Viessmann VITOCELL 100-B Operating instructions

Service instructions
for contractors
VIESMANN
Vitocell 100-B
Type CVE
DHW cylinder
VITOCELL 100-B
5677415 GB 9/2019 Please keep safe.

2
Please follow these safety instruc-
tions closely to prevent accidents
and material losses.
Safety instructions explained
Danger
This symbol warns against the risk
of injury.
!Please note
This symbol warns against the risk
of material losses and environmen-
tal pollution.
Note
Details identified by the word "Note"
contain additional information.
Target group
These instructions are exclusively inten-
ded for qualified contractors.
■Work on electrical equipment may only
be carried out by a qualified electrician.
■The system must be commissioned by
the system installer or a qualified per-
son authorised by the installer.
Regulations to be observed
■National installation regulations
■Statutory regulations for the prevention
of accidents
■Statutory regulations for environmental
protection
■Codes of practice of the relevant trade
associations
■Relevant country-specific safety regu-
lations
Working on the system
■Isolate the system from the power sup-
ply (e.g. by removing the separate fuse
or by means of a mains isolator) and
check that it is no longer live.
■Safeguard the system against recon-
nection.
!Please note
Electronic assemblies can be dam-
aged by electrostatic discharge.
Prior to commencing any work,
touch earthed objects such as heat-
ing or water pipes to discharge
static loads.
Danger
Hot surfaces can cause burns.
■Before maintenance and service
work, switch OFF the appliance
and let it cool down.
■Never touch the hot surfaces of
uninsulated pipes and fittings.
Safety instructions
Safety instructions
5677415

3
Danger
Floors that are wet or damp with
water or glycol based liquids can
cause injury due to slipping and fall-
ing.
■Keep the floor clean and dry dur-
ing installation and maintenance
work.
■Wear non-slip shoes.
Danger
Broken-off fragments of insulation
material can cause death by suffo-
cation if inhaled or swallowed.
■Do not let children play in the
installation room.
■Keep the installation room clean
after installation and maintenance
work.
Repair work
!Please note
Repairing components that fulfil a
safety function can compromise the
safe operation of the system.
Replace faulty components only
with genuine Viessmann spare
parts.
Auxiliary components, spare and wearing parts
!Please note
Spare and wearing parts that have
not been tested together with the
system can compromise its func-
tion. Installing non-authorised com-
ponents and making non-approved
modifications or conversions can
compromise safety and may invalid-
ate our warranty.
For replacements, use only original
spare parts supplied or approved by
Viessmann.
Safety instructions
Safety instructions (cont.)
5677415

4
1. Information Symbols ................................................................................................. 5
Intended use .......................................................................................... 5
Product information ................................................................................ 6
Inspection and maintenance .................................................................. 6
System examples .................................................................................. 6
Spare parts lists ..................................................................................... 6
2. Commissioning, inspec-
tion, maintenance
Steps - commissioning, inspection and maintenance ............................ 7
3. Connection and wiring dia-
gram
Immersion heater EHT ........................................................................... 14
4. Commissioning/service
reports
................................................................................................................ 15
5. Specification ................................................................................................................ 16
6. Disposal Final decommissioning and disposal ..................................................... 17
7. Certificates Declaration of conformity ....................................................................... 18
Index
Index
5677415

5
Symbol Meaning
Reference to other document containing
further information
1.
Step in a diagram:
The numbers correspond to the order in
which the steps are carried out.
Warning of material losses and environ-
mental pollution
Live electrical area
Pay particular attention.
■Component must audibly click into place.
or
■Acoustic signal
■Fit new component.
or
■In conjunction with a tool: Clean the sur-
face.
Dispose of component correctly.
Dispose of component at a suitable collec-
tion point. Do not dispose of component in
domestic waste.
The steps in connection with commissioning, inspec-
tion and maintenance are found in the "Commission-
ing, inspection and maintenance" section and identified
as follows:
Symbol Meaning
Steps required during commissioning
Not required during commissioning
Steps required during inspection
Not required during inspection
Steps required during maintenance
Not required during maintenance
Intended use
The appliance is only intended to be installed and
operated in sealed unvented systems that comply with
EN 12828 / DIN 1988, or solar thermal systems that
comply with EN 12977, with due attention paid to the
associated installation, service and operating instruc-
tions. DHW cylinders are only designed to store and
heat water of potable water quality. Heating water buf-
fer cylinders are only designed to hold fill water of pot-
able water quality. Only operate solar collectors with
the heat transfer medium approved by the manufac-
turer.
Intended use presupposes that a fixed installation in
conjunction with permissible, system-specific compo-
nents has been carried out.
Commercial or industrial usage for a purpose other
than heating the building or DHW shall be deemed
inappropriate.
Any usage beyond this must be approved by the man-
ufacturer for the individual case.
Incorrect usage or operation of the appliance (e.g. the
appliance being opened by the system user) is prohibi-
ted and results in an exclusion of liability.
Incorrect usage also occurs if the components in the
system are modified from their intended use (e.g.
through direct DHW heating in the collector).
Adhere to statutory regulations, especially concerning
the hygiene of potable water.
Information
Symbols
5677415
Information

6
Vertical DHW cylinder made from steel with Cerapro-
tect enamel coating.
With immersion heater EHE for heating with surplus
electricity and with indirect coil for reheating by the
boiler.
Inspection and maintenance
DIN 1988 requires a visual inspection and (if neces-
sary) cleaning no later than 2 years after the cylinder
has been commissioned, and thereafter according to
requirements.
Note
In addition, we recommend an annual visual inspection
of the protective magnesium anode (see page 10).
System examples
Available system examples: See www.viessmann-
schemes.com.
Spare parts lists
Information about spare parts can be found on the
Viessmann spare parts app.
Information
Product information
5677415
Information

7
Commissioning steps
Inspection steps
Maintenance steps Page
•1. Filling the DHW cylinder.................................................................................................... 8
• • 2. Draining the DHW cylinder on the DHW side (if required)............................................. 8
• • 3. Shutting down the system
• • 4. Checking the function of safety valves
• • 5. Checking the anode earth current with an anode tester................................................ 8
•6. Cleaning and descaling the inside of the DHW cylinder................................................ 9
• • 7. Checking and replacing the protective magnesium anode (if required)....................... 10
• • 8. Returning the DHW cylinder to use.................................................................................. 11
• • 9. Checking the connections on the water side for leaks
• • 10. Removing the cap from the immersion heater................................................................ 12
•11. Resetting the high limit safety cut-out............................................................................. 12
•12. Replacing the TR/HLSC combination device................................................................... 12
•13. Replacing the heating element of the immersion heater................................................ 13
Commissioning, inspection, maintenance
Steps - commissioning, inspection and maintenance
5677415

8
1. Fill the DHW cylinder on the DHW side.
Note
When the DHW cylinder is pressurised, tighten the
screws in the flange cover. Max. torque: 25 Nm
2. Check the fittings on the heating water and DHW
side for leaks and tighten if required.
3. Check the function of the safety valves according
to the manufacturer's instructions.
Draining the DHW cylinder on the DHW side (if required)
1. Shut off the cold water supply.
2. Open the DHW draw-off points (to release the
pressure).
3. Drain the DHW cylinder from the drain valve in the
cold water supply.
Shutting down the system
Checking the function of safety valves
Checking the anode earth current with an anode tester
C D
B
A
Fig. 1
1. Remove cover A and flange insulation B.
2. Disconnect earth cable C from tab D.
3. Connect tester in series across earth cable C and
tab D.
■If a current of > 0.3 mA can be measured, the
protective magnesium anode is OK.
■If a current of < 0.3 mA or no current at all can be
measured, inspect the protective magnesium
anode visually (see page 10).
Commissioning, inspection, maintenance
Filling the DHW cylinder
5677415

9
Danger
Unchecked leakage of DHW or heating water
can result in scalding and structural damage.
Only open the DHW and heating water connec-
tions after the DHW cylinder has been depres-
surised.
1. Drain the DHW cylinder on the DHW side.
!Please note
Material losses may result from draining with
a vacuum pump when the air vent valve is
closed.
Open the air vent valve during draining.
7x
1x
Fig. 2
2. Remove cover A, flange insulation B and flange
cover C. Dispose of gasket D.
Commissioning, inspection, maintenance
Cleaning and descaling the inside of the DHW cylinder
5677415

10
Fig. 3
3. Remove cap E, flange cover F and gasket G.
Dispose of gasket G.
4. Disconnect the DHW cylinder from the pipework to
prevent cleaning agents and contaminants from
entering the pipework.
5. Remove loose deposits with a pressure cleaner.
!Please note
Pointed or sharp cleaning tools will damage
the cylinder interior.
Only use plastic cleaning equipment to clean
the inside.
6. Use a chemical cleaning agent to remove hard
deposits that cannot be removed with a pressure
cleaner.
!Please note
Cleaning agents containing hydrochloric acid
will attack the DHW cylinder material.
Never use such cleaning agents.
Danger
Cleaning agent residues can cause poison-
ing.
Always observe the information provided by
the cleaning agent manufacturer.
7. Fully drain all cleaning agent.
8. Flush the DHW cylinder thoroughly after cleaning.
Checking and replacing the protective magnesium anode (if required)
E
Fig. 4
Check protective magnesium anode E.
If the 7 is ≤ 10 − 15 mm, replace the protective mag-
nesium anode.
Commissioning, inspection, maintenance
Cleaning and descaling the inside of the DHW… (cont.)
5677415

11
7x
1x
Fig. 5
1. Reconnect the DHW cylinder to the pipework.
2. Insert new gasket F.
3. Fit flange cover E with earth cable C. Max. tor-
que: 25 Nm
4. Push earth cable C onto tab D.
Fig. 6
5. Insert new gasket K.
6. Fit flange cover H.
Max. torque: 25 Nm
7. Fill the DHW cylinder on the DHW side.
8. Tighten flange covers E and H. Max. torque:
25 Nm
9. Fit flange insulation B, cover A and cap G.
Checking the connections on the water side for leaks
Commissioning, inspection, maintenance
Returning the DHW cylinder to use
5677415

12
A
B
Fig. 7
1. Disconnect the power supply and safeguard
against unauthorised reconnection.
2. Remove cap A, taking care with heating indicator
light B.
3. Remove heating indicator light B from the cap for
safekeeping.
Resetting the high limit safety cut-out
The high limit safety cut-out switches the immersion
heater off at a sensor temperature of 100 °C.
A
B
B
Fig. 8
1. Remove cap A (see page 12).
The resetting feature B is red when locked.
2. Press resetting feature B with a screwdriver.
The resetting feature B turns black when
unlocked.
3. Refit cap A along with the heating indicator light.
4. Switch the power on again.
Note
If the high limit safety cut-out locks several times in a
row, the TR/HLSC (temperature controller/high limit
safety cut-out) combination device must be replaced.
Replacing the TR/HLSC combination device
A
C
BB
D
Fig. 9
1. Remove cap A (see page 12).
2. Disconnect cables B from TR/HLSC combination
device C.
3. Remove 2 screws D from the retainer.
4. Fit new TR/HLSC combination device C.
Commissioning, inspection, maintenance
Removing the cap from the immersion heater
5677415

13
5. Reconnect cables B.
Note
Ensure the cores are correctly allocated (see
page 14).
6. Refit cap A along with the heating indicator light.
7. Switch the power on again.
Replacing the heating element of the immersion heater
A
CD E
B
Fig. 10
1. Remove cap A (see page 12).
2. Disconnect the heating element cables B from the
TR/HLSC combination device.
3. Remove retaining clip C.
4. Pull out heating element D.
5. Fit new heating element D.
Note
When inserting the new heating element, ensure
recesses E are correctly positioned at the head of
the heating element. There should be one recess
on the right, one on the left and one at the top.
6. Reattach retaining clip C.
7. Reconnect cables B.
8. Fit cap A with the heating indicator light.
Commissioning, inspection, maintenance
Replacing the TR/HLSC combination device (cont.)
5677415

14
L1
N
PE
B
A
1
2
BN
BU
GNYE
BN
BU
BK
BK
A
BC
D
E
GNYE
Fig. 11
APower supply 230 V/50 Hz
BPlug
CTR/HLSC combination device
DHeating indicator light
EHeating element (resistor)
Colour coding to IEC 60757
BK Black
BN Brown
BU Blue
GNYE Green/yellow
Connection and wiring diagram
Immersion heater EHT
5677415
Appendix

15
Commissioning Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Commissioning/service reports
Commissioning/service reports
5677415
Appendix

16
Cylinder capacity l 300
DIN registration no. Applied for
Standby heat loss
To EN 12897:2016
kWh/24 h 1.79
Dimensions
Length (7) mm 627
Total width mm 712.5
Height mm 1704
Height when tilted mm 1750
Weight kg 178
Heating water content (indirect coil) l 6
Connections
Indirect coil (male thread) G 1
Cold water, DHW (male thread) R 1
DHW circulation (male thread) R 1
Steatite immersion heater (7) mm 49
Immersion heater EHT
Cylinder capacity l 300
Pr (rated output) kW 2.7
Rated voltage 1/N/PE 230 V/50 Hz
Rated current A 11.7
IP rating IP 21
Immersion heater: Factory-set temperature °C 80±3 K
High limit safety cut-out °C 95±5 K
Specification
Specification
5677415
Appendix

17
Viessmann products can be recycled. Components
and substances from the system are not part of ordi-
nary household waste.
For decommissioning the system, isolate the system
from the power supply and allow components to cool
down where appropriate.
All components must be disposed of correctly.
Disposal
Final decommissioning and disposal
5677415
Appendix

18
We, Viessmann Werke GmbH & Co. KG, D-35107
Allendorf, declare as sole responsible body that the
named product complies with the European directives
and supplementary national requirements in terms of
its design and operational characteristics.
Using the serial number, the full Declaration of Con-
formity can be found on the following website:
www.viessmann.co.uk/eu-conformity
Certificates
Declaration of conformity
5677415
Appendix

19
5677415
Appendix

20
Viessmann Limited
Hortonwood 30, Telford
Shropshire, TF1 7YP, GB
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Viessmann Werke GmbH & Co. KG
D-35107 Allendorf
Telephone: [phone]
Fax: [phone]
www.viessmann.com
5677415 Subject to technical modifications.
