ViewSonic PJD7382 User manual

Model No. VS13338
PJD7382 ULTRA-SHORT THROW PROJECTOR
The short throw lens enables large images to
be projected from short distances in small
rooms with short throw distances.
A screen size of 80-inch is possible from just 39
inches.
Short throw lens for large, stunning
images in small places
Packs 3,000 ANSI lumens in just 7.7 pounds, and
with a high 3000:1 contrast ratio (typ), your
presentations are guaranteed to be vibrant
even in the brightest office environment.
Bright in virtually any setting with
3,000 lumens
Extend the life of your lamp up to 6,000 hours
and reduce noise output.
Eco-mode extends lamp life
Worldwide first Crestron RoomView control with
management remote contrel software system
built in.
Crestron RoomView
Schedule, manage and monitor the projector
remotely and receive e-mail alerts of projector
lamp status. Use the unique integrated clock
to perform commands even when the host PC
is powered down.
Network control through RJ45
This feature allows the busy presneter to simply
unplug the projector and go without waiting
for the usual cool down phase.
This feature also protects lamp life from
sudden power blackout.
Off-to-Go feature
Latest BrilliantColor technology delivers
stunning all-digital clarity with life-like color,
sharp graphics and outstanding video.
The sophisticated 6-segment color wheel
enhances the yellow color performance that is
key to accurate and vivid color reproduction.
BrilliantColor™ technology
The powerful PJD7382 120Hz 3D-ready projector combines
powerful features with RJ45 network capability. The projector
offers an extreme short throw ratio – producing a large
80-inch image at a distance of only 39 inches away. With its
short throw lens, the PJD7382 saves space by allowing you to
place it at the front of your table and still display large, crisp
images.
With 3,000 lumens and a 3000:1 contrast ratio, your images
look great in a classroom, meeting room or virtually any
setting. All these features are packed into an attractive,
compact design weighing only 7.7 lb. Multiple preset
presentation modes, an increased 40 degree digital vertical
keystone correction and digital zoom ensure the best
possible image regardless of location. Choose the PJD7382
for up to 6,000 hours of lamp life, low cost replacement
lamps, filter-free design and a non-degrading DLP®light
engine for the best warranty and low total cost of ownership.
** Running ECO-mode exclusively can extend lamp life.
Small budget-big presentations

PJD7382
VSI 2011/04/07 V1
For more product information, visit us at ap.viewsonic.com
Optional Accessories
Replacement Lamp
Short throw mount
Wireless G Presentation Gateway
3D goggle
RLC-057
WMK-025
WPG-350
PGD-150
ViewSonic Corporation`s QMS & EMS
have been registered to
ISO 9001 & ISO 14001, respectively,
by the British Standards Institution.
Small budget-big presentations
Model Name
Model Name
PJD7382
PJD7382
Display
Audio
Input Signal
Compatibility
Connector
Power
Language
Controls
Operating
Condition
Noise Level
Dimensions
Weight
Regulations
Packing
Contents
Type
Resolution
Lens
Keystone
Throw Distance
Throw Ratio
Zoom factor
Lamp
Lamp Life
(Normal / Eco Mode)
Brightness (Maximum)
Contrast Ratio (Typical)
Colour Depth
Colour Wheel
Colour Gamut
Speaker
Computer and video
Frequency
PC
Mac
RGB
Composite Input
S-Video Input
Audio Input
Microphone Input
Audio Output
Control
USB
DC Output
Voltage
Power Consumption
Basic
OSD
Temperature
Humidity
Normal / Eco Mode
Physical (W×H×D)
Net
0.55" Digital Micromirror Device (DLP™)
XGA 1024x768 (Native) / UXGA 1600x1200 (compressed)
Fixed Lens / Digital Zoom / Manual Focus
Vertical digital keystone correction: +/– 40 degrees
0.5m–3.7m / 1.6ft–12.1ft
0.61:1
FIXED
210 watt
4000 / 6000 hours
3000 Lumens
3000:1
24 bits, 16.7M color (8+8+8)
6-Segment RGBCYW / 7200rpm
90% NTSC 1931 CIE
10Wx1
NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N,60), SD 480i
and 576i (24fps, 25fps and 30fps), ED 480pand 576p (24fps,
25fps and 30fps), HD 720p, 1080i (24fps,25fps and 30fps)
Fh: 31–100KHz, Fv: 48–120Hz
VGA to UXGA
Up to 1400x1050 (may require Mac adapter)
Input: 15-pin mini D-sub (x2), Output: 15-pin mini D-sub
1x RCA jack
1x 4-pin mini-DIN
1x 3.5mm mini jack, 1x RCA (L/R)
1x 3.5mm mini Mono jack
1x 3.5mm mini jack
RS-232 (9-pin mini-DIN)/RJ-45
1x Type B
12V
100~240VAC (Auto Switching), 50/60Hz (universal)
329W (typ) / 1W (stand-by mode)
English/ Dutch/French/ Spanish/ Italian/ Korean/
Thai/Portuguese/ T. Chinese/ S. Chinese/ Japanese/
Russian/Germany/ Swedish/ Turkish/ Finnish /Polish/ Czech
Power, keystone/arrow keys, left/blank,
menu/exit,right/panel key lock, auto, mode/enter, source
(1)Picture: Brightest, contrast, color setting, keystone,
aspectratio, image, white intensity, gamma, 3D sync, 3D
sync invert
(2)Computer Image Picture: Brightest, contrast, color
setting,keystone, aspect ratio, image, white intensity,
gamma, 3Dsync, 3D sync invert
(3)Computer Image: Frequency, tracking, H position, V
position
(4)Video Image: Saturation, sharpness, tint
(5)Setting: Menu position, projection, signal type, lamp
hour,lamp hour reset, filter mode, filter hours, filter hours
reset,power saving, auto source, Eco-mode, high altitude,
OSD timeout
0ºC-40ºC
10%-90% (non-condensing)
32dB / 27dB
290mm x 126mm x 254mm
3.5 kg (7.71bs)
CB, UL, cUL, FCC (including ICES-003), CE, UL-Argentina,
NOM, TUV-GS, GOST-R, SASO, Ukraine, PSB, C-Tick,
Korean-eK, CCC, Hygiene, WEEE, RoHS
ViewSonic projector, power cable, VGA cable, laser
remotecontrol with batteries, lens cap, Quick Start
Guide,ViewSonic Wizard CD (with User Guide)
M Feet M inch
0.5 1.6 1.0 40
0.7 2.3 1.5 60
1.0 3.3 2.0 80
1.2 3.9 2.5 100
1.5 4.9 3.0 120
1.9 6.2 3.8 150
2.5 8.2 5.1 200
3.1 10.2 6.4 250
3.7 12.1 7.6 300
Projection Distance
4 : 3 Screen Size
