Veken W80-W User manual
User Manual
4L
Automatic
Pet Feeder
Specification
Product Features
Battery power alone lasts for up to 30 days.
To prevent food jams, the grain size should not exceed 15mm.
Batteries are not included.
Programming: up to 8 meals per day. portionable in 5g increments, max. filling 200g.
Product Weight: 1.5kg (without batteries and food)
Product Size: L206mm x W341mm x H321mm
Capacity: 4L (dry food pellets between 2-15mm only )
Dual Power Supply: Output DC power adapter, 5V - 1A // 3 x D battery.
2
4
5
6
Desiccant valve keeps kibble dry and fresh.
Top lid to protect kibble from pet access.
Transparent food canister to check filling status.
Detachable body for easy maintenance.
Separate 304 stainless steel food bowl.
Dual power supply, works through power loss.
2
4
5
6
2
Setting up the Feeder
1 Assemble the food bucket, lid and food trays as shown below pictures.
Dual power mode: Connect the USB cable to the machine and plug in the power adapter. If
you do not wish to use the power adapter for power supply, install 3 D-type batteries on the
bottom of the machine. Dual power supply is recommended.
Ensure the battery poles are correctly
directed.
3 Open the lid as shown below and lock after food is added.
Operating the Touch Panel Operation Guide
Rotate counterclockwise to open Rotate clockwise to lock
Insert the food bucket into the
slot and rotate clockwise to lock. Rotate clockwise to fix the lid. Insert the feeding tray into
the bottom slot.
Recording button
Standby status:
Long Press-Record or cancel recording.
Short Press-Play record.
Microphone
When you press and hold the recording
button on the device or click the recording
button on the App, please speak loudly into
the device microphone,not the mobile
phone.
Status Indicator
Flashing green light: It means reset successfully
and enter the Wireless Access Point Mode.
Steady red light: It is only battery powered or the
device is offline.
Steady green light: Connection succeeded.
Red and green lights appear at the same time:
Device is locked or unlocked.
Setting button
Standby status: Short Press-Manual feeding.
Setting status: Long Press-Enter Wireless
Access Point Mode and waiting for connections.
Please follow the instructions on the App.
2
3
4
1
3
4
1
2
When using battery power alone, the device will automatically disconnect from the network,
but it will feed at the previously set time.
On battery supply only,the feeder works up to 30 days.
( 1 ) Testing before use
Ensure the feeder is normally powered.
Short Press the setting button , the feeder instantly release one portion. Repeat this step for 3 times to make sure
the feeder work normally.
Download and install the App
Scan the QR code on the right to enter the APP
download page and follow the instructions on the
page to download and install.
( 2 )Distribution Network Guidelines
Add device
On the main interface of the App, click the "Add device"
button to enter the Add Device Wizard.
Registration
Follow the wizard to complete the registration
and login.
Wi Fi
Note:
Another Way To Download The App
Mobile phone brands
Apple
HUAWEI
An Android phone except HUAWEI phones
Where To Download The App
The Apple Store
The Huawei App Gallery
The Google Play
Please go to the app store to update the app and upgrade the device regularly to get a better experience.
If you want to lock or unlock the equipment, you can long press and hold the “ ” and the
“ ” at the same time.
Note:If you cannot download the app by scanning the code, pls follow another way to download the app.
