VF OSMOBIL BOX Quick guide

OSMOBIL BOX
Translation of the original ope-
rating instructions in English
Current version as of August 2022.
All previous versions are replaced by this one.
VF Reinigungstechnik
Benjamin Volk & Tobias Becker GbR
Blankenfohrweg 11
32139 Spenge
T 05225 87198-15
[e-mail]
www.gebaeudereinigung-shop.de
www.gardiner-teleskopstangen.de
www.vf-reinigungstechnik.de
Sparkasse Bielefeld
IBAN DE60 4805 0161 0003 4120 53
BIC SPBIDE3BXXX
Steuer-Nr. 324/5816/0846
box

Copy of the instructions for mobile control for water systems OSMOBIL BOX
VF Reinigungstechnik
Benjamin Volk & Tobias Becker GbR
Blankenfohrweg 11
32139 Spenge
T 05225 87198
-
15
[e-mail]
www.gebaeudereinigung-shop.de
www.gardiner-teleskopstangen.de
www.vf-reinigungstechnik.de
Sparkasse Bielefeld
IBAN DE60 4805 0161 0003 4120 53
BIC SPBIDE3BXXX
Steuer-Nr. 324/5816/0846
box
OSMOBIL BOX
Technical data:
Inlet water pressure max. 6,0 bar
Temperature Inlet water 8° - 25° C
Suitable inlet water Municipal water acc.
German drinking water
ordinance
Ambient temperature 3° - 40° C
Mains connection 230 V and 50 Hz
Dimensions in cm
(HxWxD)
approx. 33x38x31
Weight (dry) approx. 11,5 kg

Copy of the instructions for mobile control for water systems OSMOBIL BOX
VF Reinigungstechnik
Benjamin Volk & Tobias Becker GbR
Blankenfohrweg 11
32139 Spenge
T 05225 87198
-
15
[e-mail]
www.gebaeudereinigung-shop.de
www.gardiner-teleskopstangen.de
www.vf-reinigungstechnik.de
Sparkasse Bielefeld
IBAN DE60 4805 0161 0003 4120 53
BIC SPBIDE3BXXX
Steuer-Nr. 324/5816/0846
box
EC Declaration of Conformity
We hereby declare that the mobile reverse osmosis system „OSMOBIL BOX“, with
regard to its design and construction, complies with the applicable EC directives in
the manner marketed by our company.
Any change to the system that has not been agreed with our company will invalidate
this declaration.
Applicable EC Directive:
EC Machinery Directive (2006/42/EC)
Manufacturer: VF Reinigungstechnik Designation of the plant: OSMOBIL BOX
Blankenfohrweg 11 Serial number: see type plate
32139 Spenge
Tel. [phone]
Signatory: Tobias Becker (Managing Partner)
Date/Signature of the manufacturer: 01.08.2022

Copy of the instructions for mobile control for water systems OSMOBIL BOX
VF Reinigungstechnik
Benjamin Volk & Tobias Becker GbR
Blankenfohrweg 11
32139 Spenge
T 05225 87198
-
15
[e-mail]
www.gebaeudereinigung-shop.de
www.gardiner-teleskopstangen.de
www.vf-reinigungstechnik.de
Sparkasse Bielefeld
IBAN DE60 4805 0161 0003 4120 53
BIC SPBIDE3BXXX
Steuer-Nr. 324/5816/0846
box
Table of contents
1 General and overview
1.1 Introduction
1.2 Overview
1.3 Function
2 Practical use
2.1 Installation
2.2 Switching on the Box
2.3 Tank sensor
2.4 Does your water unit have a Fi switch?
3 PPM meter
3.1 Function
3.2 Overview - Control Panel
3.3 Operation
4 Special Instructions for Filling Heating Systems
4.1 VDI 2035 Standard & Water Quality for Special Cases
4.2 PH value
5 Warranty

Copy of the instructions for mobile control for water systems OSMOBIL BOX
VF Reinigungstechnik
Benjamin Volk & Tobias Becker GbR
Blankenfohrweg 11
32139 Spenge
T 05225 87198
-
15
[e-mail]
www.gebaeudereinigung-shop.de
www.gardiner-teleskopstangen.de
www.vf-reinigungstechnik.de
Sparkasse Bielefeld
IBAN DE60 4805 0161 0003 4120 53
BIC SPBIDE3BXXX
Steuer-Nr. 324/5816/0846
box
1 General and overview
1.1 Introduction
Dear user,
herewith you receive the manual for your new control unit for water systems of the „OS-
MOBIL BOX“. It describes in simple terms the basic functions and components of the unit.
In addition, it provides important information for your safety as a user and to avoid misuse
and damage to the unit or the environment.
Attention: Please read the instructions completely and carefully. This will prevent damage
and misuse! The appliance may only be operated by competent persons who have read
these instructions.
1.2 Overview - frontal view
1: 230 V power connection
2: PPM measuring device
3: Tank sensor connection
2
3
1

Copy of the instructions for mobile control for water systems OSMOBIL BOX
VF Reinigungstechnik
Benjamin Volk & Tobias Becker GbR
Blankenfohrweg 11
32139 Spenge
T 05225 87198
-
15
[e-mail]
www.gebaeudereinigung-shop.de
www.gardiner-teleskopstangen.de
www.vf-reinigungstechnik.de
Sparkasse Bielefeld
IBAN DE60 4805 0161 0003 4120 53
BIC SPBIDE3BXXX
Steuer-Nr. 324/5816/0846
box
1.2 Overview - Lateral view
1: City water inlet
2: Permeate outlet
(on the other side of the BOX are „City
water outlet“ and „Permeate inlet“)
1.3 Function
The OSMOBIL BOX is a control device that can be used to automate the lling of tank
systems with pure water. In conjunction with a tank sensor, the OSMOBIL BOX switches
o the water and power supply for the respective water unit when a desired ll level is
reached.
The OSMOBIL BOX is a product that was developed for commercial building cleaners and
heating installers. It can be connected to common mixed bed resin systems (usually wit-
hout looping through the power supply) as well as to various osmosis systems (then inclu-
ding looping through the power supply).
2 Practical use
2.1 Installation
The following diagram is intended to illustrate how the OSMOBIL BOX is connected to
your tank system and your mixed bed resin system or osmosis plant. Before a tank can be
lled, everything must be set up as follows:
12
Structure
Tank system Sewerage,
drainage
Water systemOSMOBIL BOX
Waste waterCity water
Pure waterPure water
Tank sensor

Copy of the instructions for mobile control for water systems OSMOBIL BOX
VF Reinigungstechnik
Benjamin Volk & Tobias Becker GbR
Blankenfohrweg 11
32139 Spenge
T 05225 87198
-
15
[e-mail]
www.gebaeudereinigung-shop.de
www.gardiner-teleskopstangen.de
www.vf-reinigungstechnik.de
Sparkasse Bielefeld
IBAN DE60 4805 0161 0003 4120 53
BIC SPBIDE3BXXX
Steuer-Nr. 324/5816/0846
box
2.2 Switching on the Box
If the above setup is ensured and the OSMOBIL BOX is connected to the power, the sup-
ply of city water can be turned on. Please press the „F“ button on the meter to start (see
point 3 PPM meter) If you are using a water system that also requires electricity, please
switch this on as well. Now ll the respective tank or container. The water supply ends
when the desired tank is completely full or the desired ll level of a tank system is reached.
This is done by the tank sensor, which sends a corresponding signal to the OSMOBIL BOX.
2.3 Tank sensor
The tank sensor is mounted at the desired ll level in the respective tank and then connec-
ted to the OSMOBIL BOX (see „front view page 5, „3 / Connection tank sensor“).
To install the oat, a 29 mm diameter hole must be drilled in the ceiling of the desired tank,
as the oat only works horizontally. Then the sensor is led from inside the tank through
the drilled hole to the outside and fastened there with the existing union nut.
As soon as the sensor is connected to the OSMOBIL BOX, the OSMOBIL BOX recognises
the component and regulates the switch-o via the sensor.
2.4 Does your water unit have a Fi switch?
If the water unit used with the BOX (e.g. an OSMOBIL PRO) is electrically operated
(i.e. you have connected it to the power connection of the BOX) and also has a personal
protection plug or Fi switch, it may be useful to dismantle it. With a personal protection
switch, the BOX is able to switch o the water system. However, automatic „restarting“ is
then not possible. To restart the OSMOBIL BOX, you must press the „F“ key on the meter.
We will be happy to advise you on this on request!
3 PPM meter
3.1 Function
The OSMOBIL BOX has a permanently installed, professional PPM measuring device with
which you can measure the conductance of the respective pure water and city water ap-
plied (see „front view page 5, „2 / PPM measuring device“). It indicates the conductance
of the respective permeate.

Copy of the instructions for mobile control for water systems OSMOBIL BOX
VF Reinigungstechnik
Benjamin Volk & Tobias Becker GbR
Blankenfohrweg 11
32139 Spenge
T 05225 87198
-
15
[e-mail]
www.gebaeudereinigung-shop.de
www.gardiner-teleskopstangen.de
www.vf-reinigungstechnik.de
Sparkasse Bielefeld
IBAN DE60 4805 0161 0003 4120 53
BIC SPBIDE3BXXX
Steuer-Nr. 324/5816/0846
box
3.2 Overview - Control panel
3.3 Operation
To switch on the PPM meter, please press the „F“ key.
To monitor the conductance, press the enter button until „TDS“ is displayed.
Press the enter button again to monitor the water temperature (in degrees Celcius). „NC“
is displayed if the probe is not connected.
To change the limit value, press and hold the down and enter keys. If the conductance ri-
ses above this value, the pump and TDS stop, „STP“ ashes on the control. This value can
be set between 1 and 40 ppm with the up or down key (e.g. 5) or switched o if „OFF“ is
selected.
However, we recommend switching o the limit value when working with osmosis sys-
tems.
4 Special instructions for lling heating systems
4.1 VDI 2035 standard & water quality for special cases
In order to comply with the specications of the VDI2035 standard when lling heating

Copy of the instructions for mobile control for water systems OSMOBIL BOX
VF Reinigungstechnik
Benjamin Volk & Tobias Becker GbR
Blankenfohrweg 11
32139 Spenge
T 05225 87198
-
15
[e-mail]
www.gebaeudereinigung-shop.de
www.gardiner-teleskopstangen.de
www.vf-reinigungstechnik.de
Sparkasse Bielefeld
IBAN DE60 4805 0161 0003 4120 53
BIC SPBIDE3BXXX
Steuer-Nr. 324/5816/0846
box
systems, please note that you may need an additional lter cartridge when lling heating
systems in which the smallest boiler heating surface is above 50l/kW or the total hea-
ting output is above 600kW, as the water quality for lling in these special cases must be
below approx. 3 microS/cm (approx. 2 PPM).
Mixed bed resins with sucient residual capacity usually meet this value without any
problems. If you want to use an osmosis system for such special cases, you may need an
additional lter. For this, please simply contact your specialist dealer.
4.2 PH value
In addition, you should measure the PH value of the heating water after lling the hea-
ting system and after a short period of operation and adjust it to the installed materials
if necessary. In this regard, we refer to the specic content of VDI2035, according to
which the PH value of the heating water must be adjusted to the materials primarily used.
Measuring the pH value of the ultrapure water produced with a mixed-bed resin or a re-
verse osmosis system before introducing it into the heating system makes no sense from
a practical point of view or is not possible with simple measuring methods due to the low
conductivity of the water. In addition, the PH value of the ultrapure water in the air would
very quickly become slightly acidic (pH value of 4-5), as the pure H2O is able to dissolve
carbon dioxide from the air, which also makes it impossible to achieve an objective mea-
surement result. This deviation of the pH value of the ultrapure water into the acidic range
does not usually happen in the heating system, as it is sealed accordingly.
In most cases, the PH value of the water introduced into a heating circuit will be in the
range of 8-9 after a short period of operation. This PH value is optimal for many materials.
5 Warranty
All OSMOBIL water systems and controls are subjected to extensive quality control and
testing before delivery. Even the construction of the devices is designed for unconditional
reliability and durability. Should there nevertheless be any problems or a reason for comp-
laint within the warranty period (24 months for natural persons, 12 months for tradesmen
and companies), please direct the respective claim for replacement to the company VF
Reinigungstechnik. Please note that the warranty only covers units that are structurally
unchanged and have been operated strictly in accordance with the specications in this
manual.
