ViewSonic PerfectFlat A95F User manual

• 0.25mm aperture grille at center
0.27mm aperture grille at corner
This ultra fine aperture grille pitch
produces clear, crisp images with great
picture definition, even at the highest
resolutions.
• 1,600 x 1,200 maximum
resolution
Displays a maximum resolution of 1600 x
1200; 1280 x 1024 at 89Hz flicker-free
refresh rate for easy viewing.
1600 x 1200 @ 77Hz
1280 x 1024 @ 89Hz
1152 x 870 @ 104Hz
1024 x 768 @ 118Hz
• Internet color ready
Internet color management profile included
for true color representation.
• PerfectFlat®screen
Absolute flat screen provides realistically
proportioned, precise images with
reduction of ambient light reflection,
image distortion and eye fatigue.
• High resolution big screen
18" viewable delivers a better experience
with increased productivity and 30% more
viewable area per square inch than a
typical 17" (16.0" viewable) monitor.
• Three year limited warranty
24/7 customer support.
• PC '99 compliant
Compliant with Microsoft®hardware
guidelines for ease of set up and installation.
19" (18.0" viewable) PerfectFlat Monitor
ViewSonic’s A95f PerfectFlat®monitor has it all. A big 19" (18.0" viewable) that delivers a better computing experience
with increased productivity and 30% more viewable area per square inch than a typical 17" (16.0" viewable)
monitor. PerfectFlat technology gives you an absolute flat screen that provides realistically proportioned edge-to-edge
precise images, while reducing ambient light reflection and image distortion that could lead to eye fatigue. A .25mm
aperture grille pitch and maximum resolution of 1,600 x 1,200 make this monitor ideal for high performance
applications, Internet, and gaming. As with all ViewSonic monitors, the A95f comes with a three-year limited
warranty and 24/7 technical support. When you want to do it all, get the monitor that has it all. The A95f
PerfectFlat by ViewSonic.
A - Series
A95f Monitor
ViewSonic®

A
SERIES
ViewSonic A95f
• OnView®controls including
ViewMatch®
All screen adjustments are made via an on-screen
menu using simple controls. ViewMatch allows the
user to adjust color temperature and individual
color intensity for screen-to-print matching.
• Anti-static, anti-glare screen
This anti-static, anti-glare screen coating refracts
unwanted light away from the user while maintaining
the highest quality of the displayed image.
• MPR-II and EPA E NERGY S TAR
®
compliant
This monitor surpasses these strict standards for
reduced emissions, power consumption and
efficiency.
• USB compatible base
New base design allows easy integration of an
optional ViewSonic USB (Universal Serial Bus)
hub†for convenient USB peripheral connections.
•
• PC and Mac compatible
381 Brea Canyon Road, Walnut, CA 91789 • Phone [phone] • [phone]
Fax [phone] • Internet: www.ViewSonic.com
*Requires Mac cable adapter. **Requires optional adapter. Copyright © 2000. ViewSonic Corporation. All rights reserved. Corporate names and trademarks
stated herein are property of their respective companies. Specifications subject to changes without notice. The EPA only promotes energy efficiency and does
not endorse any particular company or product. Microsoft, Windows, Windows NT and the Windows logo are the registered trademarks of Microsoft Corporation
in the United States and other countries.
VSA95f_8/00_ rev1
VS-2105
ViewSonic Corporation's QMS\EMS has been registered
to ISO 9001 & ISO 14001 by the British Standards Institution.
19" (18.0" viewable) COLOR MONITOR WITH PERFECTFLAT®TECHNOLOGY
CRT Type 19" (18.0" diagonal viewable area) 90˚ deflection
AG Pitch 0.25mm (center) - 0.27mm (corner)
Phosphor RGB medium short persistence B22
Glass Surface Tint (TM=40%), Anti-reflection and anti-static with AR-film
INPUT SIGNAL Video RGB Analog (0.7Vp-p, 75 ohms)
Sync H/V separate (TTL) composite, sync on green
Frequency Fh:30-97kHz, Fv:50-180Hz
COMPATIBILITY PC PC compatible (from VGA up to 1600 x 1200)
Mac®*Power Mac
™
compatible up to 1600 x 1200
Other** Most workstations
CONNECTOR Signal 15-pin mini D-sub (detached)
Power 3-pin plug (CEE22)
POWER Voltage AC 90-240VAC (auto switch) 50-60Hz
Consumption 150W (typ)
USER CONTROLS Basic Power, on/off, 1, up, down, 2
OnView Contrast, brightness, H/V-position, H/V-size, pincushion,
trapezoid, pin-balance, tilt, parallelogram, top/bottom hooking,
H/V-convergence, ViewMatch®color, moire, zoom, purity,
focus, V-linearity center, V-linearity symmetry, ViewMeter®
,
OSD control, degauss, language, data recall
VIDEO INPUT Bandwidth 200MHz (typ)
MISCONVERGENCE 0.25mm (max at center)
0.35mm (max at corner)
DISPLAY AREA Factory Setting 353mm (H) x 265mm (V) (Factory default image)
Maximum Scan 364mm (H) x 275mm (V) (Dependent upon signal timing used)
OPERATING Temperature 32˚F to 104˚F (0˚C to 40˚C)
CONDITION Humidity 5 – 95% (non-condensation)
DIMENSIONS Physical 470mm (W) x 470mm (H) x 477mm (D)
18.5" (W) x 18.5" (H) x 18.8" (D)
WEIGHT Net 23.0KG (50.6lb)
OTHER DDC1, DDC2B, GTF
REGULATIONS UL, CSA, FCC-B, DHHS, CB, CE, ENERGY STAR®
, MPR II, NOM,
IRAM, ISO 9241-3, ICES003
POWER MANAGEMENT Meets ENERGY STAR® , VESA® , DPMS and MPR-II standards
WARRANTY Three year limited warranty on CRT, parts and labor.
48 hour Express Exchange®service option available.
