VicSpacer
Assembling Manual

EN
2

L_VicFix MiniK_Silicone Drop
EN
3
Not Included
Included
MATERIAL NEEDED
F_Gauge
Wall Plugs and Screws
A B
DrillLevel
Measuring Tape
Hex key
Screwdriver
Rubber Hammer
C D
X_XXL GaugeFlexi Glue Ultra
Caulking Gun
F H J
E
K L MI

EN
4
Steps Material
2x A
2x B
1Attach the side metal plates to the plywood strips as shown in the diagrams. Position
the plywood strips on a at surface, so that when you lean the metal plates, they stay as
aligned as possible with each other.
1A
1B
2x
1C
Steps Material
5x J
Steps Material
5x L

EN
5
2
2A 2B
2C
2D
Steps Material
2x F
Steps Material
5x K
Steps Material
3x L
Repeat the previous step.

EN
6
3
Tighten the xing screws in the indicated places.
4
Fit the pieces together and press them to form a frame.
Steps Material
6x L

EN
7
5You can ne tune the adjustment of the metal side plates by loosening the
tightening screws. When the plates have been aligned, tighten the screws
permanently.

EN
8
6Turn the VicSpacer on its back and apply the silicone drops as indicated in the
diagram.
Steps Material
K

EN
9
i) Wall Installation
Installation Options
This product can be installed on:
i) the wall using VicFix Mini (included) or xing screws (not supplied);
ii) the ceiling using VicFix J Prole 2m (sold separately) or xing screws (not supplied)
iii) vertical corners using VicFix Corner using VicFix Corner and VicFix J Prole 80mm (sold separately)
ii) Ceiling Installation
iii) Corner Installation
For information about the various
possibilities of installing the product,
please consult the manual available on our
website: www.vicoustic.com
