VersaTables LWMS Series User manual

VersaTables.com
American Made & Guaranteed for Life
Laptop Wall Mount Computer Station Assembly Instructions
LWMS Series
delete and insert product glam shot
VersaTables.com
14105 Avalon Blvd.
Los Angeles, CA 90061 Proudly Made in the USA
How can we improve our assembly instructions?
Your comments and suggestions are important to us.
Please e-mail us at: [email protected].
Sales:
Call: 800-416-3961
Call: 310-353-7100
Fax: [phone]
Customer Service:
Call: 888 416-3961
Call: 424-244-2155
[email protected]
Revised: 03-17-14

Hardware & Parts List
Laptop Wall Mount Computer Station
VersaTables.com
14105 Avalon Blvd.
Los Angeles, CA 90061 Proudly Made in the USA
Sales:
Call: 800-416-3961
Call: 310-353-7100
Fax: [phone]
Customer Service:
Call: 888 416-3961
Call: 424-244-2155
[email protected]
50mm Furniture Bolt
Toggler
Drill & 1/2” Drill Bit
Additional Tools Required
Qty:1
Laptop Wall Mount Station
Qty:1
2” Phillips Stud Screw
1/2” Drill Bit
Qty:4
Qty:4Qty:4
Lock Chain
Qty:4
Qty:10
Long L Piece
10 -32 Carriage Bolt
12 SS Washer
Qty:6
Qty:10
Qty:10
Short L Piece
10/32 Thumb Nut
4mm Allen Wrench
Qty:1

VersaTables.com
14105 Avalon Blvd.
Los Angeles, CA 90061 Proudly Made in the USA
Laptop Wall Mount Computer Station
Sales:
Call: 800-416-3961
Call: 310-353-7100
Fax: [phone]
Customer Service:
Call: 888 416-3961
Call: 424-244-2155
[email protected]
Assembly Step-by-Step
Step 1
Toggler A: Drill a 1/2” hole. Slide Metal Anchor of Toggler through
hole. Minimum clearance behind wall is 1-7/8”.
Step Install Togglers
inside of wall. Push Plastic Collar into wall to lock in place.
Metal Anchor
Plastic Collar
Drill &1/2” Bit
NOTE: Extra Toggle Bolts are provided
AB AB C
2
Pre-mark Cabinet Holes
Qty:4
NOTE: Togglers are given for mounting to drywall only.
If mounting to wood, use Stud Screws.
Use Cabinet to premark the places where (4)holes will be drilled to use toggler and bolts
to secure it to the wall.

VersaTables.com
14105 Avalon Blvd.
Los Angeles, CA 90061 Proudly Made in the USA
Laptop Wall Mount Computer Station
Sales:
Call: 800-416-3961
Call: 310-353-7100
Fax: [phone]
Customer Service:
Call: 888 416-3961
Call: 424-244-2155
[email protected]
Assembly Step-by-Step
Place L Pieces set hardware as shown. DO NOT tighten all the way till your Laptop
is in place. Use (4)10-32 x 3/8 Carrige Bolts, (4) 10/32 Thumb Nuts and (4) 12 SS
Washers.
Step 4L Pieces Set.
Qty:4
Qty:4
Qty:4
10/32 x 3/8
Carriage Bolt
10/32 Thumb Nut
12 SS
Washer
Slide Top Short L Piece as shown and secure it with its hardware. DO NOT tighten all
the way till your Laptop is in place. Use (4)10-32 x 3/8 Carrige Bolts, (4) 10/32 Thumb
Nuts and (4) 12 SS Washers.
Step 3L Pieces Set.
Qty:4
Qty:4
Qty:4
10/32 x 3/8
Carriage Bolt
10/32 Thumb Nut
12 SS
Washer

Place Long L Piece hardware as shown. DO NOT tighten all the way till your Laptop
is in place. Use (2)10-32 x 3/8 Carrige Bolts, (2) 10/32 Thumb Nuts and (2) 12 SS
Washers.
Step 5Long L Piece.
Qty:2
Qty:2
Qty:2
10/32 x 3/8
Carriage Bolt
10/32 Thumb Nut
12 SS
Washer
VersaTables.com
14105 Avalon Blvd.
Los Angeles, CA 90061 Proudly Made in the USA
Laptop Wall Mount Computer Station
Sales:
Call: 800-416-3961
Call: 310-353-7100
Fax: [phone]
Customer Service:
Call: 888 416-3961
Call: 424-244-2155
[email protected]
Assembly Step-by-Step
Step 6L Pieces Placement
It is recommended to place L Pieces as shown to secure your Laptop. Notice the differ-
ence between the Log L Pieces and L Pieces Set placement.
Insert 10/32 x 3/8
Carriage Bolt Head as shown to be able to
place the L Piece Set as shown and adjust
them according to your Laptop size.
NOTE: Long L Pieces are placed in the back
of the unit where the Laptop sits to prevent
the Laptop from falling off when stored.

VersaTables.com
14105 Avalon Blvd.
Los Angeles, CA 90061 Proudly Made in the USA
Laptop Wall Mount Computer Station
Sales:
Call: 800-416-3961
Call: 310-353-7100
Fax: [phone]
Customer Service:
Call: 888 416-3961
Call: 424-244-2155
[email protected]
Assembly Step-by-Step
Step
Qty:4
50mm
Furniture Bolt
7Secure LWMS to wall
Attach LWMS Cabinet using (4) 50mm Furniture Bolts. Insert Bolts half way then drop
Cabinet onto Bolts and tighten.
50mm
Furniture Bolt
Firmly tight Thumb Nuts to avoid laptop from slipping when door closes.
Step 8Secure Laptop
LAPTOP BACK VIEW
Long L piece set in the back of the unit where
the Laptop sits prevent the Laptop from falling
off when stored.
Adjust to t Laptop

VersaTables.com
14105 Avalon Blvd.
Los Angeles, CA 90061 Proudly Made in the USA
Laptop Wall Mount Computer Station
Sales:
Call: 800-416-3961
Call: 310-353-7100
Fax: [phone]
Customer Service:
Call: 888 416-3961
Call: 424-244-2155
[email protected]
Assembly Step-by-Step
Step 1a Hinge Removal
Unscrew Phillips Head Bolt and remove Hinge.
How can we improve our assembly instructions?
Your comments and suggestions are important to us.
Please e-mail us at: [email protected].
Phillips
Head Bolt
Step 2a Hinge Placement
Place new Hinge back and Screw Phillips Head Bolt.
Phillips
Head Bolt
HINGE REPLACEMENT
