Vemmio SS-100 User manual

WWW.VEMMIO.COM
smoke
sensor
MODEL: SS-100
V1.0
INTRODUCTION
Thank you for choosing Vemmio. We welcome you in our cus-
tomer society.
Smoke Sensor is a smart photoelectric smoke detector with
ultra-low power wireless Z-Wave network technology design. It
is a warning device that detects presence of smoke and smoke
particles in real-time faster than any ionizing smoke alarms.
Once the smoke is detected, the 85 dB siren goes off and after
the system has been configured, e-mails, sms or push notifica-
tions are sent to the users. Standardized, future-proof Z-Wave
wireless technology guarantees reliable operation of your
Smoke Sensor over the long term. The sensor works with any
Z-Wave-certified controller.
PACKAGE CONTENTS:
• user manual
• sensor
• pin key
• 2x screws.
KEY FEATU RE S
Sensitive photoelectric smoke sensor to notify you about
Built-in siren 85 dB
Very fast smoke detection
Low-battery use
Smart and stylish design
Maintenance free .
SPECIFICATION
Wireless standard Z-Wave Plus
Frequency 868.40 MHz
Network range 70 m line of sight
Operating temperature -10°C ~ 50°C
Sound alarm 85 dB
Battery CR 123A 3V
Battery 1 year, low power indication
BATTE RY INSTALL ATIO N
When the device reports the low battery message, the user
should replace the battery to new one. The battery type is
CR123A, 3V.
To open the mounting base please follow the below steps:
1. Turn right to dismantle the mounting base of the device.
2. Replace the battery ( pay attention to polarity ). At this stage
Warm Up will commence (green, red and yellow lights flash-
ing in turns for 90 sec.).
3. Turn left to install the mounting base of the device.
INSTALLATION
The Z-Wave button, operated with the pin key, can add, remove,
reset or associate the sensor to Z-Wave network.
ADDING THE DEVICE INTO THE Z-WAVE NETWORK
FIRST INCLUSION
Bring the Smoke Sensor within direct range of your controller.
Remove the mounting base ( see Battery Installation for details)
and remove the plastic pull-tab from the battery slot of the de-
vice. At this stage Preheating will commence (green, red and yel-
low lights flashing in turns for 90 sec.). Follow the instructions
for your Z-Wave certified controller to enter inclusion mode.
When prompted by the controller, using pin key, press Z-Wave
button 3 times within 1.5 sec. The sensor will be successfully in-
cluded to Z-Wave network once the green led is off. The sensor
should appear on your controller’s device list.
Please note: first inclusion may vary depending on your gate-
way - please see gateway manual for details.
INCLUSION*
Bring the Smoke Sensor within direct range of your controller.
Follow the instructions for your Z-Wave certified controller to
enter inclusion mode. When prompted by the controller, using
pin key, press Z-Wave button 3 times within 1.5 sec. (green LED
will flash 3 times within 1 second). The sensor will be success-
fully included to Z-Wave network once the green led is off. The
sensor should appear on your controller’s device list.
*Please note: Always exclude a Z-wave product before trying
to add it to a Z-Wave network.
DEVICE TEST
Once inclusion process is successful, press Test button to test if
the device works correctly.
EXCLUSION
Bring the Smoke Sensor within direct range of your controller.
Follow the instructions for your Z-Wave certified controller to
enter exclusion mode. When prompted by the controller, using
pin key, press the Z-wave button quickly 3 times in a row. Once
the LED indicator flashes 6 times and turns off, the exclusion
process is successful. The sensor should disappear from your
controller’s device list.
If the first attempt is unsuccessful, please repeat the process
following all steps carefully.
ASSOCIATION
Have Z-Wave Controller enter association mode.
Pressing tamper key three times within 1.5 seconds will enter
association mode.
Group
ID
Maxi-
mum
Nodes
Description
1 1 Association group 1: Lifeline association
group include command classes:
• BATTERY_REPORT
• NOTIFICATION_REPORT
• BINARY_REPORT
• DEVICE RESET LOCALLY NOTIFICATION
2 5 Association group 2: Root Device
group(Binary Sensor) Binary Sensor Com-
mand Class: Compatible with 300 series
1-Binary Sensor reports status of smoke or
no smoke via Lifeline. 2-When the sensor
detects status change between smoke and
no smoke, the device will be triggered.
3 5 Association group 3: Root Device
group(Notification) 1-Notification reports
reports status of detect smoke or no smoke
via Lifeline. 2-When the sensor detects
status change between smoke and no smoke,
the device will be triggered.
FACTORY RESET
Long press the Z-Wave button while installing batteries in
Smoke Sensor. The device will be reset locally and notification
will be transmitted.
Please note: All previously recorded activity and custom set-
tings will be erased from the device’s memory.
PHYSICAL INSTALLATION
Choosing a Suitable Location
a. The sensor should be installed on the ceiling preferably in the
center (keep 30 cm distance from lighting and decorations
and minimum 15 distance from walls and corners). With slop-
ing ceiling – install the sensor 90 cm away from ceiling top.
b. Please avoid installation in bathrooms and other very humid
places, dusty or greasy areas, or very airy places e.g. near air
conditioning or fans.
c. Keep the sensor clean and do not let the dust to accumulate. It
is recommended to clean the Smoke Sensor every 6 months.
MOUNTING
Pay attention! Include the Smoke Sensor to your Z-Wave net-
work before mounting it.
Please remove the protective layer from the installation base.
Following Battery Installation section remove the installation
base and, using the provided screws, attach the installation
bracket to the ceiling.
Over the Air Firmware Update
The device supports the Z-Wave firmware update via OTA. Let
the controller into the firmware update mode, and then press
the Z-Wave button once to start the update. After completing
the firmware download, LED will start flashing every 0.5 sec-
ond. During this time, please don’t remove the battery, other-
wise it will cause the firmware failure, and the device will stop
functioning. After LED stops flashing, it is recommended that
user powers up the device. Caution: After battery removal,
please wait about 30 seconds, and then re-install the battery.
Supported Command Classes:
COMMAND_CLASS_ASSOCIATION_GRP_INFO
COMMAND_CLASS_ASSOCIATION
COMMAND_CLASS_BATTERY
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_MANUFACTURER_SPECIFIC
COMMAND_CLASS_NOTIFICATION
COMMAND_CLASS_POWERLEVEL
COMMAND_CLASS_SENSOR_BINARY
COMMAND_CLASS_VERSION
COMMAND_CLASS_WAKE_UP
COMMAND_CLASS_ZWAVEPLUS_INFO
LED INDICATION
Status LED status Alarm sound
Normal Red LED flash every
53 seconds
No sound
Test mode Red LED flash quickly Sound 3x beep
Alarm Red LED flash quickly Sound 3x beep
Silence mode Red LED flash once
every 10 seconds
No sound
Low battery Red LED flash once
every 53 seconds
Sound 1 x beep every
53 seconds
Fault Red LED flash twice
every 53 seconds
Sound 2 x beep every
53 seconds
WARRANTY
This Limited Warranty applies to physical goods, and only for
physical goods, purchased from Vemmio (the “Physical Goods”).
This Limited Warranty of Vemmio, applies to products manufac-
tured and distributed by Vemmio.
PRODUCTS COVERED AND DURATION OF WARRANTY
Warranty Period: 12 months for business customer and 24
months for individual customer from the date of purchase. The
product purchased shall be free from defects in material and
workmanship from the date of purchase. This Limited Warranty
covers any defects in material or workmanship under normal
use during the Warranty Period.
PRODUCTION STATUS
Each product is manufactured from new parts.
TERMS OF THE WARRANTY
Vemmio warrants that the product you have purchased from
Vemmio or a Vemmio’s authorized reseller is free from defects
in materials and workmanship under normal use during the
warranty period. The warranty period begins on the day of pur-
chase. The warranty extends only to the original purchaser. It
is not transferable to anyone who subsequently purchases the
product from the original purchaser.
During the Warranty Period, Vemmio will repair or replace (at
the sole discretion of Vemmio), at no charge, products or parts
of a product that proves defective. Once the defected product,
during the guarantee period, is returned, it will be repaired or
replaced no later than within 30 days. The warranty period is
extended by the amount of days it has taken to repair or replace
the product. All used elements changed under the guarantee
become the property of Vemmio. The warranty period for re-
placed elements expires on the same date as the original war-
ranty period for the product. There is a possibility that it will not
be feasible to repair or replace the product ( for example when
the product is no longer a part of Vemmio’s offer). Should this
happen, Vemmio will repair/replace the product with parts/
product of similar technical characteristics. Such procedure
will result in fulfilling Vemmio’s warranty obligation against the
customer. It is not possible to have money returned by Vemmio
for the purchased product. Warranty claim rated by Vemmio as
unwarranted will be charged for handling and servicing costs.
Vemmio may reject a warranty claim if:
• the product has not been operated according to its intended
purpose and the user manual
• the returned product is incomplete
• the cause of insufficient operation is other than a material or
production defect
• warranty date has expired or if the customer can not provide
proof of purchase.
The Limited Warranty extends only to products purchased from
Vemmio or a Vemmio’s authorized reseller. The Limited War-
ranty does not extend to any product that has been damaged or
rendered defective (a) as a result of accident, misuse or abuse;
(b) as a result of an act of God; (c) by operation outside the us-
age parameters stated in the user manual; (d) by the use of parts
not manufactured or sold by Vemmio (e) by modification of the
product; (f) as a result of war or terrorist attack; or (g) as a result
of service by anyone other than Vemmio or a Vemmio’s author-
ized service center.

WWW.VEMMIO.COM
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY,
VEMMIO MAKES NO OTHER WARRANTIES EXPRESSED
OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OR
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR-
POSE. VEMMIO EXPRESSLY DISCLAIMS ALL WARRANTIES
NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED
WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMIT-
ED TO THE TERMS OF THIS EXPRESS LIMITED WARRANTY.
LIMITED WARRANTY STATEMENT
VEMMIO is not liable for any damages caused by the product
or by the failure of the product to perform, including any lost
profits, lost savings, incidental damages, or consequential dam-
ages. VEMMIO is not liable for any claim made by a third party
or made by you for a third party.
This limitation applies whether damages are sought, or a claim
made, under this warranty or as a tort claim (including negli-
gence and strict product liability), a contract claim, or any other
claim. This limitation can not be waived or amended by any per-
son. This limitation of liability will be effective even if VEMMIO
or an authorized VEMMIO’S representative has been advised
by you of the possibility of any such damages.
HOW TO OBTAIN WARRANTY SERVICE?
Please contact us first through [e-mail] for ad-
vice because we are very often able to resolve issues/problems
without the need for warranty claim.
For a defect during the warranty period, you will need a proof of
purchase. Contact your place of purchase or a Vemmio’s author-
ized service center. Return the defective item, freight and insur-
ance prepaid, in the original packaging to your place of purchase.
Vemmio is not responsible for any loss or damages incurred in
shipping. A Vemmio Failure Analysis/Test Engineer or a Vem-
mio’s authorized reseller must validate all warranty claims.
WHAT IS NOT COVERED BY THIS WARRANTY?
Product purchased from anyone other than Vemmio or a Vem-
mio’s authorized reseller.
Routine cleaning or normal cosmetic and mechanical wear.
Damage from misuse, abuse or neglect including ingress of wa-
ter, dust or damage from dropping.
Damage from use outside the product’s usage or storage pa-
rameters.
Damage from use of parts not manufactured or sold by Vemmio.
Damage from modification or incorporation into other products.
Damage from repair or replacement of warranted parts by a
service provider other than a Vemmio’s authorized service
provider.
Damage from failure to perform preventative maintenance
as imposed by the application environment (such as recurrent
cleaning in dusty surroundings).
DECLARATION OF CONFORMITY
The manufacturer Vemmio Sp. z o.o. declares under sole respon-
sibility that the product:
Marketing model: Smoke Sensor
Regulatory model: SS-100
Brand name: Vemmio
is in conformity with the Low Voltage Directive 2009/95/EC,
EMC Directive 2004/108/EC, R&TTE Directive 1995/5/EC and
carries the CE marking accordingly.
The following harmonized standards were applied:
R&TTE (1995/5/EC)
EN 300 220-1: V2.4.1
EN 300 220-2: V2.4.1
EMC (2004/108/EC)
EN 301 481-1: V1.9.2
EN 301 489-3: V1.6.1
LVD (2006/95/EC)
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011
Changes of modification not expressly approved by Vemmio Sp.
z o.o. for compliance could void the user’s authority to operate
the equipment.
FCC INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly ap-
proved by the party responsible for compliance could void the
user’s authority to operate this equipment.
This transmitter must not be co-located or operating in conjunc-
tion with any other antenna or transmitter.
IN ACCORDANCE WITH ROHS 2011/65/EU
WARNING
Do not dispose of electrical appliances as unsorted municipal
waste, use separate collection facilities. Contact your local gov-
ernment for information regarding the collection systems avail-
able. If electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the groundwater and get
into the food chain, damaging your health and well-being.
When replacing old appliances with new once, the retailer is
legally obligated to take back your old appliance for disposal at
least for free of charge.
Please note: Vemmio provides this publication “as is” without
warranty of any kind, either express or implied, including, but
not limited to implied warranties of merchantability or fitness
for a particular purpose. The published information in the man-
ual is subject to change without notice. Vemmio reserves the
right to make changes in the product design, layout, and driver
revisions without notification to its users. This version of the
installation guide supersedes all previous versions.
Although Vemmio has attempted to ensure the accuracy of the
content of this manual, it is possible that this document may
contain technical inaccuracies, typographical, or other errors.
Vemmio assumes no liability for any error in this publication,
and for possible damages, whether direct, indirect, incidental,
and consequential or otherwise, that may result from such er-
ror, including, but not limited to loss of data or profits.
