Firmware Update
From time to time Vescent will issue new releases of firmware for the SLICE products. Below are
instructions on upgrading the SLICE-QT firmware. Please follow these instructions carefully.
Document Last Updated on 2021/08/26 14:26
Links
SLICE-QT Quick Start
SLICE-QT Manual
SLICE-QT API
SLICE-QT web page
Firmware download ftp site
Firmware Update Instructions
For SLICE-QT firmware versions 1.29 and lower, updating the firmware will reset
all stored parameters (PID loop parameters, etc.). Before beginning a firmware
update, manually record all settings for all channels. Versions 1.30 and higher will
automatically store this information.
Connecting to Host PC
Create a folder on your PC named C:\Vescent\SLICE-QT\SLICE-QT-0001.1.
Copy the latest firmware update .zip file from the github ftp website into the folder created in2.
step 1. It will contain the latest firmware and GUI revisions.
The zipped file will contain a .dfu file (System Controller firmware) and will be named
SystemController-x-x.dfu where x-x will be the version number of the firmware and a .hex file
named 90-00001-upgrade-QT-x-x.hex where x-x will be the version number of the firmware.
Intentionally left blank.3.
Determine the COM port number for the SLICE unit’s USB connection. (You can skip this step if4.
you already know which COM port is assigned to your SLICE unit.)
If the SLICE unit’s USB cable is connected to the PC, unplug it.1.
Open a Windows Command Prompt console2.
Press the Windows Start Button1.
Type cmd.exe in the box that says “Search programs and files”2.
Press the <Enter> key3.
At the command prompt type “powershell” and press the <Enter> key4.
You should see a window like the one shown in figure ## with PS preceding the5.
command prompt

Last update: 2021/08/26 14:26 slice:qt:firmware https://vescent.com/manuals/doku.php?id=slice:qt:firmware&rev=1551400345
https://vescent.com/manuals/ Printed on 2022/04/16 22:57
Fig. ##: Power Shell Command Prompt
Highlight the following text and use <CTRL> + <C> to copy it to the Windows6.
clipboard: [System.IO.Ports.SerialPort]::getportnames()
Paste it into the Command Prompt window by Right Clicking anywhere in the7.
window and selecting Paste
Press <Enter>8.
You should see a list of all your machine’s COM ports as seen in figure ##.9.
Fig. ##: COM Port Listing
Connect the USB cable from the PC to the SLICE and power on the SLICE10.
Press the <Up-Arrow> key which will repeat the command from step VI above and11.
press <Enter>. The COM port assigned to the SLICE should now appear in the list.
(NOTE: COM11 is the SLICE COM port in the example below but it may be a different
number on your machine.)

2022/04/16 22:57 3/7 Firmware Update
Product Manuals - https://vescent.com/manuals/
Fig. ##: COM Port Listing with SLICE-QT port
If you have not already done so, connect a USB cable (type B) from the back of the SLICE unit to5.
your PC
Do this step only the first time you use a new PC to do the upgrade:6.
Power OFF the SLICE-QT1.
Depress the blue button within the access hole on the lower left front side of the SLICE2.
case, located just behind the red valance as seen in figure ##.
Fig. ##: Blue button .
While holding the blue button, power on the SLICE. You should see a blank white screen3.
on the display.
Wait for Windows to acknowledge the device found and install the drivers.4.
Power Off the SLICE-QT5.
Power On the SLICE-QT7.
Copy the latest version of PC Host GUI from the FTP site (see above)8.
Copy SLICE-QT-Windows.exe to your local PC1.
Double click on SLICE-QT-Windows.exe to launch the application. You should see the2.
window in figure ##.

Last update: 2021/08/26 14:26 slice:qt:firmware https://vescent.com/manuals/doku.php?id=slice:qt:firmware&rev=1551400345
https://vescent.com/manuals/ Printed on 2022/04/16 22:57
Fig. ##: Home Screen of PC-resident GUI
Click on the Settings icon to get to the window shown in figure ##.9.
Fig. ##: Settings screen when viewed by GUI
Click on the ‘OFF’ button below COM Port. You should see a menu similar to the one shown10.
figure ##. NOTE: The COM port numbers may differ from those shown below.
Fig. ##: COM port selection
Click on the last COM port in the list (COM11 in this example). The window in figure ## should11.
appear if the connection is successful.

2022/04/16 22:57 5/7 Firmware Update
Product Manuals - https://vescent.com/manuals/
Fig. ##: Ready to upgrade
Firmware Update
Click on the Upgrade button below the version numbers to see figure ##. Note that multiple1.
SLICE-QT-000X folders can be created on your hard drive in the C:Vescent\SLICE-QT folder. The
upgrader picks the one with the highest number (SLICE-QT-0002 in the example shown below).
Fig. ##
Click Continue to reach the screen shown in figure ##.2.
Follow the instructions on this screen.1.
NOTE: The blue button is behind the small hole on the lower left side of the SLICE just
behind the red valance.

Last update: 2021/08/26 14:26 slice:qt:firmware https://vescent.com/manuals/doku.php?id=slice:qt:firmware&rev=1551400345
https://vescent.com/manuals/ Printed on 2022/04/16 22:57
Fig. ##
Click Continue to start the upgrade process.3.
NOTE: During the upgrade process, the SLICE will reset itself after the System Controller code is
loaded.
DO NOT attempt to power off or use the SLICE box yet. The QT firmware upgrade still needs to
finish.
During the second part of the update (QT firmware portion), the message in figure ## will be4.
displayed on the SLICE touch screen.
Fig. ##
When the update is complete, the SLICE unit will reset and the home screen will be displayed on5.
the touch screen.
The PC-resident SLICE-QT GUI should display the message in figure ##.

2022/04/16 22:57 7/7 Firmware Update
Product Manuals - https://vescent.com/manuals/
Fig. ##
Verify the firmware versions on the SLICE Settings screen.6.
Close GUI and restart after completion.7.
Please follow firmware update instructions
carefully.
During the upgrade, do not turn off,
disconnect, or unplug the SLICE unless
instructed to do so.
