VDO CD 4506 - Manual

RDS Tuner / CD Player
CD 4506 Product Information
• 4 x 40 Watts max. Power
• Plays CD-Audio, CD-R and CD-RW
• Service Interval Computer
• Detachable Front Panel
• FM/MW/LW Bands
• RDS/EON/PTY
• 30 Tuner Presets
• Speed Dependant Volume Control
(SDVC)
• Telephone Mute
• Steering Wheel Remote Control
Interface
• ECE 21 Compliant
CD-Audio, CD-R and CD-RW-Player
Ensures 100% music enjoyment. Simply press a
button to play most audio CDs - and enjoy maximum music
backed by exceptional ease of use.
Service Interval Computer
Performs all functions usually associated with an on-board
computer, such as displaying inspection schedule and distance.
It also warns the driver when a predefined maximum speed
is exceeded - making every journey a little bit safer and more
relaxed.
Detachable Front
For theft protection, the complete front of this car radio is
detachable.
Sound Presets
With the 6 different sound presets the user can adjust the
sound frequency to his preferred music genre.
Telephone Mute
During a telephone call the volume of the car radio is muted
automatically.
Speed Dependant Volume Control (SDVC)
Intelligent volume control which automatically adjusts loudness
depending on your speed (SDVC = SMART Volume).
Steering Wheel Remote Control Interface
The Steering Wheel Remote Control Interface allows for the operation
of the car radio via the original steering wheel remote control.*
ECE 21 Compliant
The finishing of the radio complies with the interior safety require-
ments according to the European regulations related to crash testing.
* Additional adapter necessary
CD
CD
CD
CD4506x_uk.indd 1 18.05.2006 8:54:22 Uhr

RDS Tuner / CD Player
CD 4506 X
Technical Information
01/2006 • CD 4506 • subject to modification • VU26-0013-0235502
Connections
A: Car Interface
B: Speakers
C2: RC3 interface (SWRC-In)
E: Aerial Plug (ISO)
Item Number
CD 4506
EAN Code
4025515255697
Product Design
• Black Front
• Fully Detachable Front
(Anti-Theft-Protection)
• Orange Display Illumination
• Orange Key Illumination
• Pilot Light
Tuner
• RDS Tuner
• FM/MW/LW
• RDS Evaluation/EON/PTY-31
• Traffic Announcement
• RDS Clock
• 30 Presets (15 FM, 10 MW, 5 LW)
CD Player
• Plays CD Audio, CD-R, CD-RW
• High-speed forward and reverse scanning
• Track Search
• Random CD playback
Internal Amplifier
• Max. Power: 4 x 40 Watts
• RMS Power: 4 x 19 Watts
• 6 Sound Presets
• Loudness:
4 freely selectable levels
• Speed Dependent Volume Control (SDVC)
General
• Service Interval Computer/
Speed Warning
• Dimensions: 179 mm x 50 mm x 150 mm
• DIN + JIN mounting
• ECE 21 Compliant
• Current consumption: approx. 1 A
(ca. 0.1 mA in off state)
• Power Supply: 12 V, DC at GND
• Voltage: 10,5 V ... 16 V
• Temperature Range: -20°C ... +75°C
Options
• Speakers
• OEM Steering Wheel Remote Control
(SWRC)*
* Additional adapter necessary
