INSTALLATION GUIDE FOR THE
VGA-CMP
INTRODUCTION
The VPI VGA-CMP converts VGA video to component video.
INSTALLATION
1. Turn OFF power to video source and video display device.
2. Connect a VEXT-3-MM VGA video cable (sold separately) from the video source to the female connector labeled "VGA" on
the VGA-CMP.
3. Connect a set of CMPEXT-3-MM 75 ohm RCA cables (sold separately) between the "Y", "Pb", and "Pr" connectors on the
VGA-CMP and the like connectors on the video display device. Typically the "Y" connector is green, the "Pb" connector is
blue, and the "Pr" connector is red.
4. Plug in the AC adapter and connect it to the VGA-CMP.
5. Turn ON power to the video source and video display device.
Note: Additional video cable lengths (VEXT-6/10/15/25/35/50/75/100-MM and CMPEXT-6/12/25/50/75/100-MM) may be
ordered from Video Products Inc by calling (800) 626--7801 (U.S) or 330-562-2622 or visit our website at www.vpi.us
Left End View of VGA-CMP
VGA Video
15HD Female
Connector
Power
Connector
Right End View of VGA-CMP
Component Video
75 Ohm RCA
Connectors
Tel: [phone]
www.vpi.us
1275 Danner Drive Fax: [phone]
VPI
VIDEO
PRODUCTS
INCORPORATED
Aurora,Ohio 44202
CMPEXT-xx-MM
9V
1.0 A
VGA
YPbPr
-
+
VGA-CMP
HDTV
w/ component
video
9 VDC
Adapter
ADAPTER
VGA-CMP
9VDC Adapter
(supplied)
VEXT-xx-MM
(sold separately)
CPU
VPI
Video P rod ucts I nc
(sold separately)

TECHNICAL SPECIFICATIONS
COPYRIGHT
© 2006 Video Products Inc All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written
consent of Video Products Inc, 1275 Danner Drive •Aurora, OH 44202.
CHANGES
The material in this guide is for information only and is subject to change without notice. Video Products Inc reserves the right to
make changes in the product design without reservation and without notification to its users.
WARRANTY INFORMATION
The warranty period on this product (parts and labor) is one (1) year from date of purchase. Please contact Video Products Inc at
[phone] or 330-562-2622 for information regarding repairs and/or returns. A return authorization number is required for
all repairs/returns.
MODEL NO: VGA-CMP
SERIAL NO: ____________________
DATE: ______________________
INSPECTED BY: _____________________
MAN032 Revised 4/21/2006
TROUBLESHOOTING
Problem Solution
No Video • Connect power to VGA-CMP
• Make sure cable connections are secure
and in their appropriate places
General
Description Specification
Input Signal Type VGA, SVGA, XGA
Input Signal Connector 15HD Female
Output Signal Type High Definition Component Video
Output Connectors 75 ohm RCA Female
Max. Input Levels .7vp-p
Max. Output Levels 1vp-p
Input / Output Impedance 75 Ohms
Maximum Resolution 1920 x 1080
Power 110 or 220VAC at 50 or 60 Hz-
9VDC/ 1A AC adapter
Size (In.) W x D x H 3.7 x 2.1 x 1.15
