Vegiga VGG-DVR21 User manual

Car Digital Hard Disk Recorder
User Manual
Before installing and using, be sure to read the Manual, then you will properly use and protect your
machine. The first part of the statement concerns the matters to be attention to before installing and using.

1
¾Attention
zTo protect your rights, before using and installing, please carefully read the contents of the
manual.
zThis product is used for car inside, in order to prevent short-circuit or the risk of electric shock, do
not make the machine on the rain or humidity environment.
zEvent of any solid or liquid into the machine, please disconnect the power of the machine
immediately, and ask the qualified technical staff to check, then restart it.
zThe product is high-tech equipment; machines can not be repaired by users even very small
original part. Once failure occurs, please ask for the qualified technical personnel, or contact with
the dealer. Do not repair it by users themselves.
¾Installation Environment
z8-48V DC power supply, please confirm the local power supply before power on.
zIf the machine were not used for a long time, please completely disconnect the video’s power
supply.
zPlease select the appropriate location for the installation of the machine, where the air can flow
freely around the machine to avoid overheating.
zMachine can not be installed near the radiators, or near the ventilation road which is near heat, or
directly under sunshine, or too much dust, or near the area where the mechanical vibration or
impact happens.
¾Packing List
Name Count
Four Channel HDD Recorder 1
User Manual 1
Certificate of Quality 1
Remote Control 1
Connection Port 2
PC View Soft Disk 1
Shockproof pad, DVR holder, Screw,etc. 1
Note: When the specification or parameters changes, no other announcement in addition.

2
Contents
1 Product Overview...........................................................................................................................................3
2 Features................................................................................................................................................................3
2.1 Operating System ..................................................................................................................................3
2.2 Video Compression Standard..........................................................................................................3
2.3 Surveillance and Video Processing ..............................................................................................3
2.4 Playback and Search ............................................................................................................................4
2.5 Hard Drive and Backup......................................................................................................................4
2.6 Control ........................................................................................................................................................4
2.7 Designed to Prevent Vibration........................................................................................................4
2.8 Others ..........................................................................................................................................................4
3 Technical Parameters .................................................................................................................................5
4 Optional Features ..........................................................................................................................................6
5 Instruction of Installation ...........................................................................................................................7
5.1 Instruction of External Interface Wiring....................................................................................7
5.2 Instruction of HDD Installation......................................................................................................9
6 Instruction of Using.....................................................................................................................................11
6.1 Instruction of Front Panel .............................................................................................................11
6.2 Instruction of Remote Control Operation................................................................................12
6.3 Instruction of Menu Setup...............................................................................................................13
6.4 Video Data Volume............................................................................................................................15

3
1 Product Overview
The four-channel embedded digital hard disk video recorder is designed for car safety. It uses embedded
processor and embedded operating system, combined with video / audio compression / decompression, GPS,
car recorder, and the capacity hard disk storage technology to confirm the high intelligence and high stability.
Widely used for bus, ship, train, and other areas of security.
2 Features
2.1 Operating System
zEmbedded Linux operating system, to eliminate the virus infection; more stable.
zChinese and English menu to switch.
2.2 Video Compression Standard
zH.264 Video formatsˈexcellent screen, and the best bit stream.
2.3 Surveillance and Video Processing
zSurveillance: 4 channels D1 video (PAL: 720 * 576, NTSC: 720 * 480)
zRecorder: Total resources 100PAL, 120 NTSC. 4 channels CIF (PAL: 352* 288, NTSC: 352 *
240), HD1 (PAL: 704* 288, NTSC: 704 * 240), D1. (PAL: 704* 576, NTSC: 704 * 480) video
storage separately.
zThree record modes: alarm record, timer record and manual record; support 4 channels video
and 4channels audio record at the same time.
zVideo quality: eight grades to adjust.
zSpecially design for video file system to prolong the life of hard drive.
zThe disk storage of video& audio data can not be artificially modified, which can be as the
evidence of high credibility.

4
2.4 Playback and Search
zPlayback is according to time .
zSupport 4 channel video and 4 channel audio playback simultaneously, or 1 channel video and
audio playback amplified(use the special PC viewer software).
zIf playback on the machine with a LCD monitor, then it can just support 1 channel video and 1
channel audio playback amplified
2.5 Hard Drive and Backup
zPull style of hard drive box, Support 2.5-Inch notebook computer hard drive.
zApply to Samsung, Hitachi SATA series of notebook computer drives.
zUse the USB interface to back up or hard drive box directly connected to a computer to backup.
2.6 Control
zRemote control.
zDual MCU control, high steady workability
2.7 Designed to Prevent Vibration
zNon-fixed, suspended Hard Drive for shockproof protection, with excellent damping.
zSpecial SATA hard drive box connector design and reliable contact.
zBesides hard drive, the circuit board and the electronic components are dealt with shockproof
and reinforcement.
2.8 Others
zUSB software upgrading and simple maintenance.
zPassword-protection keeps data away from destroy.
zReal-time and trigger video record to be selected.
zPrevent impulse voltage, low voltage supply protection.
zTime-lapse turn off the machine function(default: 5 seconds)
zReal-time clock

5
3Technical Parameters
Item Name 4 Channel Mobile DVR(HDD Storage)
Item Number TS-210
Items
Solutions H.264 Main Profile
Operation Language Chinese / English
Operation Interface Graphical Interfaces
System
Password Control User Password
Video Input 4ch Independent Input: 1.0Vp-pˈ75.Both B&W and Color Cameras
Video Output 1 Channel PAL/NTSC Output, 1.0Vp-pˈ75ˈComposite Video Signal
Video Display 1 Or 4 Screen Display
Viedo Standard PAL:25frames/Sec;NTSC:30frames/Sec
Video
System Resources PAL:100 Frames; NTSC:120 Frames
Audio Input Four Channels Independent Input 600
Audio Output 1 Channel(4 Channels Can Be Convert Freely)
Basic Output Level 1.0—2.2V
Distortion Plus Noise İ-30dB
Recording Mode Sound And Image Synchronization
Audio
Audio Compression ADPCM
Image Compression H.264 Fixed Code Stream
Image Format 4*CIF (352*288), or 4*HD1(704*288), or 4*D1(704*576)
Video Stream CIF: 8K-64Kbyte/s; HD1 & D1: 32K-96Kbyte/s;
Video Taking Up Of Hard Disk CIF: 28M-230Mbyte / hour / channel
HD1 & D1: 115M-340Mbyte / hour / channel
Resolution Playback 1 Channel
Video Streaming Standard H.264 Main Profile
Audio Bitrate 4Kbyte / s / channel
Audio Taking Up Of Hard Disk 14Mbyte / hour / channel
Internal Storage 1 SATA Hard Disk,Support Max 2T Hard
Digital
Processing
& Storage
Image Quality Eight Grades to Choose
Alarm Alarm in 4 Channels Independent Input. High Voltage Trigger
USB Port Available For USB Disk and Hdd˄FAT32˅Storage
Interface GPS,3G Vehicle Tracking and Data Wireless Upload
Power Consumption DC8-48v 5% 8W˄without HDD˅
Working Temperature -20ć~ +60ć
Others
Clock Built-In Clock, Calendar
Product Size 213(L)*230(W)*63(H)mm˄with Holder˅
Product Weight 1.9KG(without HDD)
Package Each In a Box, 10set/Canton
Box Size 252(L)*93(W)* 250(H)mm
Carton Size 500(L)*265(W)* 520(H)mm
Packaging
Carton Weight 19kgs/21kgs (without HDD)

6
4Optional Features
zAlarm record
zGPS module
z3G module

7
5 Instruction of Installation
5.1 Instruction of External Interface Wiring
1) BNC interface connection instruction:

8
2) 4 pin aviation interface connection instruction:
Remarks:
zIf the power supply is 12V, then the current of 12V output can be just 1A. So if there are more
than 3pcs cameras, we suggest customers to get power for other cameras from the 12V vehicle
power directly or use Teswellÿs special car power supply.
zOnly customers have special requirements when placing orders, the ĀSENSORāport will have
ALARM functions. Or this port is useless.
zRS485 and RS232 interface are optional interface, available only when you listed in the order for
this interface.

9
5.2 Instruction of HDD Installation
ķĸ
Ĺĺ
Ļļ
Ľľ

10
Ŀŀ
Make sure whether power switch is turned on or turned off, if it is turned on, please use the key, turn the
indentation on the “turn off” position.
zPull the front panel of the hard drive box. Carry out the hard drive and drop it on the table.
zSet down the two screws of the hard drive by cross-screwdriver.
zDrop the under backer of hard drive box, and then check the line whether it is on top of the under
backer or not.
zBring here the SATA hard drive which needs installation; connect the line joint of hard drive box to
the hard drive. Please note the heading of the line while connecting. Make sure all of the
connecting is complete done.
zPut the hard drive in the hard drive box. The obligate line of hard drive needs longer, the line of
hard drive needs to lie on the right position.
zLet the four white screws of the machine through the center hole of the four shockproof rubber
pads. Fix hard drive on the four holes of hard drive box, do not make the screws too taut, leave a
little space for hard drive to move. So it can reach a perfect effect.
zInsert the hard drive under backer which has hard drive to the hard drive top backer, and then,
use cross screwdriver and the screw to fix the under backer and the top backer.
zAimed the hard drive box towards the groove of the front board, level push. Please note the face
and back while pushing. Upturn the silk-screen on the right position.
zWring the lock of the front board by key. Turn the groove on the “turn on” position, lock hard drive
box to prevent hard drive from moving out.
Note : Hard drive fixing lock besides fixing the hard drive, also take the place of host power switch .So
do this operation, make sure all lines are completely connected. Otherwise, if car‘s power have
been connected with the standard input voltage, the machine should be destroyed. So while

11
installation, if the line has not been completely connected, please stop to do this step. More
careful when installation. The hard drive can not roll out even it has not been locked.
6 Instruction of Using
6.1 Instruction of Front Panel
zLED
9PWR LED: lighting while work starts. Power LED on.
9RUN LED: LED flashing when machine is normal working.
9HDD LED: when records, playback, video data are backing up, LED is flashing.
9GPS LED: GPS working LED indicator
93G LED: 3G working LED indicator
zKey and Other Descriptions
9DEBUG: Debug interface
9SIM interface: 3G interface
9IR: infrared receiving window.
9LOCK: while removing the hard drive, use the key to unlock in order to remove the hard
drive, unlock after machine’s auto-disconnects the power, the power auto-connect after
being locked.
9USB: playback the video data of hard drive via USB .
NOTE:Recommend to use the SanDisk brand of the USB disk , the minimum volume 256M, must
support the FAT32 file system.

12
6.2 Instruction of Remote Control Operation
z˖Record key
z˖Lead to menu
z˖After entering sub-menu button to confirm,
modify key parameters select .
z˖Play key
z˖Into menu mode, press left key, modify key
parameters select .
z˖Into menu mode, press right key, modify key
parameters select .
z˖Pause
z˖Stop
z˖Into menu mode, press up key.
z
˖
Into menu mode, press down key.
z˖ķ
ķ
Recording video or play, screen zoom display in first channel.
ĸ
System default
password: six 1 this key.
z˖ķ
ķ
Recording video or play, screen zoom display in second channel.
ĸ
Set System
password.
z˖ķ
ķ
Recording video or play, screen zoom display in third channel.
ĸ
Set System
password.
z˖ķ
ķ
Recording video or play, screen zoom display in fourth channel.
ĸ
Set System
password

13
z˖ķ
ķ
Four channels display.
ĸ
Modify system’s password
zOther number keys: Used for change password
6.3 Instruction of Menu Setup
In surveillance mode, press . If it is the first time to enter the MENU interface, system will
show “ENTER THE PASSWORD”(The defaulted password is 6666). When finished, press to
enter the MENU interface. In the recording mode, please press first to stop recording, and then
press to enter the MENU interface.
zSettings: To set up items as below
9TIME: Set up the time of the mobile DVR.
9CAR LICENSE
˖
Set up the vehicle ID number.
9LANGUAGE
˖
Can select“Chinese”or“English”. When finished, please restart the machine, then
this setting will be effected.
9VIDEO MODE
˖
Set up the video standard, can select PAL or NTSC. When finished, please
restart the machine, then this setting will be effected.
9DELAY TIME
˖
This item is for time-lapse turn off function. Defaulted time is 5seconds, you can
set to 5s,30s,60s,120s,300s,600s,1200s,1800s.3600s.7200s. When finished, please restart the
machine, then this setting will be effected.
9PASSWORD
˖
Before change the password, you need to enter into the original password.
9NEW PASSWORD
˖
Enter into the new password.
zHDD
˖
Can setup and check the information of the hard disk.
9HDD OVERWRITE
˖
Setup the rewrite function
9HDD TOTAL SIZE
˖
Show the total capacity of the hard disk.
9HDD FREE SIZE
˖
Show the rest capacity of the hard disk.
9HDD FORMAT
˖
Enter the password, the machine will format the hard disk and delet the video
files in the hard disk automatically.
zRecord
˖
Settings for the video files.
9REC RESOLUTION
˖
CIF/HD1/D1
9RECORD FRAME
˖
1~25frames˄adjustable˅

14
9REC QUALITY
˖
Setup the picture quality(8 grades totalˈLOWEST—HIGHEST)
9DISPLAY CH
˖
Setup how many channels display on the LCD monitor
9File time: set up record time of files (300~3600second)
9VIDEO RECORD CH
˖
Setup the recording video channels, Red means record
9AUDIO RECORD CH
˖
Setup the recording audio channels, Red means record.
9REC SCHEDULE
˖
Setup the recording mode for different time
White˖No recording Red˖Recording S˖Alarm recording
zSearch
˖
Playback the recorded videos.
9FILE LIST
˖
Display the date of the videos, enter into the date, you can see the time list of the
videos within the day. Select the time according to your needs, press “PLAY”on the remote
control to playback the videos.
9PLAYBACK CH
˖
Only 1 channel can be playbacked on the machine with a LCD monitor(not on
the computer), this item is for selecting the playback channel.
zVideo download:
9Connect USB Flash Drives or HDD to USB interface in front of the DVR
9Shift to ʾPlayback menuʾ, select target video for download by Remote control, press ʾ
OKʾto start copy.
9After download one section, do as the same way if your want to download more.
zAlarm
˖
9Alarm record time: 10-90 second since alarm record.
zNetwork
˖

9DOMAIN NAME: Used for 3G spy, Server domain
9SERVER PORT: Used for 3G spy, Server Port
9STREAM SIZE: available for 24kbps, 48kbps, 96kbps, 128kps
9STREAM FRAME: available 1~25 fps

15
6.4Video Data Volume
The required volumes of video and video-related settings please see the following table
VIDEO QUALITY Total Record Frame Data Size Per Hour
HIGHEST 100 frame 1120 MB
HIGHER 100 frame 1012MB
HIGH˄default˅100 frame 900 MB
BETTER 100 frame 780 MB
NORMAL 100 frame 675 MB
LOW 100 frame 560 MB
LOWER 100 frame 450 MB
LOWEST 100 frame 340 MB
Note: Based on users matching conditions to apply the appropriate drive and related settings.
