Vento VTX Series User manual
OPERATIONS MANUAL-VTX8A/VTX10A/VTX12A/VTX15A
Professional ABS Molded Loudspeaker
Introduction:
Congratulations on your purchase of the amplied loudspeaker; this speaker includes the very latest technology in lightweight ABS design. The
trapezoidal design was used for a more precise and accurate sound and will add increased sound denition on vocal frequencies. This state of the art
speaker will give you years of enjoyment.
Features for Active Series:
• Steel basket woofer
• Bluetooth stereo pairing (only for VTX12A and VTX15A)
• Stand mounting socket
• Auxiliary Line Input
• USB HOST/SD MMC MP3
• Metal Grill
• High Temperature Voice coil
• Rubber Feet
• Bluetooth Function
• Folder Function
• FM Function
• Remote Control
• EQ
• High wattage powered amplier
• NFC Pairing Function
Specication:
VTX8A
2-WAY CONFIGURATION
WITH PASSIVE FILTER
3.2” TITANIUM DRIVER
8” WOOFER
CLASS AB AMPLIFIER
USB HOST/SD MP3, FM RADIO,
BLUETOOTH
SPEAKON FOR PASSIVE SPEAKER
FREQ RESP: 60HZ-20KHZ
LINE/ MIC INPUT: 1/4”JACK OR XLR
AUX IN: 6.3MM JACK
TAPE IN: RCA
2 BAND EQ
LINE OUTPUT: RCA
POWER RMS: 150 WATTS
MAX SPL: 113dB/123dB(PEAK)
POWER MAX: 600 WATTS
POWER VOLTAGE: AC120V
Cautions:
1. All operating instructions should be read before using this equipment.
2. To reduce the risk of electric shock, do not open the unit. There are NO REPLACEABLE PARTS INSIDE. Please refer servicing to a qualied service
technician.
3. Do not expose this unit to direct sunlight or to a heat source such as a radiator or stove.
4. This unit should be cleaned only with a damp cloth. Avoid solvents or other cleaning detergents.
5. When moving this equipment, it should be placed in its original carton and packaging. This will reduce the risk of damage during transit.
6. DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
7. DO NOT USE ANY SPRAY CLEANER OR LUBRICANT ON ANY CONTROLS OR SWITCHES.
8. Make sure ALL of your equipment is completely OFF and lower ALL VOLUME, LEVEL & GAIN controls before connecting the speaker.
9. ONLY LINE LEVEL SIGNALS CAN BE SENT TO YOUR SPEAKER.
Disregarding any of the above will void your warranty!!!!!
VTX15A
2-WAY CONFIGURATION
WITH ACTIVE FILTER
4.5” TITANIUM DRIVER
15” WOOFER
CLASS H AMPLIFIER,
USB HOST/SD MP3, FM RADIO,
STEREO BLUETOOTH
FREQ RESP: 45HZ-20KHZ
2 WAY MIC INPUT: XLR OR 1/4”JACK
LINE INPUT: XLR OR 1/4”JACK
2 BAND EQ(80HZ, 12KHZ)
POWER RMS: 250 WATTS
MAX SPL: 121dB/130dB(PEAK)
POWER MAX: 1000WATTS
LINE OUTPUT: XLR
POWER VOLTAGE: AC100V - AC120V
VTX10A
2-WAY CONFIGURATION
WITH PASSIVE FILTER
3.2” TITANIUM DRIVER
10” WOOFER
CLASS AB AMPLIFIER
USB HOST/SD MP3, FM RADIO,
BLUETOOTH
SPEAKON FOR PASSIVE SPEAKER
REQ RESP: 55HZ-20KHZ
LINE/ MIC INPUT: 1/4”JACK OR XLR
AUX IN: 6.3MM JACK
TAPE IN: RCA
2 BAND EQ
LINE OUTPUT: RCA
POWER RMS: 200 WATTS
MAX SPL: 116dB/125dB(PEAK)
POWER MAX: 800 WATTS
POWER VOLTAGE: AC120V
VTX12A
2-WAY CONFIGURATION
WITH ACTIVE FILTER
3.5” TITANIUM DRIVER
12” WOOFER
CLASS AB AMPLIFIER,
USB HOST/SD MP3, FM RADIO,
STEREO BLUETOOTH
SPEAKON FOR PASSIVE SPEAKER
FREQ RESP: 50HZ-20KHZ
2 WAY MIC INPUT: XLR OR 1/4”JACK
LINE INPUT: XLR OR 1/4”JACK
2 BAND EQ(80HZ, 12KHZ)
POWER RMS: 250 WATTS
MAX SPL: 121dB/130dB(PEAK)
POWER MAX: 1000 WATTS
LINE OUTPUT: XLR
POWER VOLTAGE: AC100V - AC120V
Functions for VTX8A and VTX10A:
1. USB Port
2. SD MMC Port
3. LCD Display
4. Mode Button, to switch between USB/SD or Bluetooth/FM function.
5. Start Playback or to Pause.
6. To select the playback mode: RANDOM to play songs randomly, ALL
to repeat all tracks, SINGLE to play song to song.
7. To return to the start of the previous track or to lower the Digital
Audio Player’ s volume. In folder mode, to skip to the previous page.
8. To skip to the beginning of the next track or to raise the Digital Audio
Player’ s volume. In folder mode, to skip to the next page.
9. Level controls for MIC/LINE: Adjust the volume for MIC/LINE IN.
10. Level controls for Aux in: Adjust the volume for Aux in.
11. MASTER Volume controls for adjust the general sound level.
12. LINE in: Use 1/4” Jack connector balanced or unbalanced.
13. Aux in/Tape in: Use 3.5mm jack and RCA connectors balanced or
unbalanced.
14. TREBLE: Rise or attenuate 12dB at 12KHz frequency.
15. MIC IN: Use XLR connector balanced or unbalanced.
16. Link out: Use RCA connectors balanced or unbalanced.
17. BASS: Rise or attenuate 12dB at 80Hz frequency.
18. Power Supply Input Connector: Use with power cord.
19. Power Supply Switch
20. Speakon connector
21. NFC Function: Use your mobile phone to be closed to this place under Bluetooth mode, the mobile
phone and speaker will be connected automatically.
22. Remote Control
Make sure ALL of your equipment is completely OFF and lower ALL VOLUME, LEVEL & GAIN controls before
connecting the speaker.
Connections:
1. For this unit you can connect a mixer, microphone or CD pLayer directly into your speaker. To connect a
microphone use an XLR and ¼”jack connector to connect to the LINE(12)/MIC(15) input.
2. You can LINK additional speakers using the Link out(16) connection. The amplier on your speaker will
only power this speaker. If you LINK to additional speakers those speakers must be self amplied.
3. Bluetooth Usage(4): It can be changed to bluetooth mode. When you open the mobile telephone or
computer, pls search the bluetooth device,bluetooth name should be the corresponding model no. which
named VTX8A or VTX10A. After searching with it,pls click the "connection",then you can connect to this
device.
CAUTION: If the computer need to be connected the device, it is necessary to install the bluetooth
management software. If not, it only can connect and can not transmit the audio. Also, if fail to nd it, pls
press the button for two or three seconds, then you can nd it.
4. FM RADIO Usage(4): First, it can be switched to FM mode when press the mode(M) button. And press the
button, it will search the radio station automatically. Then, press the & button to select the
radio station after searching. Finally, the MP3 will be turned o if press the mode button for two or three
seconds.
STOP
MODE EQ
0
123
456
789
1
2
3
4 5 6 7 8
910
13
16 17
18
19
20
22
14
11
21
12
15
Ir
STOP
MODE EQ
0
123
456
789
26
Functions for VTX12A and VTX15A:
1. USB Port
2. SD/MMC Port
3. LCD Display
4. Mode Button, to switch between USB/SD or FM function. The default setting of Digital Audio Player is
on, press and hold this button for 2-3 seconds to turn it o.
5. Start Playback or to Pause. Folder function: when paused in USB/SD mode, press button for two or
three seconds to select a folder, then select the audio le.
6. Recording Function: Press this button rst, then press button start to record and press button
again to stop reord. Press and hold this button for 2-3 seconds to play the recording.
Caution: Only insert USB or SD card when start recording.
7. To select the playback mode: RANDOM to play songs randomly, ALL to repeat all tracks, SINGLE to play
song to song.
8. To return to the start of the previous track or to lower the Digital Audio Player’ s volume. In folder
mode, to skip to the previous page.
9. To skip to the beginning of the next track or to raise the Digital Audio Player’ s volume. In folder mode,
to skip to the next page.
10. Bluetooth Stereo Function and Signal Selection.
11. Level control for MIC/LINE Input: Control the signal for MIC/LINE Input when using the MIC/LINE Input.
12. MIC/LINE Switch: Use the MIC position(depressed) when a microphone is connected. Use the LINE
position(disengaged) when a line level source such as an audio mixing console, audio playback device or
electronic musical instrument is connected.
13. MIC/LINE inputs: these balanced inputs accepts a standard XLR and a 1/4” Jack phone plug. A board
range of signals from microphones, audio(CH1) mixing consoles and electronic musical instruments may
be connected here. The sensitivity of these inputs are controlled by the MIC/LINE switch.
14. Repeat Control: Repeat the times of ECHO when using the microphone.
15. Echo control: Control the depth of echo.
16. LINE LEVEL: Control the output volume for LINE level inputs.
17. LINE IN: Use RCA connector balanced or unbalanced.
18. TREBLE: Raise or attenuate highs at 12dB @ 12 KHz frequency.
19. BASS: Raise or attenuate lows at 12dB @ 80Hz frequency.
20. Master: Controls the master volume of the unit. By turning the knob counter-clockwise you will be
lowering the overall volume of the speaker. By turning the control clockwise you will be increasing the
overall volume of the speaker.
21. PEAK: LED illuminates when a clipped signal is present. Reduce volume to avoid distorted sound.
22. MIX OUT: Use this connector to daisy-chain several active speakers together from the same signal source.
23. Power Supply Switch.
24. Power Supply Input Connector: Use with power cord.
25. NFC Function: Use your mobile phone to be closed to this place under Bluetooth mode, the mobile phone and speaker will be connected
automatically.
26. Remote Control
27. Speakon connector(only for VTX12A)
Warning: Make sure speaker is o and all LEVEL controls are down (counterclockwise) before every use.
Connections:
1.Connect the output from your signal source (mixing console, microphone, preamp, or other mic- or line-level source) directly to the INPUT
connector on the back of the speaker. It accepts balanced line-level signals from mixers, preampliers, CD players, tape decks, etc., and accepts
direct connections from dynamic microphones through the MIC input.
2.There is also an XLR Output connector labeled LINE OUT. This allows you to connect more than one VTX12A/VTX15A to the output of your
sound source. Simply plug an XLR cable from the Line Out connector of one speaker to the input connector of another speaker, and so on,
daisy-chaining multiple speakers.
3.Turn on your signal source. (Make sure volume is turned down) Turn on VTX12A/VTX15A. Start signal source and adjust volume controls on
the signal source and VTX12A/VTX15A speaker.
Bluetooth Pairing instructions:
1. Press and release the PAIR button on one speaker only.
2. While pairing light is ashing and the VTX12A/VTX15A name should appear on your pairing device.
3. Click on VTX12A/VTX15A name on your pairing device to complete pairing to the VTX12A/VTX15A.
Bluetooth Stereo Function Usage:
1. Press and release PAIR button on one speaker only, this VTX12A/VTX15A will be left channel.
2. Seltct VTX12A/VTX15A on your device.
3. Press and release STEREO LINK button on each speaker, both speakers should be VTX12A/VTX15A and the other VTX12A/VTX15A will be
right channel.
4. Press and hold STEREO LINK button for 3 seconds to exit the connection.
NOTE: Only exit after connected successfully.
5. LEDs ash while pairing or linking. LEDs light solid when paired or linked.
6. To reset pairing and linking, press and hold either button for 2 seconds.
NOTE: Initial pairing or linking may require 1 minute.
23
4 5 6 7 8 9
10
20
21
18
16
14
11
12
13 15
17
19
22
23
24
1
25
27
Step1: Press and release the
Pairbutton on one speaker
only.Select V TX15A on your
deviceto pair with your audio
sourcedevice.
Step2: Press and release the
Linkbutton on each speaker
tolink two VTX15A speakers.
Model VTX15P VTX12P VTX10P VTX8P
Woofer 15" 12" 10" 8"
Tweeter 4.5" titanium driver 3.5" titanium driver 3.5" titanium driver 3.2" titanium driver
Horn( dispersion angle) H90ºx V60º H90ºx V60º H90ºx V60º H90ºx V60º
RMS Power 300W 250W 200W 150W
Max Power 1200W 1000W 800W 600W
Nominal Impedance 8 ohm 8 ohm 8 ohm 8 ohm
Freq.Resp 45Hz-20KHz 50Hz-20KHz 55Hz-20KHz 60Hz-20KHz
Frequency Division Dot 3.5KHz 3.5KHz 3.5KHz 3.5KHz
Sensitivity 97dB(1W/1M) 96dB(1W/1M) 95dB(1W/1M) 93dB(1W/1M)
Connectors 2xSPK4 2xSPK4 2xSPK4 2xSPK4
PROFESSIONAL PASSIVE SYSTEM
Pro. Audio
VTX15P/VTX12P
VTX10P/VTX8P
PROFESSIONAL PASSIVE SYSTEM
Congratulations on purchasing the Professional Passive System well-designed and made by our
company, it will bring you ideal music sound. Please read this manual carefully before you get started,
it will guide you in operating and maintaining this product.
Features:
1. 2-way conguration with passive lter
2. High-eciency system with higher sound pressure level
and lower distortion
3. Extremely rugged, low-resonance plastic enclosure
4. High-eciency compression driver with titanium
dome for excellent high-frequency reproduction
5. long-throw woofer with high-power magnet
6. Signals can be looped through to drive the speaker
7. Adopt the 6dBs has no source lter to make frequency
separate.
Technical Parameters:
This manual suits for next models
8
