venalsol 50W User manual

Remember
We appreciate your purchase!
Please read the instruction manual before installation and keep it handy for future reference.
Aplications
High purity light cast aluminum heatsink, high brightness, Nichia SMD chip, with a Mean Well driver. Design of the PCB LED for
medium and high height in industry: production, diaphanous warehouses with shelves at half height, workshops, gas stations,
shopping centers, markets, highway tolls and similar applications.
Troubleshooting
Problem Possible cause Solutions
LEDs stop working
The powerline is improperly
connected Connect the power cable
The power plug is loose Firming plug the power in
The LED driver malfunctions Replace with a new driver
The LED chip is damaged It can be repaired only by Venalsol.
LEDs flash on and off
The output of the driver is
abnormal Replace with a new driver
The LED chip breaks down It can be repaired only by Venalsol.
1
Warranty
Venalsol guarantees its products, within the general conditions of supply, provided it is a manufacturing or material defect for a
period of five years from the date of purchase. The guarantee consists in the repair / replacement of the parts or assemblies that
are considered defective. Therefore, it will not apply to items that show damage as a result of not following the instructions for
use correctly, or when the installation has been carried out by non-specialized personnel. Likewise, the damages caused by
improper use of the device and faults produced during transport are excluded.
To make a warranty claim, you must notify your seller in writing, provide a purchase invoice and comply with the other warranty
requirements. It will always be necessary to return the damaged product with its original identification plate of Venalsol Smart
Light and its serial number. Transportation costs are excluded.
1. The decision as to whether the product is defective will be taken by Venalsol, who will check the malfunction of the
product. If Venalsol verifies that the product is defective, it will decide if it has to be repaired or replaced by a new
one. Venalsol reserves the right to use new or repaired products in the process of repair or replacement of the
product under warranty. The product that has been repaired or replaced will be guaranteed during the original
warranty period remaining. The cost of personnel and the cost of the machinery necessary for the replacement is
excluded. The total respons
ibility of Venalsol regarding the defective product will always be limited to the money paid
by the buyer for that product originally.
2. In case of request of a product in good condition, prior to the shipment of the defective product, in order to facilitate
the substitution work, Venalsol may accept to supply it and this will be billed. This invoice will be paid, if applicable,
once the allegedly damaged product is received and verified. If the warranty requirements are not met, or the
damaged material is not received, 60 days after the previous replacement, the invoice will be charged.
The guarantee will not cover the following circumstances:
1. Damages caused by force majeure such as wars, riots, sabotages, cyclones, earthquakes, floods, explosions, fires, etc.
2. Damages caused by improper use during the delivery period, defects caused by its misuse, wrong treatment or destruction of
the machinery.
3. Disassembly, modification or improper maintenance of repaired products without the authorization of the supplier.
4. Damage caused by the buyer or installer using low quality wiring or other components not compatible with the product.
5. This warranty is not valid if the product is used for different purposes for which it is originally designed.
Read the instructions carefully before you start using the product.
50W - 100W -150W - 200W - 240W
Venalsol Smart Light S.L.
C/ Garbí nº15. - Polígono Industrial Palma de Gandía -46724 - Palma de Gandía
Valencia (España) -Customer service: [phone] [e-mail]
< PRODUCT DATA SHEET
www.venalsol.com
All rights reserved - Copyright © 2017
High bay Linear LED
Instructions
Dimmable 1-10Vcc

Connection precautions.
1. Disconnect the power supply before installation or maintenance of the light.
2. It is strictly mandatory to connect the earth cable (Yellow / Green) with the ground connection of the installation.
3. Do not touch the power source when the lamp is in operation.
4. To avoid damage, electric shock or fire, do not disassemble or replace the lamp (PCB CHIP LED).
5. To avoid damage, falls, electric shocks or fires, please do not modify or replace the original accessories with others that are not,
without consulting and being authorized by Venalsol beforehand.
6. Only qualified personnel can perform the replacement or installation of the luminaire and make sure that it follows the
instructions in the manual. If the installation is not carried out properly, it can cause falls, electric shocks, fires or other damages.
7. Disconnect the power supply if smoke or odor comes out, as this could result in a fire or electric shock.
8. Consult qualified personnel for inspection and maintenance of the lamp
9. If the wiring of the luminaire itself is damaged, it can only be replaced by Venalsol.
Applicable regulations
It has passed the tests and verifications necessary to obtain the CE Marking. This product complies with
the application standards on Low Voltage (LVD) 2014/35 / EU: EN60598-1: 2015, EN60598-2-24: 2013,
EN60598-2-1: 1989, EN62031: 2008, EN62471: 2008, EN62493: 2010 and Electromagnetic Compatibility
(EMC) 2014/30 / EU: EN61000-3-2: 2014, EN61000-3-3: 2013, EN61547: 2009, EN55015: 2013
This symbol indicates that the product at the end of its useful life should be removed separately from
other waste, since it is identified as an appliance for electrical use or domestic appliance according to
Royal Decree 208/2005. Therefore, at the end of the use, you must take charge of delivering the
product to a selective collection center or to an authorized waste manager. Venalsol is registered in the
National Registry of Electrical and Electronic Devices with registration number 3493 and is attached to a
Waste Management System for Electrical and Electronic Devices for products with the category of
"lighting devices".
LED Venalsol luminaires are respectful with the environment. They do not contain mercury and the
electronic components used comply with the provisions of the RoHS regulations transposing Royal
Decree 208/2005.
Tecnical parameters
Product specifications 50W 100W 150W 200W 240W
Input voltage AC100-277V 50/60Hz Clase I ( Needs grounding )
CRI Ra80
Beam angle 30ºX70º, 50ºX90º, 120º, 40ºX120º, 90º
Classification IP IP65
Dimensions 280x137x102mm 486x137x102 mm 718x137x102mm 948x137x102mm 1178x274x102mm
Luminaire net weight 1.9 ±0.3kg 3.4 ±0.3kg 4.7 ±0.3kg 5.7 ±0.3kg 6.9 ±0.3kg
Power factor >0.93
Useful life ≥50000Hrs (LM70@35°C)
Operating temperature -30- +50°C
Operating humidity 15%~90%RH
Storage temperature -40- +70°C
Installation instructions
A. Typology, connection and installation of the hanging cable
A
B
C
50W 137 280 102
100W 137 486 102
150W
137
718
102
200W
137
948
102
240W
274
1178
102
Measures expressed in millimeters
B. Adjustable surface installation
Dimensions
2. Pull on
1. Press
1. Insert
1. Enter tie
Ajustable range 40 - 544mm
Brown
Yellow/Green
Blue
C
A
B
Brown
Blue
IMPORTANT – DIM CONNECTION 1-10Vcc
IT IS RECOMENDED TO INSULATE AND ATTACH THE TERMINATIONS OF THIS
CONNECTION IF REGULATION IS NOT USED
