VEVOR SH-1 User manual

Magnetic Stirrer with Heater
Lab Supplies
This hot plate contains an integrated magnetic stirrer, ideal for use in a laboratory. The dual
controls allow you to set heat output and stirring speed independently. The hot plate can reach a
maximum temperature of 350 °C (662 °F ) with an output of 180 watts. The magnetic stirrer is
adjustable from 100 to 1600 rpm.
A support stand with an adjustable thermometer holder is also included. The support stand extends
about 10" above the hot plate's surface.
Components:
Base with power switch, two knobs and attached hot plate 1" Teflon coated magnetic stir bar
Power cord
Support stand (base rod, extender rod, right angle clamp and thermometer holder)
You may also want the following (not included):
Partial immersion or digital thermometer
Glass beaker or flask
Operation
To set up the support stand: Screw the two rods together making one support rod. Make sure they
fit tightly. Insert the slotted end of the rod into the plastic holder on the back of the base. Slip the
right angle clamp onto the support rod and tighten the knob. Slide in the thermometer holder and
tighten the other knob. The height of the thermometer holder can be adjusted by moving the clamp
up or down on the support.
To use the hot plate:
1.Make sure the knobs are turned off. The white mark on each knob should be pointing down.
2.Connect the power cord to the back of the base. The base should be set on a hard surface,like a
countertop or table.

3.Plug the other end of the power cord into a standard outlet. Make sure the outlet is safe and the
power cord is not twisted.
4.Filp the power switch on the right side of the b ase. T he line (-) indicates on and the circle (o)
indicates off.
WARNING: Be very careful with the hotplate turned on. Do NOT touch the aluminium surface as
it gets very hot and can cause severe bums.
5.Rotate the right knob in a clockwise direction. At maximum power the hot plate will take around
20-30 minutes to boil a large beaker of water. The surface in the middle of the plate can reach
350°C (662 °F ) when the knob is turned all the way to maximum power.
6. Adjust the knob to keep the desired heat level , using a thermometer to check the temperature of
the solution.
7. To turn off .the hot plate , rotate the knob counter-clockwise until you hear a click and the white
mark is pointing down.
8.Make sure both knobs are off and the filp the power switch off . Unplug the cord from the outlet
by pulling on the plug, not the cord.
To use the magnetic stirrer:
1.Drop the stir bar into the solution and let it settle.
2.Turn on the magnetic stirrer by flipping the power switch on (-) , then rotating the left knob in a
clockwise direction.
3.The further you rotate the knob, the faster it will spin to stir your solution.
4.To turn off the magnetic stirrer , rotate the knob counter-clockwise until you hear a click and the
white mark is pointing down. Flip the power switch off. Unplug the device.
5.Remove the stir bar with a metal utensil . The stir bar will stick to it so you can lift it out easily.
Main Technical Parameters:
Model
Voltage (V)
Speed
(r.p.m)
Heating
Power(w)
Max.Volu
me
(ml)
Max. Temp
(plate)
Plate size
(mm)
SH-1
110V
220V
230V
240V
100〜
1600
—
2000
350°C±10%
120×120
SH-2
180
SH-3
500
3000
170×170
SH-4
600
5000
190×190
