VIDA TECH F7020 User manual

vidatechelevator.com
F7020 – CANBus 7” LCD indicator
Installation manual
• Supply must be between 16VDC to 28VDC.
• Must be installed in COP
• Brightness of the LCD is controlled by “brightness” potentiometer.
• Press ENTER to go the main menu of the LCD, then navigate with UP/DOWN switches. Refer to F7022 opera-
tion manual on our website.
Status LED State Description
No communicationSteady
Slow Blink Systen error
Communication active with no errorFast Blink
• Status LED :
USB
Input for USB key
UP
ENTER
DOWN
Button to change the
configuration on board
Status Arrv
Up
Arrv
Dn
Strobe USB
USB light
Status LED State
(Refer to the chart)
Brightness
Switch setting
(Refer to the chart)
S1 S2
SPK +
SPK -
ON
OFF
24V
COM
CANH
CANL
SHLD
CANBus
Supply
FM FA
NoArr
FBLT
Portrait COM1
COM2 COM3
www.vidatechelevator.com
End off line :CanBus

• Switch setting :
SW
#
S2
#
1 FM
FA
NoArr
FBLT
Portrait
COM1
COM2
COM3
2
3
4
5
6
7
8
Text
Communication CAN Vidatech CAN JRT
Description
ON -> Blank the display in fire mode
ON -> Blank the display in fire alternate mode
ON -> Blank the arrow
ON -> Portrait mode (If existing within the config)
ON -> 100% backlight intensity
OFF -> 80% backlight intensity (Backlight life enhanced)
CAN GAL
