VIA Technologies Mobile360 FSS User manual

INSTALLATION GUIDE
VIA Mobile360 Forkli
Safety System
Le, Right & Rear People Detecon
1.00-20072022

Copyright
Copyright © 2022 VIA Technologies Incorporated. All rights reserved.
No part of this document may be reproduced, transmied, transcribed, stored in a retrieval system, or translated into any language, in any
form or by any means, electronic, mechanical, magnec, opcal, chemical, manual or otherwise without the prior wrien permission of
VIA Technologies, Incorporated.
Trademarks
All brands, product names, company names, trademarks and service marks are the property of their respecve holders.
Disclaimer
VIA Technologies makes no warranes, implied or otherwise, in regard to this document and to the products described in this document.
The informaon provided in this document is believed to be accurate and reliable as of the publicaon date of this document. However,
VIA Technologies assumes no responsibility for the use or misuse of the informaon (including use or connecon of extra device/
equipment/add-on card) in this document and for any patent infringements that may arise from the use of this document. The informaon
and product specicaons within this document are subject to change at any me, without noce and without obligaon to nofy any
person of such change.
TO THE FULL EXTENT PERMISSIBLE BY LAW, VIA DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. UNLESS EXPRESSLY PROVIDED OTHERWISE,
VIA DOES NOT WARRANT VIA SERVICE(S), INFORMATION, CONTENT, MATERIAL(S), PRODUCT(S) (INCLUDING SOFTWARE) OR OTHER
SERVICE(S) INCLUDED ON OR OTHERWISE MADE AVAILABLE TO YOU THROUGH VIA REGARDING ITS ACCURACY, COMPLETENESS, OR NON-
INFRINGEMENT OF INTELLECTUAL PROPERTY.
TO THE FULL EXTENT PERMISSIBLE BY LAW, VIA WILL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND ARISING FROM THE USE OF VIA
SERVICE(S), INFORMATION, CONTENT, MATERIAL(S), PRODUCT(S) (INCLUDING SOFTWARE) OR OTHER SERVICE(S) INCLUDED ON OR
OTHERWISE MADE AVAILABLE TO YOU THROUGH VIA, INCLUDING, BUT NOT LIMITED TO DIRECT, INDIRECT, INCIDENTAL, PUNITIVE, AND
CONSEQUENTIAL DAMAGES, UNLESS OTHERWISE SPECIFIED IN WRITING.
VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any me without prior noce.
Regulatory Compliance
FCC-A Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protecon against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instrucon manual, may cause harmful interference to radio communicaons. Operaon of this equipment in a residenal area is likely to
cause harmful interference, in which case the user will be required to correct the interference at his personal expense.
Noce 1
The changes or modicaons not expressly approved by the party responsible for compliance could void the user's authority to operate
the equipment.
Noce 2
Shielded interface cables and A.C. power cord, if any, must be used in order to comply with the emission limits.
Noce 3
The product described in this document is designed for general use, VIA Technologies assumes no responsibility for the conicts or
damages arising from incompability of the product. Check compability issue with your local sales representaves before placing an
order.
ii

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
iii
Important Safety Instrucons
Before installing and using this product, please carefully read all the safety instrucons and warnings in this
user manual. Installing this product means that you have fully understood, conrmed and agreed to operate
this product in accordance with the safety instrucons and warnings stated in this manual. If you do not agree
to these terms, please return this product to your dealer in its original packaging.
Cauon:
This product cannot replace the driver to perform any operaons, and the use of this product does not mean that
any safe driving responsibility of the driver can be reduced. In any case, drivers should strictly observe safe driving
laws and regulaons and drive carefully.
• Please understand that the VIA Mobile360 Forkli Safety System is an intelligent video surveillance
assistance system that can provide the driver with warnings in certain potenally dangerous
situaons, rather than an automated driving system. The driver cannot use it as a substute for driving
a motor vehicle or construcon vehicle. For any operaon that is usually performed at the me, the
driver should remain vigilant under any driving condions to ensure compliance with all safe driving
standards and regulaons; and abide by all safety rules.
• Please understand that although this product uses machine vision soware and other top innovave
technologies, it sll cannot guarantee 100% accurate detecon of people. The ability to recognize
and react has a great impact, and we cannot guarantee to provide all corresponding audible or
visual warnings. Therefore, we warn drivers not to rely too much on this product and lose their self-
judgment or negligence when driving. Drivers should not rely on this product for their driving safety
but should strictly abide by the safe driving regulaons.
• Please understand that before the driver is familiar with the funcons of the system operaon of this
product, please do not change any sengs for the system. During driving, please do not try to change
the system sengs of this product or change the posion of the sensor. Drivers should always abide
by safe driving regulaons when using the VIA Mobile360 7" display (upgrade opon), and should
always pay aenon to the operang environment, even when viewing the display.
Magnets Warning
• This system contains powerful magnets, use cauon when handling to avoid pinching.
• The magnets are fragile, avoid dropping or banging them.
• Do not approach magnec, electrical materials, electrical appliances, including heart rate regulators,
etc., to avoid degaussing, device failure, or even destrucon due to strong magnesm.
• Do not use in environments exceeding the operang temperature of the system specicaon to avoid
magnet demagnezaon.
• If a person is sensive to metal objects approaches the magnet, the skin will become rough and red. If
this reacon occurs, please do not handle the strong magnets.
Pre-Installaon and Use
• Please familiarize yourself with this user manual before installing this product. If you need a dealer/
third-party to install the system, contact VIA for further informaon."
• The working voltage of this product is 9VDC-36VDC.
• Do not cover or block the VIA Mobile360 camera or VIA Mobile360 7"display or controls.
• Except for the purposes stated in this user manual, this product may not be used for any other
purpose.
• If a certain funcon/accessory is marked as "oponal", it means that the funcon/accessory is not
applicable to all vehicle types and models, and addional fees may be required. Before purchasing this
product, please conrm with VIA about the suitability of this product in advance.

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
iv
• It may not be possible to install this product on every type or model of forkli. Before purchasing this
product, please conrm with the VIA whether this product is suitable for the type or model of the
forkli you intend to install it on.
• Before use, please conrm that the driver is familiar with the system operaon of this product and
ensure that the operaon of this product does not aect driving safety.
System Limitaons
1. This product is more suitable for brightly lit factories or outdoors.
2. This product is not a substute for the driver to "observe" the surrounding environment. The driver
should always remain alert during driving and operate according to the condions they observe or hear.
3. The people detecon funcon of this product can only detect people that are fully visible and cannot
detect people that are blocked or other unusual acons except standing, walking, running, squang,
lying down or lying on the ground.
4. This product cannot guarantee 100% accuracy when detecng people or warning drivers of potenal
unsafe driving condions/behaviors. In addion, light, working environment, weather and other
condions will greatly aect the recognion and response capabilies of this product. If the view of the
camera is parally or completely blocked, the funcon of this product will be lost or impaired. Please
make sure that the camera has a clear view!
License and Guarantee
Limited Use License
All intellectual property rights of this product belong to VIA. VIA only grants the purchaser of this product
a non-exclusive license to use the soware. The purchaser shall not: (a) modify, change or convert the
soware used in the product or provided with the product; (b) reverse assemble, decompile, disassemble
or other aempts to obtain the source code of the soware; (c) copying, selling, transferring, sub-licensing,
leasing, renng, lending, transferring, distribung, or otherwise transferring or disclosing the soware; or (d)
remove, cover up, or change the property rights, trademarks or other rights statements on the product or
corresponding documents.
Limited Guarantee
The limited warranty for this product (hereinaer referred to as the "limited warranty") is non-transferable. VIA
promises to provide the original purchaser of this product with a one-year free warranty service from the date
of shipment.
VIA is not responsible for any problems caused by installaon. At the same me, the following condions are
not covered by the warranty: (a) damage caused by incorrect use, negligence, incorrect installaon or accident;
(b) installing this product on an inappropriate vehicle; (c) except for VIA, any third-party repairs or changes to
the product; (d) due to accidental damage or due to factors other than the product, including but not limited
to the use of the environment does not meet the requirements or exceed the protecon standards, power
outages, current surges, voltage instability, excessive damage caused by voltage, overload, short circuit, high
temperature, high humidity, outdoor wind and rain, natural disasters or force majeure.
Disclaimer
This limited warranty is the only and exclusive warranty for this product. To the extent permied by applicable
laws, VIA does not assume any express or implied warranes or guarantees regarding product marketability or
suitability for specic purposes. No representaves, distributors or agents are authorized to make statements,
claims, or guarantees regarding this product on behalf of VIA. Except for the content clearly stated here, VIA
will not make any other declaraons or guarantees. Under no circumstances will VIA be liable for any special,
incidental, direct, indirect, punive, incidental, ancillary or punive damages related to this product or caused
by the use of this product.

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
v
Warranty Process
During the warranty period, if this product breaks down and needs to be repaired, please follow the process
below:
1. If you purchased this product from a distributor, please contact them.
2. If you purchased this product directly from VIA, please contact VIA. All products returned to VIA
must be shipped prepaid. Please contact the VIA Customer Service Department to ask for the return
authorizaon number, which must be provided when returning the goods, otherwise VIA has the right
to refuse to accept it.

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
vi
Revision History
Version Date Remarks
1.00 20/07/2022 Inial Release

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
vii
Packing List
• 1 x VIA Mobile360 M500 system
• 2 x Vibraon dampening strips
• 3 x IP67 FOV-190° le/right/rear cameras with mounng brackets (3M cable)
• 3 x Strong magnets with 6 x M5*12mm bolts
• 3 x 3M VHB GPH-160GF series tape
• 10 x M5*25mm Molly bolts for camera and system installaon
• 1 x Speaker with 3M VHB GPH-160GF series tape (3M cable)
• 1 x Wi-Fi/GPS antenna module (3M cable)x
• 1 x Power, ACC/IGN & ground cable (3M cable)
• Red/Yellow blade fuse holder cable and fuse pack. (Includes Standard, Micro, Low-Prole and Mini
sizes)
• 4 x M12 caps for DIO 1, DIO 2, CAN Bus and CVBS ports, 2 x SMA caps 4G antenna ports
• 1 x 32GB MicroSD card
Oponal Accessories
Display Opon
Part Number Descripon
M360-M500-1L07A0 7” IP67 CVBS (800x480) display kit with mounng bracket, two Molly bolts, two
strong magnets with bolts and two pieces of 3M tape
Sensor Opon
Part Number Descripon
M360-M500-1S00A0 Forkli speed sensor kit with mounng bracket, cable and M8 cap
Power Opon
Part Number Descripon
M360-PWM-2P0020 36V~100V DC power module for EV forklis.

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
viii
Table of Contents
1. Product Overview........................................................................................................................................... 1
1.1 System Layout....................................................................................................................................... 1
1.2 System Dimensions ............................................................................................................................... 2
2. Installaon...................................................................................................................................................... 3
2.1 System Preparaon ............................................................................................................................... 3
2.1.1 Inserng a MicroSD Card ............................................................................................................... 3
2.1.2 Securing the Waterproof Cover ..................................................................................................... 4
2.1.3 Aaching the I/O covers ................................................................................................................ 4
2.1.4 Aaching the Vibraon Dampening Strips..................................................................................... 5
2.2 VIA Mobile360 M500 System Installaon............................................................................................. 6
2.3 Camera Installaon ............................................................................................................................... 7
2.3.1 Scenario A: Side Cameras < 2.3m from Rear Camera .................................................................... 8
2.3.2 Scenario B: Side Cameras 2.3m ~ 3.5m from Rear Camera ........................................................... 8
2.3.3 Aaching the Cameras................................................................................................................... 9
2.4 Speaker Installaon............................................................................................................................. 11
2.5 Wi-Fi/GPS Antenna Installaon........................................................................................................... 12
2.6 Peripheral Cabling and Connecon..................................................................................................... 13
2.6.1 Connecng Ground, ACC and Power ........................................................................................... 14
2.7 Turning System On/O........................................................................................................................ 18
2.7.1 System Reset................................................................................................................................ 18
3. Safety Alerts & Camera Calibraon .............................................................................................................. 19
3.1 Camera Alerts ..................................................................................................................................... 19
3.1.1 Camera Calibraon ...................................................................................................................... 20
4. VIA Mobile360 WorkX App........................................................................................................................... 25
4.1 Connecng the VIA Mobile360 WorkX App ........................................................................................ 25
4.2 Upgrading System Firmware............................................................................................................... 26
4.3 App Menu ........................................................................................................................................... 27
4.3.1 Camera Calibraon ...................................................................................................................... 27
4.3.2 Sengs ........................................................................................................................................ 28
4.3.3 Album .......................................................................................................................................... 29
Appendix A Oponal Accessories .................................................................................................................... 32
A.1 7" CVBS Display Kit.............................................................................................................................. 32
A.1.1 Package Contents......................................................................................................................... 32
A.1.2 Installaon ................................................................................................................................... 33
A.1.3 Display Interface .......................................................................................................................... 36
A.1.4 Display Buons ............................................................................................................................ 37
A.2 Speed Sensor Kit ................................................................................................................................. 38
A.2.1 Package Contents......................................................................................................................... 38
A.2.2 Installaon ................................................................................................................................... 38
A.2.3 Connecng to System .................................................................................................................. 39
A.2.4 Conguraon ............................................................................................................................... 40
A.2.5 Display Interface and Alerts ......................................................................................................... 41
A.2.6 Deacvaon................................................................................................................................. 42

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
ix
A.3 DC Power Module ............................................................................................................................... 44
A.3.1 Package Contents......................................................................................................................... 44
A.3.2 Installaon ................................................................................................................................... 44
Appendix B Troubleshoong............................................................................................................................ 48

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
x
List of Figures
Figure 01: Front panel I/O layout ......................................................................................................................... 1
Figure 02: Rear panel I/O layout .......................................................................................................................... 1
Figure 03: Front view system dimensions ............................................................................................................ 2
Figure 04: Side view system dimensions .............................................................................................................. 2
Figure 05: Securing the waterproof cover............................................................................................................ 4
Figure 06: Covering unused front panel ports...................................................................................................... 4
Figure 07: Covering unused rear panel ports ....................................................................................................... 5
Figure 08: Vibraon dampening strip installaon ................................................................................................ 5
Figure 09: Recommended installaon space requirements................................................................................. 6
Figure 10: Recommended installaon locaons .................................................................................................. 6
Figure 11: Front & rear camera installaon locaons .......................................................................................... 7
Figure 12: Camera installaon locaons .............................................................................................................. 7
Figure 13: Scenario A camera installaon ............................................................................................................ 8
Figure 14: Scenario B camera installaon ............................................................................................................ 9
Figure 15: Aaching magnets and 3M tape to rear and side cameras................................................................. 9
Figure 16: Marking installaon locaon and drilling.......................................................................................... 10
Figure 17: Marking side camera installaon locaon rotated 30°...................................................................... 10
Figure 18: Installing cameras with Molly bolts................................................................................................... 11
Figure 19: Speaker installaon ........................................................................................................................... 11
Figure 20: Wi-Fi/GPS antenna installaon ......................................................................................................... 12
Figure 21: Applying LOCTITE 243 Threadlocker to I/O ports .............................................................................. 13
Figure 22: Front I/O cable connecons .............................................................................................................. 13
Figure 23: Rear I/O cable connecons ............................................................................................................... 14
Figure 24: M12 power cable............................................................................................................................... 14
Figure 25: Blade fuse holder cables ................................................................................................................... 15
Figure 26: System reset ...................................................................................................................................... 18
Figure 27: People detecon zone coverage ....................................................................................................... 19
Figure 28: Camera calibraon paern placement ............................................................................................. 21
Figure 29: Le/rear/right camera angle adjustment.......................................................................................... 22
Figure 30: 7" CVBS display kit............................................................................................................................. 32
Figure 31: 7" CVBS display mount assembly ...................................................................................................... 33
Figure 32: 7" CVBS display mount installaon with magnets and 3M tape ....................................................... 33
Figure 33: 7" CVBS display mount installaon with drilling ............................................................................... 34
Figure 34: 7" CVBS display installaon............................................................................................................... 34
Figure 35: 7" CVBS display cable connecons.................................................................................................... 35
Figure 36: 7" CVBS display interface with rear camera view only ...................................................................... 36
Figure 37: 7" CVBS display interface with 3-camera view .................................................................................. 36
Figure 38: 7" CVBS display buons .................................................................................................................... 37
Figure 39: Speed sensor kit ................................................................................................................................ 38
Figure 40: Assembling the speed sensor and mounng bracket........................................................................ 38
Figure 41: Speed sensor installaon .................................................................................................................. 39
Figure 42: Connecng speed sensor to the VIA Mobile360 M500 system......................................................... 40
Figure 43: 7" CVBS display interface with rear camera view only and speed reading........................................ 41
Figure 44: 7" CVBS display interface with 3-camera view and speed reading.................................................... 42
Figure 45: DC Power Module ............................................................................................................................. 44

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
xi
List of Tables
Table 01: MicroSD card recording mes ............................................................................................................. 3
Table 02: Maximum side-to-rear camera distances............................................................................................ 8
Table 03: System LED status.............................................................................................................................. 18
Table 04: People detecon audio alerts ........................................................................................................... 20
Table 05: 7" CVBS display specicaons ........................................................................................................... 32
Table 06: 7" CVBS panel alert icons .................................................................................................................. 37

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
1
1. Product Overview
Prevent accidents and injuries in busy warehouse and industrial environments with the VIA Mobile360
Forkli Safety System. This rugged and reliable people detecon system alerts and warns the driver whenever
someone steps within a hazardous range of their vehicle.
Simple to install and maintain, the VIA Mobile360 Forkli Safety System comes with 3 people detecon
cameras, a high-quality speaker and oponal accessories such as a 7” CVBS display and a forkli speed sensor
kit to provide a complete out-of-the-box soluon for a wide range of forklis. By eliminang blind spots and
giving early warning signals of people moving around the vehicle, the system provides an essenal tool for both
forkli accident aversion and enhancement of overall worksite health and safety standards.
1.1 System Layout
Power LED
Reset Buon
MicroSD Card Slot
Speaker DIO 1
Micro SIM Card Slot
DIO 2
CAN/COM
Figure 01: Front panel I/O layout
Antenna Connectors
Right PD Camera
Rear PD Camera
Le PD Camera
CVBS Connector
Power/ACC/GND
Figure 02: Rear panel I/O layout

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
2
1.2 System Dimensions
178mm
56.8mm
Figure 03: Front view system dimensions
167mm
194.6mm
Figure 04: Side view system dimensions

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
3
2. Installaon
The following items are suggested to have on hand to assist in the installaon of the VIA Mobile360 Forkli
Safety System.
Required Items
• LOCTITE 243 Threadlocker
• 3M VHB GPH-160GF series tape
• Tape measure
• Bubble level
• Phillips head screwdriver
• No. 8 pliers or wrench
• Drill (oponal)
• Zip/cable es
• Marker
2.1 System Preparaon
Before installing the VIA Mobile360 M500 system in the target forkli, it is recommended to insert a MicroSD
Card (if video recording is required), secure the waterproof cover for the MicroSD and Micro SIM card slots,
aach the I/O covers for unused ports as well as to secure the vibraon dampening strips to the boom of the
system.
2.1.1 Inserng a MicroSD Card
The VIA Mobile360 M500 system requires a MicroSD card to be installed in order to record video in real me. A
32GB MicroSD card is provided in the system package.
Note:
Failure to install a MicroSD card will not aect the operaon of the system, but video will not be saved.
If a MicroSD card is inserted, the video of the three cameras will be saved locally and looped. Meaning, when
the MicroSD card storage is full, the oldest saved les will be deleted and replaced with the new footage. See
the table below for an esmaon of the hours of video which can be saved from the three cameras based on
varying MicroSD card sizes.
MicroSD Card Size Recording Time
32GB 5.5 hours
64GB 11.2 hours
128GB 22.0 hours
256GB 44.4 hours
400GB 68.9 hours
512GB 88.2 hours
1TB 150.1 hours
Table 01: MicroSD card recording mes
Follow the steps below to insert the MicroSD card into the VIA Mobile360 M500 system:
1. Prepare a MicroSD card with the appropriate storage and ensure it is formaed with either a FAT32 or
exFAT le system. If the MicroSD Card needs to be formaed, see secon 4.3.2 for details.
2. To insert the card into the VIA Mobile360 M500 system, ensure the card is face up, then gently push the
card into the MicroSD card slot located on the front panel and ensure it has been fully inserted.
Note:
To remove the MicroSD card, push gently and the card will eject.

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
4
2.1.2 Securing the Waterproof Cover
To secure the waterproof cover for the MicroSD and SIM card slots located on the front panel, follow the steps
below:
1. Insert the at side of the rubber seal into the groove of the clear plasc cover.
2. Place the cover over the MicroSD and SIM card slots by aligning the screw holes and ensuring the rubber
plugs t securely into the MicroSD and SIM card slots.
3. Secure the cover to the system by ghtening the 6 screws with the tool provided.
Figure 05: Securing the waterproof cover
2.1.3 Aaching the I/O covers
The VIA Mobile360 M500 system comes with addional I/O ports for connecng oponal accessories. It is
recommended to cover the unused ports with the provided caps to ensure the system is waterght. To cover
the unused ports, follow the instrucons below:
1. On the front I/O panel of the VIA Mobile360 M500 system, the DIO 1, DIO 2 and the CAN/COM ports are
not required for the standard setup.
−Use three of the provided M12 caps to cover the DIO 1, DIO 2 and CAN/COM ports. Ensure the caps
are ghtened securely.
Figure 06: Covering unused front panel ports

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
5
2. On the rear I/O panel of the VIA Mobile360 M500 system, the CVBS port (display) and the ANT-M and
ANT-D (for 4G) antenna ports are not required for the standard setup.
−Use one of the provided M12 caps to cover the CVBS port. Ensure the cap is ghtened securely.
−Use the two provided SMA caps to cover the ANT-M and ANT-D antenna ports. Ensure the caps are
ghtened securely.
Figure 07: Covering unused rear panel ports
2.1.4 Aaching the Vibraon Dampening Strips
Two vibraon dampening strips are included to help protect the system against vibraon caused during
operaon of the forkli. To aach the two vibraon dampening strips, follow the instrucons below:
1. Place the VIA Mobile360 M500 system top-down on a at surface and clean the boom of the system of
any dust or debris.
2. Remove the 3M double coated ssue tape from the back of one of the vibraon dampening pads and
place it along the side of the system so the screw hole cutouts align with the system.
3. Repeat the process for the other vibraon dampening strip on the opposite side of the system.
4. Ensure the strips adhere ghtly to the system.
Figure 08: Vibraon dampening strip installaon

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
6
2.2 VIA Mobile360 M500 System Installaon
Before Installing the VIA Mobile360 M500 system on a forkli, a suitable locaon should be determined based
on the following criteria:
• A at surface with enough spacing to accommodate the system chassis and room for aaching the
cables. The recommended spacing is 218mm(W) x 70mm(H) x 327mm(D) (7.87" x 2.76" x 13.78")
• The locaon should allow for airow around the system to ensure proper operaon.
• The surface which the system will be aached to should be able to be either drilled into to support the
included four M5*25mm Molly bolts or provide proper adhesion for double-sided 3M VHB tape GPH-
160GF (not included) to secure the system such that it will not fall or shi due to vibraon or sudden
stops or starts, under normal operang condions.
Figure 09: Recommended installaon space requirements
VIA recommends the following locaons to install the system:
• Under the driver's seat
• On the rear C-pillar
• On or under the forkli roof
Figure 10: Recommended installaon locaons

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
7
2.3 Camera Installaon
The VIA Mobile360 Forkli Safety System includes three (le, right and rear) IP67-rated people detecon
cameras with 3m cables to be installed on the target forkli.
Each camera comes in a labeled box within the VIA Mobile360 Forkli Safety System package and include color-
coded cables (brown for le, black for right and purple for rear) for easy idencaon. Also included for each
camera are a strong magnet with two M5*12mm bolts, one piece of double-sided 3M tape and two M5*25mm
Molly bolts.
Each camera provides approximately a 120° eld of detecon. To minimize occluded regions in the detecon
zone around the vehicle the cameras must be installed within the following criteria:
• All cameras must be installed between 1.6m ~ 2.7m o the ground and should have an unobstructed
view (Cameras do not need to be installed at the same heights).
• All cameras must be installed with their horizon parallel to the ground.
• The rear camera should be installed in the center of the rear of the vehicle.
• The le and right cameras must be installed no further than 3.5m (X) to the le/right of the rear
camera and no further than 2.0m (Y) from the rear (camera) towards the front of the vehicle.
Figure 11: Front & rear camera installaon locaons
Le Camera
Right Camera
Rear Camera
Figure 12: Camera installaon locaons

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
8
2.3.1 Scenario A: Side Cameras < 2.3m from Rear Camera
If the side cameras can be installed no further than 2.3m (X) from the le/right of the rear camera, the
following table can be used to determine the maximum "Y' value the cameras can be installed from the rear
camera towards the front of the vehicle. When installing the side cameras, they should be facing outwards and
parallel with the side of the vehicle. This will provide roughly a 300° eld of detecon around the vehicle.
Maximum Distance 'X' (meters) Maximum Distance 'Y' (meters)
0.50 2.00
0.75 1.88
1.00 1.73
1.25 1.59
1.46 1.46
1.50 1.40
1.75 0.97
2.00 0.53
2.25 0.10
2.30 0.00
Table 02: Maximum side-to-rear camera distances
Figure 13: Scenario A camera installaon
2.3.2 Scenario B: Side Cameras 2.3m ~ 3.5m from Rear
Camera
If the side cameras need to be installed between 2.3m to 3.5m (X) to the le/right of the rear camera, they
should be installed facing outwards with a 300 rotaon towards the rear of the vehicle. The maximum "Y' value
the cameras can be installed from the rear camera towards the front of the vehicle is 2.0m. This will provide
roughly a 240° eld of detecon around the vehicle.

VIA Mobile360 Forkli Safety System 3PD Installaon Guide
9
Figure 14: Scenario B camera installaon
2.3.3 Aaching the Cameras
Aer determining the ideal installaon locaons for each camera, follow the detailed instrucons below to
install the cameras:
1. Camera and mount assembly: There are two methods to x the camera to the forkli:
−Magnet and 3M Tape - Before installing the camera to the forkli, assemble the camera and mount
by aaching the included magnet to the boom of the camera bracket with two M5*12mm bolts
(use a No. 8 wrench), then ax the 3M tape to the boom of the magnet.
Figure 15: Aaching magnets and 3M tape to rear and side cameras
Note:
This requires a magnec surface to aach the camera to. Solely using the 3M tape is not recommended for a
permanent installaon.
−Drilling - Two 25mm Molly bolts can be used to x the camera to the forkli. If drilling will be done,
then the use of the magnet and 3M tape are not required.
Note:
Ensure the surface has enough depth to insert the provided Molly bolts into.
