ViewZ VZ-DC24-320 User manual

ViewZ DC-24-30 Power Supply
VZ-DC24-320 Field Wiring and Mounting Instructions
VZ-DC24-320

2Installation InstructionsVisit the ViewZ USA website at http://www.viewzusa.com
VZ-DC24-320 Power Supply
Installaon Tools 3
Warning Statements 3
Mounng 4
Wiring
Warranty
5
6
Contents
.....................................................................................................................................................................................................
............................................................................................................................................................................................
...............................................................................................................................................................................................................
...............................................................................................................................................................................................................
...............................................................................................................................................................................................................

3Installation Instructions Visit the ViewZ USA website at http://www.viewzusa.com
VZ-DC24-320 Power Supply
PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS MUST BE READ AND COMPLETELY UNDERSTOOD. KEEP THESE
INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE REFERENCE.
Minimum screw size - 2 1/4" length, 0.117" (11/64) thread diameter, 0.4" head diameter
Wire - 14AWG ~ 18 AWG with temperature tolerance of 105c
The following tools may be required depending on your installaon.
Electronic Stud Finder Level Protecve Eye-wear Screwdriver Pencil Portable Drill Drill Bit
Wiring and Mounng of Power Supply must be done by a trained and authorized service technician.
UL Installation Requirements
Power Supply should be mounted on wall with a at service in an area designated for authorized personnel only.
Do not apply power to unit unl mounng and all connecons are made.
Only use copper wire for output cabling. The type of wire and its rated Ampacity are determined using NEC ANSI/NFPA 70 Arcle 310.
Do not install near water, high moisture, open ames or sources of high levels of heat.
The wire’s rated Ampacity for output cabling must be derated by mulplying by 0.8 as specied in ANSI/NFPA Arcle 645.5A.
Power output cabling must be housed within a cable tray, conduit, or plenum area for connuous protecon to the cabling.
Always crimp a UL listed ring terminal to each wire according to the ring terminal manufacturer’s instrucons.
It is recommended that a maximum of ⅝˝ plaster board be used when mounng to wooden studs.
Be aware of the mounng environment. If drilling and/or cung into the mounng surface, always make sure that there are no electrical wires in
wall. Cung or drilling into an electrical line may cause serious personal injury.
Make sure there are no water or natural gas lines inside the wall where the mount is to be located. Cung or drilling into a water or gas line may
cause severe property damage or personal injury.
Contact ViewZ with any quesons:
[phone]
[e-mail]
It is recommended that a maximum of ⅝˝ plaster board be used when mounng to wooden studs.
Warning Statements
Field Wiring and Mounting Instructions

4Installation InstructionsVisit the ViewZ USA website at http://www.viewzusa.com
VZ-DC24-320 Power Supply
Use #12 Screws or Bolts that are at least 1.25” in length
Mounting
Drill pilot holes
1. Use the hole paern provided to mark where the mounng screws will be located.
2. Drill in mounng screws ¼” away from wall. (Pilot holes might be needed).
3. If not drilling to a stud, use proper fastener/support (e.g. drywall anchor).
4. Place the Power Supply Box Keyholes over the mounng screws.
5. Secure the Power Supply by ghtening screws.
If mounng to wall studs or ceiling studs, make sure that the mounng screws are anchored into the center of the wall studs or ceiling studs. Use
of an edge-to-edge stud nder is recommended.
Screw Bolts (Qty 4)

5Installation Instructions Visit the ViewZ USA website at http://www.viewzusa.com
+V
ADJ .
LED
1
2
3
4
5
6
7
8
9
VZ-DC24-320 Power Supply
*Use 18AWG Copper Wire or larger for output power
Wiring
1. Connect wires from monitor to the terminal blocks (V+) and (V-) using a Phillips screwdriver.
To avoid damaging the monitor, use correct polarity.
2. Once unit is powered, the amount of output voltage can be adjusted (+V ADJ), if needed for
longer cable runs that have resulted in a voltage drop.
Voltage Adjustment ~24V DC to 27V DC
Clockwise to increase Voltage
Voltage Output (Posive, +)
Voltage Output (Negave, -)
Ground
Line In (Neutral)
Line In (Load) L
N
-V
+V
+V ADJ.
+V ADJ.
Diagram of Power Supply Connections

6Installation InstructionsVisit the ViewZ USA website at http://www.viewzusa.com
VZ-DC24-320 Power Supply
Warranty
What and Who is Covered by this Limited Warranty and for How Long
ViewZ USA warrants this product to be free from defects in material and workmanship for 2 YEAR of the original owner of
this product. The limited warranty is valid only for the original purchaser of the product.
What ViewZ USA Will Do
At the sole opon of ViewZ USA, ViewZ USA will repair or replace any product or product part that is defecve. If ViewZ USA chooses
to replace a defecve product or part, a replacement product or part will be shipped to you at no charge, but you must pay any labor
costs.
What is Not Covered; Limitaons
ViewZ USA DISCLAIMS ANY LIABILITY FOR DAMAGE TO MOUNTS, ADAPTERS, DISPLAYS, PROJECTORS, OTHER PROPERTY, OR
PERSONAL INJURY RESULTING, IN WHOLE OR IN PART, FROM IMPROPER INSTALLATION, MODIFICATION, USE OR MISUSE OF ITS
PRODUCTS.
ViewZ USA DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. ViewZ USA IS NOT RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT
NOT LIMITED TO, INABILITY TO USE ITS PRODUCTS OR LABOR COSTS FOR REMOVING AND REPLACING DEFECTIVE PRODUCTS OR
PARTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
What Customers Must Do for Limited Warranty Service
If you discover a problem that you think may be covered by the warranty you MUST REPORT it in wring to the address below within
thirty (30) days. Proof of purchase (an original sales receipt) from the original consumer purchaser must accompany all warranty
claims. Warranty claims must also include a descripon of the problem, the purchaser’s name, address, and telephone number.
General inquiries can be addressed to ViewZ USA Customer Service at 1-888-998-4399. Warranty claims will not be accepted over the
phone or by fax.
How State Law Applies
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
ViewZ USA intends to make this manual accurate and complete. However, ViewZ USA makes no claim that the informaon contained
herein covers all details, condions or variaons, nor does it provide for every possible conngency in connecon with the
installaon or use of this monitor. The informaon contained in this document is subject to change without noce or obligaon of
any kind. ViewZ USA makes no representaon of warranty, expressed or implied, regarding the informaon contained herein. ViewZ
USA assumes no responsibility for accuracy, completeness or suciency of the informaon contained in this document.
