Gas-fired wall-mounted condensing boiler
104 to 530 MBH (30 to 155 kW)
Multi-boiler installation 104 to 4240 MBH
For Natural Gas and Liquid Propane Gas
Product may not be exactly as shown
Vitodens 200-W
Series B2HA Series, Models 100, 112 and 150
Gas-Fired Wall-Mounted Condensing Boiler
with modulating MatriX cylinder burner
for room air independent operation
(using a direct vent system or room air
dependent operation).
H

5683 718 - 02
2
Vitodens 200-W B2HA 100 to 150 Technical Data
Product Information
Vitodens 200-W
2
The benefits at a glance:
■Best value in its class with new industry-leading
technology and the most standard features.
■Highest Efficiency - CSA thermal efficiency rating to
ANSI Z.21.13/CSA 4.9 of 94.5%. Energy Star and the
CSA Energy Performance are not applicable for these
models.
■Lasting performance with industry-leading Viessmann
made SA240 316 Ti stainless steel Inox-Radial heat
exchanger constructed to CSA B51 and ASME Section IV.
■Low Emission Combustion with Viessmann made
stainless steel MatriX cylinder burner. Factory calibrated.
■Fast Installation and Reduced Maintenance with Lambda
Pro, industry-first intelligent combustion management
system: Adjusts automatically to gas type and quality.
No fuel conversion kit required.
■Powerful and User-friendly
Viessmann Vitotronic on-board multi-function outdoor
reset boiler and system control for multi-temperature
space and DHW heating.
Equipped with the industry’s first intelligent combustion
management system and powerful control technology,
the new generation Vitodens 200-W gas-fired wall-mount
condensing boiler delivers unparalleled performance,
reliability and comfort.
■Expanded Application Range with increased capacity up
to 530 MBH (155 kW). Multi-boiler installation up to
4240 MBH (1240 kW) with up to 8 boilers (models B2HA
100, 112 and 150).
■Greater Venting Flexibility with increased vent length [up
to 180 ft. (55 m)] and multiple venting options.
- Horizontal or vertical sealed combustion coaxial
venting (field supplied).
- Horizontal, vertical or hybrid sealed combustion
double-pipe venting (field supplied).
- Horizontal or vertical single-wall venting (field
supplied).
■Compact, Esthetic Product Design and zero clearance
to combustibles.
■Extremely Quiet Operation; quieter than most
refrigerators.
■True High-Altitude Operation up to 10,000 ft. (3,000 m)
with simple electronic adjustment.
■Efficiency up to 98% through intensive condensation.
■The gas train on the burner meets the requirement
of ASME/CSD-1.

3
5683 718 - 02
Vitodens 200-W B2HA 100 to 150 Technical Data Product Information
3
Cross-Section
Products may not be exactly as shown
AInox-Radial heat exchanger made from stainless steel
– for high operational reliability and a long service life.
Large heating output in the smallest of spaces
B Modulating MatriX cylinder burner for extremely
clean combustion and quiet operation
CVariable speed combustion fan for quiet and
economical operation
DGas and water connections
EDigital boiler control unit
Delivered condition
Wall mounted gas condensing boiler with Inox-Radial heat
exchanger, modulating MatriX cylinder burner for natural
gas and LPG, plus wall mounting bracket. Vitotronic 200
for weather-compensated operation. Preset for operation
with natural gas. Fully plumbed and wired. White epoxy-
coated casing.
Vitodens 200-W B2HA 100 112, 150
The flue gas temperature is only approximately 9-27º F
(5-15º C) above boiler return temperature (see chart
below).

5683 718 - 02
4
Vitodens 200-W B2HA 100 to 150 Technical Data
Technical Data
Technical Data
4
*A For high altitude installations 5,000 - 10,000 ft. (1500 m - 3000 m), the input for model B2HA 100 and 150 will
have an altitude de-ration of 14% for 5,000 ft. (1500 m) and 29% for 10,000 ft. (3000 m) average of 2.8% /
1,000 ft. (305 m). The input for model B2HA 112 at 10,000 ft. (3000 m) will have an input de-rate of 13%.
*B Net AHRI rating based on piping and pick-up allowance of 1.15.
*1 If the gas supply pressure exceeds the maximum gas supply pressure value, a separate gas pressure regulator
must be installed upstream of the heating system.
*2 See “Waterside Flow” starting on page 10 of this manual.
*3 Output based on 180º F (82º C), 80º F (26º C) system supply/return temperature.
Boiler Model No. B2HA 100*A 112 150*A
Natural Gas / Liquid Propane Gas
CSA input
CSA output *3
MBH
kW
MBH
kW
104-352
30-103
98-333
29-98
113-399
33-117
103-375
30-110
113-530
33-155
103-495
30-145
DOE/AHRI Gross output
Net AHRI Rating *B
MBH
kW
MBH
kW
329
96
286
84
371
109
323
95
490
144
426
125
Heat exchanger surface area ft.2
m2
28.88
2.68
36.78
3.41
36.78
3.41
Min. gas supply pressure
Natural gas
Liquid propane gas
“w.c.
“w.c.
4
10
4
10
4
10
Max. gas supply pressure *1
Natural gas
Liquid propane gas
“w.c.
“w.c.
14
14
14
14
14
14
CSA thermal/combustion efficiency
ANSI Z21,13/CSA 4.9 % 94.5 93.9 93.5
Weight lbs
kg
194
88
298
135
298
135
Boiler water conntent USG
L
3.4
12.8
4
15
4
15
Boiler max. flow rate *2 GPM
L/h
25
5700
37.9
8600
38
8600
Max. operating pressure
at 210º F (99º C)
psig
bar
60
4
80
5.5
80
5.5
Boiler water temperature
- Adjustable high limit (AHL) range
space heating (steady state)
DHW production
- Fixed high limit (FHL)
ºF
ºC
ºF
ºC
ºF (ºC)
68 to 176
20 to 80
176
80
210 (99)
68 to 180
20 to 82
180
82
210 (99)
68 to 180
20 to 82
180
82
210 (99)
Boiler connections
Boiler heating supply and return
Pressure relief valve
Drain valve
Boiler supply/return for
indirect-fired DHW storage tank
(field supplied)
Gas valve connection
NPTM”
NPTF”
(male
thread)
NPT”
NPTF”
1b
¾
¾
1b
1
2
¾
¾
2
1
2
¾
¾
2
1

5
5683 718 - 02
Vitodens 200-W B2HA 100 to 150 Technical Data Technical Data
5
Technical Data (continued)
*A For high altitude installations 5,000 - 10,000 ft. (1500 m - 3000 m), the input for model B2HA 100 and 150 will
have an altitude de-ration of 14% for 5,000 ft. (1500 m) and 29% for 10,000 ft. (3000 m) average of 2.8% /
1,000 ft. (305 m). The input for model B2HA 112 at 10,000 ft. (3000 m) will have an input de-rate of 13%.
*4 Measured flue gas temperature with a combustion air temperature of 68° F (20° C).
*5 Based on maximum input rate.
*6 Requires 1 inch (25 mm) tubing. See the Installation Instructions of the Vitodens 200-W, B2HA for details.
*7 For side wall vent installations (coaxial system):
Do not exceed max. equivalent length specified in the Installation Instructions of the Vitodens 200-W, B2HA
Venting System.
Do not attempt to common-vent Vitodens 200-W with any other appliance.
Side wall co-axial vent installation must include Viessmann protective screen!
For details refer to the Installation Instructions for the Vitodens 200-W, B2HA Venting System.
*8 Add approximately 2b inches (65 mm) for coaxial vent pipe transition adaptor.
For information regarding other Viessmann System Technology componentry, please reference the documentation
of each respective product.
Boiler Model No. B2HA 100*A 112 150*A
Dimensions
Overall depth
Overall width
Overall height
inches
mm
inches
mm
inches
mm
21
530
19
480
43b
*8 1105
27.1
698
235/8
600
44b
*8 1128
27.1
698
235/8
600
44b
*8 1128
Flue gas *4
Temperature (at boiler return
temperature of 86º F (30º C)
- at rated full load
- at rated partial load
Temperature (at boiler return
temperature of 140º F (60º C)
ºF (ºC)
ºF (ºC)
ºF (ºC)
135 (57)
99 (37)
162 (72)
124 (51)
102 (39)
158 (70)
140 (60)
102 (39)
165 (74)
Max. condensate flow rate *5
for NG and LPG
TS/TR=104/86º F (40/30º C) USG/h
L/h
3.5
13.1
4.35
16.5
5.28
20.0
Condensate connection *6 hose
nozzle
Ø in. ¾-1¾-1¾-1
Boiler flue gas connection *7 Ø
in. (mm) 43/8(110) 43/8(110) 43/8(110)
Combustion air supply
connection (coaxial)
outer
Ø in. (mm) 6 (150) 6 (150) 6 (150)
Sound Rating
- at maximum input
- at minimum input
dB
dB
69
38
57
40
61
40

5683 718 - 02
6
Vitodens 200-W B2HA 100 to 150 Technical Data
Dimensional Information
Model B2HA 100
Legend
ABoiler Supply
BGas Connection, 1” NPTF
C Boiler Return
D Recommended height (single boiler system)
E Condensate drain

7
5683 718 - 02
Vitodens 200-W B2HA 100 to 150 Technical Data Dimensional Information
Models B2HA 112, 150
Legend
ABoiler Supply
BGas Connection, 1” NPTF
C Boiler Return
D Recommended height (single boiler system)
E Condensate drain

5683 718 - 02
8
Vitodens 200-W B2HA 100 to 150 Technical Data
Minimum Clearances
Recommended Minimum Service Clearances
Minimum Clearances to Combustibles
AL= Alcove
CL= Closet
*1Refer to the Installation Instructions of the Vitodens
200-W, B2HA Venting System for details.
Note: The Vitodens boiler has passed the zero inches vent
clearance to combustibles testing requirements
dictated by the Harmonized Standard ANSI Z21.13.
CSA 4.9.2000 and therefore is listed for zero
clearance to combustibles when vented with a
single wall special venting system (AL-29-4C
material). The zero inches vent clearance to
combustibles for the Vitodens boiler supercedes
the clearance to combustibles listing that appears
on the special venting system label.
Top Front Rear Left Right Vent
pipe *1
0 0 AL, CL 0000

9
5683 718 - 02
Vitodens 200-W B2HA 100 to 150 Technical Data Waterside Flow
Waterside Flow (primary circuit)
Supply head pressure (water)
Flow rate
The Vitodens 200-W, B2HA is designed for closed loop,
forced circulation hot water heating systems only. Use
standard friction loss method for pipe sizing. Observe
boiler maximum and minimum flow rate limitations. If
system flow rate exceeds boiler maximum flow rate
(as stated above), falls below the minimum flow rate
or if system flow rate is unknown, Viessmann strongly
recommends the installation of a low-loss header.
An alternative method may be used, such as primary
secondary piping using closely spaced tees.
A low-loss header offers additional benefits not provided
by a pair of closely spaced tees. Viessmann therefore
strongly recommends and prefers the use of a low-loss
header over closely spaced tees. See pages 28 and 29
for low-loss header information. Once the low-loss header
is connected, the built-in low-loss header logic of the
Vitodens 200-W boiler ensures the required t across the
system through the sensory communication between the
low-loss header and the boiler.
Pressure drop (primary circuit) for
Vitodens 200-W, B2HA 100
For sizing an on-site circulation system.
Max. flow rate: 25 USGPM (5700 L/h)
Pressure drop (primary circuit) for
Vitodens 200-W, B2HA 112, 150
For sizing an on-site circulation system.
Max. flow rate: 38 USGPM (8600 L/h)
Supply head pressure (water)
Flow rate

5683 718 - 02
10
Vitodens 200-W B2HA 100 to 150 Technical Data
System Flow Rates
Boiler B2HA 112 maximum flow rate; 38 GPM (8600 L/h)
Boiler B2HA 100 maximum flow rate; 25 GPM (5700 L/h)
Typical System Flow Rates
Boiler B2HA 150 maximum. flow rate; 38 GPM (8600 L/h)
Model B2HA 112 1 boiler 2 boilers 3 boilers 4 boilers 5 boilers 6 boilers 7 boilers 8 boilers
Output (NG/LPG)
MBH 375 750 1125 1500 1875 2250 2625 3000
t for NG/LPG
20º F rise GPM
(L/h)
37.5
(8500)
75
(17000)
112.5
(25600)
150
(34100)
187.5
(42600)
225
(51100)
262.5
(59600)
300
(68100)
25º F rise GPM
(L/h)
30
(6800)
60
(13600)
90
(20400)
120
(27300)
150
(34100)
180
(40900)
210
(44700)
240
(54500)
30º F rise GPM
(L/h)
25
(5700)
50
(11400)
75
(17000)
100
(22700)
125
(28400)
150
(34100)
175
(39700)
200
(45400)
35º F rise GPM
(L/h)
21.4
(4900)
42.9
(9700)
64.3
(14600)
85.7
(19500)
107.1
(24300)
128.6
(29200)
150
(34100)
171.4
(38900)
40º F rise GPM
(L/h)
18.8
(4300)
37.5
(8500)
56.3
(12800)
75
(17000)
93.8
(21300)
112.5
(25600)
131.3
(29800)
150
(34100)
Model B2HA 150 1 boiler 2 boilers 3 boilers 4 boilers 5 boilers 6 boilers 7 boilers 8 boilers
Output (NG/LPG)
MBH 495 990 1485 1980 2475 2970 3465 3960
t for NG/LPG
20º F rise GPM
(L/h)
49.5
(11243)
99
(22487)
149
(33731)
198
(44974)
247.5
(56213)
297
(67461)
346.5
(78705)
396
(89949)
25º F rise GPM
(L/h)
39.6
(8994)
79
(17990)
119
(26985)
158
(35979)
198
(44971)
237.6
(53969)
277
(62964)
317
(71959)
30º F rise GPM
(L/h)
33
(7495)
66
(14991)
99
(22487)
132
(29983)
165
(37476)
198
(44974)
231
(52470)
264
(59966)
35º F rise GPM
(L/h)
28
(6424)
57
(12850)
85
(19275)
113
(25700)
141.4
(32122)
170
(38549)
198
(44974)
226
(51399)
40º F rise GPM
(L/h)
25
(5631)
50
(11244)
74
(16865)
99
(22487)
124
(28107)
148.5
(33731)
173
(39352)
198
(44974)
Model B2HA 100 1 boiler 2 boilers 3 boilers 4 boilers 5 boilers 6 boilers 7 boilers 8 boilers
Output (NG/LPG)
MBH 333 666 999 1332 1665 1998 2331 2664
t for NG/LPG
20º F rise GPM
(L/h)
33.3
(7563)
66.6
(15128)
100
(22692)
133
(30255)
166.5
(37816)
200
(45383)
233
(52947)
266.4
(60510)
25º F rise GPM
(L/h)
26.6
(6051)
53.3
(12102)
80
(18153)
106.6
(24204)
133
(30253)
160
(36307)
187
(42377)
213
(48409)
30º F rise GPM
(L/h)
22.2
(5042)
44.4
(10085)
66.6
(15128)
89
(20170)
111
(25211)
133
(30255)
155.4
(35298)
178
(40341)
35º F rise GPM
(L/h)
19
(4322)
38.1
(8644)
57
(12967)
76
(17289)
95
(21609)
114
(25933)
133
(30255)
152
(34578)
40º F rise GPM
(L/h)
16.7
(3781.6)
33.3
(7564)
50
(11346)
66.6
(15128)
83
(18908)
100
(22692)
117
(26473)
133
(30255)

11
5683 718 - 02
Pump Information
Heating Circuit / Boiler Pumps
Viessmann offers a variety of Grundfos heating circuit
/ boiler pumps which meet typical Vitodens system
installation requirements (see “Heating circuit pump
(field supplied)” or “Boiler pump (field supplied)” in the
Installation Examples starting on page 31). See tables
below for recommended pumps. Refer to the graphs
on page 9 for the proper waterside boiler friction loss
calculations. The following pumps have been selected
based on boiler heat exchanger head loss and boiler
piping to a low-loss header.
IMPORTANT
Model B2HA 112 Flow rate Boiler pressure drop (ft.) Recommended pump option 1 Grundfos
20º F t37.5 15.0 UPS 32-160/2, 115V, Speed 1 /
UPS 26-150F, 115V, Speed 2
25º F t30.0 11.3 UPS 32-160/2, 115V, Speed 1 /
UPS 26-150F, 115V, Speed 2
30º F t25.0 8.8 UPS 32-160/2, 115V, Speed 1 /
UPS 26-150F, 115V, Speed 2
35º F t21.4 6.5 UPS 32-160/2, 115V, Speed 1 /
UPS 26-99FC, 115V, Speed 3
40º F t19.5 4.8 UPS 26-99FC, 115V, Speed 2 /
UPS 26-150F, 115V, Speed 1
Flow limitation GPM (L/h) 8600 (37.9)
Model B2HA 150 Flow rate Boiler pressure drop (ft.) Recommended pump option 1 Grundfos
20º F t-- -- --
25º F t-- -- --
30º F t33.0 12.6 UPS 32-160/2, 115V, Speed 1 /
UPS 26-150F, 115V, Speed 3
35º F t28.3 9.4 UPS 32-160/2, 115V, Speed 1 /
UPS 26-150F, 115V, Speed 2
40º F t24.8 8.0 UPS 26-99FC, 115V, Speed 3 /
UPS 32-160/2, 115V, Speed 1 /
Flow limitation GPM (L/h) 8600 (37.9)
Model B2HA 100 Flow rate Boiler pressure drop (ft.) Recommended pump option 1 Grundfos
20º F t-- -- --
25º F t-- -- --
30º F t22.2 12.0 UPS 32-160/2, 115V, Speed 1 /
UPS 26-99FC, 115V, Speed 3
35º F t19.0 8.5 UPS 26-99FC, 115V, Speed 3
40º F t16.7 6.0 UPS 26-99FC, 115V, Speed 2
Flow limitation GPM (L/h) 5700 (25)
Before using the following pumps for a DHW tank
application, find out the proper pressure drop through the
tank, the required temperature difference through the coil
and system piping head loss of the domestic hot water.
Pump selection must be based on accurate system flow
and pressure drop calculations (incl. DHW sizing).
Vitodens 200-W B2HA 100 to 150 Technical Data

5683 718 - 02
12
Vitodens 200-W B2HA 100 to 150 Technical Data
Low-Loss Header Application
Low-Loss Header Information
Note: for multiple boiler applications when using the Vitodens 200-W, B2HA boilers, refer to the multiple boiler
low-loss distribution manifold installation instructions.
*1 For system t< 20° F use low-loss header sizes for t20° F.
*2 Low-Loss sensor - standard equipment of the cascade control Vitotronic 300-K MW2B:
for use in multiple boiler applications.
Boiler
Model
No. of
Boilers
Boiler
Max.
Flow
Rate
Total
Flow
Rate
Typical System Flow Rates Viessmann
Low-loss
Temp.
Sensor
Required*2
t *1 °F
(°C)
20
(11)
25
(14)
30
(17)
35
(19.5)
40
(22)
B2HA
100
225
(5700)
50
(11400)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
66.6
(15128)
Yes
200/120
53.3
(12102)
Yes
200/120
44.4
(10085)
Yes
160/80
38.1
(8644)
Yes
160/80
33.3
(7564)
Yes
120/80
Yes
B2HA
100
325
(5700)
75
(17100)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
100
(22692)
Yes
250/150
80
(18153)
Yes
200/120
66.6
(15128)
Yes
200/120
57
(12967)
Yes
200/120
50
(11346)
Yes
200/120
Yes
B2HA
100
425
(5700)
100
(22800)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
133
(30255)
Yes
300/200
106.6
(54204)
Yes
250/150
89
(20170)
Yes
250/150
76
(17289)
Yes
200/120
66.6
(15128)
Yes
200/120
Yes
B2HA
100
525
(5700)
125
(28500)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
166.5
(37816)
Yes
300/200
133
(30253)
Yes
300/200
111
(25211)
Yes
250/150
95
(21609)
Yes
250/150
83
(18908)
Yes
250/150
Yes
B2HA
100
625
(5700)
150
(34200)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
200
(45383)
Yes
400/200
160
(36307)
Yes
300/200
133
(30255)
Yes
300/200
114
(25933)
Yes
250/150
100
(22692)
Yes
250/150
Yes
B2HA
100
725
(5700)
175
(39900)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
233
(52947)
Yes
400/200
187
(42377)
Yes
300/200
155.4
(35298)
Yes
300/200
133
(30255)
Yes
300/200
117
(26473)
Yes
250/150
Yes
B2HA
100
825
(5700)
200
(45600)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
266.4
(60510)
Yes
450/250
213
(48409)
Yes
400/200
178
(40341)
Yes
300/200
152
(34578)
Yes
300/200
133
(30255)
Yes
300/200
Yes
Sizing of Low-Loss Header in a Commercial Multiple-Boiler Application
Boiler
Model
No. of
Boilers
Boiler
Max.
Flow
Rate
Total
Flow
Rate
Typical System Flow Rates Viessmann
Low-loss
Temp.
Sensor
Required*2
t *1 °F
(°C)
20
(11)
25
(14)
30
(17)
35
(19.5)
40
(22)
B2HA
100
125
(5700)
25
(5700)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
33.3
(7563)
Yes
120/80
26.6
(6051)
Yes
120/80
22.2
(5042)
Optional
120/80
19
(4322)
Optional
80/60
16.7
(3781.6)
Optional
80/60
Optional
Sizing of Low-Loss Header in a Residential/Commercial Single-Boiler Application
*1For system t < 20° F use low-loss header sizes for t 20° F.
*2Low-Loss temperature sensor - optional equipment for use in single-boiler applications.

Vitodens 200-W B2HA 100 to 150 Technical Data
13
5683 718 - 02
Low-Loss Header Information
Low-Loss Header Application (continued)
Boiler
Model
No. of
Boilers
Boiler
Max.
Flow
Rate
Total
Flow
Rate
Typical System Flow Rates Viessmann
Low-loss
Temp.
Sensor
Required*2
t *1 °F
(°C)
20
(11)
25
(14)
30
(17)
35
(19.5)
40
(22)
B2HA
112
238
(8600)
76
(17200)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
75
(17034)
Yes
200/120
60
(13627)
Yes
200/120
50
(11356)
Yes
200/120
43
(9734)
Yes
200/120
38
(8517)
Yes
160/80
Yes
B2HA
112
338
(8600)
114
(25800)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
113
(25552)
Yes
250/150
90
(20441)
Yes
250/150
75
(17034)
Yes
250/150
64
(14601)
Yes
250/150
56
(12776)
Yes
200/120
Yes
B2HA
112
438
(8600)
152
(34400)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
150
(34069)
Yes
300/200
120
(27255)
Yes
300/200
100
(22712)
Yes
250/150
86
(19468)
Yes
250/150
75
(17034)
Yes
200/120
Yes
B2HA
112
538
(8600)
190
(43000)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
188
(42586)
Yes
300/200
150
(34069)
Yes
300/200
125
(28391)
Yes
300/200
107
(24335)
Yes
250/150
94
(21293)
Yes
250/150
Yes
B2HA
112
638
(8600)
228
(51600)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
225
(51103)
Yes
400/200
180
(40882)
Yes
400/200
150
(34069)
Yes
300/200
129
(29202)
Yes
300/200
113
(25552)
Yes
300/200
Yes
B2HA
112
738
(8600)
266
(60200)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
263
(59620)
Yes
450/250
210
(47696)
Yes
400/200
175
(39747)
Yes
300/200
150
(34069)
Yes
300/200
131
(29810)
Yes
300/200
Yes
B2HA
112
838
(8600)
304
(68800)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
300
(68137)
Yes
450/250
240
(54510)
Yes
400/200
200
(45425)
Yes
400/200
171
(38936)
Yes
300/200
150
(34069)
Yes
300/200
Yes
Note: for multiple boiler applications when using the Vitodens 200-W, B2HA boilers, refer to the multiple boiler
low-loss distribution manifold installation instructions.
*1 For system t< 20° F use low-loss header sizes for t20° F.
*2 Low-Loss sensor - standard equipment of the cascade control Vitotronic 300-K MW2B:
for use in multiple boiler applications.
Sizing of Low-Loss Header in a Commercial Multiple-Boiler Application
Boiler
Model
No. of
Boilers
Boiler
Max.
Flow
Rate
Total
Flow
Rate
Typical System Flow Rates Viessmann
Low-loss
Temp.
Sensor
Required*2
t *1 °F
(°C)
20
(11)
25
(14)
30
(17)
35
(19.5)
40
(22)
B2HA
112
138
(8600)
38
(8600)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
37.5
(8517)
Yes
160/80
30
(6814)
Optional
120/80
25
(5678)
Optional
120/80
21.4
(4867)
Optional
120/80
19.5
(4429)
Optional
80/60
Optional
Sizing of Low-Loss Header in a Residential/Commercial Single-Boiler Application
*1For system t < 20° F use low-loss header sizes for t 20° F.
*2Low-Loss temperature sensor - optional equipment for use in single-boiler applications.

Vitodens 200-W B2HA 100 to 150 Technical Data
5683 718 - 02
14
Low-Loss Header Application (continued)
Low-Loss Header Information
Boiler
Model
No. of
Boilers
Boiler
Max.
Flow
Rate
Total
Flow
Rate
Typical System Flow Rates Viessmann
Low-loss
Temp.
Sensor
Required*2
t *1 °F
(°C)
20
(11)
25
(14)
30
(17)
35
(19.5)
40
(22)
B2HA
150
238
(8600)
76
(17200)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
99
(22487)
Yes
250/150
79
(17990)
Yes
200/120
66
(14991)
Yes
200/120
57
(12850)
Yes
200/120
50
(11244)
Yes
200/120
Yes
B2HA
150
338
(8600)
114
(25800)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
149
(33731)
Yes
300/200
119
(26985)
Yes
300/200
99
(22487)
Yes
250/150
85
(19275)
Yes
250/150
74
(16865)
Yes
200/120
Yes
B2HA
150
438
(8600)
152
(34400)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
198
(44974)
Yes
400/200
158
(35979)
Yes
300/200
132
(29983)
Yes
300/200
113
(25700)
Yes
250/150
99
(22487)
Yes
250/150
Yes
B2HA
150
538
(8600)
190
(43000)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
247.5
(56213)
Yes
400/200
198
(44971)
Yes
400/200
165
(37476)
Yes
300/200
141.4
(32122)
Yes
300/200
124
(28107)
Yes
300/200
Yes
B2HA
150
638
(8600)
228
(51600)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
297
(67461)
Yes
450/250
237.6
(53969)
Yes
400/200
198
(44974)
Yes
400/200
170
(38549)
Yes
300/200
148.5
(33731)
Yes
300/200
Yes
B2HA
150
738
(8600)
266
(60200)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
346.5
(78705)
Yes
450/250
277
(62964)
Yes
450/250
231
(52470)
Yes
400/200
198
(44974)
Yes
400/200
173
(39352)
Yes
300/200
Yes
B2HA
150
838
(8600)
304
(68800)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
396
(89949)
Yes
500/300
317
(71959)
Yes
450/250
264
(59966)
Yes
450/250
226
(51399)
Yes
400/200
198
(44974)
Yes
400/200
Yes
Note: for multiple boiler applications when using the Vitodens 200-W, B2HA boilers, refer to the multiple boiler
low-loss distribution manifold installation instructions.
*1 For system t< 20° F use low-loss header sizes for t20° F.
*2 Low-Loss sensor - standard equipment of the cascade control Vitotronic 300-K MW2B:
for use in multiple boiler applications.
Sizing of Low-Loss Header in a Commercial Multiple-Boiler Application
Boiler
Model
No. of
Boilers
Boiler
Max.
Flow
Rate
Total
Flow
Rate
Typical System Flow Rates Viessmann
Low-loss
Temp.
Sensor
Required*2
t *1 °F
(°C)
20
(11)
25
(14)
30
(17)
35
(19.5)
40
(22)
B2HA
150
138
(8600)
38
(8600)
System Flow
Rate
LLH Required
LLH Model
GPM
(L/h)
49.5
(11243)
Yes
200/120
39.6
(8994)
Optional
160/80
33
(7495)
Optional
120/80
28
(6424)
Optional
120/80
25
(5631)
Optional
120/80
Optional
Sizing of Low-Loss Header in a Residential/Commercial Single-Boiler Application
*1For system t < 20° F use low-loss header sizes for t 20° F.
*2Low-Loss temperature sensor - optional equipment for use in single-boiler applications.

15
5683 718 - 02
DHW Production
Domestic Hot Water Production
Vitodens 200-W boilers can be used in conjunction
with the stand-alone DHW storage tanks offered by
Viessmann. All Viessmann DHW storage tanks sold in
North America are available in “Vitosilver” finish only.
Size and select the DHW storage tank based on the
forecasted DHW consumption of the building in question.
For further technical information on DHW storage tanks,
see the Vitocell-V Technical Data Manuals.
Legend
DR Boiler heating return for domestic hot water
production
DS Boiler heating supply for domestic hot water
production
HR Heating Return
HS Heating Supply
BD Boiler Drain
BR Boiler Return
BS Boiler Supply
GC Gas Connection
PRV Pressure Relief Valve
BF Boiler Fill
PG Pressure Gage (not shown)
*1 See page 41 for alternate DHW connection.
*2Discard when using the multi-boiler distribution
manifold
An adequately sized pre-charged expansion tank must be
used. See Installation Examples for details.
IMPORTANT
*1DHW
Connections
(Field Supplied)
For the connection of a stand-alone DHW tank,
installation fittings (field supplied), an external circulating
pump for DHW production (field supplied) and a DHW
temperature sensor (optional equipment, see Viessmann
Price List for order information) are required.
Connections for model B2HA 100
Connections for models B2HA 112 and 150
Vitodens 200-W B2HA 100 to 150 Technical Data
*1DHW
Connections
(Field Supplied)

5683 718 - 02
16
DHW Recirculation/ Boiler Mounting
Domestic Hot Water Recirculation
DHW recirculation lines increase the level of comfort and
convenience of the domestic hot water supply and reduce
water consumption.
These advantages directly derive from the immediate
availability of domestic hot water at all draw points.
Poor insulation of the DHW recirculation line, however,
can result in considerable heat loss. Viessmann therefore
recommends that effective insulation be provided and
used for DHW recirculation lines of 23 ft. (7 m) in length
or longer.
Vitocell-V stand-alone DHW storage tank
Legend
DCW Domestic Cold Water
DHW Domestic Hot Water
TPV Temperature and Pressure Relief Valve
(on tank - not shown)
R DHW Recirculation Line
RP DHW Recirculation Pump
Vitodens 200-W B2HA 100 to 150 Technical Data

17
5683 718 - 02
Boiler Mounting
Model B2HA 100 Wall Mount
1. Remove the external accessories connection box
cover.
2. Loosen the screws at the bottom of the boiler
(do not remove completely).
3. Remove the front encloser panel (lift up and pull
away from the boiler).
4. Mount boiler onto the mounting bracket.
5. Adjust the levelling screws to ensure the boiler
is level. Place the round bubble level on top of the
boiler to verify.
6. Connect the boiler to the installation fittings.
Vitodens 200-W B2HA 100 to 150 Technical Data
CAUTION
Whichever mounting method is used, ensure that the
bracket is tightly and securely fastened to wall. Failure
to secure boiler properly could cause boiler to loosen,
posing a severe safety hazard.
Fitting the wall mounting bracket
See the installation instructions applicable to the
mounting bracket on each type of material.
CAUTION
The boiler must be level both vertically and horizontally
to ensure proper draining of the condensate.

Vitodens 200-W B2HA 100 to 150 Technical Data
5683 718 - 02
18
Boiler Stand for B2HA 112 and 150
The boiler stand is used for free-standing installation of a
single boiler within the mechanical room.
When using the boiler stand, ensure that the stand is
securely fastened to the floor (recommended concrete
expansion anchors are Hilti model KB-TZ ex 4 or
equivalent.
The boiler stand is used for free-standing installation of a
single boiler within the mechanical room.
When using the boiler stand, ensure that the stand is
securely fastened to the floor (recommended concrete
expansion anchors are Hilti model KB-TZ ex 4 or
equivalent.
Boiler Stand for B2HA 100
Boiler Mounting

Vitodens 200-W B2HA 100 to 150 Technical Data
19
5683 718 - 02
Boiler Mounting
Model B2HA 100 Stand Mount
The Vitodens 200-W, model B2HA does not come with a mounting template. The wall location for the frame, mounting
bracket and all vents must be field calculated.
Boiler mounting bracket and frame
1. Attach the wall mounting bracket (supplied with the
boiler) to the boiler mounting frame using the supplied
hardware. Ensure that the wall mounting bracket is
level.
2. Move the rack into position and secure to the floor
(and to the wall if needed).
1. Remove the external accessories connection box
cover.
2. Loosen the screws at the bottom of the boiler
(do not remove completely).
3. Remove the front encloser panel (lift up and pull
away from the boiler).
4. Mount boiler onto the mounting bracket and ensure
the boiler is securely mounted. Then install the
holding bracket to the frame on top of the boiler.
5. Adjust the levelling screws to ensure the boiler
is level.
6. Connect the boiler to the installation fittings.
CAUTION
The boiler must be level both vertically and horizontally
to ensure proper draining of the condensate.

5683 718 - 02
20
Boiler Mounting
Models B2HA 112, 150
The Vitodens 200-W, model B2HA does not come with a mounting template. The wall location for the frame, mounting
bracket and all vents must be field calculated.
Boiler mounting bracket and frame
1. Attach the wall mounting bracket (supplied with the
boiler) to the boiler mounting frame using the supplied
hardware. Ensure that the wall mounting bracket is
level.
2. Move the rack into position and secure to the floor
(and to the wall if needed).
1. Remove the external accessories connection box
cover.
2. Loosen the screws at the bottom of the boiler
(do not remove completely).
3. Remove the front encloser panel (lift up and pull
away from the boiler).
4. Mount boiler onto the mounting bracket and ensure
the boiler is securely mounted.
5. Adjust the levelling screws to ensure the boiler
is level.
6. Connect the boiler to the installation fittings.
Vitodens 200-W B2HA 100 to 150 Technical Data
CAUTION
The boiler must be level both vertically and horizontally
to ensure proper draining of the condensate.
IMPORTANT
When using the boiler restraint brackets, follow the
instructions supplied with the restaints prior to installing
the mounting bracket.
