Vertiv Liebert CRV Installation and maintenance instructions

Liebert® CRV Row
BasedCoolingSystem
Installer/User Guide
600 mm and 300 mm Wide

Vertiv | Liebert® CRV Installer/User Guide
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent section of this
manual to see if the issue can be resolved by following outlined procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.
The information contained in this document is subject to change without notice
and may not be suitable for all applications. While every precaution has been
taken to ensure the accuracy and completeness of this document, Vertiv
assumes no responsibility and disclaims all liability for damages result from
use of this information or for any errors or omissions.
Vertiv recommends installing a monitored fluid detection system that is wired
to activate the automatic closure of field-installed coolant fluid supply and
return shut off valves, where applicable, to reduce the amount of coolant fluid
leakage and consequential equipment and building damage. Refer to local
regulations and building codes relating to the application, installation, and
operation of this product. The consulting engineer, installer, and/or end user is
responsible for compliance with all applicable laws and regulations relation to
the application, installation, and operation of this product.
The products covered by this instruction manual are manufactured and/or sold
by Vertiv. This document is the property of Vertiv and contains confidential
and proprietary information owned by Vertiv. Any copying, use, or disclosure of
it without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered trademarks of
the respective companies. Any questions regarding usage of trademark names
should be directed to the original manufacturer.
Vertiv Liebert® CRV Installer/User Guide

TABLE OF CONTENTS
1 Important Safety Instructions 1
2 Nomenclature and Components 7
2.1 Model Number Nomenclature 7
2.2 Component Location 7
2.3 Cooling Configurations and Liebert® CRV Overview 8
3 Pre-installation PreparationandGuidelines 9
3.1 Planning Dimensions 9
3.2 Unit Weights 9
4 Equipment Inspection and Handling 11
4.1 Packaging Material 12
4.2 Handling the Unit while Packaged 12
4.3 Unpacking the Export Shipped 600 mm(24 in.) Unit 12
4.4 Unpacking the Domestic Shipped 600 mm(24 in.) Unit 13
4.5 Removing 600 mm (24 in.) Units from the Pallet 14
4.6 Unpacking the Export Shipped 300 mm(24 in.) Unit 16
4.7 Unpacking the Domestic Shipped 300 mm(12 in.) Unit 17
4.8 Removing 300 mm (12 in.) Units from the Pallet 18
5 Installing in Enclosure Row 21
5.1 Adjusting Base Supports/Leveling Feet 21
5.2 Optional Tie Down Brackets for 300 mm (12 in.) Units 23
5.2.1 What’s Included 23
5.2.2 Tools Required 24
5.2.3 Installing Tie Down Brackets on300 mm(12 in.) andonCabinetsofDifferentHeights 24
5.2.4 Installing Tie Down Brackets on300 mm(12 in.) andonCabinetsoftheSameHeight 26
6 Piping and Refrigerant Requirements 27
6.1 Drain and Humidifier Fluid Piping 28
6.1.1 Humidifier Water Supply Line Requirements 28
6.1.2 Condensate Pump Drain Line Requirements 29
6.1.3 Condensate Pump Drain Piping for300 mm(12 in.) Models 30
6.1.4 FieldInstalled, Gravity Fed Drain Line Requirements 36
6.2 Refrigerant Piping and Charging 41
6.2.1 Refrigerant Piping Guidelines forAir CooledSystems 42
6.3 Piping Guidelines for Liebert® MC Condensers 43
6.3.1 Piping Layout and Condenser Positioning 44
6.3.2 Top or Bottom Connection for Refrigerant Piping onAir Cooled Units 45
6.3.3 Refrigerant Line Sizes and Equivalent Lengths 46
6.3.4 Refrigerant Charge Requirements for Air Cooled Systems 47
6.3.5 Additional Oil Requirements for Digital ScrollCompressors 50
6.3.6 Evacuation, Leak Testing, and Charging Air Cooled Systems without Receivers 52
Vertiv™ | Liebert® CRV Installer/User Guide | i

6.3.7 Evacuation, Leak Testing, and Charging Air Cooled Systems withLiebert® Lee-Temp Flooded Condenser
Head PressureControlSystem 56
6.3.8 Superheat and Refrigerant Charge Optimization 58
6.4 Water/Glycol Loop Piping Guidelines 59
6.4.1 Glycol Mixture 62
6.4.2 Water/Glycol Cooled Piping Connections 62
6.4.3 Leak Checking for Unit and Field Installed Piping 64
6.5 Chilled Water Loop Piping 64
7 Electrical Connections 67
7.1 Power Supply Cable Connection Guidelines 67
7.2 Wiring Connection Guidelines 67
7.3 Electrical Field Connections Descriptions 68
7.3.1 Locating the Serial Tags and Removing the Electrical Panel on 600mm (24 in.) Units 68
7.3.2 Cable Entry Points on 600mm (24in.) Units 71
7.3.3 Protective Features of Electrical Heaters—600-mm (24-in.) Units 72
7.3.4 Accessing the Electrical Panel on 300 mm (12 in) Units 72
7.3.5 Releasing the Electric Panel Lock 73
7.4 Protective Features of the Electronically Commutated (EC) Fans—All Models 74
8 Humidifier 600 mm (24 in.) Units Only 77
8.1 Principal of Operation 77
8.2 Connecting Water Supply to the Humidifier 78
8.3 Humidifier Startup and Operation 79
8.3.1 Low Water Conductivity 79
8.4 Humidifier Canister Replacement 79
8.4.1 Removing the Old Canister 80
8.4.2 Mandatory Cleaning of the Drain Valve 81
8.4.3 Installing the New Canister 82
8.5 Humidifier Maintenance during Extended Shutdown 83
8.5.1 Humidifier Troubleshooting 83
8.5.2 Humidifier Troubleshooting Steps 85
9 Startup 87
9.1 Checks to Perform after Startup 88
9.2 Automatic Restart 89
9.3 Chilled Water Valve— All Chilled Water Models 90
9.4 Adjust Baffles to Direct Air Properly 91
9.4.1 Adjusting Baffles—600mm (24in.) 92
9.4.2 Adjusting Blocker Plate—600mm (12in.) 93
9.4.3 Adjusting Baffles—300mm (12 in.) 94
10 Troubleshooting 97
11 Maintenance 101
11.1 Safety Instructions 101
11.2 Facility Fluid and Piping Maintenance forWaterandGlycolSystems 102
Vertiv™ | Liebert® CRV Installer/User Guide | ii

11.3 Glycol Solution Maintenance 102
11.4 Spare Parts 102
11.5 Maintenance Schedule 102
11.6 Thermostatic Expansion Valve (TXV) Maintenance 104
11.6.1 Determining Suction Superheat 104
11.6.2 Adjusting Superheat Setting with the TXV 105
11.7 Compressor Maintenance 105
11.7.1 Compressor Oil 105
11.7.2 Replacement Compressors 105
11.7.3 Rotalock Valve on Digital Scroll Compressors 106
11.7.4 Unloading Solenoid(s) on a Digital Scroll Compressor 106
11.7.5 Compressor Electrical Failure (Motor Burnout) 107
11.7.6 Compressor Mechanical Failure 107
11.7.7 Replacing a Compressor with Mechanical Failure 107
11.8 Inspect and Replace the Air Filters—600 mm (24in.) Models 108
11.9 Inspect and Replace the Air Filters—300mm (12in.) Models 110
11.10 Condensate Drain and Condensate Pump System Maintenance 111
11.10.1 Condensate Drain 111
11.10.2 Condensate Pump, Dual Float 111
11.11 Air-Cooled Condenser and Drycooler Maintenance 112
11.12 Electric Reheat Maintenance 112
11.13 Fan Replacement 113
11.13.1 Replacing a Fan in 600mm (24in.) Models 113
11.13.2 Replacing a Fan in 300mm (12in.) Models 114
11.14 Considerations when Dismantling the Unit 115
11.15 F-Gas Regulation (EC) No. 842/2006 116
12 Preventive Maintenance Worksheet 119
Appendices 125
Appendix A: Technical Support and Contacts 125
Appendix B: Model Number Nomenclature Detail 127
Appendix C: Submittal Drawings 131
Vertiv™ | Liebert® CRV Installer/User Guide | iii

Vertiv™ | Liebert® CRV Installer/User Guide | iv

1 Important Safety Instructions
SAVE THESE INSTRUCTIONS
This manual contains important safety instructions that should be followed during the installation and maintenance of the
Liebert® CRV. Read this manual thoroughly before attempting to install or operate this unit.
Only qualified personnel should move, install or service this equipment.
Adhere to all warnings, cautions, notices and installation, operating and safety instructions on the unit and in this manual.
Follow all installation, operation and maintenance instructions and all applicable national and local building, electrical and
plumbing codes.
Any operation that requires opening doors or equipment panels must be carried out only by properly-trained and qualified
personnel.
To identify the unit model and serial number for assistance or spare parts, locate the identification label on the unit. The
label is inside the door on 600 mm (24 in.) units and at the electrical box on 300 mm (12 in.) units.
A warning label on the front and back panels reminds users that:
•The Liebert® CRV restarts automatically
•The main switch must be opened before opening the internal compartments for any operation.
WARNING! Arc flash and electric shock hazard. Open all local and remote electric power-supply disconnect
switches, verify with a voltmeter that power is Off and wear appropriate, OSHA-approved personal protective
equipment (PPE) per NFPA 70E before working within the electric control enclosure. Failure to comply can
cause serious injury or death. Customer must provide earth ground to unit, per NEC, CEC and local codes, as
applicable. Before proceeding with installation, read all instructions, verify that all the parts are included and
check the nameplate to be sure the voltage matches available utility power. The Liebert® controller does not
isolate power from the unit, even in the “Unit Off” mode. Some internal components require and receive
power even during the “Unit Off” mode of the controller. The only way to ensure that there is NO voltage
inside the unit is to install and open a remote disconnect switch. Refer to unit electrical schematic. Follow all
local codes.
Installation, service, and maintenance work must be performed only by properly trained and qualified
personnel and in accordance with applicable regulations and manufacturers’ specifications. Opening or
removing the covers to any equipment may expose personnel to lethal voltages within the unit even when it is
apparently not operating and the input wiring is disconnected from the electrical source.
WARNING! Risk of over pressurization of the refrigeration system. Can cause explosive discharge of high
pressure refrigerant, loss of refrigerant, environmental pollution, equipment damage, injury, or death. This
unit contains fluids and gases under high pressure. Use extreme caution when charging the refrigerant
system. Do not pressurize the system higher than the design pressure marked on the unit's nameplate.
1 Important Safety Instructions 1
Vertiv Liebert® CRV Installer/User Guide

WARNING! Risk of contact with high speed rotating fan blades. Can cause serious injury or death. Open all
local and remote electric power-supply disconnect switches, verify with a voltmeter that power is off, and
verify that all fan blades have stopped rotating before working in the unit cabinet or on the fan assembly. Fan
motor controls can maintain an electric charge for 10 minutes after power is disconnected. If control voltage
is applied, the fan motor can restart without warning after a power failure.
WARNING! Risk of top-heavy unit falling over. Improper handling can cause equipment damage, injury or
death. Read all of the following instructions and verify that all lifting and moving equipment is rated for the
weight of the unit before attempting to move, lift, remove packaging from or prepare the unit for installation.
Unit weights are specified in Table 3.2 on page9
WARNING! Risk of unsecured unit rolling off pallet. Can cause equipment damage, injury or death. The unit is
on casters. Ensure that the pallet is located on a flat surface before loosening the hardware securing the to
its shipping pallet.
WARNING! Risk of hair, clothing and jewelry entanglement with high speed rotating fan blades. Can cause
equipment damage, serious injury or death. Keep hair, jewelry and loose clothing secured and away from
rotating fan blades during unit operation.
WARNING! Risk of contact with extremely hot and/or cold surfaces. Can cause injury. Verify that all
components have reached a temperature that is safe for human contact or wear appropriate, OSHA-approved
PPE before working within the electric connection enclosures or unit cabinet. Perform maintenance only
when the system is de-energized and component temperatures have become safe for human contact.
WARNING! Risk of improper wiring, piping, moving, lifting and handling. Can cause equipment damage,
serious injury or death. Installation and service of this equipment should be done only by qualified personnel
who have been specially trained in the installation of air conditioning equipment and who are wearing
appropriate, OSHA-approved PPE.
WARNING! Risk of improper wire sizing/rating and loose electrical connections. Can cause overheated wire
and electrical connection terminals resulting in smoke, fire, equipment and building damage, injury or death.
Use correctly sized copper wire only and verify that all electrical connections are tight before turning power
On. Check all electrical connections periodically and tighten as necessary.
WARNING! Risk of humidifier canister meltdown, smoke and fire. Can cause fire suppression system
activation, fire and smoke alarm activation, building evacuation, dispatching of fire and rescue equipment
and personnel and water leaks resulting in expensive equipment or building damage, injury or death. Check
steam generating humidifier electrode plugs to ensure that they are pressed firmly onto pins. Loose
connections will cause overheating of cylinder and plugs.
1 Important Safety Instructions
2
Vertiv Liebert® CRV Installer/User Guide

CAUTION: Risk of contact with sharp edges, splinters, and exposed fasteners. Can cause injury. Only
properly trained and qualified personnel wearing appropriate, OSHA-approved PPE should attempt to move,
lift, remove packaging from or prepare the unit for installation.
CAUTION: Risk of improper moving, lifting and handling. Can cause equipment damage or injury. Only
properly trained and qualified personnel should work on this equipment. Condenser fan modules weigh in
excess of 125 lb (56.7 kg). Use proper lifting techniques and wear appropriate, OSHA-approved PPE to avoid
injury and dropping the fan module during removal. Equipment used in handling/lifting, and/or installing the
fan assembly must meet OSHA requirements. Use handling/lifting equipment rated for the weight of the fan
assembly. Use ladders rated for the weight of the fan assembly and technicians if used during installation.
Refer to handling/lifting, and/or installation equipment operating manual for manufacturer's safety
requirements and operating procedures.
CAUTION: Risk of exposure to harmful noise levels. Can cause hearing injury or loss. Depending on the
installation and operating conditions, a sound pressure level greater than 70dB(A) may arise. Take
appropriate technical safety measures. Operating personnel must wear appropriate, OSHA-approved PPE
and observe all appropriate hearing protection safety requirements.
CAUTION: Risk of excessive refrigerant line pressure. Can cause tubing and component rupture resulting in
equipment damage and personal injury. Do not close off the refrigerant line isolation valve for repairs unless
a pressure-relief valve is field installed in the line between the isolation valve and the check valve. The
pressure relief valve must be rated 5% to 10% higher than the system design pressure. An increase in
ambient temperature can cause the pressure of the isolated refrigerant to rise and exceed the system design
pressure rating (marked on the unit nameplate).
NOTICE
Risk of improper power supply connection. Can cause equipment damage and loss of warranty coverage.Prior
to connecting any equipment to a main or alternate power source (for example: backup generator systems) for
startup, commissioning, testing, or normal operation, ensure that these sources are correctly adjusted to the
nameplate voltage and frequency of all equipment to be connected. In general, power source voltages should
be stabilized and regulated to within ±10% of the load nameplate nominal voltage. Also, ensure that no three
phase sources are single phased at any time.
NOTICE
Risk of oil contamination with water. Can cause equipment damage.
Liebert® CRV systems require the use of POE (polyolester) oil. POE oil absorbs water at a much faster rate
when exposed to air than previously used oils. Because water is the enemy of a reliable refrigeration system,
extreme care must be used when opening systems during installation or service. If water is absorbed into the
POE oil, it will not be easily removed and will not be removed through the normal evacuation process. If the oil
is too wet, it may require an oil change. POE oils also have a property that makes them act as a solvent in a
refrigeration system. Maintaining system cleanliness is extremely important because the oil will tend to bring
any foreign matter back to the compressor.
1 Important Safety Instructions 3
Vertiv Liebert® CRV Installer/User Guide

NOTICE
Risk of improper refrigerant charging. Can cause equipment damage.
Refrigerant charge must be weighed into air-cooled compressorized systems before they are started. Starting
scroll and digital scroll compressors without proper refrigerant charging can cause the compressors to operate
at less than 5°F (–15°C) evaporator temperature and at less than 20psig (138kPa). Operation for extended
periods at less than 20psig (138kPa) can cause premature compressor failure.
NOTICE
Risk of clogged or leaking drain lines and leaking water supply lines. Can cause equipment and building
damage.
This unit requires a water drain connection. Drain lines must be inspected at startup and periodically, and
maintenance must be performed to ensure that drain water runs freely through the drain system and that lines
are clear and free of obstructions and in good condition with no visible sign of damage or leaks. This unit may
also require an external water supply to operate.
Improper installation, application and service practices can result in water leakage from the unit. Water
leakage can result in catastrophic and expensive building and equipment damage and loss of critical data
center equipment.
Do not locate unit directly above any equipment that could sustain water damage.
We recommend installing a monitored fluid detection system to immediately discover and report coolant fluid
system and condensate drain line leaks.
NOTICE
Risk of piping system corrosion and freezing fluids. Can cause leaks resulting in equipment and very expensive
building damage. Cooling coils, heat exchangers and piping systems are at high risk of freezing and premature
corrosion. Fluids in these systems must contain the proper antifreeze and inhibitors to prevent freezing and
premature coil, heat exchanger and piping corrosion. The water or water/glycol solution must be analyzed by a
competent local water treatment specialist before start up to establish the inhibitor and antifreeze solution
requirement and at regularly scheduled intervals throughout the life of the system to determine the pattern of
inhibitor depletion.
The complexity of water/glycol solution condition problems and the variations of required treatment programs
make it extremely important to obtain the advice of a competent and experienced water treatment specialist
and follow a regularly scheduled coolant fluid system maintenance program.
Water chemistry varies greatly by location, as do the required additives, called inhibitors, that reduce the
corrosive effect of the fluids on the piping systems and components. The chemistry of the water used must be
considered, because water from some sources may contain corrosive elements that reduce the effectiveness of
the inhibited formulation. Sediment deposits prevent the formation of a protective oxide layer on the inside of
the coolant system components and piping. The water/coolant fluid must be treated and circulating through
the system continuously to prevent the buildup of sediment deposits and or growth of sulfate reducing
bacteria.
Proper inhibitor maintenance must be performed in order to prevent corrosion of the system. Consult glycol
manufacturer for testing and maintenance of inhibitors.
1 Important Safety Instructions
4
Vertiv Liebert® CRV Installer/User Guide

Commercial ethylene glycol, when pure, is generally less corrosive to the common metals of construction than
water itself. It will, however, assume the corrosivity of the water from which it is prepared and may become
increasingly corrosive with use if not properly inhibited.
We recommend installing a monitored fluid detection system that is wired to activate the automatic closure of
field installed coolant fluid supply and return shutoff valves to reduce the amount of coolant-fluid leakage and
consequential equipment and building damage. The shutoff valves must be sized to close off against the
maximum coolant fluid system pressure in case of a catastrophic fluid leak.
NOTICE
Risk of frozen pipes and corrosion from improper coolant mixture. Can cause water leaks resulting in
equipment and building damage.
When the cooling unit or piping may be exposed to freezing temperatures, charge the system with the proper
percentage of glycol and water for the coldest design ambient temperature. Automotive antifreeze is
unacceptable and must NOT be used in any glycol fluid system. Use only HVAC glycol solution that meets the
requirements of recommended industry practices.
NOTICE
Risk of no flow condition. Can cause equipment damage.
Do not leave the water/coolant fluid supply circuit in a no flow condition. Idle fluid allows the collection of
sediment that prevents the formation of a protective oxide layer on the inside of tubes. Keep unit switched On
and water/coolant fluid-supply circuit system operating continuously.
NOTICE
Risk of doorway/hallway interference. Can cause unit and/or structure damage. The unit may be too large to fit
through a doorway or hallway while on the skid. Measure the unit and passageway dimensions, and refer to the
installation plans prior to moving the unit to verify clearances.
NOTICE
Risk of improper water supply. Can reduce humidifier efficiency or obstruct humidifier plumbing.
Do not use completely demineralized water with this unit. The water must contain minerals for the electrode
principle to work.
Do not use a hot water source. It will cause deposits that will eventually block the fill valve opening.
NOTICE
Risk of water backing up in the drain line. Leaking and overflowing water can cause equipment and building
damage.
Do not install an external trap in the drain line. This line already has a factory installed trap inside the cabinet
(except for 300 mm (12 in.)) Chilled water models). Installation of a second trap will prevent drain water flow
and will cause the water to overflow the drain pan.
This line may contain boiling water. Use cooper or other material that is rated for handling boiling water for the
drain line. Sagging condensate drain lines may inadvertently create an external trap.
1 Important Safety Instructions 5
Vertiv Liebert® CRV Installer/User Guide

NOTICE
Risk of doorway/hallway interference. Can cause unit and/or structure damage. The unit may be too large to fit
through a doorway or hallway while on the skid. Measure the unit and passageway dimensions, and refer to the
installation plans prior to moving the unit to verify clearances.
NOTICE
Risk of damage from forklift. Can cause unit damage. Keep tines of the forklift level and at a height suitable to
fit below the skid and/or unit to prevent exterior and/or underside damage.
NOTICE
Risk of improper storage. Can cause unit damage.
Keep the unit upright, indoors and protected from dampness, freezing temperatures and contact damage.
NOTICE
Risk of release of hazardous substances into the environment. Can cause environmental pollution and violation
of environmental regulations.
The Liebert® CRV contains substances and components hazardous for the environment (electronic
components, refrigerating gases and oils). At the end of its useful life, the Liebert® CRV must be dismantled by
specialized refrigerating technicians. The unit must be delivered to suitable centers specializing in the
collection and disposal of equipment containing hazardous substances.
NOTE: The Liebert indoor cooling unit has a factory installed high pressure safety switch in the high side refrigerant
circuit. Consult local building codes to determine whether the Liebert® MC Condensers without receivers will require
field provided pressure relief devices such as a fusible plug. A pressure relief valve is provided with Liebert® Lee-
Temp receivers.
Agency Listed
Standard 60 Hz units are CSA Certified to the harmonized U.S. and Canadian product safety standard CSA C22.2 No
236/UL 1995 for “Heating and Cooling Equipment” and are marked with the CSA c-us logo.
1 Important Safety Instructions
6
Vertiv Liebert® CRV Installer/User Guide

2 Nomenclature and Components
This section describes the model number for Liebert® CRV units and components.
2.1 Model Number Nomenclature
The tables describe the 25 digitconfigurationnumber. The 14 digit model number consists of the first 10 digits and last 4
digits of the configuration number.
For the full description of configuration and model number refer to Model Number Nomenclature Detail on page127 .
Model Number Digits 1 to 10 Model Details Model Number Digits 11
to 14
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
C R 0 2 0 R A 1 C 7 S H 1 8 1 1 E L 1 0 P A — — —
Digits 1-2 - Unit Family Digit 14 - Air Filter
Digits 3-5 - Nominal Capacity, kW Digit 15 - Water/Glycol Valve Type
Digit 6 - Row-Based, Unit Depth Digit 16 - Enclosure
Digit 7 - System Type Digit 17 - High Voltage Options
Digit 8 - Fan Type Digit 18 - Option Package
Digit 9 - Power Supply Digit 19 - Liebert® IntelliSlot™ Housing
Digit 10 - Cooling System Digit 20 - Future Options
Digit 11 - Humidifier Digit 21 - Packaging With Ramp
Digit 12 - Control System Digit 22 - Special Features
Digit 13 - Reheat Digits 23-25 - Factory Configuration Number
2.2 Component Location
The unit component locations are described in the submittal documents included in the Submittal Drawings on page131 .
The following table lists the relevant documents by number and title.
Document Number Title
DPN003738 Component Location Diagram, 600mm (24in.) Models
DPN003583 Component Location Diagram, 300mm (12in.) Air Cooled Models
DPN003585 Component Location, 300mm (12in.) Water Glycol Cooled Models
DPN003584 Component Location, 300mm (12in.) Chilled Water Models
Table 2.1 Component Location Drawings
2 Nomenclature and Components 7
Vertiv Liebert® CRV Installer/User Guide

2.3 Cooling Configurations and Liebert® CRV Overview
The Liebert®CRV is a precision cooling unit available in compressorized (air, water, or glycol cooled) and chilled water
configurations to be installed within a row of high density computing racks in a “hotaisle-coldaisle” configuration.
Air enters the rear of the CRV from the hot aisle, is filtered, cooled and conditioned, then discharged into the cold aisle. The
CRV provides all the necessary functions of a standard Thermal Management unit, including cooling, heating,
humidification, dehumidification, air filtration, condensate management, temperature control, alarm monitoring and data
communication. (The 300 mm [12 in.] models do not provide heating, humidification or dehumidification.) The CRV is
optimized for maximum cooling capacity in a minimal footprint.
The Liebert® CRV 300 series and 600 series Thermal Management units are meant for location within a row of heat
generating IT equipment racks.
The extremely energy efficient components of the CRV are managed by the Liebert® iCOM™ control system. The iCOM
control monitors the environment in real time with rack inlet sensors on the cooled by the in-row CRV. The information
gathered allows optimization of performance and energy efficiency.
All operations and sensor data can be reported remotely via a variety of communication protocols, providing a built-in,
rack-temperature monitoring system.
The supply-air baffle directs the air leaving the CRV to the racks, maximizing its effectiveness, reducing the chance for hot
spots, and improving overall system efficiency. The angle and spacing of the baffle vanes series are optimized through CFD
modeling, laboratory testing and real world installations.
All service and maintenance is performed through the front and rear of the unit, including all component replacement. All
piping and electrical connections are made through the top or bottom of the unit.
Series Width Cooling Type Nominal Cooling Capacity, kW Input Power 60 Hz
600
24 in.
(600 mm)
Air
20
208 V/3 ph
460 V/3 ph
Water/Glycol
Air
35
Water/Glycol
Chilled Water 40
300
12 in.
(300 mm)
Air 19
208-230 V/3 ph
460 V/3 ph-Wye
Chilled Water 32
208-230 V/1 ph
208-230 V/3 ph
460 V/3 ph-Wye
120 V/1 ph
Water/Glycol 19
208-230 V/3 ph
460 V/3 ph-Wye
Table 2.2 CRV Configurations
2 Nomenclature and Components
8
Vertiv Liebert® CRV Installer/User Guide

3 Pre-installation PreparationandGuidelines
NOTE: Before installing unit, determine whether any building alterations are required to run piping, wiring and duct
work. Follow all unit dimensional drawings and refer to the submittal engineering dimensional drawings of individual
units for proper clearances.
Refer to Model Number Nomenclature on page7 and the appropriate submittal drawings, to determine the type of system
being installed and anticipate building alterations, piping and duct work needed.
The unit dimensions, pipe connection locations, and piping schematics are described in the submittal documents included
in the Submittal Drawings on page131 .
•Verify that the floor is level, solid and sufficient to support the unit. See Unit Weights below for unit weights.
•Confirm that the room is properly insulated and has a sealed vapor barrier.
•For proper humidity control, keep outside or fresh air to an absolute minimum (less than 5% of total air
circulated in the room).
•Do not install a Liebert® CRV in an alcove or at the end of a long, narrow room.
•Install the units as close as possible to the largest heat load.
•Allow at least the minimum recommended clearances for maintenance and service. See the appropriate
submittal drawings for dimensions.
•We recommend installing an under floor leak detection system. Contact your Vertiv representative for
information.
3.1 Planning Dimensions
The unit, floor stand, and plenum dimensions are described in the submittal documents included in the Submittal Drawings
on page131 .
The following table lists the relevant documents by number and title.
Document Number Title
DPN001791 Cabinet Dimensional Data 600 mm (24 in.) Models
DPN002807 Cabinet Dimensional Data 300 mm (12 in,) Models
Table 3.1 Dimension Planning Drawings
3.2 Unit Weights
Model No.
Domestic Packaging, lb (kg) Export Packaging, lb (kg)
Air Water/Glycol Chilled Water Air Water/Glycol Chilled Water
CR019 649 (294) 687 (311) — 721 (327) 782 (355) —
CR032 — — 560 (254.0) — — 683 (309.8)
CR020 846 (384) 879 (399) — 953 (432) 986 (447) —
CR035 912 (414) 956 (434) — 1019 (462) 1063 (482) —
CR040 — — 835 (379) — — 942 (427)
Table 3.2 Shipping Weights
3 Pre-installation PreparationandGuidelines 9
Vertiv Liebert® CRV Installer/User Guide

3 Pre-installation PreparationandGuidelines
10
This page intentionally left blank
Vertiv Liebert® CRV Installer/User Guide

4 Equipment Inspection and Handling
WARNING! Risk of top-heavy unit falling over. Improper handling can cause equipment damage, injury or
death. Read all of the following instructions and verify that all lifting and moving equipment is rated for the
weight of the unit before attempting to move, lift, remove packaging from or prepare the unit for installation.
Unit weights are specified in Table 3.2 on page9
WARNING! Risk of contact with sharp edges, splinters, and exposed fasteners. Can cause injury. Only
properly trained and qualified personnel wearing appropriate, OSHA-approved PPE should attempt to move,
lift, remove packaging from or prepare the unit for installation.
NOTICE
Risk of passageway interference. Can cause unit and/or structure damage. The unit may be too large to fit
through a passageway while on or off the skid. Measure the unit and passageway dimensions, and refer to the
installation plans prior to moving the unit to verify clearances.
NOTICE
Risk of damage from forklift. Can cause unit damage. Keep tines of the forklift level and at a height suitable to
fit below the skid and/or unit to prevent exterior and/or underside damage.
NOTICE
Risk of improper storage. Can cause unit damage.Keep the unit upright, indoors and protected from dampness,
freezing temperatures and contact damage.
Upon arrival of the unit and before unpacking:
•Verify that the labeled equipment matches the bill of lading.
•Carefully inspect all items for visible or concealed damage.
•Report damage immediately to the carrier and file a damage claim with a copy sent to Vertiv or to your sales
representative.
•For initial access, use a 7/32 in. Allen wrench for panel removal.
Equipment Recommended for Handling the Unit:
•Forklift
•Pallet jack
•Piano jacks
•Slings
•Spreader bars
4 Equipment Inspection and Handling 11
Vertiv Liebert® CRV Installer/User Guide

4.1 Packaging Material
All material used to package this unit is recyclable. Please save for future use or dispose of the material appropriately.
4.2 Handling the Unit while Packaged
Transport the unit with a forklift or pallet jack.
When using a forklift or pallet jack:
•Make sure that the forks (if adjustable) are spread to the widest allowable distance that will fit under the skid.
•Make sure the fork length is suitable for the skid length. Skid length is 60in (1524mm)
•When moving the packaged unit, do not lift the unit any higher than 2to4in. (51to102 mm). All personnel
except those moving the unit must be kept 12ft (3.7m) or more from the unit while it is being moved.
•If the unit must be lifted higher than 4in. (102 mm), all personnel not directly involved in moving the unit must
be 20ft (5m) or farther from the unit.
4.3 Unpacking the Export Shipped 600 mm(24 in.) Unit
1. Remove the metal clips (12 places typical) that secure the top panel of the crate to the side panels, see Figure
4.1 on the facing page .
2. Use a Phillips head screw driver to remove all the wood screws (34 places typical) that secure the side panels
together and to the pallet, see Figure 4.1 on the facing page .
3. To remove the remaining packaging, start with Step 1 , of Unpacking the Domestic Shipped 600 mm(24 in.)
Unit on the facing page .
4 Equipment Inspection and Handling
12
Vertiv Liebert® CRV Installer/User Guide

Figure 4.1 Metal Clips and Wood Screws on Crate
Item Description
1 Metal clips, typical 12 places
2 Wood screws, minimum 34 places
4.4 Unpacking the Domestic Shipped 600 mm(24 in.) Unit
1. Use a 9/16 in. socket drive or wrench to remove the lag screws (4 places typical) that secure the ramp to the
pallet, see Figure 4.2 on the next page . Set the ramps aside for use later when preparing move the unit from
the pallet.
2. Remove the exterior packaging from around the unit
NOTE: The bag may remain in place to protect from dust and to protect the unit panels, or it may be removed for
immediate installation.
3. Remove the bag from the unit when ready to move off the pallet and install the unit. See Removing 600 mm
(24 in.) Units from the Pallet on the next page .
4 Equipment Inspection and Handling 13
Vertiv Liebert® CRV Installer/User Guide

Figure 4.2 Lag Screws that Secure Ramps
4.5 Removing 600 mm (24 in.) Units from the Pallet
1. Remove front panel, see Figure 4.3 on the facing page
•Open the top panel door (with controller display).
•Using a 8 mm hex head or T30 Torx screwdriver, remove the screws securing the bottom front panel
assembly, and set aside until instructed to re attach.
•Close and latch the top panel door.
2. Lower the 4 leveling feed to touch the pallet deck as shown in Figure 4.3 on the facing page . Open the rear,
hinged door to access the rear leveling feet.
3. Using a 13 mm socket-drive or wrench, remove the screws that secure the shipping brackets to the side of the
unit, 3 each side, see Figure 4.3 on the facing page .
4. Using a 9/16 in. socket drive or wrench, remove the lag screws that secure the shipping brackets to the pallet, 4
each side, see Figure 4.3 on the facing page .
5. Adjust the 4 leveling feet equally, to raise the unit off the shipping blocks, and remove the blocks, see Figure
4.3 on the facing page .
4 Equipment Inspection and Handling
14
Vertiv Liebert® CRV Installer/User Guide
