MODEL VPSI 344TM DIGITAL CONTROL AND HIGH-DENSITY
MATRIX SWITCHING SYSTEM
1. INTRODUCTION
This manual provides information on the installation of This system should only be installed by a qualified
the VPS 1344 Digital Control and High-Density Matrix technician using approved materials and wiring prac-
Switching System, including how to install the card tices in accordance with the national, state, and local
cage and connect it to the rest of the system. electrical codes.
1 .I Purpose, Functions, and Capabilities
Vicon’s VPS1344 control and switching system
simplifies the design and installation of complex
security installations. The system consists of the
V1344SCPU-HD, which contains system software to
control switching, pan, tilt, zoom lens, auxiliary func-
tions, and alarm functions; V1344TDT-HD
time/date/titler modules; and the V4480SCC-HD
Matrix 44TM high-density card cage. The VPS1344
system will also include varying numbers of V441OS-
HD video switcher cards and, possibly, circuit cards
providing other functions. Refer to Table l-l, System
Components and Accessories and Figure l-l, Card
Cage Front and Rear Panels.
The V4480SCC-HD high-density card cage can
accommodate up to 16 video switcher cards. Each
switcher card can accept up to eight video inputs, for a
maximum card cage capacity of 128 camera inputs and
eight monitor outputs. This greatly reduces the amount
of space required for equipment installation.
The V4480SCC-HD card cage is supplied with a mother
board, a video amplifier board, and a power supply. It
also contains slots for the following boards: system
CPU, time/date/title cards, address decoder card, and up
to 16 video switcher cards. The specific combination
of these cards in a given card cage is determined by the
size and configuration of the video system it is support-
ing. In its maximum configuration, the system can
support up to 128 remote camera/lens receivers, 24
monitors, 128 inputs from alarm interface units, 128
receiver alarms, and 32 remote control panels.
1.1.1 COMPATIBILITY WITH MATRIX 44
SYSTEM
The V1344SCPU-HD and V1344TDT-HD printed
circuit boards plug directly into the Matrix 44 high-den-
sity card cage, permitting on-site serviceability and
minimizing down-time of the entire system. This
compatibility also reduces the amount of space required
for equipment installation.
1.1.2 COMPATIBILITY WITH VPS1200 AND
VPS1300 SYSTEMS
The VPS1344 maintains software compatibility with
Vicon’ s VPS1200 and VPS 1300 components. This
provides cost-effective expansion of existing VPSl200
and VPS1300 security systems. It also permits use of
VPS1200 and VPS1300 remote panels, keypads, alarm
controls, and receivers in the VPS 1344 system.
