ViewSonic G70fm User manual

Graphics Series
Save space with the multimedia G70fm and G70fmb.
The perfect choice for corporate users, both the G70fm and
G70fmb 17" (16.0" viewable) CRTs blend PerfectFlat screen technology
and multimedia capability — with built-in 3-watt speakers, micro-
phone and headphone jacks. For additional customization, choose
black or beige, or add ViewSonic’s optional USB hub base, which
snaps easily into the bottom of the monitor, allowing convenient
multiple USB peripheral connections. For corporate users looking for
an all-in-one multimedia CRT with advanced flat-screen technology,
the G70fm and G70fmb are an excellent choice.
ViewSonic
®
G70fm /G70fmb Monitor
• 0.21mm horizontal pitch
0.25mm diagonal pitch
This ultra-fine dot pitch produces super
clear, crisp images with great picture
definition, even at the highest resolutions.
•1280 x 1024 maximum resolution
Di splays a maximum resolution of 1280 x
1024; 1024 x 768 at 87Hz flicker-free
refresh rate for easy-on-the-eyes viewing.
1280 x 1024 @ 66Hz
1024 x 768 @ 87Hz
800 x 600 @ 110Hz
•PerfectFlat®screen
Absolutely flat screen provides realistically
proportioned, precise images with reduced
reflection, image distortion and eye fatigue.
•SuperClear®technology
SuperClear screen technology incorporates
enhanced phosphor treatment and opti-
mized glass to deliver vivid colors and
image clarity.
•OSD lock
Prevents accidental misadjustments of
OnView®controls to maintain optimized
image quality.
•ARAG®screen treatment
This specially formulated anti-reflection,
anti-glare screen treatment maintains
the highest image quality.

Graphics Series
*Universal Mac®adapter available. †Black case model TCO’95. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names,
trademarks stated herein are the property of their respective companies. Copyright © 2002 ViewSonic Corporation. All rights reserved. [10342-00B-09/01] VS-2125
17" (16.0" VIEWABLE) PERFECTFLAT®COLOR MONITOR
CRT Type 17" (16.0" viewable) CRT, 90ºdeflection
Dot Pitch 0.21mm horizontal, 0.13mm vertical, 0.25mm diagonal
Phosphor RGB P22 medium persistence
Glass Surface Anti-static, Anti-reflection; TM~50.0%
SIGNAL Video RGB Analog (75 ohms, 0.714 Vp-p)
Sync H/V separated (TTL), composite
Frequency fh: 30~70kHz; fv: 50~150Hz
COMPATIBILITY PC PC compatible from VGA to 1280 x 1024
Mac®*Power Mac™up to 1024 x 768
CONNECTOR Video In 15-pin mini D-sub (attached cable)
Audio In 3.5mm pin mini jack (stereo)
Microphone In 3.5mm pin mini jack (mono/auxiliary)
Microphone Out 3.5mm pin mini jack (mono)
Headphone Out 3.5mm pin mini jack (stereo)
Power 3-pin plug (CEE22)
POWER Voltage AC 100-240V (auto switch) 50–60Hz
Consumption 90W (typ), 100W (max)
CONTROLS Basic Power, on/off, 1, down, up, 2, speaker mute, volume
decrease and volume increase
OnView®Contrast, brightness, zoom, H/V size, H/V position,
pincushion, pin balance, trapezoid, tilt, H/V moiré
reduction, ViewMatch®color temperature (9300, 6500,
user), degauss, ViewMeter®
, language, OSD position,
memory recall
VIDEO INPUT Bandwidth 110MHz (typ)
DISPLAY AREA Factory Setting 310mm (H) x 230mm (V)
12.2”x 9.1”
Maximum Scan 320mm (H) x 240mm (V)
12.6”x 9.4”
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITION Humidity 5–95% (non-condensing)
DIMENSIONS Physical 412mm (W) x 435mm (H) x 412mm (D)
16.2" x 17.1" x 16.2"
WEIGHT Net 16.7 kgs. (36.8 lbs.)
REGULATIONS UL, CSA, FCC-B, ICES-003, DHHS, NOM, TUV/S-Argentina,
CB, MPR II, EPA ENERGY STAR®, Energy 2000
POWER MANAGEMENT Meets ENERGY STAR®,TCO
’99†and Energy 2000 standards
WARRANTY Three-year limited warranty on CRT, parts and labor.
Express Exchange®service option available.
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
381 Brea Canyon Road, Walnut, CA 91789 •Phone [phone] or [phone] •Fax [phone] •E-mail: [e-mail] •ViewSonic.com
•USB hub-compatible base
Base design allows easy integration of the
optional ViewSonic USB (Universal Serial
Bus) hub for convenient USB peripheral
connections.
•TCO’99†and Energy 2000 certified
•Bezel-integrated speakers and
microphone
Two 3-watt speakers save desk and work
space, while offering superior sound quality.
Built-in microphone allows bi-directional
communications in true multimedia
applications such as video conferencing
and computer telephony.
•Turn your monitor into a
high-resolution TV
Easily hook up favorite extras
like a DVD, VCR, digital
camera or gaming console
with the VG50HRTV
TV tuner module.
ViewSonic
®
G70fm /G70fmb Monitor
