INSTRUCTIONS FOR
INSTALLATION AND OPERATION
MODEL V390APT WEATHERPROOF HEAVY-DUN PAN-AND-TILT DRIVE
1. INTRODUCTION
The information in this instruction manual covers the
installation, operation, and maintenance of the
V39OAPT Pan-and-Tilt Drives. Throughout this man-
ual, the term V39OAPT and V39OAPT-PP refers to both
models unless stated otherwise.
This unit should be installed by a qualified technician
using approved materials and wiring practices in con-
formance with national, state and local electrical codes.
Model V39OAPT Pan-and-Tilt Drive is a weatherproof,
heavy-duty unit capable of operating with loads up to
80 pounds (36 kg). When mounted in an inverted posi-
tion, it will operate with loads up to 75 pounds (34 kg).
The heavy-duty motors are constructed with hardened-
steel gears that never require lubrication. All-weather
protection is provided by “0” rings and gasket seals with
Teflon* wear surfaces. Solenoid operated brakes pro-
vide excellent operating stability with minimum coast.
Counterbalanced tilt arms provide smooth, reliable tilt
operation.
CONTROL
PAN/TILT
CONTROL RELAY BOX
Figure 1
Operating Distances With
and Without Relay Box
PAN/TILT
This 120 VAC unit may be operated directly by a control
or by a combination of a control and a relay box when
greater operating distances are required. Refer to Figure
1 and Table 1 for maximum operating distances. If a
preset position option is required, use Model V129-8PP
Preset Position Control or the VPS324TM or VPS1200
systems.
The V39OAPT is UL listed under Standard 1409.
CAUTION: Mounting the unit outdoors in an
A
inverted position voids the product warranty.
TABLE 1
MAXIMUM OPERATING DISTANCES
Control
Model
V123APT
V113APT
V11306[PT-B
Relay Box
Cable Slze
(AWG)
Annealed
Covver
Maxlmum
Distance
fi ON*
..I
20 630(250)
dl 18 1300(400)
16
2200(670)
14 3400(1000)
22 6000(1600)
V185R
d2*
20 10,000(3000)
18 15,000(4600)
PI
@.L
Vicon part number 8006-8433-02-00
Product specifications subject to change without notice. T”Registered kademark of DuPont DeNemours, EL & Co., Inc.
VICON INDUSTRIES INC. 525 BROAD HOLLOW ROAD, MELVILLE, N.Y. 11747 TEL: [phone] FAX: [phone]
*, ‘1
-$,&+
TOLL FREE: l-800-645-9116 (OUTSIDE OF NEW YORK)

IMPORTANT SAFEGUARDS
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the unit.
1. Read Instructions-All the safety and operating instructions should
be read before the video product is operated.
2. Retain instructions - Ail the safety and operating instructions
should be retained for future reference.
3. Heed Waminp -All warnings on the video product and in the
operating instructtons should be adhered to.
4. Follow Instructions-All operating and use instructions should be
followed.
5. Cleanin
from the C El-
- Step a applies to equipment that can be disconnected
V system without seriously jeopardizin
7
security. Step
b applies to equipment that must operate continuous ysuch as video
smtching equipment at military installations.
a. Disconnect this video product from its power source before
cleaning. Do not use caustic, abrasive, or aerosol cleaners.
Use a damp cloth for cleaning.
b. Use a damp cloth to clean the equipment. Do not allow
moisture or liquids to enter any vents. Do not use caustic,
abrasive, or aerosol cleaners.
6. Attachments- Do not use attachments not recommended by Vicon
as they may cause hazards.
7. Water and Moisture - Do not use this video product in any location
where it may be exposed to water or moisture. This does not apply
to outdoor camera housings, outdoor pan-and-tilt drives, and other
equipment designed for direct exposure to outdoor environments.
B. Accessories -Do not place this video product on any unstable
surface or table. The video product may fall, causing serious injur
to a person and serious damage to the vtdeo product. Use only wtt 4
a mountin
product. x
accessory recommended by Vicon, or sold with the video
ny
Instructions, mounting of the video product should follow Vicon’s and a mounting accessory recommended by Vicon
should be used.
8. Ventilation -Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the video product and
:o protect it from overheating, and these openin must not be blocked
or covered. The openings should never be b ocked by 8”
video roduct on a ru
lacing the
;houlcf *cf never be place !I or other similar surface. This VI
eo product
near or over a radiator or heat register. This
video product should not be placed in a built-in installatton such as
a bookcase or rack unless pro
Instructions have been adhere t;er ventilation is provided or Vicon’s to.
II. Grounding -This a
P
plies to video products equipped with a
s-wire grounding-type p ug, a plug having a third (grounding) pin.
rhis plug only tits into a rounding-ty power outlet. This is a safety
eature. If you are unab e to insert t e plug into the outlet, contact 9 r
your electrician to replace
safety purpose of the groun 2
our obsolete outlet. Do not defeat the
trig-type plug.
12. PowerConl Protection -Power supply cords should be routed
co that they are not likely to be walked on or pinched by items placed
Jpon or against them, payin
convenience receptacles, an CP
particular attention to cords at plugs,
aroduct. the point where they exit from the video
13. Outdoor Cable Grounding -If an outside cable system is con-
lected to the video product, be sure the cable system is grounded so
as to providesome protection against voltage surgesand built-up static
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
L
A
A
char es. Section 810 of the National Electrical Code, ANSI/NFPP
70-I5 04, provides information with respect to proper groundin OI
the lead-in wire to an antenna discharge unit, size of grounB tne
conductors, location of antenna-dischar e unit, connection to
grounding electrodes, and requirements for t % egrounding electrode,
14. Lightnin - For added protection for this video product when it in
not used for ong periods of time, disconnect it from its power source$
and from the cables
due to lightning an J
stem. This prevents damage to the video produd
power-line surges.
15. Power Lines - An outside cable system should not be located in
the vicinity of overhead ower lines or other electric light or ower
circuits, or where it can all into such power lines or circuits. P e, hen
installing an outside cable system, extreme care should be taken to
kee
3
from touching such power lines or circuits as contact with then
mig t be fatal.
16. Overloading - Do not overload wall outlets and extension cords
as this can result in a risk of fire or electric shock.
17. Object and Liquid Entry -Never push objects of any kind into
this video product through openings as they may touch dan erous
voltage oints or short out
shock. R
ever spill liquid o
P
arts that could result in a fire ore ectric 7
any kind on the video product.
18. Servicing - Do not attempt to service this video product yoursell
as opening or removing covers may expose
or other hazards. Refer all servicing to qua tfted service personne . r .
ou to dangerous volta e
P
19.
its
Damage Requiring Service - Disconnect this video product from
ower source and refer servicing to qualified service Personnel
un 8er the following conditions. Note that st
outdoor camera housings, outdoor pan-an IT
c does not apply to
-b/t drives and other
equipment specifically designed for drrect exposure to outdoor envi-
ronments.
a. When the power-supply cord or plug is damaged.
b. If Ii
%
uid has been spilled, or objects have fallen into the video
pro uct.
c. If the video product has been exposed to rain or water.
d. If the video product does not operate normally by following
the operatin
fl
instructions.
covered by t Adjust only those controls that are e operating instructions, as an improper adjust-
ment of other controls may result in damage and will often
re
3
uire extensive work by a qualified technician to restore the
VI eo product to its normal operation.
e. If the video product has been dropped or the cabinet has been
damaged.
f. When the video product exhibits a distinct change in perform-
ance - this indicates a need for service.
20. Replacement Parts - When replacement parts are required, be
sure the service technician has used replacement parts specified by
Vicon or that have the same characteristics as the on inal
Unauthorized substitutions may result in fire, electric shota
part.
hazards.
, or other
21. Safety Check - Upon completion of any service or repairs to this
video product, ask the service technician to perform safety checks to
determine that the video product is in proper operating condition,
2
X433-893

2. INSTALLATION
2.1 Mounting the Unit
The V39OAFT will operate safely with loads up to 80
pounds (36 kg) mounted upright and 75 pounds (34 kg)
when inverted. To perform properly, the unit must be
securely fastened to a suitable surface and the camera
or housing must be properly mounted and balanced on
the unit. Normal mounting position for the unit is with
its axis vertical, either upright or inverted.
CAUTION: Do nat attach these units to drywall
A
su$aces and do not install screws into the end
grain of wood.
The pan-and-tilt has been assembled at the factory for
upright mounting and should be mounted directly to a
surface capable of supporting the combined weight of
the pan-and-tilt and its accessories. The V39OAW
weighs 40 pounds (18 kg).
NOTE: If the unit is to be mounted in the inverted
position, prepare the unit according to the instruc-
tions in section 2.2, Inverted Mounting.
When mounting directly to a horizontal or ceiling sur-
face, use four fasteners. When mounting to wood, use
screws long enough to penetrate at least 2 112 inches (6.4
cm). If mounting to a steel structure, drill four holes
according to the mounting pattern shown in Figure 2.
Screws should be long enough to accommodate lock-
washers and nuts. In concrete, use lead anchors or
expansion bolts with at least 150-pound (69
kg)
pullout strength, installed according to manufacturer’s
instructions,
CAUTION: If installing the unit outdoors, use
A
stainless steel hardware.
2.2 Inverted Mounting
CAUTION: To reduce the risk of fire or electric
A
shock, always mount the pan-and-tilt in the up-
right position where rain or moisture is present.
2.
The pan-and-tilt has been assembled for upright mount-
ing. When it is necessary to mount the unit in the
inverted position, it should be prepared as follows:
3.
1. Ensure that the tilt drive is in the center position so
that the camera mounting plate (Figure 3, Legend 4)
is level.
0.406 in. (1.03 cm)
diameter holes
Use 3/8-in. (10 mm)
hardware
PAN AND TILT MOUNTING BASE
Figure 2
Mounting Hole Dimensions
The front of the drive unit is identified by a decal
(see Figure 3). Facing the front of the unit, remove
the three (3) lo-32 screws (Legend 1) on the right
of the camera mounting plate.
Carefully pull the end support (Legend 2) away
from the main housing, maintaining the opposite tilt
arm in position.
4.6
(11.6
0.75 in.
11.9 cm1
J
L
(5) 0.28 in. (0.07 cm) Dia. Holes
CAMERA AND HOUSING MOUNTING PLATE
X433-893

4. Remove the two (2) counterbalance springs
(Legend 3), noting the position of the springs of the
grooved stop posts (Legend 5) for future reference.
5. Replace the end support (Legend 2), holding the
opposite tilt arm in position.
6. Replace the three (3) 10-32 screws (Legend 1).
When this unit is mounted in the inverted position, the
up-down and left-right directions are reversed for man-
ual operation. This must be corrected when wiring the
cable between the control unit and the pan-and-tilt.
Simply reverse the leads going to pins 2 and 3 and to
pins 5 and 6, respectively, at one end of the cable.
NOTE: For inverted mounting with the VPP-1
Option, reverse the leads going to pins 10 and 12.
(Refer to Figure 6, Wiring Diagram.)
If the unit is returned to upright mounting from an
inverted position, rewire the leads to their original loca-
tions and replace the counterbalance springs (Legend 3)
in the correct positions on the stop posts (Legend 5),
following the procedure outlined in steps l-6.
LEGEND
1. 1 O-32 Screws (3).
2. End Support.
3. Counterbalance Springs (2).
4. Camera Mounting Plate.
5. stop Posts.
Figure 3
Removing Counterbalance Springs
for Inverted Operation
2.3 Mounting the Camera
Before mounting the camera to the pan-and-tilt drive,
note the label FRONT on the top mounting plate. The
camera should be mounted with the lens on this side.
Three center mounting h&s ( Figure 5, Legend 5) are
provided for mounting lighter cameras. To obtain opti-
mum balance, the screw used to mount the camera can
be placed in any one of the three positions on the camera
mounting plate.
When mounting heavier camera/lens loads, best opera-
tion is obtained when the load is evenly balanced. With
the camera and lens resting on a flat surface, place a
pencil under the camera and move the camera until it
balances on the pencil. The position of the pencil under
the camera indicates the point which should be posi-
tioned at the center of the pan-and-tilt mounting plate.
The outboard mounting holes (Legend 6) can be used to
mount heavier cameras or enclosures.
CAUTION: Do not mount an autoiris lens on a
A
autopan unit. Such use will cause excessive wear
on the iris mechanism, as it constantly compen-
sates for di&ferent light levels. For lens control
connection instructions, refer to the manual that
accompanies the lens control unit being used.
4X433-893

TILT COMMON
TILT UP
TILT DOWN
PAN COMMON
-+EJ+-$
AUTOPAN
<
TO PAN AND TILT DRIVE
‘002
3oood
0
‘oooo’q
“lag”
6CONNECTOR ASSEMBLY
7
1701-3001-01
a
NOTES:
1. Connector shown from wiring side.
2. Connector shown has Vicon assembly part number.
3. If pan-and-tilt drive is mounted in the inverted position,
reverse the leads going to pins 2 and 3, and also 5 and
6, at one end of the cable.
4. For inverted mounting with the VPP-1 option, reverse
the leads going to pins 10 and 12.
5. All pins are not used.
Figure 4 Figure 5
Cable Assembly Diagram Limit Stop Adjustment
1. Left pan limit stop
2. Right pan limit stop
3. Up limit stop
4. Down limit stop
5. Center mounting holes
6. Outboard mounting holes
7. Left end plate screws (2)
6. Limit-switch actuator
9. Ground lug mounting holes
2.4 Connector Assembly
Assemble an interconnecting cable according to the fol-
lowing procedures. See Figure 4. The parts for the con-
nector assembly are provided in the accessory kit.
The kit
includes a mating connector, contacts, a keying plug, a
bushing, and a clamp.
NOTE: A silicone rubber sealant, or an equivalent
sealant, must be applied in step 8. This sealant is not
provided in the accessory hit.
1.
2.
3.
4.
Positionthebushingsoitslipsitsinsidethecableclamp.
Pull the interconnecting cable through the bush-
ing/clamp assembly.
Strip back the cable jacket no more than one (1) inch
(2.5 cm) and separate the individual conductors.
Prepare the individual conductors for soldering or
crimping. If crimping, use AMP tool part number
90277-1,90066,90067, or an equivalent tool.
NOTE: The contact cannot be removedfrom a con-
nector after it is inserted unless an AMP extraction
tool, part number 305183 (or an equivalent extrac-
tion tool), is used to remove the contact.
X433-893 5
5.
After soldering or crimping the contacts, push
them into the proper holes in the mating con-
nector until they snap in place.
6. Screw the cable clamp onto the mating connector.
7.
8.
Connect the cable to the unit, and seat the connector by
twisting the locking collar until it snaps into position.
Check the unit for proper operation, after completing
all other connections.
After verification of wiring and unit operation, remove
the cable clamp. Then, use a silicone rubber sealant
inside the cable clamp to seal the area where the cable,
clamp, and bushing meet.
CAUTION:
Af
Most sealants require a curing period
o at least 24 hours before full bonding is at-
9.
10.
tained. Until the sealant isfully bonded, the unit
cannot be considered to have an outdoor rating.
Again,screwthecableclampontothematingconnector.
Connect the cable to the unit and seat the connector
by twisting the locking collar until it snaps in place.

2.5 Grounding Connection
A ground lug and mounting screw are included in the
Legend 9). Connect a No. 18 AWG ground wire to the
accessory kit. Use the mounting hole located above the nearest earth ground.
control cable connector to attach the lug. (Figure 5,
2.6 Adjusting the
After the cable is assembled and the unit connected, plug
the control unit into a 120 VAC source and proceed as
follows:
1. Loosen the two (2) pan limit stops (Figure 5,
Legend 1 and 2).
2. Move the joystick to the RIGHT, rotating the pan
head clockwise until the desired right pan limit is
reached.
3. Locate the right pan limit stop (Legend 2) and move
it until it contacts the limit-switch actuator (Legend
8). Move the stop a slight distance further to the
deflect actuator until a “click” is heard, indicating
deflection of the actuator and opening of the limit
switch. Lock the stop in place.
4. Move the joystick to the LEFT to rotate the pan head
to the desired left limit position. Adjust the left pan
limit stop (Legend 1) in the same manner as the right
pan limit stop.
5. Wth both limit stops in place, pan to both stop
positions and recheck for exact trim of limit stops.
Tighten both stops securely.
6.
7.
8.
9.
Limit Stops
Looking at the front of the unit, remove the two (2)
screws (Legend 7) from the left end plate. Remove
the plate.
Loosen screws (Legend 3 and 4) and move the
joystick UP to rotate the tilt drive to the desired up
limit.
Move the uplimit stop (Legend 3) toward the bot-
tom end of the slot until a “click’ can be heard.
Tighten screw.
Move the joystick DOWN to rotate the tilt drive to
the desired down position,
10. Adjust the down-limit stop (Legend 4) in the same
manner as the up-limit stop.
11. Lock the limit stops securely in place and check for
exact trim of limit stops.
12. Replace the left end plate and screws.
2.7 Preset Adjustments
CAUTION: Vicon does not recommend use of the
Apreset position option in units intended for
autopan use. Such use will cause excesive wear
to internal preset components and voids product
warranty.
If a unit equipped with a preset position option is
disassembled, contact Vicon for reassembly and align-
ment instructions. Also see Figure 6 for preset wiring.
1IK
1 PBN
URN
SUPPLY IO{
IWHT/VIO
DOWN TILT
IIK IK I
I /8W 1/8W
1
6
Figure 6
Preset Wiring Diagram
X433-893

3. OPERATION
When the unit is wired to an appropriate control unit,
movements along two axes are possible. “Pan” is a
horizontal change in camera direction, moving the field
of view to the left or right. “Tilt” is a vertical change in
camera direction, raising or lowering the field of view.
2. To pan or tilt camera, move the joystick up, down,
left or right. The joystick control, when deflected
diagonally, will also drive the pan-and-tilt functions
simultaneously.
1. Apply power to the control unit. The red pilot light
3. To set the V39OAPT unit for automatic pan opera-
should illuminate. tion, press the AUTGPAN switch. The unit will
now pan continuously between the selected limits.
Ifmanual operation is desired, press the AUTGPAN
switch again.
4. MAINTENANCE
The pan-and-tilt drive is factory lubricated for the life
of the unit and no maintenance is required under normal
operating conditions. The V39OAPT pan motor is im-
pedance protected. The tilt drive motor is protected by
a thermal overload switch. If the tilt drive fails to
function after operating for an extended period, check
that the pilot light on the control unit is on.
If the pilot
light is on, the thermal overload switch may have
opened after continuous operation. In this case, the tilt
drive will resume operation after cooling down. A fuse
is also provided in the control unit to protect against a
short circuit. If the pilot light in the control unit fails to
illuminate, check the fuse. Replace with a Type 3AG
fuse of the appropriate rating.
For further information, see the Schematic, Parts Loca-
tion Diagram, and Exploded View Diagram in Figures
7,8 and 9 and refer to the Replacement Parts Lists. The
schematic is provided only for the use of a qualified
technician working in an adequately equipped facility.
7
8
9
10
Figure 7
Parts Location Diagram V390APT
X433-893 7

Shipping Instructions
Use the following procedure when returning a unit to
the factory:
1. Call or write Vicon for a Return Authorization
@A.) at one of the locations listed below. Re-
cord the name of the Vicon employee who issued
the R.A.
VICON INDUSTRIES INC.
5’25 Broad Hollow Rd
Melville, NY 11747
516-293-2200 l-800-645-9116
VICON INDUSTRIES INC.
Western Regional Office
3259 Walnut Ave.
Long Beach, CA 90807
310-595-4280 l-800-648-1832
VICON INDUSTRIES INC.
Southeastern Regional Office
3010 Business Park Dr., Suite B
Norcross, GA 30071
4044494499 l-800-824-8479
2. Attach a sheet of paper to the unit with the
following information:
a.
Name and address of the company returning
the unit
b.
Name of the Vicon employee who issued the
R.A
c. R.A. number
d. Brief description of the installation
e.
Complete description of the problem and
circumstances uncler which it occurs
f. Unit’s original date of purchase, if still under
WZUElIlty
3. Pack the unit carefully. Use the original shipping
carton or its equivalent for maximum protection.
4. Mark the R.A. number on the. outside of the
carton on the shipping label.
r
Cl
4 MCd
Z5OV
8
Figure 8
Schematic Diagram, V390APT
X433-893

74 USE A5 REQUIRED-l0
75 ’ FREVENT BINDING OF flEM 78
Figure 9
Exploded View
X433-893

PAKTOF I-EM I6
Figure 9
Exploded View (continued)
10
X433-893

93 i
94
A
Figure 9
Exploded View (continued)
X433-893
11

REPLACEMENT PARTS LIST
V390APT PAN-AND-TILT WITH AUTOPAN
Reference Designation Part Number Description
_-
1117-3314-02
PAN MOTOR AND CABLE ASSEMBLY.
__
II 17-3354-02
TILT MOTOR AND GEAR ASSEMBLY, size 8.
I -- l
1117-3238-05 1HOUSING ASSEMBLY. ~~ -7
--
--
_-
1117-3570-01 SUPPORT ASSEMBLY, drive end.
1117-3235-01
SUPPORT ASSEMBLY, spring end.
1117-3243-03
PEDESTAL ASSEMBLY, with reverse switch.
1117-3300-02 PEDESTAL PLATE ASSEMBLY.
--
--
--
-_
--
--
_-
--
1117-3255-02 MOTOR AND BRAKE ASSEMBLY, size 8.
1117-3147-00 PCB ASSEMBLY.
1117-3316-02 CABLE ASSEMBLY, pan.
1117-3267-02 GEARHEAD ASSEMBLY, 225:1, pan.
1117-3352-02
END-CAP ASSEMBLY, drive side.
II 17-3320-02 TILT MOTOR AND PLATE ASSEMBLY.
1117-3273-01
HOUSING AND BEARING ASSEMBLY.
1802-0053-01 CAPACITOR, included with motor
1117-3312-01 CONNECTOR AND COIL CORD ASSEMBLY.
1117-3275-01
SWITCH AND CABLE ASSEMBLY, 24 V with autopan.
1117-3286-01 CABLE ASSEMBLY, pedestal.
1802-0052-01 CAPACITOR, included with motor, 4 uf.
I -
I
1117-3251-02
MOTOR AND CLUTCH ASSEMBLY, pan.
~~ --1
I - I
1117-3250-02
BRAKE ASSEMBLY, size 8.
~~ 1
__
-_
--
_-
__
--
1117-3251-04 MOTOR AND CLUTCH ASSEMBLY, tilt.
800&9842-00 CONNECTOR PCB, female,
15-pin, mounting ears.
8000-9846-00 CONNECTOR, cable, male, Q-pin, AMP i-350235-9 (when exhausted i-64051 1).
1117-3315-02
TILT MOTOR AND CABLE ASSEMBLY.
1117-3353-02 GEARHEAD ASSEMBLY.
1117-3307-01 COIL CORD AND LUGS ASSEMBLY.
80069800-00 CONNECTOR CABLE, male.
6-oin. AMP l-640510-0.
--
8000-9644-00 CONNECTOR PCB, female, ti-pin, AMP 840136-5.
_-
_-
-_
_-
--
1136-2042-00
LIMIT SWITCH ASSEMBLY, with reversing switch.
1117-3274-01 CABLE REVERSE SWITCH ASSEMBLY, 24 V.
1806-5022-02
CONNECTOR PANEL, male, 16-pin, AMP 2060361.
8000-9644-00 CONNECTOR PCB, female, B-pin, AMP 640136-5.
8000-9736-00 CONNECTOR CABLE, female, B-pin, AMP I-350241-9 or 640520-o.
1806-5024-02 CONNECTOR CABLE, female, %-pin, AMP 20637-I.
1117-3318-02 MOTOR AND BASE ASSEMBLY.
12
X433-893

Reference De&nation
__
Pert Number
1117-3319-02
1117-3306-02
1117-3259-01
De&p tion
MOTOR AND BASE ASSEMBLY, tilt.
LEVER AND PLUNGER ASSEMBLY.
BRACKET ASSEMBLY, brake mount, size 8 motor.
I -- I
1117-3255-04 1MOTOR AND BRAKE ASSEMBLY, size 8, tilt.
I
--
__
__
1117-3147-00 PCB ASSEMBLY.
1117-3317-02 CABLE ASSEMBLY, tilt.
8000-9645-00 CONNECTOR CABLE, female, g-pin, AMP l-640521-0.
--
I
1117-3305-02 MOTOR PREP ASSEMBLY, pan.
~~-1
I -- l
1117-3257-01 BRAKE LEVER ASSEMBLY, size 8, motor.
~~~~~ 1
--
I
1117-3308-02 MOTOR PREP ASSEMBLY, tilt.
I
--
I
1117-3115-00 1PAN POTENTIOMETER ASSEMBLY. I
I - I
1117-3115-01 I TILT POTENTIOMETER ASSEMBLY.
I
I - I
1117-51 go-00 IPLATE POTENTIOMETER.
I
I - I
1117-5353-00 SHAFT POTENTIOMETER, gear.
1
--
I
8002-7571-00 POTENTIOMETER, 5 kohm, 5 turn, servo mount,
Spsctrol model 535.
I
I
8002-8785-00 RESISTOR, 1 kohm, 1/8 W, I%, RN55D.
-1
--
I
8002-7572-00
1.
POTENTIOMETER, 5 kohm, 3 turn, servo mount, Spectral model 533.
I
REPLACEMENT PARTS LIST
PCB ASSEMBLY
Reference Designation Psrt Number Description
I - I
1117-5619-01 PCB, pan-and-tilt control.
I
1 R5, R6 or R7, R8 I 8002-8785-00 IRESISTOR, 1 kohm, l/8 W, I%, RN55D. I
[ RI or R3
I
8002-8695-00
I RESISTOR, IO ohm, 3 w, 5%.
I
I ~2or R4 I
8002-8761-01
IRESISTOR, 1 kohm, 5 W. I
RVI, RV2 or RV3, RV4 8004-9326-00 VARISTOR
CR3, CR1 &CR2 or
CR5&CR6
c3, c4
1804-0001-02 DIODE, Hepro 170-RT.
1802-0033-01
CAPACITOR, 0.047 uf
1c5 I
8000-8739-00 1CAPACITOR, 3.3 uf I
1WI I
8001-8161-00 IJUMPER LEAD, 0.250 diameter, Gettigx L-2007-1 or Vestal V40-22.
I
8004-7693-00 TAPE, polyester
X433-893
13

REPLACEMENT PARTS LIST
Refer to Exploded View
Reference Designation Part Number
I
Description
I
I ’ I
8003-7281-00-00 SCR 1 O-32 x
i/2 SOC HD CAP SS
I
I 2 I
8005-8230-00-00 WASHER LOCK IO SS SPL
I
I 3’ I
1117-5011-01-00 TOP PLATE (1905-5001-00)
I
I 4 I 8003-8060-00-00
1 SCR 6-32 x 5/8 PAN HD PR SS
I
5 8004-7472-00-00 SWITCH 67042-508 4POS LT MOM S
6 2001-3045-01-00 ASSY SCREEN DISC END SUPPORT
7 8002-6248-02-00 O-RING 3.975 ID x.210 PARKER 2-345C147-70 OR 2-345C873-70 NEOPRENE
C366-55
8 1117-3235-01-l 1SUPPORT ASSY SPRING END
9 8002-6248-01-00 O-RING 5-l/8 ID x .210 2354 PARKER
10 1117-5061-00-00 WASHER THRUST
11
1117-5016-00-06 SPRING COUNTER BALANCE V300 SERIES SAND/DIE
12 8003-8080-00-00 SCR 6-32 x 5/8 PAN HD PR SS
13 8004-7472-00-00 SWITCH 67042-508 4POS LT MOM S
14
I
2001-304501-00 ASSY SCREEN DISC END SUPPORT
I
15 8002-624802-00 O-RING 3.975 ID x .210 PARKER 2-345C147-70 OR 2-345C673-70
16 1117-3234-01-15 SUPPORT ASSY DRIVE END
18 1117-5061-00-00 WASHER THRUST
19 8003-811 O-00-00 SCR
20 8005-6140-00-00, WASHER FLAT 8 318 x 042 CAD
21
I
1117-5536-01-00 STOP TILT
I
22
I
8003-7270-00-00 SCR 1 O-32 x
314 SOC HD CAP SS
I
23
I
8005-623(FOO-00 WASHER LOCK IO SS SPL
I
24
I
1117-3253-01-02 END CAP SUB ASSY
- SPRING SIDE
I
25
I
8003-727%00-00 SCR 1 O-32 x 3/4 SOC HD CAP SS
I
26
8005-823~00-00
27 1117-3354-02-06
31 8003-7240-00-00
WASHER LOCK IO SS SPL
TILTMOTOR & GEAR ASSY SIZE 8 115V
SCR 8-32 x 5/8 SOC HD CAP SS
32
I
8004-9950-00-00 WASHER LOCK 8 CAD SPL
7
33
I
8004-9850-00-00 WASHER FLAT 190 x 438 x 046 SS PHOENIX SS-II 79
I
134
I 8003-7828-00-00
1 SCR 1 O-32 x 2 PAN HD PR CAD
I
(35
I
1117-5430-00-00 1 PLATE LONG MOTOR V380PT
I
36 1117-3353-02-06 GEARHEAD ASSY
37
1117-3255-04-04 MOTOR & BRAKE ASSY SIZE 8 115V TILT
38 8002-9932-00-00 SCR SET SIC 8-32 x l/4 CONE CAD
39 1117-5428-00-01 SPUR GEAR
40 1117-557403-00 SHIM (.OlO)
41 8001-8322-00-00 KEY 1/8x 3/8 HARDENED RC40-50 213 WOODRUFF
14
X433-893

Reference De&nation Part Number
42
1117-557301-05
43 1117-557403-00
PINION TILT
SHIM (.Oi 0)
Description
I 44 I 5413-1281-94-00
1WIRE 13 CONTACT F LUG F 22GA VW1 YEL
~ ---I
45 5413-558-I -94-00 WIRE 13 FASTON F FASTON F 22GA VW1 WHT/YEL
46 5409-1281-55-00
WIRE 9FASTON F CONTACT F22GA VW1 GRN
47 5410-5581-95-00
48 8004-632400-00
49 8002-9310-00-00
50 1117-5028-00-04
51
8001-798&00-00
52 8001-7980-00-00
53 8003-8625-00-00
54 8005-6144-00-00
55 1117-330@02-04
WIRE 10 FASTON F FASTON F 22GA VW1 WHT/GRN
SWITCH 111 SM601 -H4 SUBMIN MICRO
RING RET 5133-l 8H WALDES
ROD SWITCH
GROMMET 3/16D x 1/2D GRV 1/16x 3/8D MILLER 217
GROMMET 3/16D x 1/2D GRV 1116 x 3/8D MILLER 217
SCR 4-40 x 5/16 PAN HD PR SS
WASHER FLAT .I43 x .044. SS PHX
PEDESTAL PLATE ASSY
156
I 1117-3286-01-05 1CABLE ASSY PEDESTAL
--~-l
j57
I 1117-3312-01-02
1CONNECTOR & COIL ASSY V390 I
158
I 1117-3316-02-01
1CABLE ASSY PAN 115V
I
59
I
1117-3147-00-14 ASSY PCB
I
160
I
8003-7836-00-00 ISCR1032x21/4SOCHDCAP I
61
I8005-623~00-00 WASHER LOCK 10 SS SPL
I
162
I 8005-6144-00-00
1WASHER FLAT .143 x .044. SS PHX 7
/ 63 I1117-325~02-07 1MOTOR & BRAKE ASSY SIZE 8 115V PAN
I
64 1117-3267-02-06
65 8003-727CbOO-00
66 8005-6230-00-00
67 8002-6248-01-00
68 1117-581 O-01 -00
69 1117-3275-01-00
71 8003-7240-00-00
GEARHEAD ASSY 225:i PAN
SCR 1 O-32 x 314 SOC HD CAP SS
WASHER LOCK 10 SS SPL
O-RING 5-1/8lDx .210 2-354 PARKER
PEDESTAL (1117-5480-01)
ASSY SWITCH & CABLE 24V WIAP
SCR 8-32 x 5f8 SOC HD CAP SS
( 72 I8004-995~00-00 1WASHER LOCK 8 CAD SPL
~ ---I
73 1117-550%01-03
74 1117-5037-02-01
75 1117-5037-03-01
76 1117-5094-00-03
77
8000-729~00-00
78 1117-3554-01-00
79 I 117-3522-01-02
80 8003-8110-00-00
81 8002-9871-00-00
GEAR INTERNAL 24P 9OT
SHIM (.005)
SHIM (.OlO)
BEARING RACE
BEARING THRUST NTA-6074 TORR
ASSY BEARING PLATE & IDLER GEAR V390 & V330 DIECAST SERVICE
SUB ASSY HOUSING
SCR 6-32 x 7/16 PAN HD PR SS
SCR SET SOC 6-32x3/8 CONE SS
X433-893

Reference Designation
82
Part Number
1117-5519-01-01
Description
STOP PAN (1221-5154-01-00)
88 8003-7162-00-00
SCR 6-32 x 7116 SOC HD CAP CAD
86 1117-551401-01 STOP PAN (12221-5154-01-00)
87 8002-9871-00-00
SCR SET SO 6-32 x 3/8 CONE SS
88 1117~501c-01-00 PEDESTAL (1117-5488-01)
89 8005-6110-00-00
WASHER LOCK 6 CAD SPL
90 1117-3351-01-04 ASSY SUB END CAP (DRIVE SIDE) V353 V355
90 1117-3281-01-01 MOTOR PLATE
I 91 I
1117-3317-02-01
1CABLE ASSY TILT 115V -7
92
I
8004-9870-00-00
WASHER FLAT 10 l/2 x 048 CAD 1
I93 I 8004-9860-00-00 1WASHER LOCK 10 CAD SPL
----1
94
I
8002-622@00-00 NUT 1 O-32 HEX ST CAD
1
95
I
1802-0053-01-00 CAPAC INCL W/MOTOR 6MF)
~~~~ ~~~~~ I
Copyright Q 1993 Vicon Industries Inc. All rights reserved. Vicon and its logo are registered trademarks of Vii011 Industries Inc.
16
X433-893
