Velleman ECAMIP501 User manual

ECAMIP501/ECAMIP501B·Quick Start Guide
Quick Start Guide
About this Manual
The Manual includes instructions for using and managing the
Product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to
firmware updates or other reasons. Please find the latest version of
this Manual at the company website
Please use this Manual with the guidance and assistance of
professionals trained in supporting the Product.
Trademarks Acknowledgement
Trademarks and logos mentioned are the properties of their
respective owners.
LEGAL DISCLAIMER
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS
MANUAL AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE,
SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH ALL
FAULTS AND ERRORS”. OUR COMPANY MAKES NO WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A
PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT
YOUR OWN RISK. IN NO EVENT WILL OUR COMPANY BE LIABLE TO
YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT
DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA,
CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING

ECAMIP501/ECAMIP501B·Quick Start Guide
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION
WITH THE USE OF THE PRODUCT, EVEN IF OUR COMPANY HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR
INHERENT SECURITY RISKS, AND OUR COMPANY SHALL NOT TAKE
ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY
LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK,
HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY
RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY TECHNICAL
SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL
APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR
ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A
MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF THIRD
PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF PUBLICITY,
INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER
PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY
PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR
PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE
DEVELOPMENT OR PRODUCTION OF CHEMICAL OR BIOLOGICAL
WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY
NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN
SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.

ECAMIP501/ECAMIP501B·Quick Start Guide
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help

ECAMIP501/ECAMIP501B·Quick Start Guide
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product contains
a battery that cannot be disposed of as unsorted
municipal waste in the European Union. See the
product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier

ECAMIP501/ECAMIP501B·Quick Start Guide
or to a designated collection point. For more information see:
www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards
requirements.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into "Warnings" and "Cautions"
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

ECAMIP501/ECAMIP501B·Quick Start Guide
Warnings
●For device with this sticker, this device is intended for installation
in a restricted access location, access can only be
gained by service persons or by users who have
been instructed about the reasons for the
restrictions applied to the location and about any precautions
that shall be taken.
●This equipment is intended for installation in a restricted access
location, access can only be gained by service persons or by
users who have been instructed about the reasons for the
restrictions applied to the location and about any precautions
that shall be taken.
●Proper configuration of all passwords and other security settings
is the responsibility of the installer and/or end-user.
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 12 VDC according to
the IEC60950-1 standard. Please refer to technical specifications
for detailed information.
●Do not connect several devices to one power adapter as adapter
overload may cause over-heating or a fire hazard.

ECAMIP501/ECAMIP501B·Quick Start Guide
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of sensor
will not be exposed to the laser beam.
●Do not place the camera in extremely hot, cold (the operating
temperature shall be -30 °C to 60 °C), dusty or damp locations,
and do not expose it to high electromagnetic radiation.

ECAMIP501/ECAMIP501B·Quick Start Guide
●To avoid heat accumulation, good ventilation is required for
operating environment.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all the
users. Please contact with your dealer for more details.
Improper use or replacement of the battery may result in hazard
of explosion. Replace with the same or equivalent type only.
Dispose of used batteries according to the instructions provided
by the battery manufacturer.
L’utilisation ou le remplacement inadéquats de la pile peuvent
entraîner un risque d’explosion. Remplacez-la par le même type
ou l’équivalent du même type seulement. Jetez les piles usagées
conformément aux directives fournies par le fabricant de la pile.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

ECAMIP501/ECAMIP501B·Quick Start Guide
1Appearance Description
The overview of the cameras are shown as the figures below.
1
2
3
45
6
Type I Camera Overview
2
1
3
45
6
Type II Camera Overview
Table 1-1 Description
No.
Description
1
Camera Body
2
Enclosure
3
Mounting Base

ECAMIP501/ECAMIP501B·Quick Start Guide
No.
Description
4
Lock Button
5
Network Cable
6
Power Cord
Notes:
⚫Only certain models support memory card installation and reset
function.
⚫Power on the camera when pressing the RESET button, and
press button for another 10 seconds to restore the default
settings, including the user name, password, IP address, port
No., etc.

ECAMIP501/ECAMIP501B·Quick Start Guide
2Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is 12 VDC or PoE, make sure your
power supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four times
the weight of the camera and the bracket.
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
2.1 (Optional) Install the Memory Card
Only certain models support memory card installation. Take type II as
an example to describe the steps.
Steps:
1. Rotate the camera body to completely expose the memory card
slot.

ECAMIP501/ECAMIP501B·Quick Start Guide
Expose the Memory Card Slot
2. Loosen the screws to remove the memory card slot cover.
3. Insert the memory card into the slot, and push to get it mounted.
Memory
Card Slot
Reset
Button
Memory
Card
Install the Memory Card
4. (Optional) To unmount the memory card, push to eject it.
5. Fix the screws to replace the slot cover.

ECAMIP501/ECAMIP501B·Quick Start Guide
2.2 Ceiling Mounting
Before you start:
Type I and Type II camera both support the ceiling mounting and the
steps are similar. Here takes type II as an example to describe the
steps.
Steps:
1. Disassemble the camera by pressing the button on the camera.
Press
Disassemble the Camera
2. Paste the supplied drill template to the desired mounting position
on the ceiling.

ECAMIP501/ECAMIP501B·Quick Start Guide
14.5
Φ125
14.5
54.3
54.3 39.7
3-Φ4.5
Figure 2-4 The Drill Template
3. Drill the screw holes or the cable hole in the ceiling according to
the drill template.
Note: Drill the cable hole if adopting ceiling outlet to route the
cable.
4. Fix the mounting base on the ceiling with supplied screws.
Fix the Mounting Base

ECAMIP501/ECAMIP501B·Quick Start Guide
Note:
⚫In the supplied screw package, both self-tapping screws, and
expansion bolts are contained.
⚫If the ceiling is cement, expansion bolts are required to fix the
camera. If the ceiling is wooden, self-tapping screws are
required.
5. Route the cables through the cable hole, or the side opening.
6. Install the camera body back to the mounting base.
Install the Camera Body
7. Connect the power cord and network cable.

ECAMIP501/ECAMIP501B·Quick Start Guide
8. Power on the camera, and set the network configuration. For
details, refer to 3 Set the Network Camera over the LAN and 4
Access via Web Browser.
9. Adjust the surveillance angle.
Rotation: 0 to 360°
Pan: 0 to 360°
Tilt: 0 to 75°
Adjust Surveillance Angle
1). Hold the camera body and rotate the enclosure to adjust the
pan angle [0° to 360°].
2). Move the camera body up and down to adjust the tilt angle [0°
to 75°].
3). Rotate the camera body to adjust the rotation angle [0° to
360°].
2.3 Wall Mounting
Before you start:
●Type I and Type II both support wall mounting and the steps are
similar. Here takes type II as an example to describe the steps.
●You need to purchase a wall mounting bracket separately.

ECAMIP501/ECAMIP501B·Quick Start Guide
Steps:
1. Disassemble the camera by pressing the button on the camera.
Press
Disassemble the Camera
2. Drill screw holes in the wall according to the holes of the bracket
and install the bracket to the wall with screws.
Install the Bracket
3. Install the mounting base to the bracket with screws.

ECAMIP501/ECAMIP501B·Quick Start Guide
Install the Mounting Base to the Bracket
4. Repeat steps 5 to 9 of 2.2 Ceiling Mounting to complete the
installation.
2.4 Mounting with Junction Box
Before you start:
●Type I and Type II both support mounting with junction box and
the steps are similar. Here takes type II as an example to
describe the steps.
●You need to purchase a junction box separately.
Steps:
1. Disassemble the camera by pressing the button on the camera.

ECAMIP501/ECAMIP501B·Quick Start Guide
Press
Disassemble the Camera
2. Paste the supplied drill template to the desired mounting position.
62.6
62.6
4-Φ6
Φ130
Φ30
Drill Template
3. Drill the screw holes according to the drill template.
4. (Optional) If you want to route the cables inside the wall, drill a
cable hole in the wall according to the adapter plate.
5. Take apart the junction box, and fix the camera mounting base on
the junction box's cover with screws.
