Vello LED Stage Bar1251 RGBWA with dot matrix User manual

1
LED Stage Bar1251 RGBWA with dot matrix
USER MANUAL
----------------------------------------Pro20130814&Ver01-----------------------------------

2
Introduction
Unpacking: Thank you for purchasing Vello Lights. Every unit has been thoroughly tested and shipped
in perfect condition. Carefully check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your unit for any damage and be sure all
accessories necessary to operate the unit has arrived well. In the case damage has been found or parts
are missing, please contact the manufacturer or your dealer for further instructions. Do not return this
unit to your dealer without pre-notice..
Protection Against Fire
1. Maintain a minimum of 1 50cm distance from any type of flame
2. Replace fuse only with the specified type and rating
3. Do not install the unit to close a heat source
4. Make sure cable are properly secured away from unit movement
5. Maximum surface operating temperature 80°
Protection Against Electrical
1. Disconnect power before servicing
2. The unit must be earthed (electronically grounded)
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock
PLEASE recycle the shipping carton whenever possible.
General Instructions
To optimize the performance of this product, please read these operating instructions carefully to
familiarize you with the basic operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please keep this manual with the unit for
future reference.

3
Features
●Multi-Colors ●Master/Slave synchronization
●Color Strobe ● LED operation menu
●Electronic Dimming 0-100% ●DMX-512 protocol
●Daisy Chain Units together in DMX Mode ●With Dot Matrix+Sound Control
Safety Precautions
●Be sure that the local power outlet match that of the required voltage for your unit,
●Do not attempt to operate this unit if the power cord has been frayed or broken. Do not attempt to
remove or break off the ground prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and fire in case of an internal short.
●Disconnect from main power before making any type of connection.
●Do not remove the cover under any conditions. There are user serviceable parts inside.
● Never operate this unit when its rear cover is removed.
●Never plug this unit into a dimmer pack.
●Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6” (15cm)
between this device and a wall.
●Do not attempt to operate this unit, if it becomes damaged.
●During long periods of non-use, disconnect the units main power.
●Always mount this unit in safe and stable matter.
●Power-supply cords should be routed so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to the point they exit from the unit.
●Cleaning unit should be cleaned only as recommended by the manufacturer. See ‘Cleaning” for
details.
●Heat –The appliance should be situated away from heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers) that produce heat.
●The unit should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits s marked change in performance.
DMX Linking: To ensure proper DMX data transmission, when using several DMX units try to use the
shortest cable path possible. The order in which units are connected in a DMX line does not influence
the DMX addressing. For example; a unit assigned a DMX address of 1 may be placed anywhere in a
DMX line, at the beginning, at the end, or anywhere in the middle. When a unit is assigned a DMX
address of 1, the DMX controller knows to send DATA assigned to address 1 to that unit, no matter
where it is located in the DMX chain.
Operating Instructions
Operating Modes: You can use the unit in 4 ways:
●Auto Mode-The unit will automatically chase through the different colors.
●DMX control mode –This function will allow you to control each individual units traits with a standard
DMX 512 controller.
●Master-slave mode –One unit will work as the master in the one of the above three modes, other
units in the chain will work in synchronization towards the master.
●Sound control - The unit will react to sound, chasing through the built-in programs.

4
DMX Mode: Operating through a DMX controller give the user the freedom to create their own programs
tailored to their own individual needs. This function also allows you to use your units as spot lights.
1. This function will allow you to control each individual unit’s traits with a standard DMX 512 controller.
2. The unit has 9/24/60 three DMX channels modes to operate. Please see “DMX channels/function/
description/ value” for the DMX traits.
3. To run your unit in DMX mode, plug in the unit via the XLR connections to any standard DMX
controller. Set your desired DMX address following the setup specifications that come with your DMX
controller.
Main Control Menu
The control board on the fixture base is your interface to access and
control all functions on the unit, Its digital display gives you a code vide of
functions and options as below:
Touch Buttons: There are four buttons under the LED display below:
There are four touch buttons under the display: Menu, Up, Down, Enter. Normally, the LED will display
the current DMX address code of the fixture. At this time, presses up and down to choose the functions
you want.
DMX Address Red Green Blue White Amber Flash
1-512 000-099 000-099 000-099 000-099 000-099 000-099
Fade Scroll Full On Effect Pixel Effect Built-in Modes Sound Dimmer Mode Operating Mode
000-099 000-099 00-0-099 00-15 ON/OFF NO/YES A /P / H
DMX Address. Press Enter to select the start address channel. The first display will let
you know what operation mode you are in. Use the up/down keys to select the desired
start address. Press Enter to confirm.
Red. This function allows you to power the red LED’s from 0-100%, Use the up/down
keys to select desired intensity setting Press Enter to confirm the setting.
Green. This function allows you to power the green LED’s from 0-100%, Use the
up/down keys to select desired intensity setting Press Enter to confirm the setting
Blue. This function allows you to power the blue LED’s from 0-100%, Use the up/down
keys to select desired intensity setting Press Enter to confirm the setting
White. This function allows you to power the white LED’s from 0-100%, Use the
up/down keys to select desired intensity setting Press Enter to confirm the setting
Amber. This function allows you to power the amber LED’s from 0-100%, Use the
up/down keys to select desired intensity setting Press Enter to confirm the setting

5
Flash .Enter to select the desired operating mode. Use the up/down keys to select desired flash speed
setting( Fast to Slow) from 000-099. Press Enter to confirm.
Fade Scroll. Press Enter to select the desired operating mode. Use the up/down keys
to select desired fade speed setting( Fast to Slow).Press Enter to confirm.
Full On Effect. Press Enter to select the desired operating mode. Use the up/down
keys to select desired color change speed setting( Fast to Slow) Press Enter to confirm.
Pixel Effect , Press Enter to select the desired operating mode. Use the up/down keys
to select, you’ll see fixed pixel effect (Fast to Slow) from 00-99, Press Enter to confirm.
Built-in Mode. , Press Enter to select the desired operating mode. Use the up/down
keys to select, you’ll see effect we premade(Fast to Slow). Press Enter to confirm.
Sound. This function allows you to activate sound control function from 00-99, Use the
up/down keys to select desired setting Press Enter to confirm the setting
DMX Mode, Press Enter to select the desired operating mode. Use the up/down keys
to select. Press Enter to confirm Mode A( 9 Channels) / Mode P( 24 Channels)/ Mode
H (60 Channels).
Dimmer Mode,. This function allows you to select dimmer mode, Use the up/down keys
to select desired setting Press Enter to confirm the setting
DMX Profile
LED Stage Bar1251 RGBWA with dot matrix Mode A ( 9 Channel)
DMX Channel
Function
Description
Value
1
Dimmer
Dimmer Off to Full
0-255
2
Strobe
Strobe Fast to Slow
0-255
3
Built-in programs
Built-in effect
0-255
4
Speed
Speed control
0-255
5
LED Color
Red LED intensity
0-255
6
LED Color
Green LED intensity
0-255
7
LED Color
Blue LED intensity
0-255
8
LED Color
White LED intensity
0-255
9
LED Color
Amber LED intensity
0-255
LED Stage Bar1251 RGBWA with dot matrix Mode P (24 Channel)
DMX Channel
Function
Description
Value
1
Dimmer
Dimmer Off to Full
0-255
2
Strobe
Strobe Fast to Slow
0-255
3
Built-in programs
Built-in effect
0-255

6
4
Speed
Speed control
0-255
5
LED Color
Red LED intensity (zone 1)
0-255
6
LED Color
Green LED intensity (zone 1)
0-255
7
LED Color
Blue LED intensity (zone 1)
0-255
8
LED Color
White LED intensity (zone 1)
0-255
9
LED Color
Amber LED intensity (zone 1)
0-255
10
LED Color
Red LED intensity (zone 2)
0-255
11
LED Color
Green LED intensity (zone 2)
0-255
12
LED Color
Blue LED intensity (zone 2)
0-255
13
LED Color
White LED intensity(zone 2)
0-255
14
LED Color
Amber LED intensity (zone 2)
0-255
15
LED Color
Red LED intensity (zone 3)
0-255
16
LED Color
Green LED intensity (zone 3)
0-255
17
LED Color
Blue LED intensity (zone 3)
0-255
18
LED Color
White LED intensity (zone 3)
0-255
19
LED Color
Amber LED intensity (zone 3)
0-255
20
LED Color
Red LED intensity (zone 4)
0-255
21
LED Color
Green LED intensity (zone 4)
0-255
22
LED Color
Blue LED intensity (zone 4)
0-255
23
LED Color
White LED intensity (zone 4)
0-255
24
LED Color
Amber LED intensity (zone 4)
0-255
LED Stage Bar1251 RGBWA with dot matrix Mode H (60 Channel)
DMX Channel
Function
Description
Value
1
LED Color
Red LED intensity(LED 1)
0-255
2
LED Color
Green LED intensity(LED 1)
0-255
3
LED Color
Blue LED intensity(LED 1)
0-255
4
LED Color
White LED intensity(LED 1)
0-255
5
LED Color
Amber LED intensity(LED 1)
0-255
6
LED Color
Red LED intensity(LED 2)
0-255
7
LED Color
Green LED intensity(LED 2)
0-255
8
LED Color
Blue LED intensity(LED 2)
0-255
9
LED Color
White LED intensity(LED 2)
0-255
10
LED Color
Amber LED intensity(LED 2)
0-255

7
Channel 11-Channel 55 are LED3-11 pixel control as LED 1 and 12 listed
56
LED Color
Red LED intensity(LED 12)
0-255
57
LED Color
Green LED intensity(LED 12)
0-255
58
LED Color
Blue LED intensity(LED 12)
0-255
59
LED Color
White LED intensity(LED 12)
0-255
60
LED Color
Amber LED intensity(LED 12)
0-255
Drawing Size:
Cleaning
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses must be carried out
periodically to optimize light output.
1. Use normal glass cleaner and a soft cloth to wipe off the outside casing.
2. Clean the external optics with glass cleaner and a soft cloth every 20 days.
3. Always be sure to dry all parts completely before plugging the unit back in.
Cleaning frequency depends on the environment in which the unit operates (i.e. smoke, fog residue, dust,
dew).
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are wired correctly (pin 3 is “hot”; on
Some other DMX devices pin 5 may be “hot”). Also, check that all cables are connected to the right
connectors; It does matter which way the inputs and outputs are connected.
Specifications
Model: LED Stage Bar1251 RGBWA with dot matrix
Working Position:Any safe working position
Voltage: 90-250V / 50~60Hz
Power: 300W
LED Lamp : Tianxin high power LEDs;
5in1(RGBWA) 25W*12pcs
DMX Channel: 9/24/60 channel mode
Waterproof rate: IP20
RGBWA color mixing and dot matrix function , Every color can be controlled alone
Product size : 1084*125*138mm
Gross Weight: 11 Kgs
Warranty: 1 Year
Note: All information is subject to change without prior notice.
