VIA Technologies EPIA-CN13000G - VIA Motherboard - Mini ITX User manual

Features
Integrated VIA UniChrome™
Pro IGP graphics with MPEG-2
decoding acceleration
Supports DDR2 400/533
SDRAM
Supports TV-out
Supports two SATA
Supports eight USB 2.0
(four as pin headers)
Mini-ITX Series
VIA
EPIA CN
Mini-ITX C7® Board with
MPEG-2 & TV Support
Board Placement
RCA/SPDIF
PS2 KB/MS
10/100 Mbps Ethernet
Audio Jacks/VIA
Smart5.1 Surround Sound
USB 2.0
VIA VT8237R Plus South Bridge
PCI
VIA C7® processor
2 x IDE ATA 133/100
VIA CN700 North Bridge
DDR2 400/533 SDRAM DIMM
WLAN USB module
Specications
Model Name EPIA CN13000G EPIA CN10000EG
Processor 1.3GHz VIA C7® 1.0GHz VIA C7®
Chipset VIA CN700 North Bridge
VIA VT8237R Plus South Bridge
System Memory 1 DDR2 400/533 DIMM slot
Up to 1GB memory size
VGA Integrated VIA UniChrome™ Pro IGP graphics with MPEG-2 decoding acceleration
Expansion Slot 1 x PCI slot
Onboard IDE 2 x UltraDMA 133/100/66 connectors
Onboard LAN 1 x VIA VT6103 10/100 Mbps Ethernet PHY
Onboard Audio VIA VT1618 Muliti-channel AC’97 Codec
Onboard TV Out VIA VT1625 Encoder
Onboard I/O Connectors 1 x USB connector for four additional USB 2.0 ports
2 x SATA connectors
1 x LPT connector
1 x CD-in connector
1 x CIR connector (switchable for KB/MS)
1 x Front panel connector
1 x Front panel audio connector for Line-out and Mic-in
2 x Fan connectors for CPU and system fans
1 x ATX power connector
Back Panel I/O 1 x PS2 mouse port
1 x PS2 keyboard port
1 x VGA port
1 x Serial port
1 x GigaLAN port
4 x USB 2.0 ports
1 x RCA port (S/PDIF or TV-out)
1 x S-Video port
3 x Audio jacks: Line-out, Line-in and Mic-in (Horizontal, Smart 5.1 support)
BIOS Award BIOS
4/8Mbit flash memory
Operating System Windows XP, Windows Embedded CE, Windows Embedded Standard, Linux
System Monitoring &
Management
CPU voltage monitoring
Wake-on LAN, Keyboard Power-on, Timer Power-on
System power management
AC power failure recovery
Operating Temperature 0° C ~ 50° C
Operating Humidity 0% ~ 95% (relative humidity; non-condensing)
Form Factor Mini-ITX (4-layer)
17 cm x 17 cm

* All product specifications are subject to change without notice. Update: June 27, 2012. www.viaembedded.com
IDE BUS
PRIMARY
SECONDARY
PRIMARY
SECONDARY
VIA
SOUTH BRIDGE
VT8237R
PCI BUS
AC LINK
VIA
NORTH BRIDGE
CN700
SMB BUS
VIA
C7
CPU
MII
VIA
ETHERNET
10/100 PHY
VT6103
DDR2 SDRAM
DIMM x1
IDE HDD
CONN
CD-ROM or
DVD-ROM
V- LINK
BUS
LPC BUS
VIA
AC97
VT1617A/18
CD AUDIO
INPUT
CONN
DC INPUT:
INPUT VOLTAGE +12V, +5V, +3V, A5V, -12V
--> +12V, +5V, +3.3V, +2.5V, +1.5V, +0.9V,
VTT, +VCORE, -12V, +5V_SB, +3V_SB,
+V_DIMM, A5V, A3V
SATA BUS
SATA
CONN
ICS
CLOCK
SYNT HESIZER
ICS9 53002
ICS
CLOCK BUFFER
ICS9 P956
SATA
CONN
VIA/WINBOND
SUPER I/O
VT1211/W85697HF
LPC
BIOS
LPT
VIA
TVO
UT
VT1625
LCD/DVI/HDCP/HDMI
I/F CONN
LCD CONNECTOR
(PIN HEADER)
YPbPr/
D-TERM/
SCART
I/F CONN
S-VIDEO
COMPOSITE
CIR CONN
USB CONN
1/3/5/7
PAGE 18
RJ-45
SPEED
LINK/ACT
PCI SLOT x1
(Suppor t 2 PCI
Devices with
Riser Card)
FRONT
AUDIO
CONN
+12
VCORE
CONN
ATX POWER
CONNECTOR
COM1 D-SUB CONN
CRT I/F
CRT D-SUB CONN MIC IN JACK
LINE IN JACK
LINE OUT JACK
S/PDIF OUT RCA
TI
RS-232
MAX3243
LPC CONN
MIC/6.1 CHANNEL
CD INPUT
USB PORT (2.0) x 4 (PIN HEADER)
USB PORT (2.0) x 4
PS2 PORT x 2
S/PDIF OUT
LINE/SPEAKER OUT
LINE IN
MIC IN
COM x 1
FAN1
FAN2
Block Diagram
AccessoriesBack Panel I/O
Ordering Information
Model Name CPU Frequency Description
EPIA-CN13000G 1.3GHz C7® Mini-ITX Board with 1.3GHz C7®, VGA, TV-out, USB, LAN, COM, IDE & SATA
EPIA-CN10000EG 1.0GHz C7® Mini-ITX Board with 1.0GHz C7®, VGA, TV-out, USB, LAN, COM, IDE & SATA
Packing List
Items
1 x ATA-66/100/133 IDE ribbon cable
1 x I/O bracket
S-Video Line-inUSBVGA-out
PS/2
keyboard
RJ-45 RCA/
SPDIF
COM1PS/2
mouse
Line-out Mic-in
EXT-PCI
1 to 2 PCI riser card
PWB-M120
DC-DC power board:
12-24V input/120W output
WLAN USB Module
802.11b/g/n standards
