Vibrant Control 4 C4-DX-DEC-5 User manual

WARNING! Use only with 24V DC drivers with a wattage capacity that can handle
the total load; see page 2 for more details. Factory warranty will be void if used
with a non-trecommended power supply, transformer or driver.
WARNING! To reduce the risk of fire, electric shock or injury to persons, make
sure that the electrical power to the system is disconnected at the source prior to
installation or any servicing.
WARNING! This device must be protected by a circuit breaker (20A max).
ATTENTION! Cet appareil doit être protégé par un disjoncteur (20A max.)
IMPORTANT! Using this product in a manner other than outlined in this document
voids your warranty. Further, Snap One is NOT liable for any damage incurred
with the misuse of this product. See “Troubleshooting.”
IMPORTANT! Snap One does not guarantee the performance of any bulb
or lamp/fixture in your environment. Customer assumes all risks, including
any damage to snap one products, associated with (i) the type, load rating
and quaility of the bulb and lamp/fixture, or (ii) any use or installation not in
accordance with the documentation furnished by snap one, either with the snap
one product or at www.Snapone.Com.
Before you install the DMX Decoder
Ensure that the location and intended use meet the following criteria:
• Your tape light does not exceed the maximum run length.
• Your power supply is rated for 20% more than the total
wattage of the run.
• The voltage drop from the tape light length and the length of
connecting wires does not go below 21.6V.
• Each decoder’s load does not exceed 192W.
1 Before you install the power supply, calculate the length of the
tape light run and multiply the length by the wattage per distance
specification.
For example, if you have 10 feet of Fully Tunable linear light at 6.5
W per foot, you need at least a 65 watt power supply, that would
mean you need the C4-PS24-96 - Control4 Vibrant 96 Watt 24V
Power Supply.
2 Ensure that the total length of tape, wiring, and connectors does
not drop the voltage below 21.6V. See this link to calculate voltage
drop based on length of wires and wire gauge:
ctrl4.co/vibrant-voltagedrop.
Installing the DMX Decoder
The DMX Decoder requires the following:
• This receiver requires a Vibrant 24V DC power supply (sold
separately).
• This receiver requires a Creative Lighting DMX Gateway (sold
separately).
1 Determine desired location of receiver. Securely mount the
decoder using the mounting tabs on either end of the receiver.
5-Channel DMX Decoder
Installation Guide
2 This receiver has 5 x 8A current output terminals that can be
used with single color, Fully Tunable White, RGB/RGBW, or
RGB+Tunable White Vibrant tape light. Wire the decoder to the
tape light by following the light’s instruction manual and wiring
diagrams, ensuring to match polarity (wiring varies depending on
product). Connect light prior to bringing any power to the system.
3 Connect the DMX controller (gateway) to the decoder. Connect
red to D+, black to D-, and green to GND.
4 Connect the 24V DC supply power to the decoder, connecting red
to V+ and black to V-.
Connecting more than one DMX decoder
With one DMX gateway to communicate with your Control4 system,
you can connect more than one Vibrant 5-Channel DMX decoder to
control multiple tape lights.
Connecting more than one DMX decoder with jumper wires
1 From the first decoder, wire D+, D-, and GND on the DMX in/
out port to D+, D-, and GND on the second decoder. Use an
appropriate wire gauge for the expected current.
2 From the first decoder, wire V+ and V- on the DC Power Input
to V+ and V- on the second decoder (or connect another power
supply to the second decoder if more wattage is needed for this
tape light).
3 For the last decoder in the line, place a 120-ohm terminating
resistor in the remaining D+ and D- terminals. Terminating RJ45
and XLR plugs are also acceptable for their respective ports.
DMX
Controller
+
1
2
3
Channel
+24V DC
R
G
B
Tape
4 WW
5 CW
24V Adaptive Series
Power Supply
Black
(Line in
/Hot)
White (Neutral)
Copper (To ground)
DMX
Controller
+24
–
+24
+24
Specifications
The specifications are described below.
Model number C4-DX-DEC-5
Input voltage 12-24V DC
Current Max 40.5A
Output wattage 96-192W per channel
Output current 8A per channel
Rating cURus Recognized / FCC Compliant / RoHs Compliant /
IP20 Dry Location
Warnings and considerations
IMPORTANT! Read all installation instructions before beginning; if not qualified,
do not attempt installation. Contact a qualified electrician
IMPORTANT! To reduce the risk of fire, electric shock, or injury to persons, pay
close attention to this manual and stay within its guidelines when using this
product. Save these instructions for future use.
IMPORTANT! Do not cover this product with paper surface coverings, fabrics,
streamers, or other similar combustible materials.
IMPORTANT! This device is rated for indoor use in dry locations.
IMPORTANT! Do not secure this product or its cord with staples, nails, or like
means that may damage the outer jacket or cord insulation.
IMPORTANT! Do not use if there is any damage to the tape light, diodes or power
cord insulation; inspect periodically.
IMPORTANT! Do not install in airtight tanks or enclosures of any kinds.
IMPORTANT! Size your 24V DC driver appropriately for your run distance.
Be sure not to load a driver to 100% as this will reduce its eciency; an 80%
maximum load is recommended.
WARNING! These products may represent a possible shock or fire hazard if
improperly installed or attached in any way. Products should be installed in
accordance with these instructions, current electrical codes, and/or the current
National Electric Code (NEC).
Supported models
• C4-DX-DEC-5 - Control4 Vibrant 5-Channel DMX Decoder
Introduction
Vibrant 5-Channel DMX signal receiver/decoder is installed
in-line between the Creative Lighting DMX Gateway and the
Vibrant tape light. This decoder translates DMX signals into
the PWM control signal used by RGB and tunable white LEDs,
and allows for flawless integration into new and existing DMX
installations. Seamlessly integrate color-changing tape light
for temporary or permanent applications.
Connecting more than one DMX decoder with Cat 6
1 From the first decoder, connect the Cat 6 cable from the DMX in/
out port to the second decoder.
2 From the first decoder, wire V+ and V- on the DC Power Input
to V+ and V- on the second decoder (or connect another power
supply to the second decoder if more wattage is needed for this
tape light).
3 For the last decoder in the line, place a 120-ohm terminating
resistor in the remaining D+ and D- terminals. Terminating RJ45
and XLR plugs are also acceptable for their respective ports.
Connecting more than one DMX decoder with 5-pin DMX XLR
1 From the first decoder, connect the 5-pin DMX XLR (120 ohm)
cable from the DMX Signal port to the second decoder.
2 From the first decoder, wire V+ and V- on the DC Power Input
to V+ and V- on the second decoder (or connect another power
supply to the second decoder if more wattage is needed for this
tape light).
3 For the last decoder in the line, place a 120-ohm terminating
resistor in the remaining D+ and D- terminals. Terminating RJ45
and XLR plugs are also acceptable for their respective ports.
DMX
Controller
DMX
Controller

Operating the DMX Decoder
1 This decoder can operate in Standalone Mode or Decoder Mode.
Before choosing any other setting, select which mode you wish to
operate: run1 for DMX Decoder Mode and run2 for Standalone
Mode.
2 Use the Up and Down buttons to toggle through menu selections.
3 Use the Enter button to select and the Back button to return to
main menu.
Menu Options
A.XXXr DMX Address: default 001
CHXX DMX Channel Quantity - Default CH05
CH01 = 1 DMX address: all output channels 001
CH02 = 2DMX address: output 1,3=001 & 2,4,5=002
CH03 = 3DMX address: output 1,2=001,002 & 3,4,5=003
CH04 = 4DMX address: output 1,2,3=001,002,003 & 4,5=004
CH05 = 5DMX address: output 1,2,3,4,5=001,002,003,004,005
btXX PWM Resolution: 8 bit or 16 bit - default 16 bit
PFXX PWM Frequency: 00 to 30 - default 1kmHz
gAXX Dimming Curve Gamma Value: 0.1 to 9.9 - default gA1.5
dPXX Decoding Mode: default dp1.1
1st X is DMX address qty, 2nd X is PWM channel qty
Example DMX Decoder settings for one Vibrant tape light
Follow this example to set up your DMX Decoder settings. In this
example, you have
• 1 DMX decoders
• 1 tape light - Fully Tunable White
1 Configure the first DMX decoder to a DMX address of 1 (A.001).
2 Configure the first DMX decoder for 3 channels (CH03) for the
Fully Tunable White tape light
3 In the driver for the Vibrant Fully Tunable White tape light in
Composer, set the Mode to Fully Tunable and set the address for
each channel (1-3).
Example DMX Decoder settings for multiple Vibrant tape lights
Follow this example to set up your DMX Decoder settings. In this
example, you have
• 2 DMX decoders
• 2 tape lights, 1 RGBTW and 1 RGBW.
1 Configure the first DMX decoder to a DMX address of 1 (A.001).
2 Configure the first DMX decoder for 5 channels (CH05) for the
RGBTW tape light.
3 Since the first DMX decoder is using 5 channels, this decoder
starts at the next channel. Configure the second DMX decoder to
a DMX address of 6 (A.006).
4 Configure the second DMX decoder for 4 channels (CH04) for the
RGBW tape light.
5 In the driver for each Vibrant tape light in Composer, set the Mode
for each light (RGB + TW and RGBW) and set the address for each
channel in each light (1-5 for the RGBTW and 6-10 for the RGBW). Copyright ©2022, Snap One, LLC. All rights reserved. Control4 and SnapAV and their respective logos are registered trademarks or trademarks of Wirepath Home Systems, LLC, dba “Control4” and/or dba “SnapAV” in
the United States and/or other countries. 4Store, 4Sight, Control4 My Home, Snap AV, Araknis Networks, BakPak, Binary, Dragonfly, Episode, Luma, Mockupancy, Nearus, NEEO, Optiview, OvrC, Pakedge, Sense, Strong,
Strong Evolve, Strong Versabox, SunBriteDS, SunBriteTV, Triad, Truvision, Visualint, WattBox, Wirepath, and Wirepath ONE are also registered trademarks or trademarks of Wirepath Home Systems, LLC. Other names and
brands may be claimed as the property of their respective owners. All specifications subject to change without notice.
200-00820-A 20221110DH
Troubleshooting
Factory Restore
• To restore factory default settings, press and hold both the Back
and Enter buttons until the digital display turns o and then
release both buttons. The system will reset and the digital display
will turn on again with all settings restored to default.
Warranty and legal information
Find details of the product’s Limited Warranty at snapone.com/legal
or request a paper copy from Customer Service at 866.424.4489 .
Find other legal resources, such as regulatory notices and patent
information, at snapone.com/legal .
