Vetek OCS-SL Series User manual

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Web www.vetek.se
Email [e-mail]
TABLE OF CONTENTS
MANUAL OCS-SL
User manual
Manual_OCS-SL_V1

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
SAFE OPERATION GUIDE--------------------------------------------------------------------------------2
CHAPTER 1 FEATURES AND SPECIFICATION--------------------------------------------------3
1. Features-----------------------------------------------------------------------------------------------------3
2..Main technical data---------------------------------------------------------------------------------------3
3. Specification-----------------------------------------------------------------------------------------------4
4. Appearance illustration-----------------------------------------------------------------------------------4
5. Power supply----------------------------------------------------------------------------------------------5
CHAPTER 2 DISPLAY------------------------------------------------------------------------------------5
1 Led display-------------------------------------------------------------------------------------------------5
2 Indicator lamp----------------------------------------------------------------------------------------------5
3 Key-----------------------------------------------------------------------------------------------------------5
4 Remote control---------------------------------------------------------------------------------------------6
CHAPTER 3 OPERATION GUIDE--------------------------------------------------------------------7
1 Turn on/off-------------------------------------------------------------------------------------------------7
2 Zero---------------------------------------------------------------------------------------------------------7
3 Tare----------------------------------------------------------------------------------------------------------8
4 Hold---------------------------------------------------------------------------------------------------------8
5 Accumulation----------------------------------------------------------------------------------------------8
6 Accumulation Search-------------------------------------------------------------------------------------8
7 Accumulation Clear---------------------------------------------------------------------------------------9
8 Battery Voltage---------------------------------------------------------------------------------------------9
9 Brightness---------------------------------------------------------------------------------------------------9
10 Zero Point-------------------------------------------------------------------------------------------------9
11 Unit---------------------------------------------------------------------------------------------------------9
CHAPTER 4 PARAMETER SETTING & CALIBRATION-----------------------------------------9
1. Parameter setting----------------------------------------------------------------------------------------10
2. calibration------------------------------------------------------------------------------------------------12
CHAPTER 5 SIGNAL ILLUSTRATION---------------------------------------------------------------15
CHAPTER 6 TROUBLESHOOTING GUIDE--------------------------------------------------------16

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
SAFE OPERATION GUIDE
：
1. The capacity of crane scale have been showed on the overlay, Don’t make lifts beyond
rated capacity of the crane scale.
2. Operators should not maneuver a loaded crane scale over personnel.
3. The scale must be routinely checked for operation. Don’t operate if hook,
shackle,sling,cable, etc show any sign of defects or excessive wear.
4. If the scale is not going to be used for long time, recharging the battery every three months
to
preserve the life-span of the battery and recharge it before operation.
5. The battery charger is included in the scale package. Please use this charger, It’s normal
that the charger will become warm when the battery is charging.
6. Please note when the digits flash on the display, it means that the battery needs to be
recharged.

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
CHAPTER 1 FEATURES AND SPECIFICATION
1. Features
◆Multi-weighing units:
Kg, lb, N are selectable, generally kg are default unit.
◆Multi-function operation:
Tare，Zero，Auto zero tracking，Total，Hold，Overload warning and record, Calibration
through remote controller,etc functions.
◆User-friendly design:
Cast aluminium housing for maximum protection; Large red 5 digit LED display (digit height
30mm); Gravity compensation; Safety factor up to 4 times capacity; Battery Operated with
low battery indication; Automatic turn off , power-saving function.
2. Main technical data
Standard
According to OIML class III
Display
30mm (1.2’’) 5digits LCD/LED
Zero Range
4% F.S.
Tare Range
20% F.S.
Stable Time
≤10 seconds
Overload Indication
100% F.S. + 9e
Max. Safety Load
125% F.S.
Ultimate Load
400% F.S.
Battery Life
≥50 hours
Battery Type
Fully sealed Lead-Acid battery, 6V/4.5Ah
Adapter
DC9V/1000mA
Operating Temp.
- 10℃~ + 40℃
Operating Humidity
≤85% RH under 20℃
Remote Controller Distance
Min. 15m
Battery of Remote Controller
7# battery, 1.5V
ⅹ
2
3.Specification
MODEL
Max. capacity
(kg)
Min. weigh
(kg)
Division
(kg)
Total display
counts (n)
OCS-SL-2
2000
20
1
2000
OCS-SL-3
3000
20
1
3000
OCS-SL-5
5000
40
2
2500
OCS-SL-10
10000
100
5
2000

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
4.Appearance illustration
MODEL
A(mm)
B(mm)
C(mm
)
D(mm
)
E(mm)
H(mm)
N．W
OCS-SL-2
95
260
35
195
130
430
10.5kg
OCS-SL-3
95
260
45
195
130
460
11.5kg
OCS-SL-5
125
325
55
235
160
525
16.5kg
OCS-SL-10
140
325
65
235
160
660
27.5kg
OCS-SL-20
170
360
85
235
160
900
55kg
5.. Power supply
Battery: 6V/4.5Ah fully sealed Lead-Acid battery
Adapter: 9VDC/1000mA adapter
Current: the crane scale average current is about DC 100mA±10%, if battery charged, it can
be used for about 50hours.
Low battery warning: When the digits flash, it means the battery needs to be recharged. The
scale will power off automatically after 1 to 2 hours operation if the battery is not charged.
Please recharge the battery before operating the scale again.
Charging method: Turn off the crane scale, use adapter in the carton, the lamp on the back
cover will become orange when charging, and it will become red when the charging finish.
Generally, charging time should not less than 8hours, the crane scale have charging
protection, long time charging can’t damage the battery.

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
CHAPTER 2 DISPLAY
1. LED DISPLAY
30mm (1.2’’) 5digits LED/LCD
2. INDICATOR LAMP
a. TARE: TARE indicator
b. STB:STABLE indicator
c. CHARGE: CHARGE indicator
3. KEY
a. ON/OFF
1．Press ON/OFF three seconds，the crane scale turn on.
2．When turn on，Press ON/OFF three seconds，the crane scale turn off.
b. TARE
1 Hang sling or container on the hook, when the weight reading stable, press this key, the
digits display “0”, and “TARE” indicator switch on.
2．Put the goods into container, the scale will display goods net weight.
3．If move goods and container, the scale will display minus value of tare weight。
4. REMOTE CONTROLLER
Press any key on the remote controller, the indicator on the controller will flash.
Key function：
1．【ZERO】：
a. In weighing status, when crane scale switch on with no load on the hook, but there are
small digits on screen, press this key to obtain zero reading.
b. In parameter setting and calibration process, it used for set value up
2．【TARE】：
a. In weighing status, the function is equal to TARE on front panel

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
b. In parameter setting and calibration process, it used for move digit（the digit choosed
flash）
3．【SHIFT】：
a. In weighing situation, used for function shift, or used with other key to more function.
b. In parameter setting and calibration process, it used for confirm setting.
4．【CLEAR】：
a. In weighing status, it used to clear accumulation.
b. In parameter setting and calibration process, it used for set value down.
5．【ACCU】：
It used for accumulation function, details see Chapter3-5.
6．【F1】：
Function Key，used with【F2】together, Press 【F1】solely, it will regulate brightness of
LED.
7．【F2】：
Function Key，used with【F1】together.
8．【HOLD】：
It used for hold function, details see Chapter3-4.
9. 【OFF】：
Turn off the crane scale
CHAPTER 3 OPERATION GUIDE
【】express key on remote controller.
1 Turn on/off
◆TURN ON
Press ON/OFF three seconds，the screen display as follows：
OPERATION
DISPLAY
ILLUSTRATION
ON/OFF
〖
8.8.8.8.8.
〗
Display two times
〖
Ert.
〗
Display two times
〖
xxxxx
〗
Display capacity
〖
U 6.XX
〗
Display current battery voltage
〖
-----
〗
Waiting stable
〖
O
〗
“STB”light on, you can operate now
◆TURN OFF
1
Press ON/OFF three seconds.
2
Press
【
OFF
】
three seconds.
3
Choose turn off method when parameter setting, the scale will
display〖-〗after no operation at 15minutes to save power,and it
will turn off automatically after 60minutes.
2 Zero
OPERATION
DISPLAY
When scale turn on,generally scale

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
2
Press
【
ZERO
】 〖
0
〗
displays
〖
0
〗
,if display small digits when
no load, press this key.
3 Tare
◆TARE DIRECTLY
OPERATION
DISPLAY
After turn on, hanging tare weight such as
sling, cable at first, press this key,
“TARE” light on,then the scale will
display net weight of the goods.
1
Press TARE
〖
0
〗
2
Press
【
TARE
】 〖
0
〗
◆SET TARE WEIGHT IN ADVANCE
OPERATION
DISPLAY
ILLUSTRATION
【
SHIFT
】【
TARE
】 〖
0000.0
〗
Current tare weight
【
TARE
】【
ZERO
】【
CLEAR】
〖
xxx
〗
Set known tare weight,
【
TARE
】
used to
move digit,【ZERO】【CLEAR】used to
set value.
【
SHIFT
】 〖
- xxx
〗
exit,“TARE”light on,it displays minus tare
weight,after hanging on goods,it will
display net weight of goods.
4 Hold
OPERATION
ILLUSTRATION
Press
【
HOLD
】
Hold the weight reading,“HOLD”light on
Press
【
HOLD
】
Return,“HOLD”light off
5 Accumulation
OPERATION
DISPLAY
ILLUSTRATION
Press
【
ACCU
】 〖
No***
〗
Current accumulation time
〖
H****
〗
Front four digits of total value
〖
L****
〗
Rear four digits of total value
After display above contents two times, the scale will return automatically, you also can press
【SHIFT】to return.
6 Accumulation Search
OPERATION
DISPLAY
ILLUSTRATION
【
SHIFT
】【
ACCU】
〖
No.***
〗
Current accumulation time
〖
*****
〗
Current weight reading
〖
H****
〗
Front four digits of total value
〖
L****
〗
Rear four digits of total value
【
SHIFT
】 〖
*****
〗
Return
Press【TARE】和【ZERO】can check different times weight and accumulation.
7 Accumulation Clear
OPERATION
DISPLAY
ILLUSTRATION

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
【
CLEAR
】 〖
CLr
〗
Ask if you want to clear or not
【
CLEAR
】 〖
noCLr
〗
Cancel clear
【
SHIFT
】 〖
8.8.8.8.8.
〗
Confirm clear
8 Battery Voltage
OPERATION
DISPLAY
ILLUSTRATION
【
SHIFT
】【
F1
】
〖
U 6.**
〗
Display current battery voltage
【
SHIFT
】
Return
The voltage should be between 5.8 and 6.9, if below than 5.8, you need to recharge
immediately.
9 Brightness
OPERATION
ILLUSTRATION
【
F1
】
1
～
5 total 5 options, from darkness to brightness(Default is 3)
___________________________________________________________________________
____
10 Zero Point
OPERATION
ILLUSTRATION
【
SHIFT
】【
ZERO】
Display current zero point
11 Unit
OPERATION
ILLUSTRATION
【
SHIFT
】【
HOLD】
Unit switch, Un=0: kg, “kg”light on, Un=1: lb,“lb”light on.
CHAPTER 4 PARAMETER SETTING &CALIBRATION
You can use remote controller to operate parameter setting and cabibration
Key function:
KEY
FUNCTION
【
TARE
】
Move digit(the digit choosed flash)
【
ZERO
】
Set value up
【
CLEAR
】
Setvalue down
【
SHIFT
】
Confirm, exit
1. Parameter setting
1. TURN ON
OPERATION
DISPLAY
ILLUSTRATION
Press ON/OFF
3seconds 〖
88888
〗
Display two times

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
〖
Ert
〗
Display two times
〖
6000
〗
New scale
，
the screen display 6000
，
if
scale calibrated，the screen display
capacity.
〖
U x.xx
〗
Display current battery voltage
〖
--------
〗
Wait stable
〖
0.0
〗
Display zero point
，
generally
，
STB
，
ZERO and kg indicator light on
Generally, battery voltage should bigger than〖U 5.80〗, lower than〖U 6.90〗, if the voltage
lower than〖U 5.80〗, digits flash, the battery should recharge
. PARAMETER SETTING
OPERATION
DISPLAY
ILLUSTRATION
Press
【
F1
】
and
【
F2
】
at same time 3seconds
〖
P0000
〗
Second digit flash
，
use function key to
move digit, set value.
Press
【
TARE
】【
ZERO
】【CLEAR】
〖
P8088
〗
Input 8088
，
8088 is parameter setting
password
Press
【
SHIFT
】 〖
SETUP
〗
Confirm, enter parameter setting program
Press
【
TARE
】 〖
FS=06
〗
New scale
，
the screen display FS=06
，
if
scale calibrated，the screen display
capacity.
Press
【
ZERO
】
or
【
CLEAR】to choose
〖
FS=05
〗
Choose capacity
，
the screen display
02/03/05/06/10/15/20/30/50/60/75
circularly，take cap:5000kg as example,
choose FS=05
Press
【
TARE
】
confirm
〖
Id=05
〗
New scale
，
the screen display Id=05, if
scale calibrated，the screen display
calibrated division.
Press
【
ZERO
】
or
【
CLEAR】to choose
〖
Id=02
〗
Choose division
，
the screen display
01/02/05/10/20 circularly. 5000kg scale
division is 2kg, so choose Id=02
〖
Pt=0
〗
New scale
，
the screen display Pt=0, if
scale calibrated，the screen display
calibrated decimal position
Press
【
ZERO
】
or
【
CLEAR】to choose
〖
Pt=0
〗
Choose decimal position, the screen
display 0/1/2/3 circularly, 0=xxxxx,
1=xxxx.x, 2=xxx.xx, 3=xx.xxx，
Cap.5000kg scale choose Pt=1
Press
【
TARE
】
confirm
〖
Ab=24
〗Display zero range , A:zero range by
hand;B:zero range automatically, 0~5 total
6 options: 0=0%F. S; 1=2%F.S; 2=4%F.S;
3=10%F.S; 4=20%F.S; 5=50%F.S
，

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
Generally，Don’t change this parameter.
Press
【
TARE
】
confirm
〖
Cd=11
〗
New scale
，
the screen display Cd=11,if
scale calibrated，the screen display
calibrated value.
Press
【
ZERO
】
or
【
CLEAR】to choose
〖
Cd=11
〗C: zero-tracking range, 0~5 total 6 options;
0=0d; 1=0.5d; 2=1d; 3=1.5d; 4=2d; 5=2.5d
d: display speed，0~2 total 3 options;
0=slow; 1=average; 2=fast; before
calibration, set Cd=00,after calibration, set
Cd=11 again, generally choose Cd==11
when ex-stock..
Press
【
TARE
】
confirm
〖
LL=2
〗
New scale
，
the screen display LL=2,if
scale calibrated，the screen display
calibrated value.
Press
【
ZERO
】
or
【
CLEAR】to choose
〖
LL=1
〗
LL
：
filter parameter
，
0~5 total 6 options
，
from smallest to biggest，before
calibration, set LL=0,after calibration, set
LL=1 again, generally choose LL=1 when
ex-stock..
Press
【
TARE
】
confirm
〖
Ab=24
〗Display zero range , A:zero range by
hand;B:zero range automatically, 0~5 total
6 options: 0=0%F. S; 1=2%F.S; 2=4%F.S;
3=10%F.S; 4=20%F.S; 5=50%F.S，
Generally
，
Don’t change this parameter.
Press
【
TARE
】
confirm
〖
Cd=11
〗
New scale
，
the screen display Cd=11,if
scale calibrated，the screen display
calibrated value.
Press
【
ZERO
】
or
【
CLEAR】to choose
〖
Cd=11
〗C: zero-tracking range, 0~5 total 6 options;
0=0d; 1=0.5d; 2=1d; 3=1.5d; 4=2d; 5=2.5d
d: display speed，0~2 total 3 options;
0=slow; 1=average; 2=fast; before
calibration, set Cd=00,after calibration, set
Cd=11 again, generally choose Cd==11
when ex-stock..
Press
【
TARE
】
confirm
〖
LL=2
〗
New scale
，
the screen display LL=2,if
scale calibrated，the screen display
calibrated value.
Press
【
ZERO
】
or
【
CLEAR】to choose
〖
LL=1
〗
LL
：
filter parameter
，
0~5 total 6 options
，
from smallest to biggest，before
calibration, set LL=0,after calibration, set
LL=1 again, generally choose LL=1 when

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
ex-stock..
Press
【
TARE
】
confirm
〖
Un=0
〗
New scale
，
the screen display Un=0, if
scale calibrated，the screen display
calibrated unit.
Press
【
ZERO
】
or
【
CLEAR】to choose
〖
Un=0
〗
Choose unit
，
Un=0
：
kg, Un=1
：
lb, Un=2:
other unit。Generally, choose Un=0 when
ex-stock.
Press
【
TARE
】
confirm
〖
OFF 1
〗
New scale
，
the screen display OFF 1,if
scale calibrated，the screen display
calibrated value.
___________________________________________________________________________
____
Press
【
ZERO
】
or
【
CLEAR】to choose
〖
OFF 2
〗
Choose turn off method, 0~2 totel 3
options; 0: turn off by hand; 1: if no
operation, the screen display 〖-〗after
15minutes to save power;2: if no operation,
the screen display 〖-〗after 15minutes,
and turn off automatically after 60minutes.
Generally, choose OFF=2 when ex-stock.
Press
【
SHIFT
】 〖
End
〗
Confirm above parameter setting
，
Exit
parameter setting program.
1. If you find mis-operation before end，Press【TARE】, the screen will display parameter
setting circularly, correct error, if you find mis-operation when parameter setting program
finished，you have to enter parameter setting program again to correct.
2. The capacity you choose relate to division, decimal position, below is detail list:
CAPACITY/DIVISION
FS
（
CAP
）
Id (DIVISION)
Pt
（
DECIMAL
POSITION）
1000kg/0.5kg
10
05
1
2000kg/1kg
02
01
0
3000kg/1kg
03
01
0
5000kg/2kg
05
02
0
10000kg/5kg
10
05
0
15000kg/5kg
15
05
0
20000kg/10kg
20
10
0
2. calibration
1．One point calibration program
OPERATION
DISPLAY
ILLUSTRATION
〖
0
〗
Take Cap:5000kg scale as example
，
pay
attention that the screen display 〖0〗
after hanging tare weight, you can hang
tare weight at first, then turn on..

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
Press
【
F1
】
and
【
F2
】
at same time 3seconds
〖
P0000
〗
Second digit flash
，
use function key to
move digit, set value.
Press
【
TARE
】【
ZERO
】【CLEAR】
〖
P1358
〗
Input 1358
，
1358 is calibration password
Press
【
SHIFT
】 〖
SCALE
〗
Confirm
，
into calibration program
Press
【
SHIFT
】 〖
CALSP
〗
No load
，
the screen display 0,and wait
until STB and ZERO light on.
Press
【
SHIFT
】 〖
LoAd1
〗
Waiting load
___________________________________________________________________________
____
Hanging standard weight
5000kg
Waiting until STB light on.
Press
【
SHIFT
】 〖
05000
〗
Display capacity you choose when
parameter setting，and first digit flash，
Do wait until STB light on.
Press
【
SHIFT
】 〖
-------
〗
Confirm
〖
-oL-
〗
〖
End
〗
Calibration end
〖
5000.0
〗
Display calibrated capacity , sometimes it
display 4999.6,4999.8,5000.2,5000.4
Press
【
TARE
】 〖
05000
〗
Move decimal position
Put down weight
〖
0
〗
Check zero point
，
it displays 0.0, and
STB, ZERO light on.
Hanging weight 5000kg
again 〖
5000
〗
Below is test program to check scale
accuracy.
Put down 500kg weight
and hang on 40kg weight 〖
40
〗
40kh is minumum apacity
（
20e
）
, 50kg,
100kg is also acceptable
Put down 40kg weight.
Hang on 1000kg weight. 〖
1000
〗
1000kg is 500e, check accuracy
Put dowm 100kg weight
〖
0
〗
Check zero point
Generally, if you have full capacity standard weight, you are strongly recommended to
use this progress, only when you find the linearity is not good, so you have to choose
following progress.
2．Three points calibration program
OPERATION
DISPLAY
ILLUSTRATION
〖
0.0
〗
Take Cap:1000kg scale as example
，
Pay
attentionthat the screen display 0 after
hanging tare weight, you can hang tare
weight at first, then turn on.

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
Press
【
F1
】
and
【
F2
】
at same time 3seconds
〖
P0000
〗
Second digit flash
，
use function key to
move digit, set value.
Press
【
TARE
】【
ZERO
】【CLEAR】
〖
P1358
〗
Input 1358
，
1358 is calibration password
Press
【
SHIFT
】 〖
SCALE
〗
Confirm
，
into calibration program
___________________________________________________________________________
___
Press
【
SHIFT
】 〖
CALSP
〗
No load
，
the screen display 0,and wait
until STB and ZERO light on.
Press
【
TARE
】【
ZERO
】【CLEAR】
〖
0500.0
〗
Input 500kg. wait until STB light on.
Press
【
SHIFT
】 〖
-------
〗
Waiting stable
〖
LoAd3
〗
Third load calibration
Hanging on third load
1000kg
Suppose third load is 1000kg,, wait until
STB light on.
Press
【
SHIFT
】 〖
0700.0
〗
Display third minimum load, equal to
second load plus 20% capacity, and first
digit flash.
Press
【
TARE
】【
ZERO
】【CLEAR】
〖
1000.0
〗
Input 1000kg. wait until STB light on.
Press
【
SHIFT
】 〖
------ -
〗
Waiting stable
〖
-oL-
〗
〖
End
〗
Calibration end
〖
000.00
〗
Display calibrated capacity , sometimes it
display 999.90,999.95,1000.05,1000.10
Press
【
TARE
】 〖
1000.0
〗
Move decimal position
Put down weight
〖
0.0
〗
Check zero point, it display 0.0, and STB,
ZERO light on.
Hanging on 1000kg
weight again 〖
1000.0
〗
Below is test program to check scale
accuracy.
Put down 1000kg weight,
hang on 10kg weight 〖
10.0
〗
10kg is minimum cap
（
20e
）
, 20kg is also
acceptable
Put down 10kg weight,
hang on 250kg weight 〖
100.0
〗
250kg is 500e, check accuracy
Put down weight
〖
0.0
〗
Check zero point
1. First load: LAOD1 must larger than 20% capacity，and LOAD1<LOAD2<LOAD3, at the
same time, between LOAD1 and LOAD2，LOAD2 and LOAD3, the interval must bigger
than 20% capacity
2. If balance of any point load is less than 20% capacity, after this point load cabliration finish,

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
the scale will end calibration progress automatically and return.
___________________________________________________________________________
____ CHAPTER 5 DISPLAY ILLUSTRATION
DISPLAY
ILLUSTRATION
REMARK
〖
CALSP
〗
Enter zero point calibration
〖
SCALE
〗
Enter calibration
〖
SEtUP
〗
Enter parameter setting
〖
UAdJ
〗
Enter voltage calibration
〖
LoAd1
〗
First calibration point
LoAd1<LoAd2<LoAd3
〖
LoAd2
〗
Second calibration point
〖
LoAd3
〗
Third calibration point
〖
¯¯¯¯¯
〗
Exceed high limit
Tare weight can’t exceed full capacity
〖
_____
〗
Exceed low limit
Tare weight can’t be negative
〖
-----
〗
Waiting
〖
Err10
〗
Weight less than Min. Capacity
Can’t accumulate the value
〖
Err11
〗
Accumumated times overflow
Can’t accumulate after 30times
〖
Err12
〗
Accumulated weight overflow
Can’t accumulate after 99999
〖
Err13
〗
Error in repeat accumulation
Can’t accumulate one weight repeatedly
〖
no***
〗
Current accumulation times
〖
H****
〗
Front four digit of accumulated
weight
Total weight=front four digit + rare four digit
〖
L****
〗
Rare four digit of accumulated
weight
Total weight=front four digit + rare four digit
〖
CLr
〗
Ask if you really want to delete
accumulated weight
In case error deletion
〖
noCLr
〗
Give up deletion
〖
88888
〗
Confirm deletion
〖
SHIFt
〗
Switch
〖
¯¯¯
〗
Input value is too large
When you input tare or weight value
〖
___
〗
Input value is too small
When you input tare or weight value
〖
noACC
〗
No any accumulated content
when you check accumulation
〖
-oL-
〗
Overload warning
Tare + Net weight exceed full capacity + 9e
〖
-Lb-
〗
Low battery warning
Turn off automatically one minute later

Hantverksvägen 15
76493 Väddö, Sverige
Tel. [phone]
Fax [phone]
Web www.vetek.se
Email [e-mail]
〖
U*.**
〗
The voltage of current battery
〖
End
〗
End
when parameter setting or calibration ready
〖
OFF
〗
Turn off
〖
Unstb
〗
Input value before STB light on
CHAPTER 6 TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
SOUTION
No display when put on
Discharged battery
Recharge
Defective battery
Replace
Defective button
Requires authorized
service
Power button not properly
depressed
Press ON/OFF in three
seconds
Digits flash
Low battery
Recharge the battery
Recharge indicator light
can’t turn on
Battery charger damaged
Check the battery charger
The Battery charger is not
plugged properly
Insert plug again
Display doesn’t respond to
weight changes
Faulty loadcell or PCB
Requires authorized
service
Loadcell cable damaged
Check and replace
loadcell
Out of calibration
Check calibration
Display experiences
excessive Zero drift
between weighment
Scale electronics do not
stabilize after turning on
After turning on, heating 3-
5 minutes.
Put the scale on ground
for too long time
Scale should be hung
Displayed weight shows
large error
Scale not Zeroed before
applying weight
Depress ZERO before
applying weight
Requires recalibration
See calibration
Kg/lb wrong selecion
See operation
Battery can’t recharge
Battery damaged
Replace battery
Outlet damaged
Replace the outlet
Remote distance
shortened
Receiver window is dirty
Check and clean
Remote Control’s battery
is low
Replace Remote Control’s
battery.
