Vigitron VPD Series User manual

Power Supply VoltagePower Supply Voltage 12 VDC12 VDC24 VAC24 VAC 28 VAC28 VAC
Voltage at the camera
100 mACamera
Dual 24 AWG
Dual 22 AWG
300 mACamera
1 Amp Camera
11.5 VDC 21 VAC 21 VAC
Dual24 AWG
Dual22 AWG
Dual24 AWG
Dual22 AWG
175 ft1,000 ft2,500 ft
300 ft
50 ft
1,500 ft 4,000 ft
850 ft350 ft
100 ft600 ft1,400 ft
15 ft100 ft250 ft
30 ft150 ft400 ft
Power Distance Chart
DVR
1053VPD
Vi1416VPD; 16-Ch Powered VPD Combiner
Cat-5
Cat-5
Data
Data
One Cat5 Cable
per 4 video feeds
Local Power
110/220 VAC
Cat-5
Vi6016HR
16-Ch. Active Receiver
16 Coax Jumpers
1053VPD
1. Use point-to-point Unshielded Twisted Pair wire, 24-16 AWG (0,5-1,3mm),
stranded or solid, Category 2 or better.
2. The Video signal may co-exist in the same wire bundle as other Video,
telephone, Data, control signals, or low-voltage Power. It is also OK to run
Vigitron Video signals in or near electromagnetic fields (in accordance with
National Electrical Code, local, or other local safety requirements).
3. Measure the wire distance.
4. DO NOT USE SHIELDED TWISTED PAIR WIRE. Multi-pair (6 pair or
more) wires with an overall shield are fine.
5. DO NOT USE UN-TWISTED WIRE.
6. DO NOT place a transmit and a receive signal in the same wire bundle. It
may cause interference.
7. DO NOT send “Up-the-Coax” Pan/Tilt/Zoom signals through active
(amplified) Vigitron transmitters or receivers.
Passive Vigitron transceivers can transmit “Up-the-Coax” P/T/Z control
signals up to 750ft (225m).
8. Vigitron recommends the use of 18AWG solid wires for power connections.
Verify wire distance, camera current requirement and wire resistance limit for
the maximum distance that Power can travel. Use “Power Distance Chart” to
verify the wire distance.
AWG
24AW G 22AW G 20AW G 19AW G 18AW G 16AW G
mm
0.5 m m 0.6 m m 0.7 m m 0.8 m m 1.0 m m 1.3 m m
Ohm
52 32 20 16 13 8.2
Loop Resistance per 1,000ft (305 m)
Vi1053VPD: Camera End Connection
Video: Connect the baseband Video signal output of the camera to the BNC
pigtail on the Vi1053VPD.
Power: Connect the Power UTP pigtail (Black/Red) of the Vi1053VPD to the
power connector of the camera.
Data: Connect the Data UTP pigtail (Black/White) of the Vi1053VPD to the
data connector of the camera.
Cat-5 Cable: Connect the RJ-45 connector attached to the camera end of
Cat-5 cable to the RJ-45 Jack of Vi1053VPD. Make sure that the pin-out of
the RJ-45 connector matches the Vigitron color code of the Cat-5 wires.
Application Diagram
Vi1408VPD - Vi1416VPD Application
Technical Wiring Notes
Video-Power-Data CCTV Product Installation Manual
Vi1051VP, Vi1053VPD, Vi1054VPD, Vi1508VPD, Vi1516VPD, Vi1408VPD, Vi1416VPD
DO NOT OPEN
RISK OF ELECTRIC SHOCK
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER. NO USER SERVISABLE
PARTS INSIDE. REFER SERVICINGTO QUALIFIED
SERVICE PERSONEL.
Important Safety Warning
- This installation should be made by a qualified service person and
should conform to all local codes
- Never put Vigitron signals in the same conduit as high-voltage wiring.
- To reduce a risk of fire or electrical shock, do not expose this product to
rain or moisture
- The Vigitron equipment shall not be exposed to Dripping or splashing.
- No objects filled with liquids, such as vases, shall be placed on Vigitron
equipment.
- The Main 110VAC fuse is 5A. Each camera poer fuse is 2A and can be
accessed by removing the front panel. Fuses may be replaced by a
qualified service person only when the unit is off and AC power cord is
The Vigitron powered VPD series are designed to combine video, PTZ data,
and camera power over a single 4-pair UTP cable to simplify CCTV
instalations in a structured wiring environment. They support up to 16
cameras. These units receive 110/220 VAC power and provide up to 16
ports of 24/28 VAC isolated power to the cameras. Each port is individually
equiped with a 2 A glass fuse that is easily accesibal from front.
Vi1408VPD or Vi1416VPD: Connecting the Control End
Video: Use a cat-5 cable with RJ-45 connectors on both ends to connect
the RJ-45 video output of the Vi1408VPD or Vi1416VPD to a Vigitron
active or passive receiver HUB.
Power: Connect the AC power cord to the unit and AC power outlet.
Make sure that the power requirement is in the recommended range.
Important Note: Do not overload the power supply.
Data: Connect the Data connector of the Vi1408VPD or Vi1416VPD to
the PTZ controlling unit such as DVR.
Camera Cable: Connect the RJ-45 connector of each Cat-5 cable
coming from cameras to the appropriate RJ-45 jack on Vi1408VPD or
Vi1416VPD. Make sure that the pin-out of the RJ-45 connector matches
the color code of the Cat-5 wires.
For short runs place the Vi1408VPD or Vi1416VPD close to the video
receiver unit at control end. For long runs place the Vi1408VPD or
Vi1416VPD at a mid span point close to the camera end to minimize the
loss of voltage over wisted pair.
Vi1051VP: Camera End Connection
Video: Connect the baseband Video signal output of the camera to the BNC
pigtail on the Vi1051VP.
Power: Connect the Power UTP pigtail (Black/Red) of the Vi1051VP to the
power connector of the camera.
Data: There is no data connection on Vi1051VP.
Cat-5 Cable: Same as Vi1053VPD.
Vi1054VPD: Camera End Connection
Video: Connect the baseband Video signal output of the camera to the BNC
pigtail on the Vi1054VPD.
Power: Connect the Power UTP pigtail (Black/Red) of the Vi1054VP to the
power connector of the camera. The output of Vi1054VP is regulated 12 VDC
at 600 mA max.
Data: There is no data connection on Vi1054VPD.
Cat-5 Cable: Same as Vi1053VPD.
Vi1051VP - Vi1053VPD - Vi1054VPD Application
Power
Power
Vi1051VP
Vi1054VP

Control Room Data Connections:
Video +
Video
Data +
Power
Power +
Data
Power +
Power
Camera Connections:
Vi1053VPD, Vi1508VPD, Vi1516VPD, Vi1408VPD, Vi1416VPD
Video/Power/Data
Local Power
Vi1516VPD
16-Ch VPD Powered Combiner Receiver
Cat-5
Cat-5
Cat-5
1053VPD
Power
Power
Data
110/220 VAC
16 Coax Jumpers
Data
DVR
1053VPD
Application Diagram
Vi508VPD - Vi1516VPD Application
Video, Data and UTP Connections
Limited Lifetime Warranty
Pin#
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Pin#
Data-1 +
Data-1 -
Data-2 +
Data-3 -
Data-3 +
Data-2 -
Data-4 +
Data-4 -
Camera 1-4
Vi1508VPD or Vi1516VPD: Connecting the Control End
Video: Use provided Coax jump cables to connect the BNC video output
of the Vi1508VPD or Vi1516VPD to the video input of your video
receiving unit such as a DVR or Matrix Switch.
Power: Connect the AC power cord to the unit and AC power outlet.
Make sure that the power requirement is in the recommended range.
Important Note: Do not overload the power supply.
Data: Connect the Data connector of the Vi1508VPD or Vi1516VPD to
the PTZ controlling unit such as DVR.
Camera Cable: Connect the RJ-45 connector of each Cat-5 cable
coming from cameras to the appropriate RJ-45 jack on Vi1508VPD or
Vi1516VPD. Make sure that the pin-out of the RJ-45 connector matches
the following color code of the Cat-5 wires
Pin#
Data-5 +
Data-5 -
Data-6 +
Data-7 -
Data-7 +
Data-6 -
Data-8 +
Data-8 -
Camera 5-8
1
2
3
4
5
6
7
8
Pin#
Data-9 +
Data-9 -
Data-10 +
Data-11 -
Data-11 +
Data-10 -
Data-12 +
Data-12 -
Camera 9-12 Pin#
Data-13 +
Data-13 -
Data-14 +
Data-15 -
Data-15 +
Data-14 -
Data-16 +
Data-16 -
Camera 13-16
Vi1516VPD, Vi1416VPD
Vi1408VPD, Vi1416VPD, Vi1508VPD, Vi1516VPD
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Control Room Video Connections:
1
2
3
4
5
6
7
8
Pin#
Video-1 +
Video-1 -
Video-2 +
Video-3 -
Video-3 +
Video-2 -
Video-4 +
Video-4 -
Camera 1-4 Pin#
Video-5 +
Video-5 -
Video-6 +
Video-7 -
Video-7 +
Video-6 -
Video-8 +
Video-8 -
Camera 5-8
1
2
3
4
5
6
7
8
Pin#
Video-9 +
Video-9 -
Video-10 +
Video-11 -
Video-11 +
Video-10 -
Video-12 +
Video-12 -
Camera 9-12 Pin#
Video-13 +
Video-13 -
Video-14 +
Video-15 -
Video-15 +
Video-14 -
Video-16 +
Video-16 -
Camera 13-16
Vi1516VPD, Vi1416VPD (Camera 9-16)
Vi1408VPD, Vi1416VPD (Camera 1-8)
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Vigitron, Inc. warrants that all Vigitron products (“Product”), if used in accordance
with these instructions, will be free of defects in material and workmanship for as
long as the original end user purchaser owns the product. At Vigitron's option,
defective product will be repaired, replaced or substituted with a product of equal
value.This warranty does not apply if, in the judgment of Vigitron, Inc., the Product
fails due to damage from shipment, handling, storage, accident, abuse or misuse,
or if it has been used or maintained not conforming to Product manual instruc-
tions, has been modified, or serial number removed or defaced. Repair by anyone
other than Vigitron, Inc. or an approved agent will void this warranty Vigitron, Inc.
shall not under any circumstances be liable to any person for any incidental,
indirect or consequential damages, including damages resulting from use or
malfunction of the product, loss of profits or revenues or costs of replacement
goods.The maximum liability of igitron, Inc. under this warranty is limited to the
original purchase price of the Product.
Prior to returning any defective Product, the end customer or the reseller from
whom the end customer originally purchased the Product must obtain a Return
Materials Authorization (RMA) number from igitron, Inc. All defective Products
should be returned to igitron, Inc. with shipping charges prepaid. No collect
shipments will be accepted.
VIGITRON, INC.
7810 Trade Street, Suite 100
San Diego, CA 92121, U.S.A.
Phone: [phone]
Fax: [phone]
Video +
Video
No Connect
Power
Power +
Power +
Power
Vi1051VP, Vi1054VPD
Video/Power/Data
Pin#
1
2
3
4
5
6
7
8
No Connect
Control Room Data Connections:
Vi1051VP
Vi1054VP
