VENETA 4 Sided L Frame Outside Mount User manual

Scan the QR code with
your smartphone to
follow along with video
instructions.
Shutters Installation Instructions
4 Sided L Frame Outside Mount
CONGRATULATIONS on purchasing the finest shutters
in the market. You can take pride that your purchase
will enhance the function and beauty of your home.
IMPORTANT: Do not mix panels or frames from other windows. Install one shutter at a time.
Getting Started
Step 1: Assemble Frame
Step 2: Level the Frame
Step 3: Secure the Frame
Step 4: Attach the Panels
Step 5: Add the Finishing Touch
Installation Overview
Tools needed for installing your shutter:
Pencil Level Box Knife Rubber mallet Drill Screwdriver
Getting Started
Remove the shutter from the package. Do not discard any of the packaging material until the
shutter operates to your satisfaction. Check the diagram below to make sure you have the
necessary parts.
Hoffmann
Keys
Hinge
Pins
Hinge
Screws
(for Deadlock)
Frame
Screws
TM
Installation Video
Hinge Pins
Shutter
Panel
Shutter
Panel
L
Frame
Frame Insert
Position the assembled frame evenly
around the window opening and secure
with a screw into the upper left frame
ONLY.
1.
Once the left side is secured, level the
frame on the window and secure with a
screw into the upper right frame. Shutter
will be fully secured in later steps.
1.
Set all frames on a flat surface. Position each side of the frame and
line up the Hoffmann Key slot. Insert the Hoffmann Key into each
slot at the back of the frame. Use a rubber mallet if necessary.
The Hoffmann Key has a rounded side and a flat side. The
rounded side should be inserted in slot first.
Remove frame inserts and place them away from the installation area.
Carefully remove panels and frames from the packaging.
All frame parts are labeled (top, bottom, left, and right).
Step 2 – Level the Frame
Step 3 – Secure the Frame
Step 1 – Assemble the Frame
1.
2.
3.
!

Lifetime Limited Warranty
All Veneta™shutters have a lifetime limited warranty and will be free from defects in
materials or workmanship for as long as the original retail purchaser owns the shutters,
provided that such products were properly installed in residential dwelling; and such
products were made or assembled exclusively from original materials and components.
Any resale or other transfer of the product and/or materials voids this warranty.
For a complete copy of this warranty, please visit www.venetawindowfashions.com, or
contact customer service by email or phone.
Customer Service
1-855-558-1222
Email: [email protected]
Website: www.venetawindowfashions.com
Adjust the Tension System
Veneta™shutters are made to resist most staining substances and may be easily cleaned
by simply wiping down or dusting. For any stains or marks, a soapy water solution may be
used along with a damp cloth. Open the louvers and panels, and wipe down the front and
back of the shutters. You may also remove the panels from the frame and take down to
clean.
Maintain Your Shutter
If over a period of time the louvers on your shutters should
loosen or not function properly, a built-in tension system can be
adjusted. Simply open the panels fully and find the tension
adjuster screw hole on the side of each panel. Use a screwdriver
to gently turn the screw on each side of the panel to your desired
resistance level. Repeat process for other panel(s) if necessary.
Tension
Adjuster
Version 37103-64100
IMPORTANT: Check shutter operation and alignment before installing frame inserts, as
frame inserts can NOT be removed once they are snapped into place.
Match each frame insert with the corresponding side of the frame: Left to Left, Top to Top,
Right to Right, Bottom to Bottom.
Snap inserts into place. This will cover screws and provide a finished look.
Step 5 – Add the Finishing Touch
A rubber mallet can be used to help install frame inserts.
!
Step 4 – Attach the Panels
Open and close panels to make sure
panels operate properly. Secure the
frame with screws through the rest of the holes.
5.
Fasten the deadlock screw for all hinges.
6.
Please check the gap between panel and
frame at the top and bottom. The gap should
be even; if not, then shift frame left to right
until the gap is even.
3.
Place the left shutter panel in the frame,
align the hinges, and insert the hinge pin.
Repeat for the right shutter panel.
1.
If panel hinges are not aligned with
frame hinges properly, then frame hinges
can be adjusted.
2.
Once even, secure a screw at the bottom
of the left frame and right frame.
4.
!
