ViewSonic CDE5560T User manual

55’’(54.6’’ viewable) Interactive
Large Format Display
CDE5560T

The ViewSonic CDE5560T 55’’(54.6’’ viewable) Full HD interactive LED display solution is perfect for business
and education. This 10-point touch-enabled display, paired with pre-installed annotation software, allows
multiple users to simultaneously write or draw on the display’s hardness surface using fingers or stylus. A Full
HD screen guarantees crisp and vivid image quality, while 350-nit brightness and wide viewing angles
provide better visual performance in well-lit rooms. With built-in dual core processor and 8GB internal
storage, as well as integrated versatile connectivity including HDMI, VGA, YPbPr, RS232, RJ45 and USB ports,
this display provides powerful computing for annotation and multimedia playback without the need for a PC.
This Energy Star certified display delivers optional slot-in PC (NMP710) capability, offering Windows®8
Professional (64 Bit) OS and ViewBoard annotation software for more computing-intensive interactive
applications. The CDE5560T is VESA mountable (wall mount kit WMK-047 included for Europe region) or
choose the optional trolley cart for flexible installation for classrooms and corporate meeting rooms.

Pre-installed convenient annotation software
ViewSonic’s easy-to-use ViewBoard Lite software is pre-installed on CDE5560T display. This software lets you
write, edit, and transform documents and images on-screen in real-time for convenient, real-time annotation.
Presenters and teachers can now interact with the screen to create lecture notes or amend collaborative
documents that can be instantly saved and shared.
10 point touch interactive capabilities for
collaboration with multiple users
With 10-point simultaneous touch technology, the CDE5560T encourages group interaction. Multiple users
can simultaneously write or draw on this larger-sized display’s 7H hardness surface using styluses or their
fingers – or both at the same time! And its superior touch report rate provides a smoother user touch
experience for both educational and corporate applications.

Easy for presentation without the needs of PCs
Equipped with a powerful dual-core processor, the CDE5560T provides smooth and fast computing for todays
demanding applications. This large format display is able to playback presentation files and multimedia
contents directly from onboard 8GB memory, USB drive, and even surf the Internet via the LAN connection.

Superior screen performance enhances
presentation quality
This large format display features a 1920 x 1080 resolution, 350 nits brightness and 1400:1 contrast ratio,
delivering sharp and crisp image performance for in-door environment. The display also features wide
viewing angles, delivering true and consistent color performance and ensures the audiences at the corners in
the boardroom and classroom can see the presentation files clearly.
Optional slot-in PC with Windows® 8

Professional (64Bit) OS and ViewBoard 2.0
whiteboard annotation software
Utilizing powerful Intel® i5 processors, ViewSonic’s optional NMP710-P8 slot-in PC provides powerful
computing capabilities. This means smooth, high-speed video and gaming performance, high-definition
graphics and more. It comes with a Windows®8 Professional (64Bit) operating system that also allows you to
browse the Internet, use Office Suite applications, and download all types of time-saving applications. In
addition, with bundled ViewBoard 2.0 whiteboard annotation software, it provides comprehensive tools to
write, take note, and various educational template to enhance teaching efficiency.
Note:
-PC-Module NMP710-P8 needs to be ordered seperately and is not automatically included in CDE5560T.
-ViewBoard 2.0 software is available for download in the download section and can be used with external
Windows 8 computer when connected to ViewBoard.
Eye-Care technologies create comfort viewing
environment
The CDE5560T adopts exclusive Flicker-free and Blue Light Filter eye-care technologies. By nearly eliminating

screen flickering at all brightness levels by providing a constant LED light source and reduce blue light
exposure, the display ensures longer viewing time and increase eye comfort for presentation and multimedia
experience – without eye fatigue.
Flexible Installation through Versatile
Connectivity
The CDE5560T integrates 3 x HDMI, 3 x VGA and component inputs for more flexible installations. In addition,
its PIP (picture in picture) function lets a presenter show more by selecting an additional high-definition input
signal to make presentations more interesting. The display also boasts 4 USB ports for more flexible
connection to an array of peripheral devices. With 3 integrated USB 2.0 ports and 1 USB 3.0 port, you can
leverage faster data transfer speeds, and connect to the rest of your must-have digital devices.

RS232 Connectivity for Easy Multi-device
Management
RS232 connectivity enables computers and laptops to be connected to the CDE5560T. RS232 connectivity
also allows IT personnel to conveniently manage multiple displays, configure devices, and upgrade firmware
from a centralized location. This provides organizations the ability to better maintain and control large
numbers of displays from a single location.

Protective ID design ensures durability
A rounded-corner design provides a safer learning environment for active students by helping to prevent
injuries in the classroom and it features 7H scratch-resistant surface hardness that ensures durability, as well
as a consistent, high-quality touch experience. In addition, an anti-glare film improves screen visibility in
bright environments.

Energy-Saving LED backlight
The CDE5560T utilizes an energy-saving LED backlight that consumes 35% less power than conventional
CCFL backlight displays. This provides for a lower overall cost of ownership, along with a higher ROI, making
this display a great long-term investment.

Accessories for improved usability and mobility
The convenient magnetic pen holder on the bottom-left bezel (see picture) frees up space and keeps the
styluses firmly in place. Utilizing this function will help save space and keep things organized, creating a
healthy working or learning environment. Although the CDE5560T can be wall mounted for a solid and safe
user touch experience, we also offer an optional trolley mount (LB-STND-003) that provides the flexibility of a
mobile display.


Technical Specifications
LCD PANEL Panel Size 55” (54.6” viewable)
Type/ Tech TFT LCD Module with LED Backlight
Display Area
(mm)
1209.6(H) x 680.4(V) (54.6” diagonal)
Aspect Ratio 16:9
Resolution 1920x1080

Colors 16.7M colors
Brightness 280 / 350 nits (Min. / Typ.)
Contrast Ratio 1000:1 / 1400:1 (Min. / Typ.)
Response Time 6ms
Viewing Angles H = 178, V = 178
Backlight LED
Backlight Life 50,000 Hours Typ
Hardness 7H
TOUCH Type/ Tech Infrared
Touch Resolution 32767 x 32767
Touch Point 10 point for gesture, 5 point for writing
Response time 15ms MAX.
System Windows8/Windows7/WindowsXP/Vista/Linux/Mac/Android/Wince/Chrome
INPUT HDMI x3
RGB / VGA x3
DisplayPort N/A
DVI N/A
RF (TV) N/A
Audio x3 (PC audio in)
CVBS x1
YPbPr N/A
MIC(Microphone) N/A
RS232 x1
SD/SDHC N/A
OPS / ViewSonic
PC module slot
N/A / x1 (for NMP710)
OUTPUT RGB / VGA x1
DisplayPort N/A
DVI N/A
Audio x1 (Earphone out)
CVBS N/A
YPbPr N/A
SPIDF x1 (optical)
RS232 N/A
Remote Control N/A
LAN RJ45 x1
USB Type A x3 (2.0); x1 (3.0)

Type B x1 (for touch)
Mini USB N/A
Micro USB N/A
SPEAKERS 10W x 2
BUILT-IN PC Processor ARM Cortex A9 Dual Core CPU
Graphic ARM Mali400 MP4
Sound card N/A
Memory 1.5GB
Storage 8GB
Networking Integrated 10/100/1000M Adaption
COMPATIBILITY RGB PC/HDMI PC Refer to timing table
CVBS 480i
S-Video N/A
YPbPr N/A
HDMI 480i, 480p,720p, up to 1080
CONTROLS Physical- Top OSD Power, Home, Return, Setting, VOL-, VOL+ INPUT: PC, Android, AV, VGA1, VGA2,
VGA3, HDMI1, HDMI2, HDMI3, HDMI4 LIGHT: 1~10 VOLUME: 0~100 VGA: H Position, V
Position, Phase, Clock, Zoom, Auto Adjust, Writing Mode PICTURE: Brightness,
Contrast, Hue, Sharpness, Color Temp, Zoom, Writing Mode
Embedded Linux
OS
SETTING: Ethernet checking, Sound, Display, Apps, Language&input, Date&time,
About device ANNOTATION: Annotation menu, Return, Main, Pen, ViewBoard Lit, Open
file, Screenshot, close menu INTERFACE: ViewBoard Lit, Folders, Browser, PIP,
Settings, Apps
Multimedia IMAGE: Close, Zoom in, Zoom out, Previous, Play/Pause, Next, Counterclockwise,
Clockwise, setting AUDIO: Close, Previous, Play/Pause, Next, Playlist, Loop, Random,
Single VIDEO: Close, Previous, Fast backward, Play/Pause, Fast forward, Next, Playlist
POWER Voltage 100-240VAC +/- 10% Wide Range
Consumption "On" 190W(typ), "Power Saving" < 0.5 W, "Off" (Suspend) < 0.5 W
ERGONOMICS Tilt N/A
Wall Mount
(VESA® )
400 x 400 (M8 x 20mm)
OPERATING
CONDITIONS Temperature (º C) 32°F to 104°F (0°C to 40°C)
Humidity 20% ~ 80% non-condensing
DIMENSIONS
(W x H x D)

Physical (inch /
mm)
51.77x31.69x3.66 / 1315x805x93
Packaging (inch /
mm)
58.27x37.60x11.02 / 1480x955x280
WEIGHT Net (lb / kg) 119.05 / 54
Gross (lb / kg) 143.30 / 65
REGULATIONS Standard CE, EAC, EEI
WARRANTY **Warranty offered may differ from market to market
What's in the
box? • CDE Interactive Large Format Display Monitor
• VGA cable
• Power cable x 4
• Remote control
• USB cable
• Audio cable
• Touching pen x 3
• User manual CD wizard
• RS232 adapter
• Wall Mount Kit: WMK-047 (in separate box, for Europe only)
ViewSonic® Limited Warranty
ViewSonic provides customers with the security of a manufacturers warranty against defected products. The
type and duration of the applicable warranty service varies by product type, country of purchase and can
also vary on an individual basis according to customer requirements agreed at time of purchase. The
warranty will expire after the end of the warranty period.
