 60 Hz. The power source must supply 650
watts of power to the projector.
The projector includes a built-in RGB input interface (Video Input Module) for
connection of external RGB sources. This input interface is shown in Figure 1.
The built-in interface is required for normal operation.
The standard RGB interface is typically used for connection of a
RedGreenBlue source having one of the following sync types: sync on
green (3-wire), composite sync (4-wire), or separate H & V sync (5-
wire).
The Marquee® HUD Series is a specialized projector utilizing a single
input or color. In this case, connect the source to the GREEN input on
the interface. If the source uses sync on green, no additional cables
are required. If the source provides a composite sync output, connect it
to the HOR/COMP input. If the source provides separate horizontal
and vertical sync outputs, connect the horizontal sync signal to the
HOR/COMP input, and connect the vertical sync input to the VERT
input. Interconnection cables must be terminated with BNC connectors.
Figure 1 shows the source connections for the built-in interface.
Figure 1. AC and Source (Green) Input Connections.
NOTE: 
This document is intended to be printed on 11 x 17, double sided

790200201
Display Systems
Marquee 8521 Quick Start Guide
1.3 Electronic Chassis Main Assemblies and Dimensions
# VDCDS P/N DESCRIPTION QTY
1 03-280336-07P Control/DPB/Stig-Waveform 1
2 81722-01 Marquee Contrast Modulation 1
3 03-270354-04P Module Focus & Geometry 1
4 03-271330-02P Stigmator Module 1
5 03-270350-01P Convergence Amp/Vertical Deflection Module 1
6 03-270335-05P Video Input Module 1
7 03-000250-02P IR Sensor 1
8 03-000310-02P HVPS 1
9 03-000229-05P LVPS 1
Ref 81721-01 Conv/Stig/Vert Adaptor, PCB 1
Ref 81730-01 HUD Mother Board, Elec. Chassis 1
Ref 81741-01 Vertical Load 2
HOR/COMPRED GREEN BLUE VERT
SYNC
RESET
POWER
STANDBY
HFAIL
VFAIL
CLVPS
ERROR
DIAGNOSTICS
EHT
REMOTE
RS-232
IN OUT SWI TCHER
21.2 in. [54 cm]
17.1 in [43 cm]
22.0 in. [56 cm]
10.6 in.
[27 cm] 23.0 in. [58 cm]
22.0 in. [56 cm]
R
ear
Vi
ew
Top View
Front View
Side View
1
2
3
45
Blan
k
6
Blank
7
8 9
1.4 CRT Head Main Assemblies and Dimensions
VDCDS P/N DESCRIPTION QTY
03-007062-03P Green CRT 8" MAG Focus 1
03-270338-02P Video Neck Module 1
21-000687-04 Stigmator Ring 1
21-000691-01 Yoke Deflection 8" 1
21-000692-01 Coil, Convergence 8" 1
21-000695-01 Focus MAG with Stigmator 8" 1
59874-01 Splitter, 1 IN, 1 OUT 1
59879-01 Lens, Low MAG, Hud 1
81731-01 HUD Mother Board, Head 1
81732-01 HUD Horizontal. Deflection Module 1
25.0 in. [64 cm]
27.4 in [70 cm]
34.6 in [88 cm]
TOP VIEW
FRONT VIEW SDIE VIEW REAR VIEW
9.5 in.
[24 cm]
9.5 in.
[
2
4 cm]
Examine the lens and hardware as shown in Figure
2. The lens consists of a single focus barrel. The lens
is secured in place with a lens locking ring.
Additionally, the lens consists of a metal lens cover
which is screwed in-place. To remove the lens cover,
rotate the cover counterclockwise (CCW) and place
in a secure location for reuse. To focus the lens,
loosen the lens locking ring. Note; the lens locking
ring employs fine threads and requires multiple turns.
Once loosen, rotate the lens barrel until the desired
focus is achieved.
Figure 2. 8521 Lens Assembly
LENS LOCKING
RING
LENS COVER
