Verasys SBH200 User manual

Technical Specifications (Continued)
North American Emissions Compliance
United States
© 2018 Johnson Controls.
Part No. 24-10737-00229, Rev. A
Issued March 2018
Smart Building Hub Quick Start Guide
SBH200
*241073700229A*
24-10737-00229, Rev. A
Transmission
Speeds
Serial Communication (SA/FC Bus): 38.4 kbps
Ethernet Communication: 10, 100 Mbps,1 Gbps
Wireless
Security
WPA2-PSK TKIP (Wi-Fi Protected Access Pre-
Shared Key mode Temporal Key Integrity
Protocol).
Network and
Serial
Interfaces
Two SA/FC ports (RJ12 6-pin port; connects with
1.5 m [4.9 ft] RJ-12 field bus cable, and one screw
terminal plug, 4-pin).
Three USB ports (one Micro-B port, and two USB
A ports). All support USB 2.0 and Open Host
Controller Interface [Open HCI] specification.
Dimensions
(H x W x D)
190 x 125 x 44.5 mm (7.48 x 4.92 x 1.75 in).
Housing White Polycarbonate and Acrylonitrile butadiene
styrene (ABS) blend.
Web Browser
Requirements
for Computers
and Handheld
Devices
Computer:
Windows Internet Explorer® 10 and Windows
Internet Explorer 11, or Google® Chrome™
Handheld Device:
The handheld device must be running either
Internet Explorer Mobile for Windows® Mobile
version 5 or version 6 operating system (OS);
Android™ 4.0.3, 4.0.4, and 4.1+, or Google
Chrome. Other web browsers may display the UI,
but the functionality is not guaranteed.
Compliance United States UL Listed File E107041, CCN
PAZX, UL 916, Energy Management Equipment,
FCC Compliant to CFR47, Part 15, Subpart B,
Class B.
Canada: UL listed file E107041, CCN PAZX7,
CAN/CSA C22.2 No.205, Signal Equipment;
Industry Canada Compliant.
Europe: CE Mark - Johnson Controls, Inc.
declares that this product is in compliance with the
essential requirements and other relevant
provisions of the EMC Directive.
Australia and New Zealand: RCM Mark,
Australia/NZ Emissions Compliant.
This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference when this equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area may
cause harmful interference, in which case users will be required to
correct the interference at their own expense.
Warning (Part 15.21)
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
European Single Point of Contact: NA/SA Single Point of Contact:
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
APAC Single Point of Contact:
JOHNSON CONTROLS
C/O CONTROLS PRODUCT MANAGEMENT
NO. 22 BLOCK D NEW DISTRICT
WUXI JIANGSU PROVINCE 214142
CHINA
SSID: Verasys-SBH Username: Admin
Passphrase:
Place Label here
Password:
Place Label here
SYSTEM BUS EOL USB B USB A ETHERNET
24 VAC COM
24 VDC
EOL
SYSTEM BUS
USB A
WI-FI CLIENT
WI-FI AP
USB B
UPGRADE RUN
100/1G LINK ETHERNET
FAULT POWER
RESET REBOOT
SMART BUILDING HUB
TM
Canada
For more information on the Smart Building Hub or to get
access to Johnson Controls Quicklit use these two QR
codes.
Refer to the QuickLIT website for the most up-to-date
version of this document and for more installation
information:
www.cgproducts.johnsoncontrols.com
Industry Canada Statement(s)
The term IC before the certification/registration number only signifies
that the Industry Canada technical specifications were met.
Le terme « IC » précédant le numéro d'accréditation/inscription
signifie simplement que le produit est conforme aux spécifications
techniques d'Industry Canada.
The performance specifications are nominal and conform to
acceptable industry standard. For application at conditions beyond
these specifications, consult the local Johnson Controls office.
Johnson Controls, Inc. shall not be liable for damages resulting from
misapplication or misuse of its products.
SBH200 QR Code QuickLit QR Code

1. Connect the Smart Building Hub to Equipment
The Smart Building Hub (SBH) permanently connects to the
VerasysTM system using the 4-terminal System bus port. Wire
the system bus communications to the blue, 4-terminal
connector and plug it into the port.
Note: If this device is at the end of a line, set the end of the
line switch to on.
Note: The RJ-12 jack next to the 4-terminal block can be used
as a temporary connection to the System bus using the RJ-12
cable supplied with the SBH.
Figure 1: Connecting the SBH
a. Wire your cable to the supplied four-pin adapter as
illustrated.
b. Plug the Wi-Fi adapter that comes with the SBH into either
of the USB ports.
c. Connect the RJ45 Ethernet port to the building Ethernet
network as instructed by the building IT department. The
Ethernet must be plugged into the device if you choose the
(optional) Ethernet setup in step 6.
d. Connect power to the Smart Building Hub.
Once power is supplied to the SBH, the WiFi AP LED
flashes to indicate that the device is initializing. When the
Fault LED turns off, the WiFi AP LED flashes, and the
RUN LED is on, you can connect the SBH using the built-
in Wifi access point.
Figure 2: SBH LED Map
2. Connect to the Smart Building Hub Wi-Fi access point
The SBH can be configured over Wi-Fi using a mobile device or
laptop.
a. In your Wi-Fi enabled device, access the Wi-Fi settings
and select the Verasys-SBH access point name.
b. Connect to the SBH Wi-Fi network using the supplied
credentials from the beginning of this guide.
3. Open a Web Browser
a. Navigate to the following URL: www.smartbuildinghub.com,
to open the SBH browser interface.
Note: The SBH ships with a private smartbuildinghub.com
SSL certificate installed to ensure secure communication
with the SBH. However, this certificate does not indicate
that it is trusted in a browser. If you wish to install your own
certificate, refer to the Smart Building Hub Network and IT
Guidance Technical Bulletin (LIT-12012324) for more
information.
4. Log in to the Smart Building Hub
a. Use the default Admin login credentials from the beginning
of this guide.
b. Read and accept the SBH license agreement.
5. Change Passwords and SSID
The first time you log into the SBH, the Change Password and
Passphrase web page appears. You must change the Admin
password, Wi-Fi passphrase, and the SSID.
a. In the New Admin Password field, enter a new password.
b. In the Verify New Admin Password field, enter the same
new password.
c. In the New Wi-Fi SSID field, enter the new Wi-Fi SSID.
d. In the New Wi-Fi Passphrase field, enter the new Wi-Fi
Passphrase.
e. Click the Save button.
Navigate to the following URL: www.smartbuildinghub.com, to
open the SBH browser interface.
Note: The SBH ships with a private smartbuildinghub.com SSL
certificate installed to ensure secure communication with the
SBH. However, this certificate does not indicate that it is trusted
in a browser. If you wish to install your own certificate, refer to
the Smart Building Hub Network and IT Guidance Technical Bul-
letin (LIT-12012324) for more information.
Navigate to the following URL: www.smartbuildinghub.com, to
open the SBH browser interface.
Note: The SBH ships with a private smartbuildinghub.com SSL
certificate installed to ensure secure communication with the
SBH. However, this certificate does not indicate that it is trusted
in a browser. If you wish to install your own certificate, refer to
the Smart Building Hub Network and IT Guidance Technical
Bulletin (LIT-12012324) for more information.
6. Ethernet Setup (Optional)
This step describes how to access the SBH over an Ethernet
network.
a. In the SBH UI, navigate to Settings > Ethernet.
b. On the Ethernet drop-down list, select On to enable the
SBH Ethernet port.
c. Click the Save button.
d. Take note of the address in the IP Address field. By
default, the SBH is configured to dynamically receive an IP
address from your network using DHCP.
Note: If the IP Address does not appear, refresh the
screen.
e. Enter the IP address from the previous step. You now have
access to the SBH over an Ethernet network.
Refer to the Smart Building Hub Network and IT Guidance
Technical Bulletin (LIT-12012324) for more options.
7. Use the Smart Building Hub
Select a device from the equipment list and use the web pages
from the SBH to view, commission, and configure devices as
needed.
Technical Specifications
Smart Building Hub
+
COM
SH
LD
EOL
SYSTEM BUS
USB A
WI-FI CLIENT
WI-FI AP
USB B
UPGRADE RUN
100/1G LINK ETHERNET
FAULT POWER
RESET REBOOT
IMPORTANT: After you change the Wi-Fi passphrase or
SSID, the web server restarts and you must rejoin the SBH
Wi-Fi network using the new passphrase. On some mobile
devices, you must select and forget the original SBH Wi-Fi
network before rejoining the network with the new
passphrase. A laptop running Microsoft Windows is a device
that behaves this way.
IMPORTANT: Save this guide. It contains your default user
name and password information. This information may be
needed to reset your Smart Building Hub to factory defaults.
Power
Consumption
38W maximum
Ambient
Temperature
Conditions
Operating: 0 to 50°C (32 to 122°F)
Operating Survival: -30 to 60°C (-22 to 140°F)
Non-Operating: -40 to 70°C (-40 to 158°F)
Ambient
Humidity
Conditions
Storage: 5 to 95% RH 30°C (86°F) maximum dew
point conditions
Operating: 10-90% RH, 30°C (86°F) maximum
dew point conditions
