Victory LSR23HC User manual

INSTALLATION AND OPERATING INSTRUCTIONS
for all Hydrocarbon
LSR Refrigerator Models
3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105
Phone: [phone] | Fax: [phone] | Web:victoryrefrigeration.com
809-200A Rev. 06/07/23 SEE BACK COVER FOR
WARRANTY REGISTRATION

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory2
WELCOME
Contents
Safety ...............................................................................................3
Important Information .................................................................5
Product Information .....................................................................6
Clearance and Placement ............................................................7
Unpacking and Set Up ..................................................................8
Shelf Installation............................................................................9
Electrical........................................................................................10
Using The Unit - Danfoss Controller.........................................11
Sequence of Operations Refrigerator............................12
Using The Unit - Eliwell Controller .......................................... 16
Sequence of Operations Refrigerator............................ 17
Cleaning and Maintenance ...................................................... 20
Condenser Cleaning..................................................................... 21
Methods For Cleaning Stainless Steel................................... 22
Help................................................................................................ 23
For The Service Tech - R290 ................................................... 24
For The Service Tech - Wiring Diagrams............................... 25
Units with Electronic Locks ......................................................27
Limited Warranty ....................................................................... 28
Limited Warranty (continued)................................................. 29
Important Information
• PLEASE READ THESE INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR USING, IF RECOMMENDED
PROCEDURES ARE NOT FOLLOWED, WARRANTY
CLAIMS MAY BE DENIED.
• Your warranty registration information is located with
this manual. Please complete the card and submit
it to Victory within TEN days of installation. Failure
to properly register equipment may limit or void the
warranty.
• Victory reserves the right to change specications
and product design without notice. Such revisions
do not entitle the buyer to corresponding changes,
improvements, additions, or replacements for
previously purchased equipment.
Congratulations on your purchase of Victory food service
equipment. Every employee welcomes you to the family
of satised Victory customers.
From the earliest stages of production design, to focused
steps in fabrication and assembly, rigid standards of
quality are maintained by our sta of skilled employees.
Victory strives to supply superior products through strict
quality control guidelines exceeding industry standards,
this means that each unit, given the proper maintenance
will provide years of trouble free experience to its owner.
Additionally, Victory food service equipment has one
of the best warranties in the food service industry, and
backed by a professional sta of service technicians
across the country.
We thank you for your choice and condence in Victory
Equipment.
For part inquiries or orders please call our Technical
Service Department at [phone]. 8:00 AM to 5:00
PM EST.

User Manual for LSR Refrigerators Victory
Rev. 06/23 Victory 3
SAFETY
This appliance has been designed with your safety in mind. It has many features to keep you from being harmed. However,
safe operation and maintenance are your responsibilities. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Use: When using this unit, please:
• Move it carefully. If on casters be sure the casters
do NOT run over the power cord.
• Lock the casters when in use.
• Seek help. This machine is heavy! Be sure to move
with enough help to avoid tipping or dropping the
cabinet.
• Prevent children from playing in or on the cabinet.
Persons unable to use this product must be
prevented access.
• Follow all instructions. There are many safety
labels and directions on the unit. Heed them.
• Watch your ngers. There may be pinch points near
the door hinges.
Maintenance
Do NOT:
• Clean a frozen evaporator with a sharp object
• Clean a dirty condenser with a sharp object.
• Store gasoline, kerosene or any other ammable
material near the cabinet.
Do ALWAYS
• Use a Victory recommended technician certied to
repair R290 equipment.
• Use ONLY Victory factory service parts. Use of non
OEM parts can be dangerous because of the design
changes needed to safely use R290.
Observe the Caution and Warning notices. They are indicators of
important safety information. Keep this manual for future reference.
Important Information to Add
Record the model number, serial number and the date of installation here for future reference. The model and serial
numbers are on the unit's serial number dataplate, which is located on the left inside wall.
Model Number
Serial Number
Date of Installation
Purchased From
CAUTION
WARNING
CAUTION
CAUTION

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory4
CAUTION: If it is necessary to move the Refrigerator after removal from the skid,
remove all doors and carefully push the unit at a point of no more than 36” from the
bottom to avoid damage.
CAUTION
SAFETY
Push ONLY below the 36 inch / .91 meter height
Height
will vary
by model
Do NOT push in this area.

User Manual for LSR Refrigerators Victory
Rev. 06/23 Victory 5
IMPORTANT INFORMATION
This unit is intended to be used in a commercial application. That includes bars and restaurants.
If installed in a residence some commercial service companies may not be able to service it on site.
The manufacturer has designed and produced this machine with the nest in materials. The manufacturer assumes no
liability for units that have been altered in any way. Alterations or part substitutions will void the warranty.
Limitations
The machine is designed for use indoors in a controlled
environment. It must be kept dry, not overheated or
subjected to excessive cold. May only be connected to
a dedicated electrical circuit. Extension cords are not
permitted.
Minimum Maximum
Voltage 103.5 126.5
Room Air Temp 60º F 100º F
Air Flow, All Models regardless of section, door count or door material.
Agency Approvals
These marks appear on the dataplate or serial tag, located
in the inside of the left wall. The dataplate also contains
the model and serial numbers as well as electrical
requirements.
WARM AIR OUT
ROOM AIR INROOM AIR IN

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory6
Model Cabinet Dimensions
w x d x h (Inches) Door Count
Full
Load
Amps
Power
Cord
Plug
(NEMA)
Refrigerant Type /
Charge (g) / Charge (oz.)
LSR23HC 27 1/4 x 34 1/16 x 83 15/16 1 Full Glass
5-15P
R-290 / 90 / 3.04
LSR27HC 30 x 34 1/16 x 83 15/16 1 Full Glass
LSR49HC 51 15/16 x 34 1/16 x 83 15/16 2 Full Glass 3.9 R-290 / 110 / 3.72
LSR72HC 75 1/16 x 34 1/16 x 83 15/16 3 Full Glass R-290 / 100 /3.38
UNITS WITH ELECTRONIC SMART LOCKS
LSR23HC-IQ 28 3/8x 34 1/16 x 83 15/16 1 Full Glass
5-15P R-290 / 90 / 3.04
LSR27HC-IQ 31 1/8 x 34 1/16 x 83 15/16 1 Full Glass
LSR49HC-IQ 51 15/16 x 34 1/16 x 83 15/16 2 Full Glass 3.9 R-290 / 110 / 3.72
Height includes casters.
PRODUCT INFORMATION
• All models will maintain product temperature between 36 and 38 degrees F. at the factory setting of 38.0F.
• All models are 115 volts, 60 Hz AC and are equipped with a NEMA 5-15P plug.
• ALWAYS REFERENCE YOUR EQUIPMENT DATA PLATE AMPS, REFRIGERANT AND REFRIGERANT CHARGE FOR THE
MOST UP TO DATE AND ACCURATE VALUES.
• There are no access valves on the refrigeration system.

User Manual for LSR Refrigerators Victory
Rev. 06/23 Victory 7
CLEARANCE AND PLACEMENT
User Manual for TMR Refrigerators Beverage-Air
Rev. 12/21Beverage-Air24
GENERAL PARTS
12" TOP MINIMUM
CLEARANCE
6"
BOTTOM
MINIMUM
CLEARANCE
3"
REAR
MINIMUM
CLEARANCE
3"
LEFT/RIGHT SIDE
MINIMUM
CLEARANCE
12" TOP MINIMUM
CLEARANCE
6"
BOTTOM
MINIMUM
CLEARANCE
3"
REAR
MINIMUM
CLEARANCE
3"
LEFT/RIGHT SIDE
MINIMUM
CLEARANCE
6"
BOTTOM
MINIMUM
CLEARANCE
6"
TOP
MINIMUM
CLEARANCE
0"
LEFT/RIGHT SIDE
MINIMUM
CLEARANCE
3"
REAR
MINIMUM
CLEARANCE
Placement
Consider the following when selecting a location for your Refrigerator:
Clearance:
• 6 in. at the top
• 3.0 in. at the rear,
• 0 in. at the left side
• 0 in. at the right side
• 6 in at the bottom
Floor Load: the oor on which the Refrigerator is located must be even and level, free from vibrations, and strong enough
to support the combined weights of the unit and maximum product load.
Ventilation: Grille area at front must be free and clear of any object or wall.
Power Outlet: Dedicated power outlet is located within the length of the unit's power cord.

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory8
UNPACKING AND SET UP
CAUTION
Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is
suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim.
Do NOT contact the manufacturer.
Uncrating
Tools Needed: ¾" box wrench, adjustable wrench, level, at
head screw driver, and box cutter.
1. Remove the cardboard top capping, all clear tape,
and all staples including those at the bottom of the
cardboard carton and skid.
2. Start from the top of the carton. Using the box cutter,
carefully make one continuous cut to the bottom of the
skid. Remove cardboard carton and discard.
3. Move unit as close to nal position as possible before
removing the skid.
Note: The skid must be removed before the casters or
legs can be attached.
Do NOT tip unit on its front or sides. If tipped onto the back,
unit must not be started for 3 hours.
Note: additional clear plastic protective wrap is applied
directly to any product with a glass door.
Skid Removal and Caster Attachment
Tip the unit forward and remove the skid.
1. Remove the shipping bolts using the ¾" box wrench
while cabinet is held in one direction. Repeat the
process while the cabinet is held in the opposite
direction.
2. Tilt the cabinet in one direction approximately 8" and
block it securely with pieces of 2x4 lumber or other
suitable material.
Note for the following: None of the threads on the leg or
caster stem should be visible once screwed in.
3. Thread the stem casters or legs into the ½ -13 holes in
the bottom of the cabinet. Tighten by hand as much as
possible.
4. Once the caster or leg cannot be turned any further,
use a 3/4 inch wrench to tighten the nut in between the
mounting plate and the wheel of the caster until snug.
5. Repeat this procedure with unit secured in the opposite
direction so as to access the remaining legs/casters/
levelers
Leveling
Cabinets must be leveled when installed. Level should be
measured on the headrail.
Failure to level your cabinet may result in door not sealing,
closing correctly, or condensed water not draining properly.
For cabinets with legs, rotate the foot of the leg with an
adjustable wrench to achieve desired height for leveling.
For cabinets with casters, level by placing large washers in
between the ½' stud and the holes in the bottom of the case.
Do NOT loosen casters to level the
cabinet. Casters MUST be tightly
secured to cabinet for full strength.
Install or attach any accessories that will be used Remove
any plastic covering the stainless steel.
Risk of personal injury.
Unit must be securely supported
while attaching casters or legs.
WARNING

User Manual for LSR Refrigerators Victory
Rev. 06/23 Victory 9
1. Determine the proper location for the shelf clips.
2. Insert the top tab of the shelf clip into the desired
hole of the pilaster. The retaining tab MUST be facing
up as shown.
3. Rotate the clip downwards and insert the bottom tab
into the matching hole in the pilaster. The clip may
need to be squeezed slightly during installation.
4. Install all remaining clips.
5. Install shelves onto clips with the product retention
bar facing up. Be careful not to dislodge clips during
installation.
6. Place shelves so that the retaining tab on the clip
captures the shelf as shown.
7. Conrm that the shelf is resting on ALL 4 clips and
that the clips are securely attached to the pilasters.
8. Improper shelf clip installation could cause the shelf
and / or the product on it to fall, resulting in damage
to the unit and possible bodily injury.
9. Do NOT overload the shelves. The unit is designed to
use all shelves that are supplied in an equally spaced
manner. Contact Victory customer service if fewer
shelves or a dierent conguration to ensure shelf
overloading will not occur.
SHELF INSTALLATION
CORRECT
PROPERLY INSTALLED CLIPS
INCORRECT

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory10
This is a cord-connected unit, and must be connected to its own dedicated power supply. Check the dataplate on the
machine to conrm the voltage and per the dataplate use the correct fuses or HACR circuit breakers.
Note: Do not connect to GFI / GFCI outlets. Connection to that type of outlet can result in product loss due to
unsafe cabinet temperature when GFI device trips from moisture.
This 115 volt model is equipped with a cord and 5-15P plug.
If the power cord becomes damaged, it must be replaced
with the identical cord.
Follow All National and Local Codes
This unit must be grounded. Do not use extension cords
and do not disable or by-pass ground prong on electrical
plug.
Initial Start Up
Plug the power cord into the proper power supply.
The cabinet will soon begin to blow warm air out of the
top area, and cool air will ow from the inside blower.
The cabinet temperature has been set at the factory and
should not need adjustment, however if it was changed,
the standard setting is 38º F.
Cautions
Care must be taken whenever moving or servicing the
unit. The refrigerant is contained in a sealed system, but if
released it may be ammable.
After the cabinet has been installed, leveled, and cleaned
as described above, refer to the following checklist:
 Check for proper electrical hook-up.
Cabinet MUST NOT SHARE A RECEPTACLE with another
piece of equipment
 Check that all clearances are in line with the
aforementioned guidelines.
 Check that cabinet is level.
ELECTRICAL

User Manual for LSR Refrigerators Victory
Rev. 06/23 Victory 11
USING THE UNIT
38.0
oF
USING THE UNIT - DANFOSS CONTROLLER
Operation is simple, just keep it connected to the correct
power supply and the refrigerator will maintain the
internal temperature it has been set to. Keep the doors
closed as much as possible to avoid unnecessary run time.
The controller is located in the lower front grille of the
cabinet. The controller displays the current internal
temperature.
Adjusting the set temperature lower will NOT cause the
system to lower the temperature faster. When on, the
refrigeration system is always operating at maximum.
For best results, make certain the unit remains
powered and has achieved the desired set point
before loading it with product. Pull down time will
vary depending upon the type of unit and ambient
conditions
The refrigerator temperature was set at the factory at 38º.,
but you can adjust it to your own selected temperature.
The refrigerator will automatically defrost as needed,
there is no set time for defrost. Push and immediately
release the "melting" or defrost button for a manual
defrost.
Note: Holding the defrost button in too long will shut the
controller o.
The internal fan will be on whenever the appliance is
connected to power.
The compressor and condenser fan motor will only be on
when the controller senses an increase in internal cabinet
temperature passed the set point.
Select
Defrost Increase
Decrease
In most cases the only thing displayed will be the cabinet temperature. When something other than normal operation has
occurred, a message will be shown.
Message Displayed Why What to do
dEF Unit is defrosting Nothing. Normal operation.
Hi Cabinet temperature too warm Conrm doors or drawers are closed.
dOr Door is open Close door, if message does not
change, call for service.
LEA Compressor run time too long Check doors closed. If yes, call for
service.
E01, E02, E03, E04 Sensor unplugged or has failed Call for service.

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory12
SEQUENCE OF OPERATIONS REFRIGERATOR
0123ÿ567869ÿ3ÿ5ÿ9ÿ59ÿ923ÿ3
ÿ !"#$%&
'()*(+,(ÿ./ÿ.0(1234.+'ÿ1(/145(123.1
678ÿ:8;:<=8:>?@:ÿ@A8:>?8BÿC>B8Dÿ@Eÿ?78ÿ><:ÿ?8FA8:>?G:8ÿF8>BG:8DÿCHÿ?78ÿA:@C8ÿI@J>?8Dÿ>?ÿ?78ÿ:8?G:Eÿ><:Kÿÿ
LMLNN
OLPQLMRM6 LQRST6ULMOLM6SLVVRSÿTO6ULMLQRST6ULMOLM6SLVVRSÿTO6ULM
OLPQSRWWLS
O@FA:8BB@:ÿ?G:EBÿ
@EÿX78Eÿ?78ÿ><:ÿ
?8FA8:>?G:8ÿ>?ÿ?78ÿ
A:@C8ÿ<Bÿ>C@Y8ÿ?78ÿ
BGFÿ@;ÿ?78ÿB8?ÿA@<E?ÿ
Z[
678ÿO@FA:8BB@:ÿ
O@E?>J?ÿ<Bÿ8E8:=<\8D O@FA:8BB@:ÿ?G:EBÿ @]ÿX78Eÿ?78ÿ><:ÿ
?8FA8:>?G:8ÿ>?ÿA:@C8ÿ<Bÿ
8^G>Iÿ?@ÿ@:ÿI8BBÿ?7>Eÿ?78ÿ
B8?ÿA@<E?ÿ_[
678ÿO@FA
:8BB@:ÿ
O@E?>J?ÿ<BÿD8_
8E8:=<\8D
`RSOÿ%%[ÿaÿ68:F<E>Iÿb%c `RSOÿ%%[ÿaÿ68:F<E>Iÿ
b%c
OLMdRMWRSÿNTM
678ÿO@ED8EB8:ÿN>Eÿ
?G:EBÿ@EÿÿX78Eÿ
?78ÿO@FA:8BB@:ÿ<Bÿ
:GEE<E=
678ÿO@ED8EB8:ÿN>Eÿ
<BÿX<:8DÿD<:8J?IHÿ?@ÿ
?78ÿO@FA:8BB@:eÿE@?ÿ
?7:@G=7ÿ?78ÿJ@E?:@II8:
678ÿO@ED8EB8:ÿN>Eÿ
?G:EBÿ@]ÿX78Eÿ?78ÿ
O@FA:8BB@:ÿ<BÿE@?ÿ
:GEE<E=
678ÿO@ED8EB8:ÿN>Eÿ
<BÿX<:8DÿD<:8J?IHÿ?@ÿ
?78ÿO@FA:8BB@:eÿE@?ÿ
?7:@G=7ÿ?78ÿJ@E?:@II8:
RfTQLST6LSÿ
NTM
678ÿRY>A@:>?@:ÿN>Eÿ
:GEBÿJ@E?<EG@GBIHÿ<Eÿ
:8;:<=8:>?@:
BKÿg78Eÿ
?78ÿGE<?ÿ<BÿAIG==8Dÿ
<Eeÿ?78ÿRY>A@:>?@:ÿ
N>EÿX<IIÿ:GEK
678ÿ8Y>A@:>?@:ÿN>Eÿ<Bÿ
J@EE8J?8DÿD<:8J?IHÿ?@ÿ
<EJ@F<E=ÿA@X8:eÿE@?ÿ
?7:@G=7ÿ?78ÿJ@E?:@II8:
678ÿRY>A@:>?@:ÿN>Eÿ
:GEBÿJ@E?<EG@GBIHÿ<Eÿ
:8;:<=8:>?@:BKÿg78Eÿ?78ÿ
GE<?ÿ<BÿAIG==8Dÿ<Eeÿ?78ÿ
RY>A@:>?@:ÿN>EÿX<IIÿ:GE
678ÿ8Y>A@:>?@:ÿN>Eÿ<Bÿ
J@EE8J?8DÿD<:8J?IHÿ?@ÿ
<EJ@F<E=ÿA@X8:eÿE@?ÿ
?7:@G=7ÿ?78ÿJ@E?:@II8:K
O@ED<?<@E
O@FA:8BB@: O@ED8EB8:ÿN>E RY>A@:>?@:ÿ N>E V<=7?B
O>C<E8?ÿ68FAÿhÿW8?ÿA@<E?ÿZÿ[LMLMLMLMÿ@:ÿLNN
O>C<E8?ÿ68FA8:>?G:8ÿijÿW8?ÿA@<E?ÿ_ÿ[LNNLNNLMLMÿ@:ÿLNN
¶ÿ¦ÿÿ
»¼½¾¹ÿ
}~ÿ~ÿ¦ÿÿÿ
¦~ÿ~ÿÿÿÿÿ
ÿÿ¦~ÿ
~ÿÿÿÿ
¦~ÿÿ³ÿ
}~ÿ¿~ÿ¥ÿÿ
ªÿ }~ÿ~ÿ¦ÿÿÿ
¦~ÿ~ÿÿÿÿÿ
ÿÿ¦~ÿ~ÿ
ÿÿÿ¦~ÿÿ
³ÿ
}~ÿ¿~ÿ¥ÿÿ
¬ªÿ
®¯¥ÿ°°©ÿ±ÿ} ÿ
²À³ÿ ®¯¥ÿ°°©ÿ±ÿ} ÿ ²À³ÿ
ÿ
ÿ
ÿ
ÿ
ÿ
ÿ
ÿ
ÿ
¡rpÁyxyrpÿ
¡rÂuvmzzrvÿ ¡rpÁmpzmvÿ wpÿ
¤Ãwurvwxrvÿ wpÿ
»y|Äxzÿ
¡wÅypmxÿ¹mÂuÿÆÿlmxÿurypxÿÇÿÈÿ tÿ tÿ tÿ tÿrvÿtÿ
¡wÅypmxÿ¹mÂumvwxovmÿÉÊÿlmxÿurypxÿËÿÈÿ tÿ tÿ tÿ tÿrvÿtÿ
´msvrzxÿ tÿ tÿ tÿ tÿrvÿtÿ
ÿ
ÍÎÏÐÎÑÒÎÿÓÔÿÕÖÎ×ØÙÚÓÑÛÿÜÎÔ×ÚÝÎ×ØÙÓ×ÿ
ÿ
Þßàÿâàãâäåàâæçèâÿèéàâæçàêÿëæêàìÿèíÿçßàÿæäâÿçàîéàâæçïâàÿîàæêïâàìÿëðÿçßàÿéâèëàÿñèòæçàìÿæçÿçßàÿ
âàçïâíÿæäâóÿÿÿ
ÿ
ÿ
ÿ
Õôÿ Õõõÿ
ö÷øù÷úûúüÿ ÷ùûþÿü 0 ÷úÿ ö÷úüþ÷
11 ûþÿ
ÿöü 0 ÷úÿ ÷ùûþÿü
0 ÷úÿ ö÷úüþ÷
11 ûþÿ
ÿöü 0 ÷úÿ
2 Õ 34 Ü 5 ÍÍÕÜÿ
6 èîéâàêêèâÿçïâíêÿ
èíÿ 7 ßàíÿçßàÿæäâÿ
çàîéàâæçïâàÿæçÿçßàÿ
éâèëàÿäêÿæëè 8 àÿçßàÿ
êïîÿèãÿçßàÿêàçÿéèäíçÿ
9 ÿ
Þßàÿ 6 èîéâàêêèâÿ
6 èíçæòçÿäêÿàíàâåä  àìÿ
6 èîéâàêêèâÿçïâíêÿèããÿ
7 ßàíÿçßàÿæäâÿ
çàîéàâæçïâàÿæçÿéâèëàÿäêÿ
à  ïæñÿçèÿèâÿñàêêÿçßæíÿ
çßàÿêàçÿéèäíçÿ  ÿ
Þßàÿ 6
èîéâàêêèâÿ
6 èíçæòçÿäêÿìà 
àíàâåä  àìÿ
6 ÿ  ÿ  ÿÞàâîäíæñÿ
 ÿ
6 ÿ  ÿ  ÿÞàâîäíæ
ñÿ
 ÿ
2 Õô 5 ôÍ 5 Üÿ
õ  ôÿ
Þßàÿ 6 èíìàíêàâÿ  æíÿ
çïâíêÿèíÿÿ 7 ßàíÿçßàÿ
6 èîéâàêêèâÿäêÿ
âïííäíåÿ
Þßàÿ 6 èíìàíêàâÿ  æíÿäêÿ
7 äâàìÿìäâàòçñðÿçèÿçßàÿ
6 èîéâàêêèâ  ÿíèçÿ
çßâèïåßÿçßàÿòèíçâèññàâÿ
Þßàÿ 6 èíìàíêàâÿ  æíÿ
çïâíêÿèããÿ 7 ßàíÿçßàÿ
6 èîéâàêêèâÿäêÿíèçÿ
âïííäíåÿ
Þßàÿ 6 èíìàíêàâÿ  æí
ÿ
äêÿ 7 äâàìÿìäâàòçñðÿçèÿçßà
ÿ
6 èîéâàêêèâ  ÿíèçÿ
çßâèïåßÿçßàÿòèíçâèññàâ
ÿ
54 ÕÜ  ÕÜÿ
õ  ôÿ
Þßàÿ 8 æéèâæçèâÿ  æíÿ
âïíêÿòèíçäíïèïêñðÿäíÿ
âàãâäåàâæçèâêóÿÿ  ßàíÿ
çßàÿïíäçÿäêÿéñïååàìÿ
äí  ÿçßàÿ 8 æéèâæçèâÿ
 æíÿ 7 äññÿâïíóÿ
Þßàÿ 8 æéèâæçèâÿ  æíÿäêÿ
òèííàòçàìÿìäâàòçñðÿçèÿ
äíòèîäíåÿéè 7 àâ  ÿíèçÿ
çßâèïåßÿçßàÿòèíçâèññàâóÿ
Þßàÿ 8 æéèâæçèâÿ  æíÿ
âïíêÿòèíçäíïèïêñðóÿÿ
 ßàíÿçßàÿïíäçÿäêÿ
éñïååàìÿäí  ÿÞßàÿ
8 æéèâæçèâÿ  æíÿ 7 äññÿâïíóÿ
Þßàÿ 8 æéèâæçèâÿ  æí
ÿ
äêÿòèííàòçàìÿìäâàòçñð
ÿ
çèÿäíòèîäíåÿéè 7 àâ  ÿ
íèçÿçßâèïåßÿçßàÿ
òèíçâèññàâóÿ
 ÿ
Þßàÿñäåßçÿ 7 äññÿçïâíÿèíÿ
7 ßàíÿçßàÿÿÿÿäêÿ
éâàêêàìÿ  èâÿ 7 ßàíÿ
çßàÿìèèâÿäêÿèéàíàìÿ
7 äçßÿêèñäìÿìèèâê  ÿ
Þßàÿ äåßçÿ 6 èíçæòçÿäêÿ
àíàâåä  àìÿ Þßàÿñäåßçÿ
7 äññÿçïâíÿèããÿ
7 ßàíÿçßàÿÿÿÿäêÿ
éâàêêàìÿ  èâÿ 7 ßàíÿçßàÿ
ìèèâÿäêÿòñèêàìÿ 7 äçßÿêèñäìÿ
ìèèâê  ÿ
Þßàÿ äåßçÿ 6 èíçæòçÿäê
ÿ
ìà  àíàâåä  àìÿ
6 ÿ  ÿ  ÿÞàâîäíæñÿ
! ÿ
6 ÿ  ÿ  ÿÞàâîäíæ
ñÿ
! ÿ
ÿ
ÿ
ÿ
ÿ
ÿ
2 ÓÑ " ÚÙÚÓÑÿ
×ÎÛÛÓ×ÿ
ÎÑÛÎ×ÿ
×ØÙÓ×ÿ
Ûÿ

User Manual for LSR Refrigerators Victory
Rev. 06/23 Victory 13
User Manual for UCR Refrigerators Beverage-Air
Rev. 09/21 Beverage-Air 11
DANFOSS CONTROLLER
Electronic Controller
Control Panel Display
Note: Defrost is manual, LED indicator is inoperative.
Defrost LED Alarm LED
On xed: Defrost active On xed: ALARM Present
O: Defrost is o Flashing: ALARM Silenced
O: No Alarm
Fan LED Compressor LED
On xed: Fan active On xed: Compressor active
O: Fan O Flashing: Delay, protection or activation blocked
O: No Alarm
Keyboard Functions
UP
Quick press and release
•
Increases Set Point
Long press and release
• Increases display brightness
DOWN
Quick press and release
•
Decreases Set Point
Long press and release
• Decreases display brightness
DEFROST (ESC)
Quick press and release
•
Activates manual defrost
Long press and release
• Controller enter stand-by mode
SET (ENTER)
Quick press and release
•
Toggles lights on/o
Long press and release
• Toggles display °F/°C
NOTE: When switched on, the instrument panel performs a lamp test for a few seconds.
UP
DOWN
DEFROST (ESC)
SELECT (OK)
Note: When the controller is in a Standby Mode, a blue dot
will be displayed as shown here. To switch out of Standby
Mode, push and hold the Defrost button until the display
reads ON.
.

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory14
0123ÿ567869ÿ3ÿÿ9ÿ59ÿ923ÿ223623
ÿ !"!#$%!'(#)*

User Manual for LSR Refrigerators Victory
Rev. 06/23 Victory 15
0123ÿ567869ÿ3ÿÿ223623
ÿ !"#$% '
()*+,ÿ./ÿ01023ÿ4561789:;ÿ<9348ÿ024ÿ9;ÿ=2:>2488ÿ?@A@ÿ/:1C42ÿ:/ÿ<D4ÿ=02034<42ÿ<0E14FGÿ<D4ÿ01023ÿ98ÿ;:<ÿ89>;014CH

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory16
0123ÿ567869ÿ3ÿÿ9ÿ59ÿ923ÿ223623
ÿ !"!#$%!'(#)*
+,-./ÿ123ÿ+.-1ÿ4ÿ35-6355ÿ78.1985539

User Manual for LSR Refrigerators Victory
Rev. 06/23 Victory 17
Refrigerator with Eliwell Controlle
r
Beverage-Ai
r
SEQUENCE OF OPERATIONS REFRIGERATOR
The refrigerator operates based on the air temperature measured by the probe located at the return air.
ON OFF
COMPONENT OPERATION CONTROLLER
ACTION OPERATION CONTROLLER ACTION
COMPRESSOR
Compressor turns on
when the air
temperature at the
probe is above the
sum of the set point
+ 4
The Compressor Contact
is energized
Compressor turns
off when the air
temperature at
probe is equal to
or less than the
set point
The Compressor Contact
is de-energized
(EW+978 - Terminal
#1)
(EW+978 - Terminal #1)
CONDENSER FAN
The Condenser
Fan turns on when
the Compressor is
running
The Condenser Fan is
wired directly to the
Compressor, not throu
g
h
the controller
The Condenser Fan
turns off when the
Compressor is not
running
The Condenser Fan is
wired directly to the
Compressor, not throu
g
h
the controller
EVAP FAN
The Evaporator
Fan turns on when
the unit is
powered on.
The Evaporator Fan is
wired to constant power
The Evaporator Fan
turns off when the
unit is unplugged
or put into standby.
The Evaporator Fan is
wired to constant power
Some models will be
wired to the fan relay
(EW+978 - Terminal
#3)
Some models will be
wired to the fan relay
(EW+978 - Terminal
#3)
LIGHT
The light will turn on
when the down
button is
pressed (or when the
door is opened with
solid doors)
The Light Contact is
energized The light will turn
off when the down
button is
pressed (or when the
door is closed with
solid doors)
The Light Contact is de-
energized
(Ew+978 – Terminal #2) (Ew+978 – Terminal #2)
Condition
Compressor Condenser Fan Evaporator Fan Lights
Cabinet Temp > Set point + 4 ON ON ON ON or OFF
Cabinet Temperature <= Set point - 4 OFF OFF ON ON or OFF
Defrost OFF OFF ON ON or OFF
Refrigerator with Eliwell Controlle
r
Beverage-Ai
r

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory18
0123ÿ567869ÿ3ÿÿ9ÿ59ÿ923ÿ223623
ÿ !"!#$%!'(#)*

User Manual for LSR Refrigerators Victory
Rev. 06/23 Victory 19
0123ÿ567869ÿ3ÿÿ9ÿ59ÿ923ÿ223623
ÿ !"!#$%!'(#)*

User Manual for LSR Refrigerators Victory
Rev. 06/23Victory20
CLEANING AND MAINTENANCE
Cleaning Schedule:
Cabinet
Daily wipe down
Weekly interior
Condenser coil
Monthly inspection,
cleaning as required
Gaskets
Daily inspection, check
that hinges are tight to
the cabinet.
Routine maintenance
Annually
Daily Exterior Cleaning
It is much easier to clean on a regular basis than to have to remove stains once they have built up.
1. Wash with a clean sponge and a mild detergent that
does not contain chlorine.
2. Rinse with clean water.
3. Dry with a soft cloth.
4. Polish with a soft cloth, wiping with the grain.
5. Wipe weekly with stainless steel cleaner.
Weekly Interior Cleaning
1. Remove all food, food related items and shelves. Store
the food at a safe temperature.
2. Disconnect power to the unit (unplug it or switch the
breaker o).
3. Remove all loose food particles from the inside walls,
oor, door liner and ceiling.
4. Scrub all interior surfaces and door gaskets with a
warm (100oF to 110oF) detergent solution and a soft
scrub brush.
5. Rinse with clean water and allow to air dry.
6. Return the shelves to the unit and secure them.
7. Restore power.
8. Return food to the unit when it has reached a safe
temperature.
