Vidal Sassoon VSM7275A User manual

Model VSM7275A
I-TwIn TrIm
Dual BlaDe lIThIum TrImmer

I-TWIN TRIM
The Vs For Men i-Twin Trim Dual Blade Lithium Trimmer is a professional
grade rechargeable trimmer with a twin blade system for 2x the cutting
power. The lithium-ion technology gives sustained power performance,
even at lower charge levels. Super sharp, stainless steel dual blades
gives smooth, effortless cutting for all over facial grooming.
FEATURES
•Rechargeable trimmer with 2 interchangeable cutting heads.
•Dual blade precision trimmer for 2x the cutting power
•Single blade for detailing, edging and precision trimming
•5-position comb guide for cutting lengths 4mm, 6.5mm, 9mm,
11.5mm & 14mm trims
•3 x Stubble combs for different stubble lengths
•Lithium-ion technology gives sustained power performance, even at
lower charge levels
•Cleaning brush.
•Lubricating oil.
• 3 jaw line combs (1-3mm)
•Hygienic rotary trimmer for safe and gentle removal of unwanted
nose and ear hair
• Charging and storage stand
•2 year guarantee.

SAFETY CAUTIONS
WARNING! Polythene bags over the product or packaging
may be dangerous. To avoid danger of suffocation, keep
away from babies and children. These bags are not toys.
• This appliance should only be used as described within
this instruction book. Please retain for reference.
• Do not immerse the appliance in water or other
liquids.
• Always inspect the appliance before use for noticeable
signs of damage. Do not use if damaged or if the appliance
has been dropped. In the event of damage contact the
Conair Customer service line 1800 650 263
• Only use the attachments supplied with this appliance.
• Do not leave the appliance unattended when switched
on.
• Do not place the appliance on any surface whilst in
operation.
• Special care is required when using the appliance close
to the ears, eyes and face.
• This appliance should not be used by adults whose
reduced physical, sensory or mental capabilities, or
whose lack of experience and knowledge, might cause
a hazard, unless they have been correctly instructed to
understand the safe use and hazards involved and are
adequately supervised.
• Careful adult supervision is required when this appliance
is used on or near children. Do not use on very young
children.
• This appliance should not be used, cleaned or maintained

by children. Keep out of reach of children.
• Always ensure that this appliance is kept out of the reach
of children at all times, particularly during use and whilst
cooling.
• Allow the appliance to cool before storing away.
• The battery should be removed for safe disposal at the
end of its life.
• When the battery has run down, it should be disposed
of at a recycling centre to safeguard the environment. If
the battery leaks, avoid touching it and dispose of it at a
recycling centre.
INSTRUCTIONS FOR USE
IMPORTANT! Only use the adaptor and attachments supplied with
this appliance.
Inserting the Adaptor Cord into the Stand
• Remove the trimmer and accessories from the stand.
• Insert the adaptor plug into the hole on the base of the stand and
push rmly into position.
• Route the cord through the channel on the base of the stand and
secure in place.
• Should you wish to charge the appliance without using the charging
stand, simply place the adaptor plug directly into the main trimmer
unit.
Charging the Appliance
• A full 1hr charge will provide approximately 60 minutes use.
• Ensure the appliance is switched off.
• Insert the charger into the base of the trimmer

• Before the appliance is used for the rst time, it should be charged
for 3 hours. During charging, the indicator will ash continuously
until the battery is full charged. then the charging indicator will stop
ashing but remain on.After the rst hours battery charge, it can then
be charged in approximately 1 to 3 hours.
• When the trimmer is about to run out of energy, the charging indicator
will ash to indicate that you have less than 15% battery capacity
remaining.
Preserving the batteries
In order to maintain the optimum capacity of the rechargeable batteries,
the trimmer should be fully discharged and then recharged for 3 hour
every 6 months.
Preparation for Use
• Always inspect the appliance before use for noticeable signs of
damage. Do not use if damaged.
• Ensure the heads are free from hair and debris and that the blades
are properly oiled (refer to Cleaning & Maintenance section for further
information).
• Ensure the appliance is sufciently charged.
• Use on clean, dry hair that has been combed until tangle free.
How to use the single detail trimming blade
• The trimmer’s upper blade can be removed to use the single detailing
blade as shown in Fig. 1 and Fig. 2.
NOTE: All attachments combs also t on the single detailing blade for
single blade trimming.
Fig.1 Fig.2
Step 1
Push the
upper blade
forward.
Step 2 Lift the
blade off.

• To re-attach upper blade see Fig. 3 and Fig.4.
COMB GUIDES
The table below explains the trim length for each comb. You should
start out with a longer trim length comb and work your way down to
the desired trim length.
How To Use 5 position Comb Guide
• The trimmer includes a ve-position comb for use with the hair
trimming blade (4-14mm). Each position increases the length by
2.5mm.
• To use the 5-position comb, slide the unit over the trimmer blade and
snap it down into position.
J1 1mm trim
J2 2mm trim
J3 3mm trim
S1 Close stubble look
S2 Medium stubble look
S3 High stubble look
J1
S1
J2
S2
J3
S3
4mm, 6.5mm, 9mm,
11.5mm & 14mm trims
5-POSITION COMB
Fig.3 Fig.4
Step 3 Line up
white tab with
opening in
lower blade.
Step 4 Insert the white
tab, slide forward until
the 2 front tabs drop
in and the blade snaps
in place.

• At rst, until you become familiar with the adjustments, use the
longest trim setting. (You can always go back and make your beard
a little shorter.)
• Begin trimming your beard using smooth, even strokes. Start with
your sideburns and work downward toward your chin. (Never attempt
to trim against the natural growth of your beard because the hair will
be cut too short.)
• If you decide you want a closer trim, you can now adjust the 5-position
comb attachment to a shorter setting (such as 4mm or 6.5mm) and
go over your beard again until you achieve the desired length.
Stubble Trimming
The three stubble attachments will help you to achieve the perfect
stubble you are looking to achieve. S1 = close stubble, S2 = medium
stubble, S3 = longer stubble
Hold the trimmer in an upright position and begin trimming under your
jawline, using short, even strokes.
Blending the Jawline
1. The three jawline attachments will help you to achieve a neat,
nished trim under your chin. To use one of the attachments, press
it down over the trimmer blades until it clicks into position (jawline
J1 provides 1mm, jawline J2 provides 2mm and jawline J3 provides
3mm).
2. Hold the trimmer in an upright position and begin trimming under
your jawline, using short, even strokes.

3. After your beard is blended, turn off the trimmer and remove the
attachment by gently pulling up on tab.
Nose & Ear Trimmer
To remove the precision trimmer, hold the handle of the appliance with
one hand, hold the head with the other hand and pull the head back
and away from the front of the handle.
• To attach the nose and ear trimmer head, make sure that the base of
the head is seated in the handle, click the head into position.
Using the Nose & Ear Trimmer:
• For the safe and easy removal of unwanted nose and ear hair use the
rotary trimmer head.
• Switch the trimmer on.
• Insert the trimmer into the nose or ear and gently move the trimmer
in a circular motion.
• Only use the trimmer at the entrance to the ear or nose. Do not use
any deeper, as this could cause injury.
• Never turn the trimmer off whilst in the nose and ear hair.
CLEANING & MAINTENANCE
For easy cleaning, the blades on your Vs For Men Trimmer are
removable. Regular cleaning will maintain their high performance level.
To clean proceed as follows:
• Switch the appliance off and unplug at the mains supply.
• Remove any comb guides. Rinse the comb guide under running
water and dry thoroughly before storage or use.
• Before storing you trimmer use a cleaning brush to whisk away any
loose hair from the unit and the blades. You should remove the upper
blade after a few uses to clean between the blades. To remove entire

®
Vidal Sassoon and related logos are trademarks of
The Procter & Gamble Company used under license
by Conair
©2014
Conair Australia Pty. Ltd.
Suite 101, 18 Rodborough Rd
Frenchs Forest NSW, 2086
Australia
Customer Service Hotline (Australia): 1800 650 263
Customer Service e-mail: [e-mail]
Conair New Zealand Limited, PO BOX 251159,
Pakuranga, Auckland
1706 New Zealand
Customer Service Hotline (New Zealand): 0800 266 247
blade set from your trimmer, make sure the trimmer is in the OFF
position. Remove the blade set by placing thumb against the smaller
cutter and pushing forward, releasing the cutter assembly from the
trimmer housing. Replace with new cutting system and reverse the
removal procedure, only this time place your thumb on the large
cutter and snap into place.
LIMITED TWO -YEAR WARRANTY
This product is subject to the express warranty given on the warranty
card included with the product, as may be amended by reference to
and in accordance with the terms of the warranty cards displayed on
VS For Men website www.vsformen.com.au
To make a warranty claim you must retain your proof of purchase.
Further details can be found at www.vsformen.com.au and click on
‘customer service’.
