VIA Technologies VNT5103Q28PS User manual

VNT5103Q28PS
Installation Guide
Revision 1.3
VIA TECHNOLOGIES, INC.
VIA TECHNOLOGIES, INC.

Copyright Notice:
Copyright © 2013 VIA Technologies Incorporated. All Rights Reserved. No part of this document may
be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, in
any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise
without the prior written permission of VIA Technologies Incorporated. The material in this document is
for information only and is subject to change without notice. VIA Technologies Incorporated reserves the
right to make changes in the product design without reservation and without notice to its users.
Trademark Notices:
is a registered trademark of VIA Technologies, Incorporated.
All trademarks are the properties of their respective owners.
Disclaimer Notice:
No license is granted, implied or otherwise, under any patent or patent rights of VIA Technologies. VIA
Technologies makes no warranties, implied or otherwise, in regard to this document and to the products
described in this document. The information provided by this document is believed to be accurate and
reliable as of the publication date of this document. However, VIA Technologies assumes no
responsibility for any errors in this document. Furthermore, VIA Technologies assumes no responsibility
for the use or misuse of the information in this document and for any patent infringements that may arise
from the use of this document. The information and product specifications within this document are
subject to change at any time, without notice and without obligation to notify any person of such change.
Offices:
VIA Technologies Incorporated
Taiwan Office:
1st Floor, No. 531
Zhongzheng Rd., Xindian Dist.
New Taipei City 231, Taiwan
Tel: [phone]
Fax: [phone]
Home page: http://www.via.com.tw
VIA Technologies Incorporated
USA Office:
940 Mission Court
Fremont, CA 94539
USA
Tel: [phone]
Fax: [phone] or [phone]
Home Page: http://www.viatech.com

VNT5103Q28PS
I
Revision History
Release
Date
Revision
Initials
1.0
2013-09-24
1st release
TC
1.1
2013-10-29
Add Swtich Figures Port Connection
TC
1.2
2013-11-08
Add Chapter 7 : Troubleshooting
TC
1.3
2013-12-06
Revise Revision History Format
TC

VNT5103Q28PS
II
P r e f a c e
Introduction
The guide includes these chapters:
Chapter 1: Switch Description
Includes a switch overview, key component identification and key technical
specifications
Chapter 2: Installation Overview
Includes details of the package contents and an outline of switch installation tasks
Chapter 3: Switch Chassis
Includes switch chassis rack installaion, and system cooling requirements.
Chapter 4: Power and Grounding
Includes information on AC power requirements, switch grounding, and powering
on the switch
Chapter 5: Port Connections
Includes information on network interfaces, installing optional transceivers, and
cabling specifications
Chapter 6: Switch Management
Connecting to the switch for management, and information on the system status
LEDs
Chapter 7: Troubleshooting
Information for troubleshooting switch installation and operation.

VNT5103Q28PS
III
Content
Chpater1 Switch Description.................................................................................................1
1.1 Overview........................................................................................................................1
1.2 Power-over-Ethernet......................................................................................................1
Chpater2 Installation Overview .............................................................................................4
2.1 Package Contents .........................................................................................................4
2.2 Switch Installation Tasks ...............................................................................................4
Chpater3 Switch Chassis......................................................................................................8
3.1 General Installation Guidelines......................................................................................8
3.2 How to Install the Switch in a Rack ...............................................................................8
3.3 Rack-Mounting Items.....................................................................................................9
3.4 Rack-Mount Procudure..................................................................................................9
3.5 How to Install the Switch on a Shelf or Desktop......................................................... 11
3.6 Switch Cooling Requirements..................................................................................... 11
3.7 Rack Cooling............................................................................................................... 12
Chpater4 Power and Gronding........................................................................................... 13
4.1 Switch Power Supply.................................................................................................. 13
4.2 Grounding the Chassis ............................................................................................... 14
4.3 How to Connect to AC Power..................................................................................... 15
Chpater5 Port Connections................................................................................................ 16
5.1 Cable Labeling and Connection Records................................................................... 16
5.2 Understanding the Port Status LEDs.......................................................................... 17
5.3 How to Install an SFP Transceiver ............................................................................. 18
5.4 How to Connect to Twisted-Pair Copper Ports........................................................... 19
5.5 Copper Cabling Guidelines......................................................................................... 20
5.6 10/100BASE-TX Pin Assignments ............................................................................. 20
5.7 1000BASE-T Assignments......................................................................................... 21
5.8 Power-over-Ethernet................................................................................................... 23
5.9 Connection Procedure................................................................................................ 23
5.10 How to Connect to SFP Fiber Optic Ports................................................................ 24
5.11 Connection Procedure.............................................................................................. 25
Chpater6 Switch Management........................................................................................... 27
6.1 Understanding the System Status LEDs .................................................................... 27

VNT5103Q28PS
IV
6.2 How to Connect to the Console Port .......................................................................... 28
6.3 How to Reset the Switch............................................................................................. 30
6.4 Reset to the Saved Configuration File........................................................................ 30
6.5 Reset to Factory Default Settings............................................................................... 30
Chpater7 Troubleshooting.................................................................................................. 31
7.1 Diagnosing LED Indicators ......................................................................................... 31
7.2 System Self-Diagnostic Test Failure........................................................................... 31
7.3 Power and Cooling Problems..................................................................................... 32
7.4 Installation................................................................................................................... 32
7.5 In-Band Access........................................................................................................... 32

VNT5103Q28PS
V
F i g u r e
Figure 1: Front Panel VNT5103Q28PS....................................................................................................2
Figure 2: Rear Panel................................................................................................................................3
Figure 3: Installing the Switch in a Rack ..................................................................................................4
Figure 4: Connecting AC Power...............................................................................................................5
Figure 5: System LEDs ............................................................................................................................6
Figure 6: Console Port .............................................................................................................................6
Figure 7: Making a Connection to an SFP Port .......................................................................................7
Figure 8: Attaching the Brackets..............................................................................................................9
Figure 9: Installing the Switch in a Rack............................................................................................... 10
Figure 10: Attaching the Adhesive Feet................................................................................................ 11
Figure 11: VNT5103Q28PS Switch Cooling ......................................................................................... 12
Figure 12: VNT5103Q28PS Switch Cooling ......................................................................................... 12
Figure 13: AC Power Supply Socket..................................................................................................... 13
Figure 14: Grounding Terminal ............................................................................................................. 14
Figure 15: AC Power Cord and Power Socket...................................................................................... 15
Figure 16: Port Status LEDs ................................................................................................................. 17
Figure 17: Inserting an SFP Transceiver into a Slot............................................................................. 19
Figure 18: RJ-45 Connector.................................................................................................................. 21
Figure 19: Making Twisted-Pair Connections ....................................................................................... 23
Figure 20: Making a Connection to an SFP Port .................................................................................. 25
Figure 21: System Status LEDs............................................................................................................ 27
Figure 22: Console Port ........................................................................................................................ 28
Figure 23: Console Port Connection..................................................................................................... 29
Figure 24: Reset Button ........................................................................................................................ 30

VNT5103Q28PS
VI
Table
Table 1: AC Power Supply Specifications............................................................................................. 13
Table 2: Port Status LEDs..................................................................................................................... 17
Table 3: Maximum Twisted-Pair Copper Cable Lengths ...................................................................... 20
Table 4: 10/100BASE-TX MDI and MDI-X Port Pinouts....................................................................... 21
Table 5: 1000BASE-T MDI and MDI-X Port Pinouts............................................................................. 22
Table 6: Maximum Gigabit Ethernet Fiber Cable Lengths.................................................................... 24
Table 7: System Status LEDs ............................................................................................................... 27
Table 8: Console Cable Wiring ............................................................................................................. 28
Table 9: Troubleshooting Chart............................................................................................................. 31

VNT5103Q28PS
1
Chpater1 Switch Description
1.1 Overview
Thank you for choosing the VNT5103Q28PS switch system. This switch is built with
leading-edge technology to deliver reliable high-performance connectivity for your data
network.
The VNT5103Q28PS is Gigabit Ethernet Layer 2 switches with 24 10/100/1000BASE-T ports,
and four Small Form Factor Pluggable (SFP) transceiver slots for fiber connectivity.
The switch include an SNMP-based management agent, which provides both in band and
out-of-band access for managing the switch. Further, the switches support both web and
CLI-based configuration.
1.2 Power-over-Ethernet
All of the 10/100/1000 Mbps ports on the ECS4210-28P support both the IEEE 802.3af-2003
and IEEE 802.3at-2009 PoE standards that enable DC power to be supplied to attached
devices using wires in the connecting Ethernet cable.
Key Hardware
The switches consist of several key hardware components. This manual describes
Components
Each specific component, or related components, together with their installationrequirements
and procedures in each chapter. To understand each component indetail, refer to the
relevant section.

VNT5103Q28PS
2
Figure 1: Front Panel VNT5103Q28PS
10/100/1000BASE-T RJ-45 Ports
The switch contains 24 10/100/1000BASE-T RJ-45 ports that support 10/100/1000BASE-T
copper links to other devices. For more information, see “How to Connect to Twisted-Pair
Copper Ports”.
Gigabit SFP Slots
The switch contains four Small Form Factor Pluggable (SFP) transceiver slots that operate
up to 1 Gbps full duplex. For more information, see “How to Connect to SFP Fiber Optic
Ports”.
PoE Button
Pressing the PoE button on the VNT5103Q28PS front panel changes the Port LEDs to
display PoE status. For more information, see “Understanding the System Status LEDs”.
Reset Button
Pressing the reset button on the right side front panel causes the switch to restart or restore
factory default settings. For more information, see “How to Reset the Switch”.
System LEDs
For information on system status LED indicators, see “Understanding the System Status
LEDs”.
