Vetra Systems MegaTouch VIP-804-V-TS Series User manual

User Instructions for
The VIP- 804-V-TS Series "MegaTouch"


Video Switch with Serial Touch Screen Capabilities
FEDERAL COMMUNICATIONS COMMISSION
This equipment has been tested and found to comply with the limits of a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when equipment is operated in
a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his expense.
CE
This equipment has been tested and found to conform to the directives and standards for a Class A Information Technology
Equipment type and for the Commercial Light Industrial equipment class.
INTRODUCTION
The VIP-804 "MegaTouch"Video with Serial Touch Screen capabilities are available as an Integrated Video Switch with
Remote Control, switching one video monitor with touch screen between four PC’s.
The "MegaTouch" system consists of the following components:
1. One – Video Switch Unit;
2. One – VIP-210 power supply.
Note: The "MegaTouch” does not come with VGA or serial extension cables. They may be ordered from Vetra
separately.
INSTALLATION
There are three main steps to connect the Video Switch:
1. Connect PC's to Switch unit:
a) Connect the Video outputs of the PC's to the Switch using 15 pin HDD15 male/female extension cables. Connect
PC#1's video output to the backpanel connector of the Video Switch marked "TO PC1 VIDEO". Connect PC#2's thru
PC#4’s video outputs to the backpanel connectors of the Video Switch marked "TO PC2 VIDEO" thru “TO PC4
VIDEO”.
Or in the case of V2 series
Connect PC#1’s Video A to the backpanel connector of the Video Switch marked “TO PC1 VIDEO A” and Video B to
connector marked “TO PC1 VIDEO B”. Repeat for PC’s #2, #3, and #4.
b) Connect the Touch Screen inputs of the PC’s to the Switch using 9 pin DB9 male/female extension cables. Connect
PC#1’s touch screen input to the backpanel connector of the Switch marked “TO PC1 T.S.”. Connect PC#2’s thru
PC#4’s touch screen inputs to the backpanel connectors of the Switch marked “TO PC2 T.S.” thru “TO PC4 T.S.”.
Or in the case of V2 series
Connect PC#1’s touch screen inputs A to the backpanel of the Switch marked “TO PC1 T.S. A” and input B to the
backpanel connector marked “TO PC1 T.S. B”. Repeat for PC’s #2, #3, and #4.
275 Marcus Blvd. Ste-J, Hauppauge, NY 11788-2022 USA
Tel: 631.434.3185 Fax: 631.434.3516
www.vetra.com email: sales@vetra.com
2
VETRA Systems Corporation 275 Marcus Blvd. Ste-J, Hauppauge, NY 11788-2022 USA
Phone: 631. 434.3185 Fax: 631. 434.3516
e-mail: sales@vetra.com http://www.vetra.com
2. Connect a Monitor to Switch unit:
a) Connect the VGA monitor to the 15-pin HDD connector on the backpanel of the Video Switch marked "MONITOR
IN".
Or in the case of V2 series
Connect VGA monitor A to the backpanel connector on the Video switch marked “MONITOR A IN” and VGA
monitor B to the connector marked “MONITOR B IN”.
b) Connect the Touch Screen to the 9-pin DB9 connector on the backpanel of the Switch marked “TOUCH SCREEN
IN”.
Or in the case of V2 series
Connect Touch Screen A to the backpanel connector on the Video switch marked “TOUCHSCREEN A IN” and
Touch Screen B to the connector marked “TOUCHSCREEN B IN”.
3. Connect the Power Supply to the Video Switch:
The Video Switch is powered by an external wall plug-in supply the VIP-210 (+5Vdc 1A reg. 110 – 240 Vac 50 – 60 Hz).
First plug the power output plug of this external supply into the mating jack on the backpanel of the Video Switch marked
“+5VDC IN”, and only then plug the supply into a suitable AC power source. Since the Video Switch has no separate power
on/off switch, it is recommended that the power supply be connected to an AC power source that has a power on/off switch.
OPERATION
1. Power Up Sequence:
The switch derives its power from an external power supply provided with the MegaTouch. When the Video Switch is
powered up, observe on the Video Switch that the front panel Led marked “PWR ON” comes on.
2. Monitor Selection:
a) Front Panel Selection:
1) NEXT MON (available on all Standard models): To select another PC, press the “NEXT MON” pushbutton
located on the front panel of the MegaTouch. The MegaTouch will switch from on PC to the other. If PC #1 is
selected the MONITOR STATUS 1 SEL indicator will be on. If PC #2 is selected then the MONITOR STATUS 2
SEL for that PC will be on.
2) Direct Entry (available on DE models only): To select another PC, press the MONITOR SELECTION
pushbutton for the appropriate PC desired.
b) Remote Control (available on all models): The MegaTouch may also be switched via remote control. A Hex 31
for (PC #1) thru Hex 34 for (PC #4) sent via RS-232 to pin 2 of the DB 9 connector on the rear panel marked
“REMOTE CONTROL” will switch the MegaTouch from PC1 to PC2. The data format is one start bit, eight data
bits, least significant bit first, one stop bit and no parity. The baud rate is 9600. Pin 5 is ground.
3
VETRA Systems Corporation 275 Marcus Blvd. Ste-J, Hauppauge, NY 11788-2022 USA
Phone: 631. 434.3185 Fax: 631. 434.3516
e-mail: sales@vetra.com http://www.vetra.com
SPECIFICATIONS
Mechanical Dimensions
Model # Height Width Depth Weight
VIP-804-V-TS 3.38” (8.59 cm) 8.08” (20.52 cm) 6.32” (16.05 cm) 1 lb. 15 oz.
VIP-804-V-TS-DE 3.38” (8.59 cm) 8.08” (20.52 cm) 6.32” (16.05 cm) 2 lb. 5 oz.
VIP-804-V2-TS2 4.04” (10.26 cm) 8.08” (20.52 cm) 6.32” (16.05 cm) 2 lb. 9 oz.
VIP-804-V2-TS2-DE 4.04” (10.26 cm) 8.08” (20.52 cm) 6.32” (16.05 cm) 2 lb. 13 oz.
Environmental Operating Temp: 5 to 104 deg. F (-15 - 40 deg. C)
Storage Temp: -4 to 122 deg. F (-20 - 50 deg. C)
Supported Hardware Video Monitors: VGA, SVGA
Maximum Resolution: up to 1600 x 1200 to 75 Hz
MegaTouch is a trademark of Vetra Systems Corporation Copyright © 2003 - 2008 by Vetra Systems Corporation All Rights Reserved
