Vents VUE2 150 P EC Comfo A6 User manual

VUE2 150 P EC Comfo A6
AIR HANDLING UNIT WITH HEAT
AND ENERGY RECOVERY
USER’S MANUAL

2
CONTENTS
Safety Requirements 3
Introduction 5
Use 5
Delivery Set 5
Designation Key 5
Technical Data 6
Design and Operating Logic 7
Mounting and Setup 8
Connection to Power Mains 9
Unit Control 10
Technical Maintenance 15
Troubleshooting 17
Transportation and Storage Regulations 17
Manufacturer's Warranty 18
Acceptance Certicate 19
Seller's Information 19
Mounting Certicate 19
Warranty Card 20

3
VUE2 150 P ЕС Comfo
• Read this user's manual carefully prior to the operation and installation of the air handling unit with heat and energy recovery,
hereinafter the unit.
• Installation and operation of the unit shall be performed in accordance with the present user's manual as well as the provisions
of all the applicable local and national construction, electrical and technical codes and standards.
• The warnings contained in the present user's manual must be considered most seriously since they contain vital personal safety
information.
• Failure to follow the safety regulations may result in an injury or unit damage.
• Upon familiarization keep the user's manual for the entire service life of the unit.
• While transferring equipment control the user's manual must be turned over to the receiving operator.
The symbols used in the present user's manual have the following meaning:
UNIT INSTALLATION SAFETY PRECAUTIONS
ATTENTION!
RESTRICTIONS!
The unit must be disconnected from the power
supply prior to every installation or repair
operation.
The unit must be properly grounded!
The unit must not be operated outside the
temperature range stated in the user's manual
or in aggressive or explosive environments.
Do not use damaged equipment or
conductors to connect the unit to the power
mains.
While installing the unit follow the safety
regulations specic to the use of electric tools. Unpack the unit with care.
Do not change the power cord length at your
own discretion. Do not bend the power cord.
Avoid damaging the power cord.
Do not position any heating devices or other
equipment in close proximity to the unit
power cord.
ТРЕБОВАНИЯ БЕЗОПАСНОСТИ

4
UNIT OPERATION SAFETY PRECAUTIONS
Do not touch the controller or the control
panel with wet hands. Do not carry out the unit
maintenance with wet hands.
Do not wash the unit with water. Avoid
penetration of water onto the electric parts
of the unit.
Use the unit only as intended by the
manufacturer. Do not connect any clothes
dryers or other similar equipment to the unit or
the ventilation circuit.
Do not put any water containers (e.g. vases
etc.) on top of the unit.
Kg Do not sit on the unit or put any foreign objects
on top of the unit.
OFF
ON
Disconnect the unit from the power mains
prior to any technical maintenance.
Do not let children operate the unit.
Keep the power cord intact while operating
the unit. Do not put any foreign objects on
top of the power cord.
Do not store any ammable gases or highly
ammable substances in close proximity to the
unit.
Do not open the unit during its operation.
Should the unit generate any unusual sounds,
smells or smoke disconnect it from the power
mains and contact the service centre.
Check the unit for secure installation
periodically in case of prolonged operation.
Do not block the air duct while the unit is
operating.
Do not direct the air ow generated by
the unit onto combustion equipment or
burning candles.

5
VUE2 150 P ЕС Comfo
INTRODUCTION
Unit - 1 piece;
Control Panel — 1 piece;
Remote Control - 1 piece;
User's manual - 1 piece;
Shipping Box - 1 piece.
Installation type
Motor Type
Unit Type
VUE - energy recovery ventilation
VUE2 150 P ЕС L(R) Comfo
Air capacity [m3/h]
EC — electronically commutated
Number of heat exchangers
P - suspended installation
Modication type
L - Left-Hand, R - Right-Hand
This user's manual combines technical description, operation and service manual, technical data sheet and installation guidelines for
the air handling unit with heat recovery VENTS VUE2150 P EC Comfo, hereinafter the unit.
The unit is designed to ensure continuous mechanical air exchange in houses, oces, hotels, cafés, conference halls, and other utility
and public spaces as well as to recover the heat energy contained in the air extracted from the premises to warm up the ltered stream
of supply air.
The unit is not intended for organizing ventilation in swimming pools, saunas, greenhouses, summer gardens, and other spaces with
high humidity.
Due to the ability to save heating energy by means of energy recovery, the unit is an important element of energy-ecient premises.
The unit is a component part and is not designed for stand-alone operation.
It is rated for continuous operation.
Transported air must not contain any ammable or explosive mixtures, evaporation of chemicals, sticky substances, brous materials,
coarse dust, soot and oil particles or environments favourable for the formation of hazardous substances (toxic substances, dust,
pathogenic germs).
Relative humidity of transported air must not exceed 80 % at an ambient temperature of +20 °C.
THE UNIT IS NOT INTENDED FOR OPERATION BY CHILDREN OR ANY PERSONS WITH REDUCED PHYSICAL,
MENTAL OR SENSORY CAPACITIES AS WELL PERSONS LACKING THE REQUIRED TRAINING.
THE UNIT MUST BE HANDLED ONLY BY PROPERLY QUALIFIED PERSONNEL AFTER THE APPROPRIATE SAFETY
BRIEFING. THE UNIT INSTALLATION SITES MUST PREVENT ACCESS BY UNATTENDED CHILDREN.
USE
DELIVERY SET
DESIGNATION KEY

6
Fig. 1. Overall and connecting dimensions
873592
777529
Ø124 250
233 247
Type VUE2 150 P EC Comfo
Supply voltage [V] / 50/60 Hz 1 ~ 230
Total Unit power [W] 57
Total unit current [A] 0.55
Max. air ow [m3/h] 170
Rotation speed [min-1] 3730
Sound pressure level at 3 m [dB(A)] 28
Max. transported air temperature [°C] from -25 °C to +40 °C at max. humidity of 80%
Casing material Zinc aluminium
Insulation mineral wool, 20 mm
Filter (Air extract/ air supply) G4 (order code: SFK VUE2 150 P EC Comfo)
Connected air duct diameter [mm] Ø 125
Weight [kg] 18
Heat recovery eciency up to 87%
Heat exchanger type Cross ow, 2 items
Heat exchanger material Polymerized cellulose
Table 1. Main technical parameters
TECHNICAL DATA
The unit is designed for operation in an enclosed area at ambient temperatures from +5 ºС to + 40 ºС at relative humidity of up to
80%.
In order to prevent condensation on the internal walls of the units, it is necessary that the surface temperature of the casing is 2-3 °C
higher than the dew point temperature of the transported air.
The unit must be grounded.
Hazardous parts access and water ingress protection ratings:
Unit motors - IP 44;
Unit assembly connected to air ducts - IP 22.
The main overall and connecting dimensions as well as the unit view and technical parameters of the unit are given on Fig. 1 and in
Table 1.
The unit design is regularly improved, so some models may slightly dier from those ones described in this manual.

7
VUE2 150 P ЕС Comfo
The unit design and operating logic are stated on g. 2:
The warm stale air from the premises enters the unit through air ducts where it is stripped of impurities and then extracted through
the heat exchangers by means of the exhaust fan further outside via the air ducts. The cool fresh air from the outside enters the unit
through air ducts where it is stripped of impurities in the supply lter and then extracted through the heat exchangers by means of the
supply fan further into the premises via the air ducts.
The heat exchangers ensure energy exchange between the warm stale air extracted from indoors with the cool fresh air supplied
from outdoors.The air streams remain completely separated in the process. Sensible and latent heat energy recovery reduces heat energy
losses and, consequently, heating costs in the cold season and the air conditioning costs in the warm season.
The units are oered in the left-hand and right-hand variants for installation convenience.
The polymerized cellulose heat exchangers are used to recover both sensible and latent energy contained in the extract air and
transfer it to the cold intake air ow from outside.
The polymerized cellulose heat exchangers act as air moisture accumulators when the ambient air humidity is too low or as supply
air dehumidiers if the ambient humidity is high. Due to the excellent water-absorbing properties of the heat exchanger material the
unit drainage is not required. The heat exchangers are used to minimise heat energy losses and, consequently, heating costs in the cold
season.
The unit design is shown on Fig. 2.
The units are equipped with a quick-release access panel on special gaskets for easy repair and maintenance.
DESIGN AND OPERATING LOGIC
Table 2. Control panel parameters
Ambient temperature [°C] from 0 up to +40
Relative humidity [%] from 5 up to 90 (no condensation)
Cable cross section [mm2] from 0.18 to 0.35
Material ABS plastic
Dimensions (WхHхD) [mm] 86х86х14
Cable length [m] up to 10
IP rating IP30
Exhaust air Intake air
Extract air Supply air
Extract lter
Supply lter
Control unit
Heat exchanger
Supply fan
Heat exchanger
Exhaust fan
Right-hand modication
Left-hand modication
Intake air Exhaust air
Extract airSupply air
Heat exchanger
Exhaust fan
Fig. 2. Design and operating logic

8
While installing the unit ensure convenient access for subsequent maintenance and repair. The unit is attached to the ceiling by
means of two brackets secured to the ceiling with screws and dowels and four triangular yokes (the brackets and yokes are included in
the delivery package), see Fig. 3.
The wall mounting option is also available. The unit can be mounted on a wall by means of a single bracket, see Fig. 3.
Fig. 3. Unit installation
Unit installation on vertical plane
Internally threaded boss for
triangular suspension yokes
Ceiling installation of the unit
While mounting the unit check the brackets
for uniform orientation.
MOUNTING AND SETUP
The absence of a drain pan in the unit enables its installation in any position provided unhindered access for maintenance.
For best unit performance connect a straight duct section at least 1 m long on both sides of the unit.
The unit spigots must be equipped with grates or other similar devices with the maximum cell diameter of 12 mm to prevent free
access to the fans.
Safety Precautions:
The unit must be mounted on a rigid and stable substructure. Make sure that the installation structure can sustain the weight of the unit.
Reinforce the installation area with beams etc. if required. Prior to installation make sure that the ambient conditions are suitable for the unit
operation. Prior to installation make sure that the casing does not contain any foreign objects such as wrapping lm and paper.
If the abnormal noise is generated at the spiral duct connection point replace the spiral air duct with a exible one to eliminate resonance.
The same eect may be achieved by using exible connectors.
Control panel installation.
The wall-mounted control panel is installed as follows:
Use a screwdriver to carefully undo the clips in the lower part of the wall-mounted control panel through the access holes, Fig.
4.1.
Remove the back cover.
Disconnect the cable from the terminal block.
Lay the cable in the wall to the panel installation site.
Attach the panel back cover to the wall, Fig. 4.2.
Connect the cable to the terminal block.
Clip the wall-mounted panel fascia in place.

9
VUE2 150 P ЕС Comfo
Fig. 4. Control panel installation
1. 2.
The unit is designed for connection to 230 V / 50/60 Hz single-phase AC mains. The unit has a power cord with a Euro plug to connect
to a grounded IEC 60884-1 compliant socket. The power cord is pre-wired to X1 terminal block.
The external power input must be equipped with an automatic cut-out switch built into the stationary wiring to disconnect all the
power mains phases. The external switch position must ensure free access for quick power-o of the unit. The trip current must be not
less than the consumption current. The recommended automatic switch rated current is 1 A. The conductor cross section is 0.75 mm2. The
given conductor section value is tentative. In practice the conductor selection shall be based on the maximum permissible wire heating
depending on the wire type, its insulation, length and installation method (i.e. overhead, in pipes or inside the walls).
Use only copper core wires.
The unit must be properly grounded!
The unit enables the following external connection options (Х3 connector markings as shown on the label are given in round brackets
- Fig. 5):
- Automatic re extinguishing system contact («PK»);
- Humidity relay (humidistat) contact or CO2 sensor contact («H»);
- «3-point control» air damper contact («Y-N, Y-L, Y-C»).
Upon connecting the automatic re extinguishing system contact remove the jumper between the terminals Х3:1 and Х3:2 of
terminal block Х3. In this case a normally closed «dry» contact is used which opens the unit control circuit on re-triggered actuation
from the central re-ghting station cutting the unit power.
The humidistat (or СО2 sensor) is connected to the terminals Х3:3 and Х3:4 of the terminal connector Х3. The connection relies on a
normally closed «dry» contact. Once closed the unit switches to maximum speed.
The air damper actuator is connected to the terminals Х3:5, Х3:6 and Х3:7 of terminal block Х3. The same contacts can be used for
parallel connection of one more damper. Any extra contacts are connected according to the wiring connection diagram (Fig. 5).
CONNECTION TO POWER MAINS
THE POWER MAINS CONNECTION SHALL ONLY BE PERFORMED BY QUALIFIED PERSONS AFTER CAREFUL STUDY
OF THE PRESENT USER’S MANUAL.
THE UNIT IS ONLY INTENDED FOR AC MAINS SUPPLYING THE VOLTAGE COMPLIANT WITH THE TECHNICAL
PARAMETER TABLE. CHECK THE CABLE FOR CHOKING.
DO NOT SWITCH ON THE UNIT IF THE CABLE IS DAMAGED. NEVER UNPLUG THE UNIT FROM THE SOCKET WITH
WET HAND OR BY HOLDING THE ELECTRIC CABLE.
DISCONNECT THE UNIT FROM THE POWER SUPPLY PRIOR TO ANY WORK ON THE UNIT!
THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE STATED ON THE RATING PLATE.
ANY TAMPERING WITH THE INTERNAL CONNECTIONS IS PROHIBITED AND WILL VOID THE WARRANTY.

10
Fig. 5. External Connection Diagram
1
2
3
4
"2"
L
L
ÐÊ ÍY-L
Y-C
Remove the jumper on connecting the
NC contact to the re alarm system.
PK - to the re
alarm system
board
РК H
“1”
“2”
“3”
Y-C
C
L
N
Y-L
X3
1
2
3
4
5 7
6
Y-N
H - to the humidity
(or CO2) sensor Damper actuator
Y - to the external air
damper
UNIT CONTROL
Fig. 6. Control panel and remote control panel
The unit is controlled by means of the remote-mounted control panel and the remote controller (Fig. 6).
1. Unit Activation \ Deactivation.
The unit is activated \ deactivated:
from the control panel — with the On/O button ;
from the remote control panel by means of the Unit On/O button .
Unit on/o
Unit operation mode buttons (see details below)
Fan speed control buttons
Remote control panel
Remote Controller
Unit On/O
Fan speed up
Disabled
Disabled
Fan speed down
Speed 1 Speed 3
Speed 2
Scheduled operation On
On/O timer
Control panel

11
VUE2 150 P ЕС Comfo
Fig. 7. Panel display in the OFF mode
When the unit is o (Fig. 7) the control panel display indicates:
Room temperature;
Day;
Time;
Deactivated status .
2. Unit Ventilation Mode Selection
The unit fan speed can be set in several ways:
From the control panel: Press the button to increase the speed or press the button to reduce the speed cyclically (i.e. speed
1 - speed 2 - speed 3);
From the remote controller: Press the button to increase the speed or press the button to reduce the speed cyclically
(i.e. speed 1 - speed 2 - speed 3);
From the remote controller: Press the button to select speed 1, press the to select speed 2 or press the button to
select speed 3 correspondingly.
The control panel display shows the current fan speed status:
Indicator — «Speed 1» mode;
Indicator — «Speed 2» mode;
Indicator — «Speed 3» mode.
Рис. 8. Дисплей во включенном состоянии
When the unit is on (Fig. 8) the control panel display indicates:
Room temperature;
Day;
Time;
Fan speed status ;
Timer status;
• Timer operation is shown by the
indicator.
• When the timer is switched o the
indicator goes on.
3. Timer.
The timer enables automatic switching of the fans to the maximum speed with automatic reset after a set period of time in the range from
20 to 60 minutes.
The timer can be activated / deactivated:
From the control panel: to activate the timer press and hold the button and then press the button. A single press of the
button sets the timer to 20 minutes while each subsequent press increases the timer setting in 10 minute increments. The maximum timer
value is 60 minutes. To deactivate the timer press and hold the button for 3 seconds;
From the remote controller: to activate the timer for 20 minutes press the button. To deactivate the timer switch the unit o
by means of the button.
4. Heat Exchanger Freezing Protection.
If the exhaust air temperature downstream of the heat exchanger falls below +3 °C the supply fan shuts down. When the air temperature
rises above the +3 °С threshold, the unit reverts to rated operation.

12
5. Unit Parameter Setup.
CHANGING THE UNIT SETTINGS WILL DISCARD THE FACTORY SETTINGS!
FAN SPEED CAN ONLY BE ADJUSTED FROM THE CONTROL PANEL!
Fan Speed Setup Mode.
At the setup stage each of the speed settings (Speed 1, Speed 2 and Speed 3) can be attributed a specic supply and exhaust fan
performance. To enter the fan speed setup mode switch o the unit, then press and hold the button on the control panel and hold
button for 3 seconds.
Fig. 9. Fan Power Adjustment
Upon entering the setup mode the panel display screen will show
the and indicators (Fig. 9).
Set the fan speed as necessary using the and
buttons.
While the speed is being set the display screen will show the
currently selected speed , or .
To change the supply fan power press and hold the button, then press the button to increase the speed or press the
button to decrease it. Each press of the and buttons increases or reduces the supply fan power in 1 % increments. While the
button is pressed the display screen will indicate the current supply fan power (Fig. 10).
To change the exhaust fan power press the button and while holding it use the button to increase the power or the
button to decrease the power. Each press of the and buttons increases or reduces the exhaust fan power in 1 % increments. With
the button pressed the display screen will indicate the current exhaust fan power.
To exit the fan speed setup mode and save the changes press and hold the button. The remote controller cannot be used to adjust
the fan speed.
To revert to the factory settings enter the fan speed setup mode,
press the and buttons simultaneously and hold them for 3
seconds.
Factory Fan Speed Settings:
Speed 1 — 40 %
Speed 2 — 70 %
Speed 3 — 100 %
Fig. 10. Fan Power Adjustment
6. Filter Replacement Indication.
When the lters have reached the end of their service life (3,000
hours) the operating mode temperature normally shown on the
control panel display is replaced by the indicator prompting lter
replacement or cleaning (Fig. 11).

13
VUE2 150 P ЕС Comfo
Fig. 11. Filter replacement alert
In case of lter replacement alert switch o the unit
by pressing the button and disconnect it from the power
mains. Replace the lters (see the sequence given in the "Technical
Maintenance" section, page 14).
Connect the unit to the power mains and switch it on
by means of the button on the control panel or the
button on the remote control. Then press the and buttons
simultaneously to reset the motor meter. Otherwise the motor meter
will not be reset and the display will show the alert.
7. Date and Time Setup.
Switch the unit o.
To enter the date and time setup mode press and hold the , button, then press the button on the control panel.
While holding the button select the parameter for adjustment by using the and buttons. The parameter being
adjusted is blinking.
The date and time parameters are ordered as follows:
1. Minutes;
2. Hours;
3. Day;
4. Date;
5. Month;
6. Year.
Set the necessary parameter value on the control panel using the and buttons.
To exit the date and time setup mode press the button.
8. Scheduled Operation Mode.
To activate the scheduled operation mode press and hold the button, and then press the button on the control panel.
The scheduled operation mode is conrmed by the indicator glowing on the display screen.
To deactivate the scheduled operation mode press and hold the button, and then press the button on the control
panel.
The scheduled operation mode can be activated or deactivated using the button on the remote controller.
The timer settings will always prevail over the scheduled operation parameters.
9. Scheduled Operation Setup.
There are four entries available for each day which may contain the time for unit switching to a specic fan speed.
To access the scheduled operation settings switch o the unit using the button on the control panel or the button
on the remote controller.
Press and hold the button on the control panel, then press the button.

14
Fig. 12. Scheduled operation setup mode indicators
Day
Time
Entry
number
Fan speed
To select the scheduled operation setup mode parameters hold the button and use the and buttons to make the
selection as necessary.
Use the and buttons to set the parameter values.
Scheduled operation setup mode parameters (Fig. 12):
• Entry number — there are four entries for each day.
• Day — day setting.
• Fan speed — fan speed setting for the current entry.
• Time — time setting for the current entry.
To copy the entries to the following day press and hold the button, then press . Please note that copying entries from
Sunday onto Monday is not possible.
To exit the scheduled operation setup mode press the button on the control panel or the button on the remote
control.
A sample schedule programming sequence is given in Table 3.
Day
Entry number
1 2 3 4
Start
time Mode Start time Mode Start time Mode Start time Mode
Mo. 07:00 Speed
208:00 Speed 117:00 Speed 222:00 Speed 1
Tu. 07:00 Speed
208:00 Speed 117:00 Speed 222:00 Speed 1
We. 07:00 Speed
208:00 Speed 117:00 Speed 222:00 Speed 1
Th. 07:00 Speed
208:00 Speed 117:00 Speed 222:00 Speed 1
Fr. 07:00 Speed
208:00 Speed 117:00 Speed 222:00 Speed 1
Sa. 10:00 Speed
212:00 Speed 217:00 Speed 223:00 Speed 1
Su. 10:00 Speed
212:00 Speed 217:00 Speed 223:00 Speed 1
Table 3 . Sample programming sequence

15
VUE2 150 P ЕС Comfo
10. Alarms.
In case of an emergency the unit switches o while the alarms are displayed on the control panel display screen, Fig. 13. The list of
possible alarms is given in Table. 4.
Fig. 13. Alarm Indication
Freezing protection
sensor breakout
Freeze protection sensor
triggering
Table 4. Unit-specic alarms
ALARM INDICATION FAULT HANDLING
Freezing protection
sensor triggering Contact the maintenance service.
Freezing protection
sensor breakout
Contact the maintenance service to x the
freezing protection sensor.
TECHNICAL MAINTENANCE
The unit must undergo technical maintenance 3 or 4 times a year. The technical maintenance includes general cleaning of the unit and
the following operations:
1. Filter service (3-4 times a year).
Contaminated lters increase air resistance thus impairing supply air delivery into the premises. The lters should be cleaned as they get
dirty, but at least 3-4 times a year. Use a vacuum cleaner to remove the contamination or use a new lter. New lters can be purchased from
your seller.
To remove the lters (Fig. 14):
• Step 1. Undo the clips.
• Step 2. Remove the service panel.
• Step 3. Turn the retainers and remove the lters.
2. Heat exchanger inspection (once a year).
Even regular technical maintenance may not completely prevent dirt accumulation on the heat exchanger assemblies. Subject the heat
exchangers to regular cleaning to ensure high heat exchange eciency. To clean the heat exchangers remove those from the unit and blow
with compressed air. Wet cleaning is prohibited.
To remove the heat exchangers (Fig. 14):
• Step 1. Undo the clips.
• Step 2. Remove the service panel.
• Step 4. Turn the retainers and remove the heat exchangers.
The lter and heat exchanger installation is in the reverse order of the removal.

16
Fig. 14. Filter and heat exchanger removal
1. 2.
3. 4.
The lower part of the unit has a special
retaining plate for convenient removal
and replacement of the service panel
(in case of the wall mounting).
ATTENTION! If the unit is mounted to the ceiling hold the service panel up while removing to avoid injuries.
3. Fan inspection (once a year).
Even regular technical maintenance of the lters may not completely prevent dirt accumulation in the fans which impairs the unit
performance and supply air delivery into the premises.
Clean the fans with a cloth or a soft brush. Do not use water, aggressive solvents, sharp objects etc. as they may damage the impeller.
4. Fresh air supply duct inspection (every 6 months).
The supply duct grill may get clogged with leaves and other objects impairing the unit performance. Check the supply duct grille
twice a year and clean it, if necessary.
5. Duct system inspection (every 5 years).
Even regular the timely performance of all the aforesaid operations specic to the technical maintenance of the unit may not
completely prevent dirt accumulation in the air ducts which impairs the unit performance. The air duct maintenance includes their
periodic cleaning or replacement.
6. Control unit maintenance (if necessary).
The control unit maintenance must be performed by an expert qualied for unassisted operations with electrical installations up to
1000 V after careful reading of the user's manual.
To access the control unit electronics follow the operations on Fig. 15.
1. Undo the self-tapping screws retaining the control unit cover.
2. Remove the control unit cover.
On completing the control unit maintenance replace the cover and x it with the self-tapping screws.

17
VUE2 150 P ЕС Comfo
Fig. 15. Control unit maintenance
1. 2.
TROUBLESHOOTING
Table 5. Possible malfunctions and fault handling
Problem Possible Reasons Fault handling
The fan (fans) will not start The unit is not connected to the power mains.
Make sure that the unit is properly connected
to the power mains and make any corrections,
if necessary.
Supply air too cold
Exhaust lter clogged. Clean or replace the extract lter.
Heat exchanger icing.
Check for ice in the heat exchanger. If there
is ice in the heat exchanger let it melt before
switching the unit back on.
Low air ow
Filters, fans or heat exchanger clogged. Clean or replace the lters; Clean the fans and
the heat exchanger.
Air handling system clogged or damaged.
Check for unobstructed diuser and louvre
shutters opening, check the exhaust hood and
the supply grille and clean those, if necessary;
make sure that the air ducts are clean and
intact.
Noise and vibration
Fan impellers dirty. Clean the fan impellers.
Fan fastening screws loose. Make sure the fastening screws are tight.
TRANSPORTATION AND STORAGE REGULATIONS
Store the unit in the manufacturer's original packing box in a dry ventilated premise at the temperatures from -10 °C up to + 40°C .
Storage environment must not contain aggressive vapours and chemical mixtures provoking corrosion, insulation and sealing
deformation.
Use hoist machinery for handling and storage operations to prevent the unit damage in consequence of falling or excessive oscillation.
Full the handling requirements applicable for the applicable freight type.
Transportation with any vehicle type is allowed provided that the unit is protected against mechanical and weather damage.
Avoid any mechanical shocks and strokes during handling operations.

18
MANUFACTURER'S WARRANTY
The manufacturer hereby warrants normal operation of the unit over the period of 24 months from the retail sale date provided the
user's observance of the transportation, storage, installation and operation regulations.
Should any malfunctions occur during the unit operation through the manufacturer's fault during the warranty period the user is entitled
to elimination of faults by means of warranty repair performed by the manufacturer.
The warranty repair includes work specic to elimination of faults in the unit operation to ensure its intended use by the user within the
warranty period. The faults are eliminated by means of replacement or repair of the complete unit or the faulty part thereof.
The warranty repair does not include:
• Routine maintenance;
• Unit installation / dismantling;
• Unit setup.
To benet from warranty repair the user must provide the unit, the user's manual with stamped sale date and the payment document
certifying the purchase.
The unit model must comply with the one stated in the user's manual.
Contact your Seller for warranty service.
The manufacturer's warranty does not apply to the following cases:
• User's failure to provide the unit with the entire delivery package as stated in the user's manual or with missing component parts
previously dismounted by the user;
• Mismatch of the unit model and make with the respective details stated on the unit packing and in the user's manual;
• User's failure to ensure timely technical maintenance of the unit;
• External damage to the casing (excluding external modications of the unit as required for its installation) and the internal
components of the unit;
• Alteration of the unit design or engineering changes of the unit;
• Replacement and use of the unit assemblies, parts and components not approved by the manufacturer;
• Unit misuse;
• User's violation of the unit installation regulations;
• User's violation of the unit management regulations;
• Unit connection to the power pains with a voltage dierent from the one stated in the user's manual;
• Unit breakdown due to voltage surges in the power mains;
• User's discretionary repair of the unit;
• Unit repair performed by any persons without the manufacturer's authorization;
• Expiry of the unit warranty period;
• User's violation of the established regulations specic to the unit transportation;
• User's violation of the unit storage regulations;
• Wrongful acts against the unit committed by third persons;
• Unit breakdown due to circumstances of insuperable force (re, ood, earthquake, war, hostilities of any kind, or blockade);
• Missing seals if provided by the user's manual;
• Failure to provide the user's manual with the sale date stamp;
• Missing payment document certifying the unit purchase.
USERS' CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON PRESENTATION OF THE
UNIT, THE PAYMENT DOCUMENT AND THE USER'S MANUAL WITH THE SALE DATE
STAMP.
FOLLOWINGTHE REGULATIONS STIPULATED HEREINWILL ENSURE A LONG ANDTROUBLE-
FREE OPERATION OF THE UNIT.

19
VUE2 150 P ЕС Comfo
SELLER’S INFORMATION
Address
Phone number
E-mail
Sales date
Дата покупки
This is to certify delivery of the complete unit with the user’s manual. The warranty terms are
acknowledged and accepted.
Customer’s signature
Seller's seal
MOUNTING CERTIFICATE
VUE2150 P EC Comfo unit has been connected to power mains pursuant to the requirements
stated in the present user’s manual.
Company name
Address
Phone number
Installation technician's
full name
Installation date: Signature:
Installation technician's
company seal
This is to certify that the work specic to the unit installation has been performed in accordance
with all the applicable provisions of local and national construction, electrical and technical codes
and standards. The unit operates normally as intended by the manufacturer.
Signature:
ACCEPTANCE CERTIFICATE
Product Type Air handling unit with heat and energy recovery
Model VUE2150 P EC Comfo
Serial Number
Manufacturing Date
is compliant with the technical specications and is hereby declared ready for service.
Quality Inspector's
Stamp

20
WARRANTY CARD
Product type Air handling unit with heat and energy recovery
Model VUE2150 P EC Comfo
Serial number
Manufacturing date
Sales date
Warranty period
Sales company
Seller's seal
NOTES
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
