Victor ML102 User manual

Item number 193102
August 2021
Victor Products Ltd
Unit 3A, Tyne Dock East Side
Port of Tyne,
South Shields,
Tyne and Wear
NE33 5SQ
United Kingdom
Tel : [phone]
Fax : [phone]
2813
0518
Making Hazardous
Environments Work
TYPE ML102 LED FACE LIGHT
EXPLOSION PROOF LUMINIARE WITH FLAMEPROOF PROTECTION (TYPE d)
Certification number SIRA 09 ATEX 1328 I M2 Ex db I Mb IP65
Certification number IECEx SIR 09.0134 Ex db I Mb IP65
Certification number CSAE 21UKEX1316 I M2 Ex db I Mb IP65
The certificate carries the group and category marking: - I M2
Where: I signifies suitability for use in mining and M2 signifies suitability for use in mines
where it must be de-energised in the presence of an explosive atmosphere.
IMPORTANT
1. Read this leaflet carefully before commencing to install the luminaire and retain it for future reference.
2. Check the rating label to ensure that the luminaire is suitable for the supply provided.
3. The operating temperature range is –15°C to + 45°C.
4. The luminaire MUST be earthed.
5. Under NO circumstances should a luminaire be opened, even when isolated, when an explosive gas
or dust environment is present.
6. If using non-threaded glands, the 2 off screws per gland must be M6 socket head cap screws, steel or
stainless steel, grade 8.8min to ISO 898-1, and must have a thread engagement between 6mm and
10mm into the gland fixing holes.
7. DO NOT LOOK DIRECTLY INTO LUMINAIRE.

2
INSTALLATION
a) Mounting
The luminaire has mounting brackets as shown on the diagram above. The luminaire must be securely
fastened in place. It can be mounted in any attitude. If magnets are to be used for mounting, they can be
supplied by Victor Products Limited.
b) Cable entries
Up to two cable entry holes for the accommodation of a suitable certified flameproof cable entry
device/blanking plug ( with or without the interposition of a suitable flameproof adaptor ). The flameproof
cable entry device/blanking plug/adaptor must be certified Group I under an EC-type certificate to
directive 2014/34/EU, or Group I certified under the IECEx scheme, or Group I UKEX certified as
appropriate to the installation. The cable entry devices and cabling methods used in service must be
suitable for their intended duty and the special types of cable used in mining.
Access to the terminal block is made by removing all eight socket head cap screws on the front of the
unit. The hinged lampglass assembly can then be opened. The terminal block is suitable for 6mm2 cable.
All terminal screws, used and unused should be fully tightened down.

3
FITTING OR REPLACING LED STRIPS OR DAMAGED LAMPLGLASS ASSEMBLIES
1. Remove all eight socket head cap screws from the front of the unit. The hinged lampglass assembly
can then be opened.
2. The LED strips and/or driver assembly can be removed by disconnecting the cables from terminal
block and from the push on terminals on the driver assembly. Remove the retaining screws.
3. Replace the LED strips and/or driver assembly. Fasten in place with the retaining screws and
washers. Connect the cables to the terminal block ensuring all terminal screws are fully tightened
down. Connect the cables from the LED strips to the push on terminals on the driver assembly
ensuring correct polarity.
4. If the lampglass assembly is to be replaced, remove the hinge screws. Replacement is the reversal of
this procedure.
5. Ensure O ring is fitted in place and apply a thin coating of a non-setting grease ( silicone ) to the FLP
surfaces before closing the lampglass assembly.
6. Re-fit all eight socket head cap screws and washers. Fully tighten down all screws.
MAINTENANCE AND INSPECTION.
Frequency of inspection must be determined by the installer, but should be frequent enough to ensure that the
luminaires continue to work in their designed manner. The more onerous the working conditions, the more
frequent the inspection. The interval should never exceed two years.
The following list indicates some of the points that should be given particular attention. Suitable repairs should
be carried out if required:-
a) Clean all flameproof paths using a non-metallic or suitable non-corrosive cleaner and examine the
flameproof paths for signs of damage. Replace damaged parts.
b) Dirty lampglass should be cleaned.
c) Replace cracked or damaged lampglass assemblies.
d) Replace any missing fasteners with items of the correct type and quality.
e) Fit new gaskets, lock-washers, etc as appropriate.
f) Grease all flamepaths and screw threads with a non-setting grease (e.g. silicone )
g) Ensure that blind tapped holes are clear of dirt, etc that could prevent correct closure of joints.
h) Do not over-tighten fasteners on re-assembly.
i) Ensure all mountings are secure and not corroded.
j) Check cable glands for tightness and check the luminaire is efficiently earthed.
k) Check resined joints for deterioration. If damaged then the assembly must be replaced in its entirety.
Resined components cannot be repaired except by the manufacturer.
l) Any mechanically damaged parts must be replaced.
m) A list of spares can be obtained from the manufacturer.
GENERAL
All components that are replaced should be in accordance with the manufacturer’s specification. Failure to use
approved parts invalidates the certification and approval of the luminaire and may make it dangerous.

4
NO modifications should be made to the luminaire without the knowledge and approval of the manufacturer.
HEALTH AND SAFETY AT WORK etc. ACT 1974
In the United Kingdom all equipment must be installed, operated and disposed of (as required) within the legislative
requirements of the Health and Safety at Work etc. Act 1974. Leaflet No. HSS L1 refers to the Company’s
obligation and is available on request.
It is the responsibility of the user to select, install, operate and maintain the equipment in accordance with the
relevant legislation and appropriate code of practice.
EU Only
WEE Producers Identification No. WEE/EA 0073UQ
Prices and design are subject to alteration without notice. All products are sold subject to our conditions of sale,
copies of which are available on request.
We reserve the right to change characteristics of our products. All data is for guidance only

5
BLANK

6
BLANK

7
TYPE ML102 LED FACE LIGHT
Certification number CSAE 21UKEX1316
Victor Products Ltd
Hereby declare our sole responsibility that the product which is the subject of this declaration is in
conformity with the following standards or normative documents.
Number and date of standard
UK Legislation
BS EN IEC 60079-0:2018
BS EN 60079-1:2014
Equipment and Protective Systems Intended
for use in Potentially Explosive Atmospheres
Regulations 2016
EN 50082 (1992)
EN 55015 (1993)
EN 60555-2 (1987)
2016 No 1091: Electromagnetic Compatability
UK Approval Body:
CSA Group Testing UK Ltd
Deeside CH5 3US
Notified Body No. 0518
H. Davis
Engineering & Quality Manager
August 2021
SERIAL NUMBER
UK Declaration of Conformity
Victor Products Ltd
Unit 3A, Tyne Dock East Side
Port of Tyne,
South Shields,
Tyne and Wear
NE33 5SQ
United Kingdom

8
Declaration of Conformity
Dèclaration De Conformitè
Konformitätserklärung
Victor Products Ltd
Unit 3A, Tyne Dock East Side
Port of Tyne,
South Shields,
Tyne and Wear
NE33 5SQ
United Kingdom
TYPE ML102 LED FACE LIGHT
Certification number SIRA 09 ATEX 1328
IECEx SIR 09.0134
Victor Products Ltd
Hereby declare our sole responsibility that the product which is the subject of this
declaration is in conformity with the following standards or normative documents.
Erklären in alleiniger Verantwortung, daβdas Product auf das sich diese Erklärung bezieht, mit
der/den folgenden Norm(en) oder normativen Dokumenten Ubereinstimmt.
Déclarons de notre seule responsabilité, que le produit auquel cette déclaration se rapporte, est
conforme aux norme(s) ou aux documents normatifs suivants.
Number and date of standard
Nr. Sowie Ausgabedatum der Norm
No. Ainsi que date d’emission des normes.
Directive description
Bestimmungen der Richtlinie
Prescription de la directive
BS EN IEC 60079-0:2018
BS EN 60079-1:2014
Equipment and protective systems intended for use in
potentially explosive atmospheres.
This Attestation is valid for directive 2014/34/EU.
Geräte und Schutzsysteme zur bestimmungsgemäßen
Verwendung in explosionsgefährdeten Bereichen.
Diese Bescheinigung gilt für die Richtlinie 2014/34 /EU.
Appareils et systèmes de protection destinés a êtré utilisés
en atmosphères explosibles.
Cette Attestation est valable pour la directive 2014/34 /UE.
EN 50082 (1992)
EN 55015 (1993)
EN 60555-2 (1987)
2014/30/EU: Electromagnetic Compatability
2014/30/EU: Elektromagnetische Verträglichkeit
2014/30/EU: Compatabilité électromagnétique
Notified Body:
CSA Group Netherlands B.V.
Notified Body No. 2813
H. Davis
Engineering & Quality Manager
August 2021
SERIAL NUMBER
