MAXIMUS MVX DELUX
High-spec ex-proof HD camera in a compact design
Manual B

EN
English - Instruction manual
ENGLISH
MAXIMUS MVX DELUX
High-spec ex-proof HD camera in a compact design
Manual B

Instruction manual - English - EN
3MNVCMVXHDBCAM_1813_EN
Contents
ENGLISH 1
1 About this manual ......................................................................................................... 4
1.1 Typographical conventions.................................................................................................................................. 4
2 Notes on copyright and information on trademarks.................................................. 4
3 Identication.................................................................................................................. 4
3.1 Product marking ...................................................................................................................................................... 4
4 Installation ..................................................................................................................... 5
4.1 Range of use.............................................................................................................................................................. 5
4.2 Connection of the power supply line............................................................................................................... 5
4.3 Connection of the Ethernet cable...................................................................................................................... 6
4.4 Signal cable connection........................................................................................................................................ 6
4.4.1 Alarm and relay connections............................................................................................................................................... 6
4.4.1.1 Connecting an alarm with dry contact ................................................................................................................................................. 6
4.4.1.2 Relays connection......................................................................................................................................................................................... 7
4.5 Washing system connection................................................................................................................................ 7
5 Switching on .................................................................................................................. 7
5.1 Before powering the product in an explosive atmosphere...................................................................... 7
5.2 First start-up............................................................................................................................................................... 7
6 Conguration................................................................................................................. 8
6.1 Default IP address.................................................................................................................................................... 8
6.2 Web interface ............................................................................................................................................................ 8
6.2.1 First access to the web pages.............................................................................................................................................. 8
7 Accessories..................................................................................................................... 8
8 Instructions for normal operation................................................................................ 8
8.1 Enabling the wiper (Wiper).................................................................................................................................. 8
8.2 Enabling the washer (Washer)............................................................................................................................ 8
8.3 Special controls ........................................................................................................................................................ 8
9 Maintenance .................................................................................................................. 9
9.1 Firmware updating.................................................................................................................................................. 9
9.1.1 Factory Default ......................................................................................................................................................................... 9
10 Information on disposal and recycling...................................................................... 9
11 Troubleshooting ........................................................................................................ 10
12 Technical data ............................................................................................................ 10
12.1 Cameras..................................................................................................................................................................10

EN - English - Instruction manual
4 MNVCMVXHDBCAM_1813_EN
1 About this manual
Read all the documentation supplied carefully before
installing and using this unit. Keep the manual in a
convenient place for future reference.
1.1 Typographical conventions
DANGER!
High level hazard.
Risk of electric shock. Disconnect the
power supply before proceeding with any
operation, unless indicated otherwise.
DANGER!
Explosion hazard.
Read carefully to avoid danger of explosion.
CAUTION!
Medium level hazard.
This operation is very important for the
system to function properly. Please read
the procedure described very carefully and
carry it out as instructed.
INFO
Description of system specications.
We recommend reading this part carefully
in order to understand the subsequent
stages.
2 Notes on copyright and
information on trademarks
The mentioned names of products or companies are
trademarks or registered trademarks.
3 Identication
3.1 Product marking
See the label attached to the product.

Instruction manual - English - EN
5MNVCMVXHDBCAM_1813_EN
4 Installation
CAUTION! Device installation and
maintaining must be performed by
specialist technical sta only.
The external multi-polar cable shield
(armature) must be earthed.
All disconnected wires must be electrically
isolated.
The product comes with a multi-polar cable
or a cable tail for coupling purposes. When
installing the device with the multi-polar
cable, keep at least 250mm free space from
the bottom of the housing to allow for the
minimum curvature radius of the multi-
polar cable.
4.1 Range of use
For installation indoors and outdoors
Installation temperature: from -40°C (-40°F) up to
+60°C (140°F).
Operating temperature:
• Cold start from -40°C to +65°C.
• Operation from -50°C to +65°C.
Relative humidity: from 10% up to 95% (no
condensation).
4.2 Connection of the power
supply line
Electrical connections must be performed
with the power supply disconnected and
the circuit-breaker open.
When commencing installation make sure
that the specications for the power supply
for the installation correspond with those
required by the device.
Check that the power supply is adequately
dimensioned.
The device can be provided with dierent power
supply voltages. The power supply voltage is
indicated on the product identication label. (3.1
Product marking, page4).
The multicore cable has the power and earth cables
inside.
Perform the connections following the instructions
reported in the table .
CONNECTION OF THE POWER SUPPLY LINE
Power supply 24Vac/ 24Vdc/ 12Vdc
Colour Terminals
Black 1 (+) L (Phase)
Black 2 (-) N (Neutral)
Yellow/Green
Tab. 1

EN - English - Instruction manual
6 MNVCMVXHDBCAM_1813_EN
4.3 Connection of the Ethernet
cable
The Ethernet cable shield must always be
earthed via the connector. Always use a
shielded RJ45 connector.
Use of Ethernet cables with the following
characteristics is highly recommended:
• STP (shielded)
• Category 5E (or higher)
The product can be directly connected to an Ethernet
switch.
Carry out the connections as described in the table
(according to the standard specications: TIA/EIA-
568-B).
CONNECTION OF THE ETHERNET CABLE
Pin number Cable color
1 Orange-White
2 Orange
3 Green-White
4 Blue
5 Blue-White
6 Green
7 Brown-White
8 Brown
Tab. 2
The example below shows a typical installation.
Switch
Personal
Computer
Fig. 1
4.4 Signal cable connection
CAUTION! TNV-1 installation type. The
installation is type TNV-1, do not connect it
to SELV circuits.
SIGNAL CABLE CONNECTION
Colour Function
White RS-485 A (+)
Yellow RS-485 B (-)
Pink Relay 1, Terminal A
Violet (blue, cable
tail version)
Relay 1, Terminal B
Red (brown, cable
tail version)
Alarm/Digital input
Green GND/Common alarm
Grey Reset
Tab. 3
4.4.1 Alarm and relay connections
The external relay and alarm cable shield
must be earthed.
The unit is equipped with the alarms and relays
indicated in the table (Tab. 3, page6).
4.4.1.1 Connecting an alarm with dry contact
In case of free contact alarm make the connection as
shown in the gure.
AL1 COM
dry contact
Fig. 2AL1: Alarm 1. COM: Common alarms.
Clean contact of the alarm can be set NO (normally
open) or NC (normally closed) using the web
interface.

Instruction manual - English - EN
7MNVCMVXHDBCAM_1813_EN
4.4.1.2 Relays connection
The relays are usable with the specications
described below. Working voltage: up
to 30Vac or 60Vdc. Current: 1A max. Use
suitable cable sections with the following
characteristics: from 0.25mm² (23AWG) up
to 1.5mm² (16AWG).
Due to the absence of polarity, both terminals of
the same relay can be used equally with either
alternating or continuous current.
4.5 Washing system connection
For further details on conguration and
use, refer to the relative manual.
5 Switching on
The automatic pre-heating procedure (De-
Ice) activates for 2 hours if on device switch
on an ambient temperature is detected
under -10 °C (+14°F). The procedure is
necessary to guarantee correct operation of
the devices even at low temperatures.
Complete functionality of the product is guaranteed
up to the following ambient temperature: -40°C.
Do not turn on the unit when the ambient
temperature is lower than indicated: -40°C.
The unit is switched on by connecting the power
supply.
To switch o the unit disconnect the power.
5.1 Before powering the product
in an explosive atmosphere
Make sure that all parts are fastened down
rmly and safely.
Make sure that the unit and other
components of the installation are closed
so that it is impossible to come into contact
with live parts.
Make sure that the device has been
connected to an earth link as described.
Ensure the rear cover plate is correctly
closed.
Ensure the product is correctly closed.
Ensure that the sealing of cable entry
systems (if any) has been performed
properly and the time of glue hardening
has been observed.
5.2 First start-up
Make sure that the unit and other
components of the installation are closed
so that it is impossible to come into contact
with live parts.
Make sure that all parts are fastened down
rmly and safely.

EN - English - Instruction manual
8 MNVCMVXHDBCAM_1813_EN
6 Conguration
6.1 Default IP address
The unit is congured to obtain an IP
address from a DHCP server.
The IP address acquired via DHCP is visible in the
DHCP server log le.
If the DHCP server is not available, the unit
automatically congures itself with a self-generated
IP address in the 169.254.x.x/16 subnet. Conguring
the IP address of the PC as belonging to the same
subnet (example: IP address: 169.254.1.1, subnet
mask: 255.255.0.0).
Use an ONVIF compatible VMS or a network snier to
nd the IP address of the device (IP scan utility).
6.2 Web interface
Browsers supported: Microsoft Internet
Explorer, Microsoft Edge, Google Chrome,
Mozilla Firefox.
6.2.1 First access to the web pages
The rst operation in conguring the device consists
in connecting to the web interface.
To access the web interface of the product, simply
use a browser to connect to http:/ ip_address.
7 Accessories
A series of accessories for the device in use
is available. Refer to the HANDBOOK A for
relative descriptions.
8 Instructions for normal
operation
8.1 Enabling the wiper (Wiper)
Do not use the wiper if the outside
temperature is below 0°C or in case of ice.
To activate/deactivate this function, refer to the
manual of the control device used or to the relative
chapter (8.3 Special controls, page8).
8.2 Enabling the washer (Washer)
To activate/deactivate this function, refer to the
manual of the control device used or to the relative
chapter (8.3 Special controls, page8).
8.3 Special controls
SPECIAL CONTROLS
Action Command
Protocol
HTTP API ONVIF (auxiliary
command)
Wiper Start Save Preset 85 tt:Wiper|On
Wiper Stop Save Preset 86 tt:Wiper|O
Washer Save Preset 87 tt:Washing Proced
ure|On
Night Mode On Save Preset 88 tt:IRLamp|On
Night Mode O Save Preset 89 tt:IRLamp|O
Night Mode Auto – tt:IRLamp|Auto
Reboot the device Save Preset 94 –
Tab. 4 For further information please contact the VIDEOTEC
service center.
