Vibradorm VHS/CDL-BF-07 User manual

Cable handset
VHS/CDL-BF-07
Operating Instructions
For adjustable beds with a
VIBRADORM dual drive
V-MAT-Basic-4500 or
V-MAT-Basic-6000

2
Foreword
Revision history
Version Date
1.0 1 3.09.2019
Change
First edition
In your own interest
Read these operation instructions and
keep them in a safe place. Observe the
safety instructions.
Disclaimer
We would like to point out that the
company VIBRADORM GmbH will not
assume any liability for injuries or damage
that occurs as a result of
■ non-observance of these operating
instructions,
■ changes to the product that were not
approved by VIBRADORM GmbH, or
■ the use of spare parts not
manufactured or released by
VIBRADORM GmbH, or
■ plug-in parts not manufactured or
released by VIBRADORM GmbH.
Manufacturer's address
VIBRADORM GmbH
Relystraße 38
64720 Michelstadt
GERMANY
Tel.: ++49 (0)6061 / 94 44 0
Fax: ++49 (0)6061 / 94 44 10
http://www.vibradorm.de
E-Mail: [email protected]
Foreword

3
Table of contents
Foreword 2
Revision history 2
In your own interest 2
Disclaimer 2
Manufacturer's address 2
Table of contents 3
1 General . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 How to use these instructions . . . . . . . . 4
1.2 Information about these operating
instructions. . . . . . . . . . . . . . . . . . . . . . . . 4
2 Safety instructions . . . . . . . . . . . . . . . . 4-6
2.1 Intended use. . . . . . . . . . . . . . . . . . . . . . 5
2.2 Improper use. . . . . . . . . . . . . . . . . . . . . . 5
2.3 Specific safety instructions . . . . . . . . . . 6
2.4 Operating instructions of the bed
manufacturer . . . . . . . . . . . . . . . . . . . . . 7
2.5 Electronic medical equipment. . . . . . . 7
3 Commissioning . . . . . . . . . . . . . . . . . . . . 8
3.1 The dual drive . . . . . . . . . . . . . . . . . . . . . 8
3.2 Connections . . . . . . . . . . . . . . . . . . . . . . 8
4 Operation . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1 Status LED . . . . . . . . . . . . . . . . . . . . . . . . 9
4.2 Bed adjustment . . . . . . . . . . . . . . . . . . 10
4.3 Torch function. . . . . . . . . . . . . . . . . . . . 10
4.4 Battery emergency lowering . . . . . . . . 9
6 Malfunctions / troubleshooting . . . . . 10
7 Maintenance and cleaning . . . . . . . . 10
8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table of contents

4
1 General
1.1 How to use these instructions
Symbols used
Indicates about a dangerous situation;
potential consequences: death or
serious injury.
Potentially dangerous situation;
potential consequences: slight or
minor injuries.
General information;
Information that is important for the
function or operation, or that will
facilitate operation or assembly.
1.2 Information about these
operating instructions
These operating instructions serve the
successful and safe use of the cable
handset VHS/CDL-BF-07.
The operating instructions will help you
to avoid dangers, and minimise repairs
and failures.
These operating instructions were
compiled with great care. No liability
will be assumed for the accuracy and
completeness of the data, images or
drawings, unless prescribed by law.
Subject to technical amendments that
serve continuous product improve-
ment without prior announcement!
2 Safety instructions
The cable handset VHS/CDL-BF-07 can
be used by children aged 8 and
upwards and by persons with limited
physical, sensory or mental aptitude or
lack of experience and/or knowledge if
they are supervised or have received
instruction from a person responsible for
their safety as to how the cable
General
Warning
Caution

5
Safety instructions
handset is used and the associated
risks.
Children may not play with the cable
handset.
Children may not clean or service the
device without supervision.
2.1 Intended usage
The cable handset is designed for:
• operating VIBRADORM dual drives.
• use within the home
The cable handset is only designed for
the designated purpose. Any other
use is deemed improper and can lead
to accidents or the destruction of the
device.
This will lead to immediate invalidation
of the warranty and any warranty
claims by the end user with respect to
the manufacturer.
2.2 Improper usage
Please observe the following
information about improper usage.
The cable handset and the dual drive
may not be used
• with a medical product or installed
in a medical product,
• in an environment in which there
are inflammable or explosive gases
or vapours (e.g. anaesthetics),
• in damp environments,
• outdoors,
• in applications that are washed in
mechanical washing systems,
• for lifting and lowering of loads, in
craftsman or industrial areas or in
the household.
Caution
Warning

6
Safety instructions
2.3 Specific safety instructions
The following safety instructions serve
to protect you, third parties and the
equipment, and must therefore be
adhered to strictly.
Operating environment
• The cable handset may not come
into direct contact with damp or
water. The cable handset is only
suitable for dry indoor rooms.
• When switching from cold to warm
environments, allow the cable
handset time to adjust to the
ambient temperature for a few hours
before use, otherwise it may suffer
damage as a result of
condensation.
• Never use the cable handset close
to devices that emit strong
electromagnetic fields. This could
impact on its function.
• Also avoid environments exposed to
direct sunlight, high temperatures,
cold, damp or wet.
The device
• Check first whether the housing or
cable is damaged. If this is the case,
do not use the cable handset but
contact the supplier for a
replacement.
• For safety reasons, it is prohibited to
make any unauthorised changes to
the cable handset. Do not open the
housing of the cable handset, other-
wise the warranty will become void.
Operation
• The cable handset only functions
correctly if it is commissioned and
used properly.
• To avoid injury, never allow children
or other vulnerable persons to use
the cable handset unsupervised.
Caution

7
2.4 Operating instructions of the
bed manufacturer
Also observe the safety notes in the
operating instructions of the bed
manufacturer!
Depending on the design or model of
the adjustable bed, hazards to the
user may occur that are not covered
by this manual.
These installation instructions do not
contain all information required to
safely operate the end product,
because the bed manufacturer will
carry out a risk assessment for the
adjustable bed. This will then be used
as the basis for the safety notices in its
operating instructions.
2.5 Electronic medical equipment
This product is designed and
manufactured according to the
Standard DIN EN 60335-1 (Safety of
Household and similar Electrical
Appliances) and carries the CE mark.
If you use a Medical Device such as
pacemaker you may wish to contact
your specialist to answer any questions.
Safety instructions

8
111222333
hhh
Commissioning
3 Commissioning
3.1 The dual drive
There are 3 different dual drive types
that differ by the emergency lowering
batteries:
No batteries / emergency lowering 11
One battery22
Two batteries33
No batteries / emergency lowering 1
not available
One battery2
Two batteries3
With one or two batteries an emer-
gency lowering is possible. The
difference ist the speed of the drives.
Socket for the cable Handseth
3.2 Connections
• First connect the cable Handset to
the corresponding socket of the h
dual drive.
• Then connect the mains plug to the
mains socket.
• The system is now ready for use.

ttt
9
111222
333444
555666
777
sss
Operation
4.1 Status LED s
When a button is pressed, this LED
lights up. If the button is kept pressed,
the LED flashes.
4.2 Bed adjustment
Before making any adjustments:
Check that neither you nor anyone
else or any pets are at risk from to the
moving parts of the adjustment
mechanics!
Both drives upwards.1
Both drives downwards.2
3 Back adjustment upwards.
4 Back adjustment downwards.
5 Leg adjustment upwards.
6 Leg adjustment downwards.
As long as you keep the buttons
pressed, the drives will move.
Caution
4 Operation

10
Operation
4.3 Torch function
The torch LED lights up as long as t
the button is kept pressed.7
4.4 Battery emergency lowering
The battery emergency lowering
allows the drive system to be opera-
ted during a power failure. One or two
9V batteries can be used to power the
dual drive in the event of a power
failure.
Because of their very limited capacity
the batteries should only be connec-
ted when a power failure occurs. They
can only be used for emergency
lowering once. The used batteries
should then be replaced and properly
disposed of.
The battery emergency lowering is not
a safety system and does not avert
danger!
Remove the strain or load from the
adjustable bed before you perform an
emergency lowering! See also page 7
of these instructions!
In the case of a power failure:
1. Connect the 9V batteries.
2. Remove loads from the bed.
3. Move the bed with the cable
handset into the flat (Sleep) position.
Caution

11
Troubleshooting, maintenance, disposal
6 Malfunctions /
troubleshooting
Before contacting the service office of
the furniture manufacturing company,
please try the following in the event of a
malfunction:
• Check to ensure that the dual drive is
connected to the mains supply (power
socket).
• Check (e.g. with a lamp) that the
power socket actually works (fuse).
• Check the cable handset for proper
connection to the dual drive.
7 Maintenance and
cleaning
The cable handset is maintenance-free,
apart from the replacement of the
batteries.
Clean the housing with a slightly damp
cloth. Do not use any aggressive
detergents or scouring agents.
8 Disposal
This symbol on the product or its packa-
ging indicates that the product may not
be disposed of via the household waste
system. Users have a duty to dispose of
the old equipment via the collection
point for electronic and electrical scrap.
Separate collection and correct disposal
of your old equipment helps conserve
natural resources and guarantees recyc-
ling, which protects human health and
preserves the environment.
Please contact your local council or
waste disposal authority to find out
where the collection points are for your
old equipment.
Disposal of the cable handset in Germa-
ny is subject to the Electrical Equipment
Act, internationally to the EU Directive
2011/65/EU RoHS or the respective natio-
nal laws. (The product is not subject to
the EU Directive 2002/96/EC (WEEE) and
its supplement EU Directive 2003/108/EC.)
Disposal of batteries in the EU is subject
to the Battery Directive 2006/66/EU, in
Germany to the Battery Act (BattG)
dated 25.6.2009, and internationally to
the respective national laws.

Document is subject to change without prior
announcement.
© 2019 VIBRADORM GmbH. All rights reserved.
It is strictly forbidden to duplicate this
document in any form without the prior
consent of the company VIBRADORM GmbH.
VIBRADORM GmbH is not liable for any errors in
this document or for any ensuing damages
connected to the delivery, performance or
use of this material.
VIBRADORM GmbH
Relystrasse 38 • D-64720 Michelstadt
eMail: [email protected]
Internet: www.vibradorm.de
© VIBRADORM GmbH, September 2019
Drawing No. 080.000.519
Item No. 006255
