Vertiline Vertiline8i User manual

CCTV Isolated Rack Mount
Power Supplies
Installation Guide
Models Include:
Vertiline8i Vertiline8Di
- 24VAC or 28VAC @ 8A - 24VAC or 28VAC @ 8A
- Eight (8) fuse protected electronically - Eight (8) PTC protected electronically
isolated outputs isolated outputs
Vertiline16i Vertiline16Di
- 24VAC or 28VAC @ 16A - 24VAC or 28VAC @ 16A
- Sixteen (16) fuse protected electronically - Sixteen (16) PTC protected electronically
isolated outputs isolated outputs
Rev. 031808 More than just power.TM

- 2 - Vertiline8i/Vertiline16i
Overview:
Altronix Vertiline AC Isolated CCTV Rack Mount Power Supplies provide 8 or 16 camera channels in a space saving 1U
EIA 19” rack mount chassis which may be rack, wall or shelf mounted. The units feature individually selectable 24VAC
and/or 28VAC power outputs.
Specifications:
Eight (8) and Sixteen (16) Output Rack Mount Configuration Reference Chart:
Altronix
Model
Number
Output Voltage (VAC) Total Output Current (Power) Number of Outputs Output Protection Class 2 Rated Power- Limited Output Protection Current (max. per output) Fuse Rating 115VAC 60Hz Input Current 230VAC 50/60Hz Input Current Agency Listings UL Listings and File Numbers
Vertiline8i
24VAC or
28VAC 8A 8
Fused -- 3A 3A
2.5A 1.5A UL Listed for Commercial
CCTV Equipment (UL 2044).
CUL Listed - CSA Standard
C22.2 No.1-04,
Audio, Video and Similar
Equipment.
Vertiline8Di
24VAC or
28VAC 8A 8
-- PTC 2.5A --
Vertiline16i
24VAC or
28VAC 16A 16
Fused -- 3A 3A
5A 2.5A
Vertiline16Di
24VAC or
28VAC 16A 16
-- PTC 2.5A --
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to the National
Electrical Code and all local codes.
Installation Instructions:
1. Set the input voltage selector switch located on the left side of the Vertiline unit for 115VAC or
230VAC operation (Fig. 1c, pg. 4).
2. Attach mounting brackets to Vertiline unit for rack or wall mount installation (Figs. 4-5, pg. 7). Affix rubber pads to
Vertiline for shelf installation (Fig. 6, pg. 7).
3. Secure the unit in a rack, mount unit to a wall or place unit on a shelf as desired (unit should be spaced at least
3” from any video monitors).When installing the unit in a rack, allow for one half of a U spacing above the unit
for ventilation.
4. Plug the grounded AC line cord (included) into the IEC 320 connector of the Vertiline unit (Fig. 1f, pg. 4).
Insert the plug end of the line cord into a grounded AC receptacle.
5. Set illuminated master power disconnect circuit breaker to the (ON) position (Fig. 3, pg. 6).
6. Select 24VAC or 28VAC power output for cameras 1-8 for Vertiline8i and Vertiline8Di or cameras 1-16 for
Vertiline16i and Vertiline16Di with the corresponding voltage adjustment switches (Fig. 1b, pg. 4).
7. Measure output voltage before connecting cameras. This helps avoiding potential damage.
All terminals with common suffix (P) “1P, 2P ...” are the same polarity.
8. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 3, pg. 6).
Input:
• Selectable 115VAC 60 Hz or 230VAC 50/60 Hz input.
Output:
• Eight (8) or sixteen (16) individually selectable
24VAC or 28VAC power outputs with OFF position.
• Maximum 1A per output.
• Individual electronically isolated outputs.
• Eight (8) or sixteen (16) power LED indicators.
• External automotive blade fuses or PTC protected outputs.
• Surge suppression.
Features:
• Illuminated power disconnect circuit breaker with
manual reset.
• Removable terminal blocks with locking screw flange.
• Ease of installation saves time and eliminates costly labor.
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19” rack mount chassis
• Enclosure Dimensions (H x W x D approx.):
1.625” x 19.125” x 8.5” (41.3mm x 486mm x 216mm).

Vertiline8i/Vertiline16i - 3 -
9. Connect the power outputs of the terminals marked [1P & 1N] to the power inputs of camera 1 (Fig. 2, pg. 5).
Repeat this step for each additional camera (Outputs 2-16). After wiring is completed, insert terminal block into the
corresponding connector and secure by tightening the screws.
10. Upon completion of wiring, set illuminated master power disconnect circuit breaker to the
ON (RESET) position (Fig. 3, pg. 6).
11. The power LEDs (Green) on the faceplate for Outputs 1-8 for Vertiline8i and Vertiline8Di or Outputs 1-16 for
Vertiline16i and Vertiline16Di will illuminate when AC power is present (Fig. 1a, pg. 4). If all of the LEDs are OFF,
there may be a complete loss of supply power to the Vertiline unit or the illuminated master power disconnect circuit
breaker is in the OFF position.
To restore the power output for Vertiline8i or Vertiline16i:
1- Switch corresponding output voltage switch to the OFF position (Fig. 1b, pg. 4).
2- Eliminate the trouble condition.
3- Replace the corresponding automotive blade fuse.
Replace fuses with same type and rating:
Output fuses are rated @ 3A for all models.
4- Switch output voltage switch to the 24VAC or 28VAC position as desired (Fig. 1b, pg. 4).
To restore the power output for Vertiline8Di or Vertiline16Di:
1- Switch corresponding output voltage switch to the OFF position (Fig. 1b, pg. 4).
2- Eliminate the trouble condition.
3- Allow 1 minute for PTC to cool off.
4- Switch output voltage switch to the 24VAC or 28VAC position as desired (Fig. 1b, pg. 4).
Automotive
Blade Fuse

- 4 - Vertiline8i/Vertiline16i
28VAC
OFF
24VAC
1234 5678 910111213141516
28VAC
OFF
24VAC
OFF
RESET
AC POWER
13141516
NPNPNPNP
9101112
NPNPNPNP
5678
NPNPNPNP
1234
NPNPNPNP
AC POWER
13141516
NPNPNPNP
9101112
NPNPNPNP
5678
NPNPNPNP
1234
NPNPNPNP
1b - Output voltage switches: Selects 24VAC or 28VAC or OFF for each output.
1a - LED(s) 1-16: Video signal indicators.
1f - IEC 320 Connector: 115VAC 60Hz/230VAC 50/60Hz (grounded line cord included).
Fig. 1 1c - Input Voltage Switch:
Selects 115VAC/230VAC 50/60Hz (switch is located on the left side of the unit).
115VAC 220VAC
1d - Power Outputs: 24VAC or 28VAC.
1e - Output Fuses: Automotive blade fuses.
Vertiline16i (rear) Vertiline16i and Vertiline16Di (front)
Vertiline16Di (rear)
PTC protected models (Vertiline8Di and Vertiline16Di) do not have output fuses on the rear of rack mount chassis. The PTCs are located on the inside of the rack mount chassis.

Vertiline8i/Vertiline16i - 5 -
Fig. 2
28VAC
OFF
24VAC
1234 5678 910111213141516
28VAC
OFF
24VAC
OFF
RESET
AC POWER
13141516
NPNPNPNP
9101112
NPNPNPNP
5678
NPNPNPNP
1234
NPNPNPNP
Typical Hookup:

- 6 - Vertiline8i/Vertiline16i
(ON)
AC POWER
13141516
NPNPNPNP
9101112
NPNPNPNP
5678
NPNPNPNP
1234
NPNPNPNP
28VAC
OFF
24VAC
1234 5678 910111213141516
28VAC
OFF
24VAC
OFF
RESET
1.625"
41.3mm
17.625"
447.7mm
8.5"
216mm
0.75"
19.05mm
19.125"
486mm
1U EIA 19” Rack Mount Chassis Mechanical Drawing & Dimensions (H x W x D):
1.625” x 19.125” x 8.5” (41.3mm x 486mm x 216mm)
TOP & BOTTOM
REAR
FRONT
Fig. 3
Power switch with built-in circuit breaker:
OFF position - Switch not Illuminated. Outputs not powered.
RESET (ON) position - Switch illuminated. Outputs powered.
Circuit breaker tripped - Switch not Illuminated. Power LEDs on faceplate
are not illuminated. Outputs not powered.
To reset circuit breaker set power switch to the ON (RESET) position
(Fig. 3, pg. 6).
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
CAUTION: To reduce the risk of electric shock do not open enclosure. There are
no user serviceable parts inside. Refer servicing to qualified service personnel.

Vertiline8i/Vertiline16i - 7 -
Mounting Options:
Fig. 4
Wall Mount Installation
1- Install mounting brackets (A) on the left and right side of rack chassis using
two (2) flat head screws (B) (included) (Fig. 5a).
2- Place unit at desired location and secure with mounting screws (not included) (Fig. 5b).
Caution: It is necessary to make sure mounting screws are securely fastened to a beam when installing.
Rack Mount Installation
1- Remove factory installed screws from both sides of rack chassis (Fig. 4a).
2- Install mounting brackets (A) on the left and right side of rack chassis using the
two (2) flat head screws (B) (included) (Fig. 4b).
3- Place unit into desired EIA 19” rack position and secure with mounting screws (not included) (Fig. 4c).
Fig. 6
Fig. 5
Shelf Installation
1- Position and affix rubber pads (C) (included) at each
corner on the bottom of the unit (Fig. 6).
2- Place unit in desired location.
B
A
C
Mounting Hardware (Included):
BA
Fig. 5b
Fig. 5a
C
A
B
Fig. 4b
Fig. 4a Fig. 4c
Top Top Top
Front
Left
Front
Left Front Left
Left Side
Rubber Pad
Two (2) mounting brackets
Six (6) flat head screws
for mounting brackets.
Four (4) rubber pads.
Remove

- 8 - Vertiline8i/Vertiline16i
