VelociRAX Light Bar User manual

Rack'em Fast
VelociRAX Light Instruction Manual
Latest instructions and videos: https://velocirax.com/assembly
PACKAGE CONTENTS
(2) Double Sided Foam Tape
(8-10) Self Tapping Screws
(1) Wired Light Assembly
(1) Wire Clamp
(1) 4 Pin to 7 Pin Adaptor
(1) Wire Shield
Integrated Lights

Latest instructions and videos: https://velocirax.com/assembly
ASSEMBLY INSTRUCTIONS
● Wrench or socket
13, 18 & 19 mm
TOOLS REQUIRED FOR ASSEMBLY
Alternate
● 1 X
1. Test Light Assembly
2. Peel and Stick Foam Tape to Both Light Assemblies
● Drill with #2 Phillips Tip Screwdriver
Plug into hitch electrical outlet receiver
on the vehicle and confirm functionality
(Left/Right Signal, Brake, Tail lights)
3. Peel and Stick Both Lights Assemblies to the Bottom of the Lower Bar
● Safety Glasses
Drivers side – short wire Passenger side – long wire
Note: Tape will cover the full surface including the screw holes on the light assembly
Side View
Tape
Tape
Light Assembly
Lower Bar
Place both lights ¼ - ⅜ inch
from both sides of the black
support structure on the post.
Bottom View
● 5 mm Allen

ASSEMBLY INSTRUCTIONS - CONTINUED
5. Screw Lights to Lower Bar with Self Tapping Screws
4. Mount Wire Shield
Over tightening can
deform crossbar
Wear eye protection
● Drill with #2 Phillips Tip
Screwdriver
● Safety Glasses
A. Remove 2 nuts securing the lower bar
(Do not remove the lower bar)
19 & 18 mm
B. Route wires as shown above
C. Ensure wire grommet and wire
shield is in place and no wires
are pinched
19 & 18 mm (7 ft-lbs)
C. Wire
Shield
C. Wire Grommet
After Installed (View from Vehicle)
B.
A&D.
Wire Shield
Wire Grommet
(Screw count varies based on light bar size)
D. Re-tighten both bolts to secure lower bar and wire shield making sure wires
are not pinched

WARRANTY INFORMATION
2 Year Limited Warranty for defects in materials and/or workmanship for
the original retail purchaser. This warranty does not cover normal wear
and tear, scratches, accidents, misuse, or overloading.
CONTACT INFORMATION
VELOCIRAX
Email: [email protected]
Web address: www.VelociRAX.com
Phone: [phone]
Secure wire loosely to ensure rack can still be placed into garage mode
Take care when moving the rack to ensure the wire doesn’t get damaged
TIPS
Wire routing below the stop pin will result in wire damage
when hinging the rack
6. Route Wire As Desired
Secure wire with cable
clamp
Do NOT route wire under stop pin. This will
result in wire damage when hinging the rack.
ASSEMBLY INSTRUCTIONS - CONTINUED
Wire
Remove nut, insert cable into clamp,
slide cable clamp on bolt, replace
washer and nut
13 mm 5 mm
(6 ft-lbs)
