INSTRUCTIONS FOR
INSTALLATION AND OPERATION
MODEL V21 ODA-B DISTRIBUTION AMPLIFIER
1. INTRODUCTION
This manual covers the installation, operation, and
maintenance of the Model V210DA-B Distribution Am-
plifier. This unit should be installed by a qualified
technician using approved materials and wiring prac-
tices in accordance with national, state, and local wiring
codes. Read these instruction through completely before
attempting installation.
The V210DA-B Distribution Amplifier provides a
maximum of six video outputs each equal to the single
video input to be used for operation of other video
equipment. Circuitry with individual and isolated com-
plementary transistor pairs provides power for several
75ohm loads, Refer to Figure 1.
Characteristics include AC coupling (for operation with
both AC- and DC-coupled cameras), color compatibil-
ity, and a broad frequency response. The V210DA-B is
available in two input voltage configurations, 120 VAC
and 230 VAC (Model V210DA-B-230). The term
V210DA-B is used throughout this manual to refer to
both models unless specifically stated otherwise.
Model V210DA-B is housed in a sturdy, heavy-gauge
steel chassis protected by a steel cover finished in gray
textured enamel.
s
VICON
POWER
Legend
1 CAMERA video input
2Video outputs, 1-6
3 Power cord
4 POWER push button
5 Power LED
FRONT PANEL
b
5
Figure 1
Front and Rear Panels
WARNING: TO PREVENT RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
Product specifications subject to change without notice.
Vicon part number 8006-8671-02-00
VICON INDUSTRIES INC. 89 ARKAY DRIVE, HAUPPAUGE, N.Y. 11788 l TEL: 516-952-CCTV (2288) l FAX: 516-951-CCTV (2288)
TOLL FREE: l-800-645-91 16 . UK: 44/(O) 1489/577775 . INFOFAX: 1-800-287-l 207

IMPORTANT SAFEGUARDS
I
GRAPHIC SYMBOL EXPLANATION
The Ii
triang f
htning flash with arrowhead symbol, within an equilateral
e, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation
alert the user to t PI
oint within an equilateral triangle is intended to
e presence of important operating and mainte-
nance (servicing) instructions in the literature accompanying the
unit.
1. Read Instructions - All the safety and operating instructions should
be read before the video product is operated.
2. Retain Instructions-All the safety and operating instructions should
be retained for future reference.
3. Heed Warnings - All warnings on the video product and in the
operating instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should be
followed.
5. Cleaning - Step a applies to equipment that can be disconnected
from the CCTV system without seriously jeopardizin7security. Step b
applies to equipment that must operate continuous y such as video
switching equipment at military installations.
a. Disconnect this video product from its power source before
cleaning. Do not use caustic, abrasive, or aerosol cleaners. Use
a damp cloth for cleaning.
b. Use a damp cloth to clean the equipment. Do not allow
moisture or liquids to enter any vents. Do not use caustic,
abrasive, or aerosol cleaners.
6. Attachments - Do not use attachments not recommended by Vicon
as they may cause hazards.
7. Water and Moisture - Do not use this video product in any location
where it may be exposed to water or moisture. This does not apply to
outdoor camera housings, qutdoor pan-and-tilt drives, and other
equipment designed for direct exposure to outdoor environments.
8. Accessories - Do not place this video producton any unstable surface
or table. The video product may fall, causing serious Injury to a person
and serious damage to the video product. Use onl
accessory recommended by Vicon, or sold with t
with a mounting
it e video product.
Any mounting of the video product should follow Vicon’s instructions,
and a mounting accessory recommended by Vicon should be used.
9. Ventilation -Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the video product and
to protect it from overheating, and these openin s must not be blocked
or covered. The openings should never be b ocked by $
video
cr roduct on a ru 8
or other similar surface. This VI J
lacing the
shoul never be place eo product near or over a radiator or heat register. This
video product should not be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or Vicon’s
instructions have been adhered to.
10. Power Sources -This video product should be operated only from
the type of power source indicated on the marking label. If you are not
sureof the type of power supplied to your installation site, consult your
Vicon dealer or local power company. For video products intended to
operate from battery power, or other sources, refer to the operating
instructions.
12. Power-Cord Protection - Power supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, payin
convenience receptacles, an B
particular attention to cords at plugs,
product. the point where they exit from the video
13,OutdoorCableGrounding-Ifanoutsidecablesystem isconnected
to the video product, be sure the cable system is grounded so as to
provide some protection against voltage surges and built-up static
A
A
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
charges. Section 810 of the National Electrical Code, ANSI/NFPA
70-l 984, provides information with respect to proper grounding of the
lead-in wire to an antenna discharge unit, size of grounding conduc-
tors, location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
14. Lightninv -
not used for For added protection for this video product when it is ong periods of time, disconnect it from its power source
and from the cable system. This prevents,damage to the video product
due to lightning and power-line surges.
15. Power Lines - An outside cable system should not be located in
the vicinity of overhead
P
ower lines or other electric light or ower
circuits, or where it can all Into such power lines or circuits. e, hen
installing an outside cable system, extreme care should be taken to
kee from touching such power lines or circuits as contact with them
mlg t be fatal. 3
16. Overloading - Do not overload wall outlets and extension cords
as this can result in a risk of fire or electric shock.
17. Object and Liquid Entry - Never push objects of any kind into this
video product through openings as they may touch dangerous volta e
points or short out
Never spill liquid o
Parts that could result in a fire or electric shot
i
.
any kind on the video product.
18. Servicing - Do not attempt to service this video product yourself
as opening or removing covers may expose ou to dangerous voltage
or other hazards. Refer all servicing to qua11 led service personnel. 4
19. Damage Requiring Service - Disconnect this video product from
its power source and refer servicing to qualified service personnel
under the following conditions. Note that step c does not apply to
outdoorcamera housings, outdoorpan-and-tiltdrivesandotherequip-
ment specifically designed for direct exposure to outdoor envlron-
ments.
a. When the power-supply cord or plug is damaged.
b. If Ii
%
uid has been spilled, or objects have fallen into the video
pro uct.
c. If the video product has been exposed to rain or water.
d. Ifthevideo productdoes not operate normally b followingthe
operatin
ered by t e operating instructions, as an impro !l
instructions. Adjust only those contra s that are cov- Y
er adjustment
of other controls may result in damage and WII often require
7
extensive work by a qualified technician to restore the video
product to its normal operation.
e. If the video product has been dropped or the cabinet has been
damaged.
f. When the video product exhibits a distinct change in perform-
ance - this indicates a need for service.
20. Replacement Parts-When replacement parts are required, be sure
the service technician has used replacement parts specified b Vicon
or that have the same characteristics as the original part. iiUnaut orized
substitutions may result in fire, electric shock, or other hazards.
21. Safety Check - Upon completion of any service or repairs to this
video product, ask the service technician to perform safety checks to
determine that the video product is in proper operating condition.
2X671-697

COAXIAL CABLE RECOMMENDATIONS
CAUTION:
A
Careful selection of the proper cab/e is essen-
tial to obtain the bestperformance from this equipment.
Vicon assumes no responsibility for poor performance
when cables other than those recommended are in-
stalled. In all cases, coaxial cable impedance should be
7.5 ohms.
Installation Tips
Do not stretch cable or subject it to sharp bends.
Keep the cable out of contact with hot pipes or any other heat
source. Even ifthere is notenough heattocauseobviousdamage
to the cable, transmission characteristics will be affected.
Materials
Use only cable with a pure copper center conductor, Do not
use cable with either a copper-plated steel or an aluminum
center conductor because these do not transfer signals effec-
tively in the frequency range used in CCTV networks. Acenter
conductor with low DC resistance is required for effective
CCTV operation.
Solid-core bare copper conductor is best suited to video
applications, except where flexing occurs. If the coaxial
cable will be subjected to flexing during normal use, select
a cable with a stranded center conductor.
In locations where the cable must be continuously flexed (for
example, with scanners or pan-and-tilt drives), use cable
intended for such movement. This cable will have stranded
wire center conductor.
Use only crimp-type BNC connectors.
Cable Types and Operating Distances
The most commonly used cable types are RG-59/U and
RG-II/U. Each is actually a family of cables with widely
varying electrical characteristics, some of which are
not
suitable for CCTV applications.
The preferred dielectric material is cellular (foam) polyethyl-
ene. It has better electrical characteristics than solid polyeth-
ylene, but is morevulnerableto moisture. Therefore, useonly
solid polyethylene dielectric cable with a heavy exterior
insulation in applications subject to moisture.
The maximum camera-to-unit distance for the three most
common cables is listed in Table A. The characteristics of the
cables in this table should be used as a guideline when cables
other then Belden are used. Materials and construction must
follow the guidelines above. Table B gives some equivalent
cable numbers of other manufacturers. Vicon recommends
The shield must be copper braid providing 95% or better
coverage. the following coaxial cable types, unless otherwise specified
elsewhere in this manual.
TABLE A
RECOMMENDED CABLES
Cable
Type Belden
Type No.
Alpha
Type No.
West Penn
Type No. Type Center Conductor Type Shield and 70 Coverage Maximum Distance
for Best Picture
FIG-1 l/U 8213 9847
RG-6U 9248 9804C
8281 9803
RG-59/U 9259 -
9659
-
‘BC = bare copper, 2TC = tinned copper
ail,4811 14 Solid BC’ BC braid (95%) 820 ft (250 m)
806,4806 18 Solid BC Foil +61%TC2 (100%) 530ft(160m)
al5
20 Solid BC 2 TC braids (96%) 400 ft (120 m)
816 22 Stranded BC BC braid (95%) 400 ft (120 m)
-
22 Stranded BC ,BC Braid (95%) 400ft(120m)
TABLE B
DC RESISTANCE (OHMS) PER 1000 FEET OF EQUIVALENT CABLES
Cable Belden
Type No. DCRI 1000 ft (km)
Alpha
Type No. DCFU 1000 ft (km) West Penn Type No. DCRI 1000 ft (km)
RG-1 l/U
RG-6/U
8213
9248
2.6 (8.5)
7.5 (24.6)
9847
9804c
2.6 (8.5)
7.5 (24.6)
aii,4811
806,4806
2.6 (8.5)
7.5 (24.6)
8281 9.9 (32.5) 9803 9.9 (32.5) al5
9.9 (32.5)
RG-59/U
9259 15.0 (49)
- - 816 15.0 (49)
9659 15.0 (49)
- - - -
X671-697
3

2. INSTALLATION
2.1 Unpacking and Inspection
All Vicon equipment is tested and inspected before leaving
the factory. It is the carrier’s responsibility to deliver the
equipment in the same condition as it left the factory.
2.1.1 INSPECTION FOR VISIBLE DAMAGE
2.1.2 INSPECTION FOR CONCEALED
DAMAGE
As soon as possible after delivery, unpack the unit and
inspect it for concealed damage. Do not discard the carton
or packing materials. If the unit is damaged, contact the
Immediately inspect the cartons upon delivery. Make acarrier immediately and request forms for filing a damage
note of any visible damage on all copies of the carrier’s claim. Make arrangements for a representative of the
freight bill. carrier to inspect the damaged equipment.
Make sure the carrier’s agent (the person making the
delivery) signs the note on all copies of the bill. If the agent
does not have claim forms, contact the carrier’s office.
If the equipment must be returned for repair, follow the
Shipping Instructions at the end of this manual.
2.2 Typical V21 ODA-B Systems
In a simple V210DA-B configuration, the output from multiple locations. Monitors and video devices cabled
one video source (camera or switcher) is fed to the input
for nonterminating (looping) use may be used in the
connector of six separate pieces of video equipment
branch, however the last unit in line must be terminated
(monitors or video cassette recorders). See Figure 2. with 75 ohms.
The V210DA-B may also be used in more complex
systems. Figure 3 illustrates a branching video system,
in which video from a single camera can be viewed at
NOTE: Each output of the V21 ODA-B must be ter-
minuted with 75 ohms, either locally or remotely.
2.3 Connecting the Unit to the System
Figure 2 illustrates a typical system connection for a
simple system; Figure 3 illustrates system connections
for a branching system, Refer to these figures as neces-
sary while performing the following procedures.
2.
3.
1. Connect the input video cable to the connector
marked CAMERA on the rear panel of the
V210DA-B. The V210DA-B can accept video input
from equipment other than cameras.
4,
Connect video cables from connectors 1,2,3,4, 5,
and 6 on the rear panel of the unit to the input
connectors on the associated video equipment.
Terminate unused outputs of the V210DA-B with
75 ohms (Vicon V75T terminators may be used).
Connect the line cord to a power source of the
appropriate voltage.
3. OPERATION
Press the front panel POWER switch to energize the unit.
The power indicator lamp lights when the unit is energized.
X671-697

If an operating failure occurs in the system, inspect all
cables and connections. Check the cameras to ensure that
it is functioning properly. Check each successive connec-
tion for the presence of a good video signal. If necessary,
interchange the V210DA-B output connectors to deter-
mine if the amplifier or the branch wiring is faulty.
This solid-state unit is designed for troublefree operation
in normal room environments. Repairs should only be
attempted by qualified personnel in an adequately
equipped facility.
If local troubleshooting is required, the unit may be
opened using the following procedure.
1. Use a Phillips-head screwdriver to remove the two
top and two side screws.
2. Lift the cover off the chassis.
If it is necessary to change the fuse, be sure to replace it
with one of the same value, l/S A, 3 AG slo blo (120 VAC)
and l/8 A 250 V slo blo (230 VAC).
CAMERA
Figure 2
System Connection Diagram, Simple System
X671-697
5

L
CAMERA
II I
II
I
L
Figure 3
System Connection Diagram, Branching System
6
X671-697

Shipping Instructions
Use the following procedure when returning a
unit to the factory:
2. Attach a sheet of paper to the unit with the fol-
lowing information:
1. Call or write Vicon for a Return Authorization
a.
(R.A.) at one of the locations listed below. Record
the name of the Vicon employee who issued the
Name and address of the company returning
the unit
R.A.
VICON INDUSTRIES INC.
89 Arkay Drive
Hauppauge, New York 11788
5 16-952-CCTV (2288) or toll free l-800-645-9 116
Fax: 5 16-95 1 -CCTV (2288)
b. Name of the Vicon employee who issued the
R.A.
C. R.A. number
d. Brief description of the installation
e. Complete description of the problem and
circumstances under which it occurs
For service or returns from countries in Europe,
contact
VICON INDUSTRIES (U.K.) LTD
Brunel Way
Fareham, PO15 5”
United Kingdom
44/(O) 1489/577775 Fax: 44/(O) 1489/578923
f. Unit’s original date of purchase, if still under
warranty
3. Pack the unit carefully. Use the original shipping
carton or its equivalent for maximum protection.
4. Mark the R.A. number on the outside of the
carton on the shipping label.
Copyright 0 1997 Vicon Industries Inc. All rights reserved. Vicon and its logo are registered trademarks of Vicon Industries Inc.
X671-697
7
