Getting Started
Congratulations on your purchase of a Optiquest®color monitor. Important!
Save the original box and all packing material for future shipping needs.
NOTE: The word “Windows” in this user guide refers to the following Microsoft
operating systems: Windows 95, Windows NT, Windows 98, Windows 2000,
Windows Me (Millennium), and Windows XP.
Package Contents
Your package includes:
• Color monitor
• DB-15 video cable
• Power cord
• Wizard CD-ROM
NOTE: The CD includes the User Guide PDF files and INF/ICM display
optimization files. The INF file ensures compatibility with Windows operating
systems, and the ICM file (Image Color Matching) ensures accurate on-screen
colors. Optiquest recommends that you install both files.
Precautions
• For best viewing conditions sit at least
18” from the monitor.
• AVOID TOUCHING THE SCREEN
WITH YOUR FINGERS. Oils from the
skin are difficult to remove.
• NEVER REMOVE THE REAR
COVER. The monitor contains high
voltage parts. You may suffer serious
injury if you touch these parts.
• Avoid exposing the monitor to direct
sunlight or another heat source,
including an open flame. The monitor
should be facing away from direct
sunlight to reduce glare.
• Always handle your monitor with care
when moving it.
• Place your monitor in a well ventilated
area. Do not place anything on the
monitor that prevents adequate
dissipation of heat.
• Ensure the area around the monitor is
clean and free of moisture.
• Keep the monitor away from magnets,
motors, transformers, speakers, and
televisions.
• Do not place heavy objects on the
monitor, video cable, or power cord.
• If smoke, abnormal noise, or strange
odor is present, immediately switch the
monitor off and call your dealer or
ViewSonic. It is dangerous to continue
using the monitor.
Optiquest Q71/B-8 3

Quick Installation
1 Connect power cord
Connect the power cord to a properly
grounded AC outlet.
2 Connect video cable
Make sure both the monitor and computer
are turned OFF.
• Connect the video cable to the computer.
Macintosh®users: Models older than G3
require a Macintosh adapter. Attach the
adapter to the computer and plug the video
cable into the adapter.
To order anadapter, contact ViewSonic.
See “Customer Support” on page 12.
3 Turn ON monitor and computer
Turn ON the monitor, then turn ON the
computer. This sequence (monitor before
computer) is very important.
NOTE: At this point Windows users may
receive a message asking them to install the
INF file.
4 Install Display Optimization files
(INF and ICM files)
(1) Insert the Wizard CD-ROM into your
computer’s CD-ROM drive.
NOTE: If your computer does not have a
CD-ROM drive, see “Customer Support” on
page 12.
(Continued)
(2) Wait for the CD-ROM to auto-start.
NOTE: If the CD-ROM does not auto-start:
double-click on the CD-ROM icon in
Windows Explorer, then double-click on
viewsonic.exe.
(3) Follow the on-screen instructions.
5 Windows users: Set the Timing
Mode (resolution and refresh rate) Example:
1024 X 768 @ 75Hz.
For instructions on changing the resolution
and refresh rate, see the graphic card’s user
guide.
Installation is complete. Enjoy your new
Optiquest color monitor.
To be best prepared for any future customer
service needs: print this user guide and write
the serial number in "For Your Records" on
page 2. (See back of monitor.)
To register your product go online to
www.viewsonic.com.
The Wizard CD-ROM also provides an
opportunity for you to print the registration
form which you may mail or fax to ViewSonic.
Video cable
Power cord
AC wall
outlet
Optiquest Q71/B-8 4

Using the Monitor
Setting the Timing Mode
Setting the timing mode is important for maximizing the quality of the
screen image and minimizing eye strain. The timing mode consists of the
resolution (example 1024 x 768) and refresh rate (or vertical frequency;
example 85 Hz). After setting the timing mode, use the OnView®controls
to adjust the screen image.
For the best picture quality set your monitor timing mode to:
VESA 1024 x 768 @ 85 Hz.
To set the Resolution:
1Right-click on the Windows desktop.
2Click Properties on the drop-down menu.
3Click the Settings tab.
4Move the slider pointer which displays in the Desktop area or Screen area in
the window.
NOTE: The refresh rate should already be set if you have done the CD
installation (or refer to your graphics card documentation).
Optiquest Q71/B-8 5

Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OnView®
controls which display on the screen. The OnView controls are explained at the
top of the next page and are defined in “Main Menu Controls” on page 8.
Main Menu
With OnView controls
Front Control Panel
Displays Main Menu; also saves
changes/exits Main Menu Power Light Power On/Off
Scroll through menu Displays control screen for
highlighted control (or pair
of controls). Also, toggles
between pairs of controls on
some control screens
options and adjust the
displayed control
Optiquest Q71/B-8 6

Do the following to adjust the screen image:
1To display the Main Menu, press button [1].
2To select a control you want to adjust, press the arrow buttons on the front
control panel of your monitor and scroll through the choices. When the
control you want is highlighted, press button [2].
NOTE: Some controls on the Main Menu are listed in pairs, such as
Contrast/Brightness. Display control screen (sample shown in step 3 below).
Press button [2] to toggle to the next control in the pair.
3To adjust the selected control, such as CONTRAST in the sample below,
press the arrow buttons.
4To save the control setting and Exit the menu press button [1] twice.
BRIGHTNESS
OSD Lock Settings
You have the option of using the On Screen Display (OSD) locking feature,
OSD LOCK, to prevent unwanted changes to the current image settings.
•OSD Lock: Press and hold the [1] and [
▼
] buttons on the face of the monitor
for 10 seconds. The message "OSD LOCK" will then display briefly,
indicating that the OSD image settings are now locked.
•OSD Unlock: Press and hold the [1] and [
▼ ] buttons again for 10 seconds. The
message "OSD UNLOCK"will then display briefly, indicating that the OSD
image settings are now unlocked.
Optiquest Q71/B-8 7

Main Menu Controls
Adjust the menu items shown below by using the up and down buttons.
Control Explanation
Contrast adjusts the difference between the image
background (black level) and the foreground (white level).
Brightness adjusts the background black level of the screen
image.
Zoom expands and contracts the entire screen image.
Horizontal Position moves the screen image left or right.
Horizontal Size adjusts width of the screen image.
Vertical Position moves the screen image up or down.
Vertical Size adjusts the height of the screen image.
Pincushion curves the vertical sides of the screen image.
Pin Balance curves the vertical edges of the screen image to
the left or right.
Trapezoid adjusts the top and bottom of the screen image
until they have equal length.
Parallel slants the vertical edges of the screen image until
they are parallel.
Tilt rotates the entire screen image.
Optiquest Q71/B-8 8

Degauss removes the build-up of magnetic fields that can
cause irregular colors to appear around the edges of screen
images. There are two ways to degauss the display:
automatically by turning the monitor on, or manually by
selecting the Degauss control from the menu.
With Degauss selected from the menu, press button [2] to
degauss the monitor manually.
Important: Do not degauss repeatedly. Doing so can be
harmful to the display. Wait at least 20 minutes (before
selecting this control again.
ViewMatch®Color provides several color options: several
preset color temperatures and User Color which allows you
to adjust red (R), green (G), and blue (B). The factory
setting for this product is 9300K (9300°Kelvin).
9300K — Adds blue to the screen image for cooler white
(used in most office settings with fluorescent lighting).
6500K — Adds red to the screen image for warmer white
and richer red.
5000K — Adds blue and green to the screen image for a
darker color.
User Color — Individual adjustments for red, green, and
blue.
Moire reduces interference patterns that appear as ripples,
waves, or unwanted background color textures. Interference
patterns of this type are most noticeable when viewing
images having closely spaced lines or finely detailed
patterns.
Language allows you to choose from among several
languages for the menus and control screens: English,
French, German, Italian, and Spanish.
Memory Recall returns adjustments to the original factory
settings if the display is operating in a factory preset timing
mode listed in this user guide.
Exception: This control does not affect changes made with
the User Color control.
ViewMeter displays the frequencies (horizontal and
vertical) coming from the graphics card of the computer.
Control Explanation
Optiquest Q71/B-8 9
