Velleman CAMTVI13 User manual

CAMTVI13
HD CCTV DOME CAMERA - OUTDOOR
HD CCTV DOMECAMERA - GEBRUIK BUITENSHUIS
CAMÉRA DÔME HD CCTV - EXTÉRIEUR
CÁMARA HD CCTV DOMO - EXTERIORES
HD CCTV-DOME-KAMERA - AUßENBEREICH
KAMERA HD CCTV - ZEWNĘTRZNA - KOPULKOWA
CÂMARA HD CCTV - TIPO DOME - EXTERIOR
HD-TVI –VARIFOCAL –IR –1080P
USER MANUAL 6
HANDLEIDING 13
MODE D'EMPLOI 20
MANUAL DEL USUARIO 27
BEDIENUNGSANLEITUNG 34
INSTRUKCJA OBSŁUGI 41
MANUAL DO UTILIZADOR 48

CAMTVI13
V. 01 –09/01/2017 2 ©Velleman nv

CAMTVI13
V. 01 –09/01/2017 3 ©Velleman nv

CAMTVI13
V. 01 –09/01/2017 4 ©Velleman nv

CAMTVI13
V. 01 –09/01/2017 5 ©Velleman nv

CAMTVI13
V. 01 –09/01/2017 6 ©Velleman nv
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of
the device after its lifecycle could harm the environment. Do not
dispose of the unit (or batteries) as unsorted municipal waste; it
should be taken to a specialized company for recycling. This device
should be returned to your distributor or to a local recycling
service. Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Velleman! Please read the manual thoroughly before
bringing this device into service. If the device was damaged in transit, do
not install or use it and contact your dealer.
2. Safety Instructions
Keep this device away from children and unauthorized
users.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety. Children shall be supervised to ensure that they do
not play with the appliance.
Do not disassemble or open the cover. There are no user-
serviceable parts inside the device. Refer to an authorized
dealer for service and/or spare parts.
Risk of electroshock when opening the cover. Touching
live wires can cause life-threatening electroshocks. Do not
disassemble or open the housing yourself. Have the device
repaired by qualified personnel.

CAMTVI13
V. 01 –09/01/2017 7 ©Velleman nv
3. General Guidelines
Refer to the Velleman® Service and Quality Warranty on the last pages
of this manual.
Keep this device away from dust and extreme temperatures.
Protect this device from shocks and abuse. Avoid brute force
when operating the device.
Familiarise yourself with the functions of the device before actually
using it.
All modifications of the device are forbidden for safety reasons. Damage
caused by user modifications to the device is not covered by the
warranty.
Only use the device for its intended purpose. Using the device in an
unauthorised way will void the warranty.
Damage caused by disregard of certain guidelines in this manual is not
covered by the warranty and the dealer will not accept responsibility for
any ensuing defects or problems.
Due to constant product improvements, the actual product appearance
might differ from the shown images.
Product images are for illustrative purposes only.
Do not use this product to violate privacy laws or perform other illegal
activities.
Do not switch the device on immediately after it has been exposed to
changes in temperature. Protect the device against damage by leaving
it switched off until it has reached room temperature.
Keep this manual for future reference.
4. Features
weatherproof
with B/W night vision (IR LEDs)
1080P video signal
vandal-proof bracket

CAMTVI13
V. 01 –09/01/2017 8 ©Velleman nv
5. Installation
Refer to the illustration on page 2 of this manual.
1
lens
5
fixation ring
2
IR LEDs
6
mounting ring
3
light sensor
a
power plug
4
camera
b
video plug
6. Installation
1. Disassemble the camera. You should have three parts: the mounting
plate, the fixation ring and the camera.
2. Choose a location for the camera, keeping following guidelines in
mind:
odo not install the camera in locations where extremely high or low
temperatures or excessive vibrations may occur.
oavoid mounting the camera near high electro-magnetic fields.
odo not aim the camera at the sun or other extremely bright objects
or reflections (e.g. metal doors).
3. Use the mounting plate to determine the position of the mounting
holes. Drill the holes.
4. Fix the mounting plate on the ceiling or wall with the four screws.
Place the camera on the mounting plate and slide the fixation ring over
the camera. Tighten the locking screw slightly.
5. Connect all wires. Set up the desired field of observation by adjusting
the position of the camera in the fixation ring.
6. Tighten the locking screw to fix the fixation ring.

CAMTVI13
V. 01 –09/01/2017 9 ©Velleman nv
7. Connection
1. Connect the power terminal of the camera to a 12 VDC regulated
power supply.
2. Connect the video output of the camera to the video input of your DVR
using a 75 Ωcoaxial cable.
Only use a regulated 12 VDC power adapter. Using any
other type will damage this camera.
Protect the connectors against moisture by applying some
insulating tape over the connectors.
8. Focal Length and Focal Adjustment
1. On the DVR live view, click the camera’s channel to display it in full
screen.
2. Open the control panel by clicking the camera icon.
zoom in/out max.
zoom in/out
click to display the image at its
largest/smallest
zoom in/out max.
zoom in/out
click to zoom in/out
focus near/far
click to adjust the focal distance
IR intensity
click and drag the slider from 0 to 5;
the higher the value, the brighter
the image

CAMTVI13
V. 01 –09/01/2017 10 ©Velleman nv
9. Camera Configuration
1. On the DVR live view, right-click in the screen to display the DVR
menu.
2. Select ADVANCED CONFIG > DCCS.
ADVANCED CONFIG
CAMERA
CH1
CH2
CH3
CH4
DETECTION
OSD MENU
SETUP
ALERT
DCCS MENU
SETUP
NETWORK
DISPLAY
RECORD
F.W.
E8
DCCS
DEVICE
AVT SERIES
NOTIFY
CONNECTION
OK
EXIT
3. In DCCS SETUP, click the value to change from 1 to 100.
DCCS SETUP
IR1 BRIGHTNESS USER
100
4. Select ADVANCED CONFIG > DCCS > OSD MENU. Select the
camera’s channel and click SETUP to enter the camera’s menu.
ADVANCED CONFIG
CAMERA
CH1
CH2
CH3
CH4
DETECTION
OSD MENU
SETUP
ALERT
DCCS MENU
SETUP
NETWORK
DISPLAY
RECORD
F.W.
1015
DCCS
DEVICE
AVTXXX
NOTIFY
CONNECTION
OK
EXIT
