ViewSonic VP201b-1 User manual

Model No.
20" Color TFT LCD Display
Service Manual
ViewSonic VP201b/s-1
ViewSonic381 Brea Canyon Road, Walnut, California 91789 USA - [phone]
(VP201b/s-1_SM_685 Rev. 1dMay. 2005)
VLCDS26064-2W/-4W

Copyright
Copyright
¤
2005by ViewSonic Corporation. All rights reserved. No partof this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of ViewSonic Corporation.
Disclaimer
ViewSonic makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranty of merchantability or fitness for any particular
purpose. Further, ViewSonic reserves the right to revise this publication and to make changes from time
to time in the contents hereof without obligation of ViewSonic to notify any person of such revision or
changes.
Revision History
Trademarks
ViewSonic is a registered trademark of ViewSonic Corporation.
All other trademarks used within this document are the property of their respective owners.
Optiquest is a registered trademark of ViewSonic Corporation.
ECR Number Description of Changes EditorRevision SM Editing Date
1a 08/28/03
Initial Release
F. Fan
Panel Change LG U04 Panel 16ms DCN-3773
1b 25/03/04 A. Lu
Scalar Change to GM1601
1c 03/09/05
A. Lu
4923
i
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1
Panel change form: LG U04 Panel 16ms to AUO M201UN02 V3 16ms
1d 05/19/05 A. Lu
5321

TABLE OF CONTENTS
2. Specification
3. Front Panel Function Control Description
4. Circuit Description
6. Troubleshooting Flow Chart
9. Block Diagram
10. Schematic Diagrams
7. Recommended Spare Parts List
1. Precautions and Safety Notices
5. Adjustment Procedure
8. Exploded Diagram and Spare Parts List
11. PCB Layout Diagrams
1
3
12
18
19
37
40
58
60
61
68
ii
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

1. Appropriate Operation
(1) Turn off the product before cleaning.
(2) Use only a dry soft cloth when cleaning the LCD panel surface.
(3) Use a soft cloth soaked with mild detergent to clean the display housing.
(4)Use only a high quality, safety approved AC/DC power cord.
(5)Disconnect the power plug from the AC outlet if the product will not be used for a long period of time.
(6) If smoke, abnormal noise, or strange odor is present, immediately switch the LCD display off.
(7) Do not touch the LCD panel surface with sharp or hard objects.
(8) Do not place heavy objects on the LCD display, video cable, or power cord.
(9) Do not use abrasive cleaners, waxes or solvents for your cleaning.
(10) Do not operate the product under the following conditions:
- Extremely hot, cold or humid environment.
-Areas containing excessive dust and dirt.
- Near any appliance generating a strong magnetic field.
- In direct sunlight.
2. Caution
No modification of any circuit should be attempted. Service work should only be performed after you are thoroughly familiar
with all of the following safety checks and servicing guidelines.
3. Safety Check
Care should be taken while servicing this LCD display. Because of the high voltage used in the inverter circuit, the voltage is
exposed in such areas as the associated transformer circuits.
4. LCDModule Handling Precautions
4.1 Handling Precautions
(1) Since front polarizer is easily damaged, pay attention not to scratch it.
(2)Be sure to turn off power supply when connecting or disconnecting input connector.
(3)Wipe off water drops immediately. Long contact with water may cause discoloration or spots.
(4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
(5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
(6)Since CMOSLSI isusedinthis module, take care of static electricity and ensure human earth when handling.
(7)Do not open or modify the Module Assembly.
(8)Do not press the reflector sheet at the back of the module in any direction.
(9)In the event that a Module must be put back into the packing container slot after it was taken out of the
container, do not press the center of the CCFL Reflector edge. Instead, press at the far ends of the
CFL Reflector edge softly. Otherwise the TFT Module may be damaged.
(10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate or tilt the Interface
Connector of the TFT Module.
1. Precautions and Safety Notices
1
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

(11) After installation of theTFT Module intoan enclosure(LCDmonitor housing, for example), do not twist or
bend the TFT Module even momentarily. When designing the enclosure, it should be taken into consideration
that no bending/twisting forces may be applied to the TFT Module from outside. Otherwise theTFT Module
may be damaged.
(12) The cold cathode fluorescent lamp in the LCD contains a small amount of mercury. Please follow local
ordinances or regulations fordisposal.
(13) The LCD module contains a small amount of materials having no flammability grade. The LCD module
should be supplied with power that complies with the requirements of Limited Power Source
(IEC60950 or UL1950), or an exemption should be applied for.
(14) The LCD module is designed so that the CCFL in it is supplied by a Limited Current Circuit (IEC60950
or UL1950). Do not connect theCCFL to a HazardousVoltage Circuit.
2
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

A.General specification:
1. General specification:
LCD panel suppliers: AUO: M201UN02 V.3
a. Panel size: 20.1-inch (viewable).
b. Driver element: a - Si TFT active matrix.
c. Effective display area: 408.0 (H) X 306.0 (V) mm.
d. Pixel pitch: 0.255 (H) X 0.255 (V) mm.
e. Max. resolution: UXGA (1600X1280 pixel).
f. Display color: 16.7M colors (R, G, B 8-bit data).
g. Response time: LG: 16 ms. (Typical)
AUO: 16 ms (Typical)
h. Color filter arrangement: R/G/B vertical stripe.
i. Black light: Edge – light type with 6CCFLs.
j. Contrast ratio: LG: 400:1
AUO: 700:1
k. Luminance: 250cd/m2(Typical).
l. Luminance variation: 1.54 (MAX.). (Note.1)
LCD panel specification:
m. Viewing angle (CR >10): Horizontal: 170o, Vertical: 170o.
Input signals: a. Analog R / G / B (0.7Vp-p/75 ohm) Positive.
b. Digital R /G / B DVI rev. 1.0 (TMDS single link)
c. H & V separate Sync: TTL level; Polarity: Positive or Negative.
d. H & V composite Sync: TTL level; Polarity: Positive or Negative.
e. SOG (Sync level 0.3Vp-p).
Input connector: a. Analog D-sub 15pin x 1.
b. Digital DVI-I 29 pin x 1. (Analog + Digital)
c. USB up stream x1.(VP201s/b only)
Output connector: a. USB down stream x 4.(VP201s/b only)
Display data channel: DDC2B.
Signal frequency range: a. Horizontal:
a-1. Analog: 30KHz ~ 92KHz.
a-2. Digital: 30KHz ~ 92KHz.
b. Vertical: 50Hz ~ 85*1Hz.
*Note: When the resolution is set to 1600x1200, the maximum vertical
refresh rate is: Analog input: 60 Hz.
Digitalinput:60Hz.
c. Pixel clock:
c-1. Analog: 165MHz.
c-2. Digital: 165MHz.
d. Non-interlaced.
Resolution: 1600x1200. (UXGA)
Power supply: AC Input Range: AC 90 to 264V, 50/60Hz ± 3Hz,
1.5A.
Less then 50Ap. For 115VAC.Inrush current
Less then 100Ap. For 230VAC.
Less then 73W. On mode.
Less then 4W. Active off mode.
Power Consumption:
Less then 2W. DC power off.
2. Specification
3
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

2. Physical specification:
a. Height: 480.55mm.
b. Width: 448.00mm.
Overall dimension:
c. Depth: 266.65mm.
a. Net weight: 8.5kg.Weight:
b. Gross weight: 11.2kg.
a. Tilt: +25o~ -5o.
b. Swivel: ±45o.
c. Height adjust: 110mm.
Mechanical adjustment:
d. Pivot: 90o.
a. Height: 494mm.
b. Width: 345mm.
Packaging: a. Carton dimension:
c. Depth: 560mm.
Accessories: Power cable 1.8m.
User guide (English).
CD ROM.
Warranty card.
HD15 - HD15 cable.
DVI (D) – DVI (D) cable.
3. Regulatory & Standard certification.
Regulatory standards UL, cUL, FCC-B, CB, CE, ENERGY, NOM, TUV/GS, TUV ERGO (covers
ISO13406-2 & MPRII), TCO’03(for VP201s/VP2000s), TCO99 (for VP201
b
),
NEMKO, SEMKO, DEMKO, FIMKO, GOST-R + 20 ORIGINAL COPIES
HYGIENIC, (SASO), PCBC, VCCI, BSMI, CCC, (PSB), (C-TICK), TUV-S
Note.1: Luminance variation:
FIG.1 Luminance test points
L = 408mm / W = 306mm
10%
50%
90%
10%
50%90%
BU = MAX. Luminance in 9 point (1 ~ 9)
MIN. Luminance in 9 point (1 ~ 9) 1.54
4
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

B. OSD Menu Functions
1. Interface board function test.
1.1 Function keys: Power, 1, ▲, ▼, 2.
1.2 Basic function check.
1.2.1 Input 1600x1200 / 60Hz, cross-hatch reverse pattern.
1.2.2 Push “1” & “2” key, select Auto image adjust, Contrast, Brightness, Input select, Color,
Manual image adjust, Setup menu, Memory recall function.
1.2.3 Push “▲” or “▼” key check Contrast, Brightness, Input select, Color, H/V position, H size,
Fine tune, Sharpness, Scaling Language Select, OSD Position OSD Timeout, OSD
Background functions.
1.2.4 Push “2” to cycle among Analog / DVI-A / DVI-D signals.
1.2.5 When the OSD is not active, the “▲” and “▼” buttons increase/decrease Contrast or
Brightness.
2. Interface power test.
2.1 The test point:
2.1.1 TP251 = NA.
2.1.2 TP252 = 5V ± 5%.
2.1.3 TP253 = 18V ± 5%.
3. OSD function.
Auto Image Adjust2
Contrast/Brightness: Contrast, Brightness.
Input Select: D-Sub, DVI-A, DVI-D.
Color Adjust: SRBG, 9300K, 6500K (default), 5400K, 5000K, User Color (R, G, B).
Information: Resolution, Horizontal Frequency, Vertical Frequency, Model Number, Serial Number,
Web Site.
Manual Image Adjust: H. / V. Position2(H. Position, V. Position), H. Size2, Fine Tune2, Scaling3(Fill
Screen, Fill Aspect Ratio4, 1:1).
Setup Menu:
Language:
English, French, German, Spanish, Italian, Finnish, Japanese, Traditional Chinese, Simplified Chinese.
Resolution Notice: Enable, Disable.
Input Priority: D-Sub, DVI-A, DVI-D, Auto Search.
OSD Position: H. Position, V. Position.
OSD Timeout: 5SEC, 15SEC, 30SEC, 60SEC
OSD Background: On, Off.
Memory Recall
Notes:
2
These functions are not available in Digital mode; the item is faded out and can’t be
selected.
When auto tuning, the image should not go blank.
3These functions are not available in 1600x1200 mode; the item is faded out and can’t be
selected.
4When the input signal’s aspect ratio is 4:3, the “Fill Aspect ratio” function yields the same
result as “Fill Screen”.
5
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

2. 9300K alignment:
1.2.1 Input 1600x1200 / 60Hz & full white pattern at 100IRE.
1.2.2 Adjust R, G, and B Gain to meet following chromaticity spec:
9300K →x = 0.283 ± 0.005, y = 0.298 ± 0.005, Y > 150cd/m2(Both analog & DVI).
3. 6500K alignment:
1.3.1 Input 1600x1200 / 60Hz & full white pattern at 100IRE.
1.3.2 Adjust R, G and B Gain to meet following chromaticity spec:
6500°K →x = 0.313 ±0.005, y = 0.329 ± 0.005, Y > 200cd/m2(Both analog & DVI).
4. 5400K alignment:
1.4.1 Input 1600x1200 / 60Hz & full white pattern at 100IRE.
1.4.2 Adjust R, G, and B Gain to meet following chromaticity spec:
5400K →x = 0.335 ± 0.005, y = 0.350 ± 0.005, Y > 180cd/m2(Both analog & DVI).
5. 5000K alignment:
1.5.1 Input 1600x1200 / 60Hz & full white pattern at 100IRE.
1.5.2 Adjust R, G and B Gain to meet following chromaticity spec:
6. sRGB alignment:
1.6.1 Input 1600x1200 / 60Hz & full white pattern at 100IRE.
1.6.2 Adjust R, G and B Gain to meet following chromaticity spec:
sRGB →x = 0.313 ±0.005, y = 0.329 ± 0.005, Y > 200cd/m2(Both analog & DVI).
7. 64 grays and 16 grays pattern check:
7.1 Input a 1600x1200 / 60Hz, 64 gray-level pattern at 100IRE, with brightness set to 100% and
contrast set to 70%.
7.2 Verify that under the 9300K / 6500K / 5400K / 5000K settings, no more than 2 of the 64
grays are saturated.
7.3 Input a 1600x1200 / 60Hz, 16 gray-level pattern at 100IRE, with brightness set to 100% and
contrast set to 100%.
7.4 Verify that under the 9300K / 6500K / 5400K / 5000K settings, no more than 4 of the 16
grays are saturated.
6
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1
C. Image Calibration
1. Video alignment.
Initial Settings
1.1 Set contrast to 70% and brightness to 100%.
1.2 Input a 640x480 / 60Hz, 5-block (5-MOSAIC) pattern (input level 100IRE 0.7Vp-p), then
activate the White Balance function.
Set SRBG/9300K / 6500K / 5400K / 5000K, R G B Gain as shown below:
sRGB 9300K 6500K 5400K 5000K
Analog DVI Analog DVI Analog DVI Analog DVI Analog DVI
R Gain 255 255 255 255 255 255 255 255 255 255
G Gain 255 255 255 255 255 255 255 255 255 255
B Gain 255 255 255 255 255 255 255 255 255 255

D. Image test
1. Picture size & position.
1.1 Picture size.
Input analog timing modes 1 ~28 and DVI timing modes 1 ~ 28:
H-size: 408mm ±1mm.
V-size: 306mm ±1mm.
(Extra 640x350)
1.2 Screen center.
a. 1600x1200: H ± 1mm, V ± 1mm.
b. Other modes: H ± 1.5mm, V ± 1mm.
1.3 Picture position (refer to FIG.2).
H-position:︱g3-g4︱≦1.5mm.
V-position:︱g1-g2︱≦1.5mm.
2. Luminance test.
2.1 Input a 1600x1200 / 60Hz full white pattern at 100IRE with brightness set to 100% and contrast set to
70%.
Y (Luminance)
Color temperature x y Analog DVI
sRGB 0.313 ± 0.01 0.329 ± 0.01 >200 nit >200 nit
9300K 0.283 ± 0.01 0.298 ± 0.01 >150 nit >150 nit
6500K 0.313 ± 0.01 0.329 ± 0.01 >200 nit >200 nit
5400K 0.335 ± 0.01 0.350 ± 0.01 >180 nit >180 nit
5000K 0.346 ± 0.01 0.359 ± 0.01 >180 nit >180 nit
2.2 Input a1600x1200 / 60Hz full white pattern at 100IRE with brightness set to 100% and contrast set to
100%.
Y (Luminance)
Color temperature Analog DVI
9300K >220 nit >220 nit
6500K >220 nit >220 nit
5400K >220 nit >220 nit
5000K >220 nit >220 nit
3. Picture performance test.
3.1 Picture quality:
Test pattern signal The following image faults shall not be conspicuous:
1 100IRE white raster pattern Seam, Noise, Beat, Flicker
2 Cross hatch pattern Ringing, Overshoot, Smear, V-jitter, H-jitter
3 Color bar Color distortion, Noise, Beat, Color tangent
4 Gray scale (16 steps) Noise, Beat, Gamma distortion
5 1 dot ON / 1 dot OFF pattern Noise, Flicker
6 40IRE gray raster Noise, Beat, Gamma distortion
3.2 DVI performance test.
3.2.1 Test equipment:
a. VG828 digital pattern generator.
b. “TTL” DVI-D single link cable.
3.2.2 Test conditions:
a. Resolution: 1600x1200; refresh rate: 75KHz vertical / 60Hz horizontal.
b. 16, 32, 64, and 256-level horizontal gray scales..
c. 16, 32, 64, and 256-level vertical gray scales..
408mm
306mm
g4
g2
g1
g3
FIG. 2
7
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

4. Shortcut keys and factory presets
4.1 Shortcut keys: Press the following keys to adjust settings directly, when the OSD is not active.
[1]. Main Menu.
[2]. Select next input. (Sequence: D-SUB →DVI-A → DVI-D)
[UP] or [DOWN] arrow. Directly activate the Contrast menu. Switch to Brightness menu by
pushing button [2].
[UP] + [DOWN] arrows. Recall either Contrast or Brightness settings while the Contrast or
Brightness adjustment OSD is active, or recall both Contrast and
Brightness settings when the OSD is not active.
[1] + [2]. Toggle 720x400 and 640x400 mode when input 720x400 or 640x400
mode.
[1] + [UP] + [DOWN]. White Balance (press and hold for 5 seconds).
[2] + [UP] + [DOWN]. Video Mirror Function
[1] + [DOWN]. Power Lock / Power Unlock (press and hold for 10 seconds).
[1] + [UP]. OSD Lock / OSD Unlock (press and hold for 10 seconds).
DC-Power + [2] + [UP]. Copy EDID to E2PROM.
DC-Power + [1]. Factory mode. (Burn in mode on)
DC-Power + [2] + [DOWN]. Burn in mode on.
DC-Power + [UP] + [DOWN]. Burn in mode off.
DC-Power + [2]. All mode recall.
AC-Power on. Enter ISP mode.
4.2 All mode recall settings:
Contrast 70%.
Brightness 100%.
Color Temperature 6500K.
Scaling Full Screen.
Input Priority Auto Search.
OSD H. Position 50%.
OSD V. Position 50%.
OSD Time Out 15 Sec
OSD Background On
Resolution Notice Enabled
720x400/640x400 720x400
User color. 50%.
Language. English.
Clear burn in mode.
Clear user mode table.
4.3 Factory shipment settings:
4.3.1 Main power switch: Off.
4.3.2 AC power button: Off.
4.3.3 Others settings same as “All mode recall” settings.
5. Power management tests.
5.1 Power consumption test table:
Monitor status LED color Video signal Power consumption Recover time
Normal / Unstable / Warning Green Active <73W
Power save Amber Blank <4W 5sec
Aging Note NA <73W
DC power off Off NA <2W
AC power off Off NA -
See note: Amber (0.5sec) →Green (0.5sec) →Amber (0.5sec) →Green (0.5sec)… continuously.
6. DDC test.
6.1 DDC / EDID specification compliance requirement.
The data that is transmitted shall be stored in the monitor in non-volatile memory, which is a
requirement of the VESA EDID version 3.0 standard.
8
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

6.2 IC954 EEPROM data see Appendix-B item a.6.3 For the EDID data see Appendix B. VP2000s
analog & DVI-A are the same as item h. For the DVI-D input 1 see item i.
7. USB test (VP201s/b only)
7.1 Use a USB test hub such as “UPT2 USB2.0 8-port tester” to test USB up stream and down stream
transfers. Each port must pass the test.
7.2 Use a PC to check the USB VID, which should be 0543,and the PID, which should be 1169.
7.3 For USB test settings see Appendix E.
8. For auto alignment, it is necessary to execute the auto image adjust command for 3 DOS modes (640x350,
720x400, 640x400).
E. Analog and Digital timing chart.
Mode No. 1 2 3 4 5 6 7 8 9 10
Mode Name
TEXT
640 x
350
VGA
640 x
400
VESA
640 x
480
VESA
640 x
480
MAC
640 x
480
VESA
640 x
480
VESA
640 x
480
VESA
640 x
480
TEXT
720 x
400
VESA
800 x
600
Horizontal Freq. 31.468 31.468 24.688 31.469 35.000 37.861 37.500 43.269 31.469 35.156
Video clock Freq. 25.175 25.175 19.75 25.175 30.240 31.500 31.500 36.000 28.322 36.000
Sync. Polarity ＋－－－－－－－－＋
H. total (Dots) 800 800 800 800 864 832 840 832 900 1024
H. sync. (Dots) 96 96 64 96 64 40 64 56 108 72
H. back porch (Dots) 48 48 80 48 96 128 120 80 54 128
H. active (Dots) 640 640 640 640 640 640 640 640 720 800
H. front porch (Dots) 16 16 16 16 64 24 16 56 18 24
Vertical Freq. (Hz) 70.087 70.087 49.673 59.940 66.667 72.809 75.000 85.008 70.087 56.250
Sync. Polarity －＋＋－－－－－＋＋
V. total (Lines) 449 449 497 525 525 520 500 509 449 625
V. sync. (Lines) 2 2 4 2 3 3 3 3 2 2
V. back porch (Lines) 60 35 10 33 39 28 16 25 35 22
V. active
(Lines) 350 400 480 480 480 480 480 480 400 600
V. front porch (Lines) 37 12 3 10 3 9 1 1 12 1
9
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

Mode No. 11 12 13 14 15 16 17 18 19 20
Mode Name
VESA
800 x
600
VESA
800 x
600
VESA
800 x
600
VESA
800 x
600
MAC
832 x
624
VESA
1024 x
768
VESA
1024 x
768
XGA
1024 x
768
VESA
1024 x
768
VESA
1024 x
768
Horizontal Freq. (KHz) 37.879 48.077 46.875 53.674 49.727 48.363 56.476 58.099 60.023 68.677
Video clock Freq. 40.000 50.000 49.500 56.250 57.285 65.000 75.000 78.084 78.750 94.500
Sync. Polarity ＋＋＋＋－－－－＋＋
H. total (Dots) 1056 1040 1056 1048 1152 1344 1328 1344 1312 1376
H. sync. (Dots) 128 120 80 64 64 136 136 136 96 96
H. back porch (Dots) 88 64 160 152 224 160 144 160 176 208
H. active (Dots) 800 800 800 800 832 1024 1024 1024 1024 1024
H. front porch (Dots) 40 56 16 32 32 24 24 24 16 48
Vertical Freq. (Hz) 60.317 72.188 75.000 85.061 74.553 60.004 70.069 72.082 75.029 84.997
Sync. Polarity ＋＋＋＋－－－－＋＋
V. total (Lines) 628 666 625 631 667 807 806 806 800 808
V. sync. (Lines) 4 6 3 3 3 6 6 6 3 3
V. back porch (Lines) 23 23 21 27 37 29 29 29 28 38
V. active
(Lines) 600 600 600 600 624 768 768 768 768 768
V. front porch (Lines) 1 37 1 1 3 3 3 3 1 1
Mode No. 21 22 23 24 25 26 27 28 29 30
Mode Name
APPLE
1152x
870
VESA
1280 x
960
VESA
1280 x
960
VESA
1280 x
1024
VESA
1280 x
1024
VESA
1280 x
1024
HDTV
1280 x
720
VESA
1600 x
1200
Horizontal Freq. (KHz) 68.681 60.000 75.231 63.981 79.976 91.146 45.000 75.000
Video clock Freq. 100.00 108.00 130.00 108.00 135.00 157.50 74.250 162.00
Sync. Polarity －＋－＋＋＋－＋
H. total (Dots) 1456 1800 1728 1688 1688 1728 1650 2160
H. sync. (Dots) 128 112 136 112 144 160 40 192
H. back porch (Dots) 144 312 224 248 248 224 270 304
H. active (Dots) 1152 1280 1280 1280 1280 1280 1280 1600
H. front porch (Dots) 32 96 88 48 16 64 60 64
Vertical Freq. (Hz) 75.062 60.000 74.857 60.020 75.025 85.024 60.000 60.000
Sync. Polarity －＋＋＋＋＋－＋
V. total (Lines) 915 1000 1005 1066 1066 1072 750 1250
V. sync. (Lines) 3 3 4 3 3 3 5 3
V. back porch (Lines) 39 36 38 38 38 44 20 46
V. active
(Lines) 870 960 960 1024 1024 1024 720 1200
V. front porch (Lines) 3 1 3 1 1 1 5 1
10
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

Appendix B: DDC contents.
a. 128 bytes of EDID code for VP201s analog.
0 1 2 3 4 5 6 7 8 9
0 00 FF FF FF FF FF FF 00 5A 63
10 18 0C 01 01 01 01 01 0F 01 03
20 0E 29 1F 78 2E 30 85 A6 56 4A
30 99 24 14 50 54 BF EF 80 A9 40
40 81 80 81 40 71 4F 01 01 01 01
50 01 01 01 01 48 3F 40 30 62 B0
60 32 40 40 C0 13 00 98 32 11 00
70 00 1E 00 00 00 FF 00 41 32 55
80 30 35 30 31 30 30 30 30 31 0A
90 00 00 00 FD 00 32 4B 1E 5C 11
100 00 0A 20 20 20 20 20 20 00 00
110 00 FC 00 56 50 32 30 31 73 0A
120 20 20 20 20 20 20 00 B0
b. 128 bytes of EDID code for VP201s digital.
0 1 2 3 4 5 6 7 8 9
0 00 FF FF FF FF FF FF 00 5A 63
10 18 0C 01 01 01 01 01 0F 01 03
20 80 29 1F 78 2E 30 85 A6 56 4A
30 99 24 14 50 54 BF EF 80 A9 40
40 81 80 81 40 71 4F 31 0A 01 01
50 01 01 01 01 48 3F 40 30 62 B0
60 32 40 40 C0 13 00 98 32 11 00
70 00 1E 00 00 00 FF 00 41 32 55
80 30 35 30 31 30 30 30 30 31 0A
90 00 00 00 FD 00 32 4B 1E 5C 11
100 00 0A 20 20 20 20 20 20 00 00
110 00 FC 00 56 50 32 30 31 73 0A
120 20 20 20 20 20 20 00 05
11
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

AdjustingtheScreen Image
Use the buttons on the front control panel to display and adjust the OnView®
controls which display on the screen. The OnView controls are explained at the
top of the next page.
Front Control Panel
shown below in detail
Main Menu
with OnView controls
Scrolls through menu options and
adjusts the displayed control.
Also a shortcut to display the
Contrast adjustment control
screen.
Power
On/Off
Displays the control
screen for the highlighted
control.
Also toggles between two
controls on some
screens.
Also a shortcut to toggle
analog and digital connection.
Power light
Green = ON
Orange = Power
Saving
Displays the Main Menu
or exits the control screen
and saves adjustments.
3. Front Panel Function Control Description
12
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

Do the following to adjust the screen image:
1To display the Main Menu, press button [1].
NOTE: All OnView menus and adjustment screens disappear automatically
after about 30 seconds.
2To select a control you want to adjust, press ▲or ▼to scroll up or down the
Main Menu.
3After the control is selected, press button [2].
4To adjust the control, press the up ▲or down ▼buttons.
5To save the adjustments and exit the menu, press button [1] twice.
The following tips may help you optimize your display:
• Adjust your computer's graphic card so that it outputs a video signal 1600 x
1200 @ 60 Hz to the LCD display. (Look for instructions on “changing the
refresh rate” in your graphic card's user guide.)
• If necessary, make small adjustments using H POSITION and V POSITION
until the screen image is completely visible. (The black border around the
edge of the screen should barely touch the illuminated “active area” of the
LCD display.)
13
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

Main Menu Controls
Adjust the menu items shown below by using the up ▲ and down ▼ buttons.
Control Explanation
Auto Image Adjust automatically sizes, centers, and fine tunes
the video signal to eliminate waviness and distortion.
Press the [2] button to obtain a sharper image.
NOTE: Auto Image Adjust works with most common video
cards. If this function does not work on your LCD display, then
lower the video refresh rate to 60 Hz and set the resolution to its
pre-set value.
Contrast adjusts the difference between the image background
(black level) and the foreground (white level).
Brightness adjusts background black level of the screen image.
Input Select allows you to toggle between an analog and a
digital signal.
Color Adjust provides several color adjustment modes: preset
color temperatures and RGB which allows you to adjust red (R),
green (G), and blue (B) separately. The factory setting for this
product is 6500K (6500 Kelvin).
9300K — Adds blue to the screen image for cooler white (used
in most office settings with fluorescent lighting).
6500K — Adds red to the screen image for warmer white and
richer red.
5400K — Adds green to the screen image for a darker color.
5000K — Adds blue and green to the screen image for a darker
color.
User Color — Individual adjustments for red (R), green (G),
and blue (B).
1To select color (R, G or B) press button [2].
2To adjust selected color, press ▲or ▼.
14
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

Important: If you select RECALL from the Main Menu when
the product is set to a Preset Timing Mode, colors return to the
6500K factory preset.
Control Explanation
Information displays the timing mode (video signal input)
coming from the graphics card in your computer. See your
graphic card’s user guide for instructions on changing the
resolution and refresh rate (vertical frequency).
NOTE: VESA 1600 x 1200 @ 60 Hz (recommended) means
that the resolution is 1600 x 1200 and the refresh rate is 60
Hertz.
Manual Image Adjust displays the Manual Image Adjust menu.
The Manual Image Adjust controls are explained below:
Horizontal Size adjusts the width of the screen image.
Horizontal Position moves the screen image left or right.
Vertical Position moves the screen image up or down.
Fine Tune sharpens focus by aligning the illuminated text and/
or graphic characters.
Sharpness adjusts the clarity and focus of the screen image.
Scaling adjusts the video input signal to the screen size other
than 1600 x 1200 using the following options.
1:1 adjusts the video signal so that the height and width of the
picture are the same.
Fill all adjusts the video signal to fill the screen.
Fill Aspect Ratio maintains the correct video signal proportions
for different resolutions.
15
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

Setup Menu displays the menu shown below.
The Setup Menu controls are explained below:
Language allows you to choose the language used in the menus
and control screens.
Resolution Notice displays the Resolution Notice menu shown
below.
Resolution Notice advises the optimal resolution to use.
Control Explanation
Input Priority
If multiple computers will be connected to the display,
this function can be used to select which computer has priority
Depending on the selected Input Priority, the display will do a one
time detection for available inputs when first powered on.
OSD Position allows you to move the on-screen display menus
and control screens.
OSD Timeout sets the length of time an on-screen display
screen is displayed. For example, with a “15 second” setting, if
a control is not pushed within 15 seconds, the display screen
disappears.
16
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1

Memory Recall returns adjustments to the original factory
settings if the display is operating in a factory Preset Timing
Mode listed in this user guide.
Exception: This control does not affect changes made with the
User Color control.
Control Explanation
OSD Background allows you to turn the On-Screen-Display
background on or off.
OSD Pivot This function is used to rotate the OSD menu,
when the display is changed from Landscape to Portrait mode.
17
ViewSonic CorporationConfidential
-
Do Not Copy VP201b/s-1
