VERIPURE VERIPUREVPC5000 User manual

1
REVISED 4/13/2020
OWNERS MANUAL VERIPUREVPC5000

2
2425 HUTSON ROAD
GREEN BAY WI, 54303
[phone]
www.veripure.com
THANK YOU FOR CHOOSING VERIPURE®
PLEASE TAKE A FEW MOMENTS TO FILL IN THE INFORMATION BELOW, SAVE THIS
MANUAL AS A CONVENIENT INFORMATION SOURCE FOR YOUR VERIPURE® SYSTEM.
Date of Purchase:
Purchased From:
Phone Number:
Serial Number:
Installed By:
Dealer Name:
Dealer Phone

3
PERFORMANCE DATA SHEET
Model VPC5000 & Model VP5000
This system has been tested by WQA according to NSF/ANSI 42 and 53 for the reducon of the substances
listed below. The concentraon of the indicated substances in water entering the system was reduced to a
concentraon less than of equal to the permissible limit for water leaving the system, as specied in NSF/
ANSI 42 and 53. While tesng was performed under standard laboratory condions, actual performance
may vary. Do not use with water that is microbiologically unsafe or of unknown quality without adequate
disinfecon before or aer the system. Systems cered for cyst reducon may be used on disinfected
waters that may contain lterable cysts.
Stage One — Filtraon Process:
The VeriPure Maintenance Kit- Consists of a two lter conguraon that is a proprietary design of VeriPure, Inc. The rst lter
is a sediment lter that greatly reduces suspended and parculate maer from the incoming water source. The second lter
(a carbon block lter for cyst removal, lead and chlorine reducon) greatly reduces free chlorine and cysts from the water
source to disinfect and improve the taste and odor of the water.
Carbon Block Filter Data
Operang Specicaons:
Capacity: 1 ,250 Gallons Lead Reducon
Flow Rate: 0.50 to 1.0 GPM
Minimum Pressure: 50 PSI
Maximum Pressure: 125 PSI
Temperature: 35-90 F (2-32 C)
Parameter
Chlorine >=50%
Cyst >=99.95%
Lead 0.01 mg/L

4
IMPORTANT SAFEGUARDS AND PRECAUTIONS
• INSTALL YOUR VERIPURE® SYSTEM IN COMPLIANCE WITH STATE AND LOCAL LAWS AND
REGULATIONS FOR PLUMBING AND ELECTRICAL CODES. AS WITH ANY WATER DEVICE, PLEASE
CHECK YOUR SYSTEM FOR LEAKS ON A REGULAR BASIS. CONTACT A PLUMBER IMMEDIATELY
• VERIPURE® PERFORMANCE IS BASED UPON INPUT WATER WHICH MEETS MINIMUM EPA
NATIONAL PRIMARY AND SECONDARY DRINKING WATER STANDARDS.
• SEE WWW.EPA.GOV/DWSTANDARDSREGULATIONS
•
ATTENTION: THIS UNIT IS DESIGNED FOR TREATMENT OF COLD WATER ONLY.
• READ INSTRUCTIONS- ALL SAFETY AND OPERATING INSTRUCTIONS SHOULD BE READ BEFORE THE UNIT IS
OPERATED.
• RETAIN INSTRUCTIONS– SAFETY AND OPERATING INSTRUCTIONS SHOULD BE KEPT IN AN ACCESSIBLE LOCATION
FOR FUTURE REFERENCE.
• FOLLOW INSTRUCTIONS– ALL INSTRUCTIONS SHOULD BE FOLLOWED FOR MAINTAINING AND OPERATING YOUR
VERIPURE® SYSTEM PROPERLY.
• MAINTENANCE PRECUATIONS– ALWAYS TURN OFF THE WATER SUPPLY AT THE SINK OR WATER SOURCE AND
UNPLUG POWER JACK FROM THE VERIPURE® SYSTEM BEFORE PERFORMING ANY MAINTENANCE.
• ACCESSORIES– DO NOT USE ANY ACCESSORIES, INCLUDING FILTER CARTRIDGES THAT ARE NOT RECOMMENDED
BY VERIPURE®
• WATER AND MOISTURE– DO NOT ALLOW MOISTURE TO CONTACT ANY INTERNAL OR EXTERNAL ELECTRONIC
COMPONENTS. SHOULD A LEAK OCCUR, IMMEDIATELY SHUT OFF THE WATER SUPPLY AND CONTACT YOUR
DEALER OR DISTRIBUTOR FOR SERVICE.
• POWER SOURCES– YOUR VERIPURE® SYSTEM SHOULD ONLY BE OPERATED FROM THE TYPE OF POWER SOURCE
INDICATED ON YOUR AC ADAPTER. IF YOU ARE NOT CERTAIN OF THE TYPE OF POWER SUPPLY TO THE OUTLET
PLEASE CONSULT YOUR VERIPURE® DEALER OR POWER COMPANY. ALTERNATIVE POWER SUPPLY ADAPTERS FOR
VOLTAGES FOUND IN MANY COUNTRIES OUTSIDE THE UNITED STATES ARE AVAILABLE THROUGH YOUR DEALER
ON SPECIAL ORDER. YOUR VERIPURE® SYSTEM MAY ALSO BE OPERATED WITH A BATTERY PACK OR GENERTOR.
• POWER CORD PROTECTION– VERIPURE® RECCOMENDS THAT POWER SUPPLY CORDS SHOULD BE ROUTED SO
THAT THEY ARE NOT LIKELY TO BE WALKED ON OR PINCHED BY ITEMS PLACED UPON OR AGAINST THEM.

5
HOW YOUR VERIPURE® SYSTEM WORKS
YOUR PATENTED VERIPURE® SYSTEM HAS BEEN DESIGNED TO USE TWO STAGES OF PRIMARY FILTRATION
AND LOW LEVEL OZONE TECHNOLOGY®. OPERATIONAL MAINTENANCE AND REPLACEMENT REQUIREMENTS
ARE ESSENTIAL FOR THE VERIPURE® SYSTEM TO PERFORM TO SPECIFIATIONS. CONTACT YOUR LOCAL
DEALER OR DISTRIBUTOR FOR REPLACEMENT FILTERS AND PARTS, OR CONTACT VERIPURE FOR THE DEALER
NEAREST YOU. THE VERIPURE® SYSTEM IS RECCOMENDED TO BE CONNECTED TO MUNICIPAL WATER
SOURCES.
FOOD & SURFACES
GENERAL RECOMENDATIONS FOR USING OZONATED WATER ARE AS FOLLOWS-
• PLACE ITEM OR ITEMS TO BE WASHED UNDER A STEADY STREAM OF VERIPURE® WATER AND RINSE.
• FOOD PREPARATION: IT IS RECOMMENDED ITEMS BE RINSED FOR 3 MINUTES WITH VERIPURE® WATER.
• FOOD ITEMS: PLACE IN A BOWL, COLANDER OR STRAINER. RINSE WITH VERIPURE® WATER.
STORING WATER
• SELECT A CONTAINER THAT IS FOOD GRADE QUALITY, SUCH AS GLASS OR STAINLESS STEEL. THOROUGHLY RINSE
THE CONTAINER WITH VERIPURE® WATER AT LEAST TWICE. FILL THE CONTAINER TO WITHIN ONE TO TWO INCHES
FROM THE TOP AND REPLACE CAP.
• STORE WATER IN REFRIGERATOR AND MAKE CERTAIN THE CAP IS REPLACED AFTER EVERY USE.
• WHEN WATER IS FRESHLY OZONATED YOU MAY INITIALLY BE ABLE TO DETECT A SLIGHT HINT OF OZONE. PEOPLE
VARY IN THEIR SENSITIVITY TO OZONE. ANY HINT OF THE OZONE TASTE WILL DISAPPEAR WITHIN A SHORT PERIOD
OF TIME. YOUR SYSTEM PRODUCES MINIMAL WASTE WHILE PRESERVING MINERALS IN YOUR WATER.
IMPORTANT NOTE: VERIPURE® PERFORMANCE IS BASED UPON INPUT WATER WHICH MEETS MINIMUM
EPA NATIONAL PRIMARY AND SECONDARY DRINKING WATER STANDARDS. SEE WWW.EPA.GOV/
DWSTANDARDSREGULATIONS

6
A LOOK AT YOUR VERIPURE® SYSTEM
UNIT DIMENSIONS: 11.5”L X 7”W X 5.5”H 9.0LBS (4.05KG)
IT IS IMPORTANT TO BE FAMILIAR WITH CERTAIN COMPONENTS OF YOUR VERIPURE® SYSTEM FOR
MAINTENANCE PURPOSES.
DIAGRAM 1

7
INSTALLATION INSTRUCTIONS
BEFORE INSTALLING
1. YOUR VERIPURE® SYSTEM IS DESIGNED TO BE USED WITH COLD WATER ONLY.
2. NEVER RUN WARM OR HOT WATER THROUGH YOUR VERIPURE® SYSTEM AS HOT WATER
CAN DAMAGE THE CARBON BLOCK FILTER.
3. WATER TEMPERATURES ABOVE 90° F CANNOT CONTAIN DISSOLVED OZONE; THUS
ELIMINATING DISINFECTION. WATER TEMPS APPROACHING 85° F REQUIRE LONGER
PERIODS OF CONTACT TIME FOR DISINFECTION PURPOSES.
4. FOR OPTIMAL PERFORMANCE , LIMIT YOUR VERIPURE® SYSTEM TO 70 PSI OF WATER
PRESSURE. VERIPURE® RECOMMENDS A MINIMUM WATER PRESSURE OF 50 PSI. LOW
WATER PRESSURE WILL CAUSE YOUR VERIPURE® SYSTEM TO PRODUCE A LOWER
QUANTITY OF FILTERED AND OZONATED WATER.
5. POWER REQUIREMENTS ARE 120 VAC 60 HZ. USE AC ADAPTER PROVIDED WITH YOUR
SYSTEM.
NOTE: VERIPURE® UNITS ARE DESIGNED TO BE UNDER CONTINUAL WATER PRESSURE WHEN
INSTALLED AND NOT IN USE, THE ON/OFF VALVE AND OR FAUCET SHOULD BE ON THE
OUTLET OF THE VERIPURE AT OR BETWEEN THE POU AND VERIPURE® UNIT. THIS ENSURES
PROPER FUNCTION ON THE VERIPURE® .
 VPC5000 INSTALLATION INSTRUCTIONS BEGIN ON NEXT PAGE (PAGE 8)

8
INSTALLATION INSTRUCTIONS(VPC5000)
*COMMERCIAL/COUNTER-TOP MODEL*
Due to variance in plumbing and power outlets; we recommend that a plumber and or electrician install your VeriPure® System
by following these installaon instrucons. If you choose to install the unit yourself please call [phone] for assistance.
Installaon of the VeriPure® System must conform to state and local plumbing and electrical codes, laws, regulaons and the
instrucons provided with your VeriPure® System. Failure to install as instructed will void the warranty.
Please check your VeriPure® System to be certain all items listed below are included.
• QTY 1 AC ADAPTER (POWER
SUPPLY) WITH OUTLET PLUG
• QTY 1 DIVERTER VALVE ASSEMBLY
• QTY 1 FAUCET ADAPTERS (QTY 3)
• QTY 1 MOUNTING PLATE
• QTY 1 HEX WRENCH
• QTY 1 SPANNER TOOL
• QTY 1 COLD WATER ONLY LABEL
• QTY 4 RUBBER FEET
• QTY 1 OWNERS MANUAL

9
VPC5000 WALL MOUNT INSTALLATION STEPS
Step 1: Please inspect your VeriPure® System Glass Dielectric Tube at this me. Locate the knob on your
VeriPure® System. Rotate 1/4 turn counter clockwise and PULL STRAIGHT OUT VERY CAREFULLY as to prevent
breaking. Inspect the dielectric for any cracks or breakage that may have occurred in shipping. If none are found, then
replace dielectric. When replacing dielectric, rotate 1/4 turn clockwise to lock in place.
Step 2: Locate the power outlet for the power supply.
Step 3: Locate the best area for hanging the VeriPure® System. Directly above the faucet or slightly to the le. Aach
the diverter valve to the faucet, CAUTION: DO NOT OVERTIGHTEN. Stretch out the hoses to get an approximate
locaon for the VeriPure® System.
Step 4: Mount screws for the VeriPure® System by using the provided screws and mounng plate.
Step 5: Locate the 1/4" lter inlet ng on your VeriPure® System. Remove the 3/8" red locking clip also located on
your VeriPure® System on the 3/8" outlet ng.
Step 6: Mount your VeriPure® System onto the mounng screws previously installed and ghten screws.
Step 7: Insert the 1/4” stem adapter ng at the end of the hose into the 1/4" lter inlet ng on your
VeriPure® System.
Step 8: Insert the other end of the 3/8" tubing into the 3/8" outlet ng located on your VeriPure® System. Replace
the 3/8" red locking clip.
Step 9: Thread the power supply into the power jack located on your VeriPure® System. Plug the power supply into the
electrical outlet.
MOUNTING PLATE
WALL MOUNTED EXAMPLE POWER PLUGGED INTO POWERJACK
THESE 3 HOLES USE TO MOUNT PLATE TO WALL
SCREW ON EACH END OF
MOUNTING PLATE USED
TO FASTEN VERIPURE®
SYSTEM TO PLATE

10
VPC5000 COUNTER TOP INSTALLATION INSTRUCTIONS
Your VeriPure® System oers the opon of quick counter top installaon.
Cauon: Please be aware that your VeriPure® System CANNOT BE SUBMERGED IN WATER. Extra care should
be taken when choosing the counter top locaon for your VeriPure® System so that it will not get wet or
accidentally knocked into a sink or water basin.
Step 1: Place your VeriPure® System on a counter on the le side of your sink. There are only two possible
orientaons for the VeriPure® System to sit on a counter top (see photos on page 11).
Step 2: Remove the 3/8” clip from the 3/8 outlet on the Veripure® System.
Step 3: Insert the 3/8 tube into the VeriPure® System outlet unl fully seated, Replace red 3/8” locking clip
Step 4: Insert the 1/4” stem adapter ng into the lter cartridge.
Step 5: Posion the handle of the diverter valve in your preferred locaon and then hand ghten the diverter valve
collar.
Step 6: Connect power cord to the VeriPure System and plug into wall outlet.
Step 7: To operate your VeriPure System turn on your faucet, COLD WATER ONLY and turn the diverter valve handle.
Your VeriPure System will automacally turn on as water ows through it (veried by green unit on light on LED
readout). Flush the lters for 10 minutes as directed and check for leaks.
Note: See Flushing Instrucons Below.
FLUSHING INSTRUCTIONS
• TURN ON THE WATER SUPPLY AND FLUSH NEW CARTIDGES FOR 10 MINUTES, RUNNING
WATER THROUGH THE SYSTEM
• NEW FILTER ASSEMBLIES MAY CONTAIN “CARBON FINES” AND THE WATER MAY BRIEFLY
APPEAR GRAY, BUT WILL QUICKLY DISAPPEAR ONCE FLUSHED.
• IMPORTANT– CHECK THAT ALL WATER LINES ARE SECURE AND FIRMLY SEATED WITH NO
EVEIDENCE OF WATER LEAKAGE. IF A LEAK IS DETECTED, SHUT OFF WATER SUPPLY AND
DISCONNECT LINES AND VISUALLY CHECK FOR ANY DEFECTS AT THE END OF LINES. INSERT
LINES BACK IN UNTIL FULLY SEATED AND TURN WATER SUPPLY BACK ON. RECHECK FOR
ANY LEAKS.

11
VPC5000 COUNTER TOP INSTALLATION EXAMPLES
INSTALLATION OF RUBBER PADS
• IF UNIT IS HUNG ON WALL USING THE MOUNTING PLATE ONLY 2 PADS ARE REQUIRED THAT MOUNT ON
BOTTOM SIDE OF UNIT TO REST AGAINST THE WALL.
• IF THE UNIT IS PLACED IT THE FILTER DOWN POSITION/ DIELECTRIC UP POSTION 4 PADS ARE REQUIRED.
PLACE THESE PADS APPROXIMATLY 1.5 INCHES FROM THE END OF EACH CORNER FOR FILTER DOWN
POSITION. FOR DIELECTRIC UP POSITION THE TOP SIDE OF BOTTOM ( SIDE THAT REST AGAINST WALL)
WILL RECEIVE 2 PADS WHILE THE OTHER TWO ARE PLACED ON THE BOTTOM SIDE OF THE COVER (SIDE
THAT THE UNIT IS RESTING ON).
DIELECTRIC UP POSTION
USE ONLY IF SYSTEM WILL BE LEFT OF SINK
FILTER SIDE DOWN POSITION
PAD PLACED ON BOTTOM 1.5 INCHES
FROM CORNER END.
PAD PLACED ON CORNER OF COVER
FOR DIELECTRIC UP POSITION

12
MAINTAINING YOUR VERIPURE® SYSTEM
When performing maintenance as recommended, you should enjoy years of excellent
performance from your VeriPure® System. The LED indicator lights will conrm that your
VeriPure® System is working properly or if your system is malfunconing.
LED READOUT
INSTALLED VERIPURE®
There are two maintenance requirements for your VeriPure® System:
1. Change the lter cartridge assembly when indicated by the LED readout on your
VeriPure® System.
2. Replace the Dielectric tube whenever you change your lters (included in your
maintenance kit).
3. Refer to Maintenance Kit supplied by VeriPure, LLC on page 13.
CAUTION: REMOVE DIELECTRIC TUBE CAREFULLY AS STRAIGHT AS POSSIBLE TO PREVENT
BREAKAGE.

13
CHANGING THE FILTERS (VPC5000)
*COMMERCIAL/COUNTER-TOP MODEL*
PREPARATION
1. Shut o water supply to the unit.
2. Unplug your VeriPure® System unit from electrical connecon before changing lter cartridges. *THIS
STEP IS IMPORTANT, IN ORDER TO RESET YOUR VERIPURE UNIT.
3. Disconnect the input and output ngs on your VeriPure® System using spanner tool provided in
maintenance kit (Refer to Diagram 1)
NOTE: To remove waterlines at the unit, you must rst remove red locking clips. Next press each collar inward toward the unit
using spanner tool, pulling hose simultaneously.
CAUTION: If you do not depress collar(s) before pulling hose(s), you can damage unit ngs. See Warranty Specicaons.
TO REMOVE THE FILTER CARTRIDGES
1. Place a towel/absorbent cloth on counter or work surface.
2. Remove unit from wall mounng plate by loosening screws. If unit is wall mounted, li up and pull out
from mounng plate.
3. Place unit face down on towel.
4. Unscrew the locking bolt in the center of the cartridge assembly (Refer to Diagram 1).
5. Using spanner tool, depress collar inward toward unit and pull lter assembly up.
6. Remove lter assembly by pping and sliding.
7. Dispose of the used lter assembly.
Please Reference Part# VERIVPC5000MAINTKIT
• Replacement Maintenance Kits contain a two-
stage lter cartridge assembly and one
thermoplasc–capped borosilicate glass
dielectric tube. Please follow replacement
guidelines as referenced above.
(CONTINUED ON PAGE 14)

14
CHANGING THE FILTERS (VPC5000) (CONTINUED)
*COMMERCIAL/COUNTER-TOP MODEL*
TO INSTALL FILTER CARTRIDGES
1. Slide assembly into unit housing matching the lter outlet to unit inlet and press rmly.
2. Be sure the lter assembly is seated on guide pins (Refer to Diagram 1)
3. Replace locking bolt and turn nger ght.
RETURNING UNIT TO USE
1. If wall mounted, line up mounng guide holes to guide bolts on mounng plate. Allow unit to seat into
place, checking stability before releasing unit from your grip. Tighten screw on mounng plate.
2. Reconnect water lines by popping line into ng unl seat feels rm.
3. Replace red locking clip on larger line assembly.
4. Plug unit back in AND PRESS FILTER RESET BUTTON.
5. Follow FLUSHING INSTRUCTIONS on page 16.

15
CHANGING THE DIELECTRIC TUBE *(VP5000&VPC5000)
CAUTION: The Dielectric Tube is glass and is fragile. Dielectric tubes are not designed for bending or to
sustain impact.
Dielectric Tube
1. Make sure your VeriPure® unit remains unplugged.
2. Locate the Dielectric. (Refer to Diagram 1) page 5.
3. Rotate the Dielectric cap one quarter (1/4) turn counterclockwise, to unlock the Dielectric. You
will feel a click.
4. Slowly remove the Dielectric tube from the VeriPure® housing by sliding the Dielectric out, IN A
STRAIGHT LINE, unl the Dielectric tube is completely separated from the VeriPure® housing.
5. The old Dielectric tube should be immediately discarded of into the trash/garbage. DO NOT
TOUCH THE GLASS BECAUSE STAINING FROM NITROGEN BY-PRODUCTS CAN STAIN THE SKIN.
6. Carefully slide new Dielectric tube in place unl the cap is ush with the VeriPure® Housing.
7. Rotate the Dielectric cap one quarter (1/4) turn clockwise unl it locks in place.
PROPER DIELECTRIC POSTION WHEN
INSERTING OR REMOVING.

16
FLUSHING INSTRUCTIONS
1. Turn on the water supply and FLUSH NEW FILTER CARTRIGES FOR 5 MINUTES, running
water through the system.
2. New lter assemblies may contain "Carbon Fines" and the water may briey appear
gray ,but will quickly disappear once ushed.
3. IMPORTANT - CHECK THAT ALL WATER LINES ARE SECURE AND FIRMLY SEATED WITH
NO EVIDENCE OF WATER LEAKAGE. If a water leak is detected, REPEAT 'Returning Unit
to use', Steps 2-4.
TROUBLE SHOOTING GUIDE
At VeriPure®, Inc. we expect your VeriPure® System to funcon properly for years as long
as you perform the maintenance according to the prescribed schedule. However, the
following table will help to idenfy any problem which may occur.
**NOTE: The service technicians at VeriPure® are trained to address any undened issues.
Please call [phone] should you not be able to diagnose any problem.
TROUBLE SHOOTING CHART LOCATED ON PAGE 17

17
PROBLEM POSSIBLE CAUSE SOLUTION
NO OZONE NO POWER TO SYSTEM PLUG CHECK POWER SUPPLY CORD IS SEATED INTO
VERIPURE SYSTEM AND WALL OUTLET.
RESET ANY GFI OUTLET RESET BUTTONS IN THE
AREA.
CHECK IN-HOME ELECTRICAL BREAKER.
FILTER LIFE IS EXPRIRED AND FILTER
IS LIMITING WATER PRESSURE TO
FLOW SWITCH. CHANGE YOUR SYSTEM FILTERS
WET GLASS DIELECTRIC
*CAREFULLY* REMOVE THE GLASS
DIELECTRIC AND INSPECT FOR
MOISTURE. IF WET, CONTACT VERIPURE 2425
Hutson Road Green Bay, WI 54303
920.613.6771
DROP IN HOUSE OR MUNICIPLE WA-
TER PRESSURE.
LOW WATER PRESSURE WILL NOT
ALLOW YOUR SYSTEM OZONATION
COMPONENTS TO TURN ON. REGAIN
INCOMING WATER PRESSURE TO
MINIMUM OF 50 PSI. CONTACT YOUR PLUMBER
OR MUNICIPALITY.
DROP IN OR NO WATER
FLOW PLUGGED FILTER CHANGE YOUR SYSTEM FILTERS.
DROP IN HOUSE OR MUNICIPLE
WATER PRESSURE.
CONTACT YOUR PLUMBER OR
MUNICIPALITY.
SYSTEM LIGHTS NOT ON NO POWER TO SYSTEM PLUG. CHECK POWER SUPPLY CORD IS SEATED INTO
VERIPURE SYSTEM AND WALL
OUTLET.
RESET ANY GFI OUTLET RESET BUTTONS IN THE
AREA.
CHECK IN-HOME ELECTRICAL BREAKER.
PANEL INDICATION
LIGHTS HAVE NOT
RETURNED TO STANDBY
MAY HAVE NOT UNPLUGGED POWER
WHEN CHANGING FILTER/GLASS
DIELECTRIC TUBE.
UNPLUG YOUR SYSTEM, WAIT 10 SECONDS
PLUG BACK IN AND PRESS THE RESET BUTTON
ON YOUR FRONT PANEL.
TROUBLE SHOOTING CHART

18
COMMON QUESTIONS ABOUT OZONE
HOW DOES THE VERIPURE® SYSTEM TREAT WATER FOR DRINKING?
VeriPure® provides a three-layered system. The rst two levels of ltraon are followed by injecng powerful ozone gas as a nal
stage disinfectant which ensures avorful and safe water.
1. As water passes through the rst sediment lter dirt, rust and other parculates from the water are removed.
2. Water is then ltered a second me when it passes through a carbon block lter which reduces cysts, chlorine, organics and
other impuries.
3. In the nal stage, ozone is injected into water via the dielectric tube.
HOW MUCH OZONE IS INJECTED INTO THE WATER?
The VeriPure® patented process creates Low Level Ozone Technology®. The ozone level in the water at one half (1/2) gallon per
minute is approximately 0.4 parts per million.
IS THE OZONE SAFE TO DRINK?
Yes. Due to our patented Low Level Ozone Technology®, the ozone turns back into oxygen very quickly. To give an idea of how
much ozone is in the water, 0.40 parts per million is the equivalent to one inch in 64 miles. The ozone in the water is within
the guidelines for ozone established by the FDA Boled Water Regulaons. Ozone was rst discovered in 1840 and has been
used to treat municipal drinking water since 1905.
DOES THE OZONE AFFECT THE TASTE OF THE WATER?
Inially, there is a slight aroma of ozone. This dissipates aer a short period of me, approximately 20 seconds.
IS THE OZONE GAS RELEASED INTO THE AIR BY VERIPURE@ TREATED WATER HARMFUL?
No. Your VeriPure® System employs Low Level Ozone Technology® which is harmless. Ozone is classied as an irritang gas only in
high concentraons. The EPA has established strict guidelines liming 0.1 parts per million in the air for eight hours of connuous
exposure. Only a small poron of the ozone in the treated water is released momentarily into the air. If all the ozone in one gallon
of water were released into one cubic foot of air, the level would amount to 0.03 parts per million and it would revert to oxygen
within a few minutes.
WHAT IF MY WATER DOESN'T TASTE GOOD?
If your water suddenly has a bad taste, the problem could be the lter cartridge(s) are spent. Changing the lter may take
care of taste. Refer to "Filter change" Instrucons in this manual or contact your dealer or distributor.
IF I WANT TO REDUCE THE 'POPPING' WHEN I INITIALLY TURN ON MY VERIPURE®FAUCET,
WHAT CAN I DO?
Aer you have the faucet running, gradually decrease the ow to totally shut the faucet o( watching for the water stream to
become clear and void of bubbles). What this will do, is decrease the ozone in the water stream to virtually nothing. So the next
me you turn on the faucet, there will be no pressure in the line from previous use.

19
LIMITED WARRANTY
Badger-VeriPure, LLC warrants to the original purchaser of the VeriPure ®System products that such equipment is free from
defects in materials and workmanship.
If within one (1) year from the date of purchase, any product purchased from Badger-VeriPure, LLC shall prove to be defecve
in materials or workmanship, the Badger-VeriPure, LLC product shall be repaired or replaced, at Badger-VeriPure’s sole
discreon and expense.
This warranty shall not apply to:
a. Product that has been damaged by improper installaon.
b. Product that has been improperly used or maintained.
c. Product subjected to temperatures below 35 or over 1200 F.
d. Product operated in water pressures exceeding 90 psi.
e. Product damaged aer delivery.
f. Product that has not been properly maintained.
VeriPure® Maintenance Kits are specically not covered under this warranty.
Requests for service under this warranty shall be made by contacng our customer service team at [e-mail] in a
mely manner following discovery of the claimed defect. Any claim under this warranty must be made within 30 days following
the expiraon of the one year warranty.
Badger-VeriPure, LLC reserves the right to improve designs or change specicaons at any me without any conngent
obligaon to owners of products previously sold.
Badger-VeriPure, LLC shall not be liable for any consequenal, incidental or conngent damages. The foregoing warranes are
exclusive and in lieu of all other express warranes. Implied warranes, including but not limited to the implied warranes of
merchantability and tness for a parcular purpose, shall not exceed beyond the duraon of this applicable express warranty
provided herein. It is acknowledged that select states do not permit exclusive or limitaons of incidental or consequenal
damages or limitaons on the duraon of an implied warranty, so the above limitaons or exclusions may not apply to you.
This warranty extends to your specic legal rights and you may also have other rights which vary from state to state.
2425 HUTSON ROAD
GREEN BAY WI, 54303
[phone]
www.veripure.com
